[ Edit: 2012/ 1/ 17 Model: V36-D ]8-10 Maintenance and do-it-yourself SDI2043
CHECKING ENGINE COOLANT LEVEL GUID-0A58561D-6ED8-4332-9DEB-68F0F2BD40A6
Check the coolant level in the reservoir
when the engine is cold. If the coolant
level is below MIN
* 2
, open the reservoir
tank cap and add coolant up to the MAX
* 1
level. If the reservoir tank is empty, check
the coolant level in the radiator when the
engine is cold. If there is insufficient
coolant in the radiator, fill the radiator
with coolant up to the filler opening and
also add it to the reservoir tank up to the
MAX level
* 1
.
Tighten the cap securely after adding
engine coolant. If the cooling system requires coolant
frequently, have it checked by an INFINITI
retailer.
CHANGING ENGINE COOLANT GUID-5414AC03-7904-49CD-BD61-168CF59A9756
Major cooling system repairs should be
performed by an INFINITI retailer. The
service procedures can be found in the
appropriate INFINITI Service Manual.
Improper servicing can result in reduced
heater performance and engine overheat-
ing.
WARNING . To avoid the danger of being scalded,
never change the coolant when the
engine is hot.
. Never remove the radiator cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escaping
from the radiator.
. Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner as
soon as possible.
. Keep coolant out of reach of children and
pets. Engine coolant must be disposed of
properly. Check your local regulations.

Black plate (417,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-FB0623EB-5FAD-40C4-9AB0-442E7E1A0410
SDI2505
VQ25HR engine
SDI2045
VQ37VHR engine CHECKING ENGINE OIL LEVEL GUID-EB400D20-7A84-4713-89BD-9708FBC8D001
1. Park the vehicle on a level surface and
apply the parking brake.
2. Run the engine until it reaches operat-
ing temperature.
3. Turn off the engine. Wait more than 15
minutes for the oil to drain back into
the oil pan.
4. Remove the dipstick and wipe it clean.
Reinsert it all the way.
5. Remove the dipstick again and check
the oil level. It should be within the
range
* 1
. If the oil level is below
* 2
,
remove the oil filler cap and pour
recommended oil through the opening.
Do not overfill
* 3
.
6. Recheck oil level with the dipstick.
It is normal to add some oil between oil
maintenance intervals or during the break-
in period, depending on the severity of
operating conditions.
CAUTION Oil level should be checked regularly.
Operating the engine with an insufficient
amount of oil can damage the engine, and such damage is not covered by warranty.
CHANGING ENGINE OIL AND FILTER GUID-8EFE39B7-109C-4EBB-91A7-80DFF961CBD7
Vehicle set-up GUID-4BC77A05-BF08-445F-911E-85628C534413
1. Park the vehicle on a level surface and
apply the parking brake.
2. Run the engine until it reaches operat-
ing temperature.
3. Turn the engine off and wait more than
15 minutes.
4. Raise and support the vehicle using a
suitable floor jack and safety jack
stands. .
Place the safety jack stands under
the vehicle jack-up points. .
A suitable adapter should be at-
tached to the jack stand saddle.
5. Remove the plastic engine undercover.
a. Remove the small plastic clip at the
center point of the undercover.
b. Then remove the other bolts that
hold the undercover in place.
Maintenance and do-it-yourself
8-11ENGINE OIL

Black plate (418,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8-12 Maintenance and do-it-yourselfCAUTIONMake sure the correct lifting and support
points are used to avoid vehicle damage.
SDI2335
Two-wheel drive (2WD) models (VQ25HR/
VQ37VHR engine)
Engine oil and filter GUID-189A8074-AB5D-4F02-B5E6-2CEF3A0EAAE3
1. Place a large drain pan under the drain
plug.
2. Remove the oil filler cap.
3. Remove the drain plug
* 1
with a
wrench and completely drain the oil.
CAUTION Be careful not to burn yourself, as the
engine oil is hot. SDI2047
All-wheel drive (AWD) models (VQ25HR/
VQ37VHR engine) .
Waste oil must be disposed of
properly. .
Check your local regulations.
4. (Perform steps 4 to 7 only when the
engine oil filter change is needed.)
Loosen the oil filter
* 2
with an oil filter
wrench. Remove the oil filter by turning
it by hand.
5. Wipe the engine oil filter mounting
surface with a clean rag.

Black plate (419,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]CAUTIONBe sure to remove any old rubber gasket
remaining on the mounting surface of the
engine. Failure to do so could lead to engine
damage.
6. Coat the gasket on the new filter with
clean engine oil.
7. Screw in the oil filter clockwise until a
slight resistance is felt, then tighten
additionally more than 2/3 turn.
Oil filter tightening torque:
11 to 15 ft-lb
(14.7 to 20.5 N·m)
8. Clean and re-install the drain plug with
a new washer. Securely tighten the
drain plug with a wrench.
Drain plug tightening torque:
22 to 29 ft-lb
(29 to 39 N·m)
Do not use excessive force.
9. Refill engine with recommended oil and
install the oil filler cap securely.
See “ Capacities and recommended
fuel/lubricants ” (P.9-2) for drain and refill capacity. The drain and refill
capacity depends on the oil tempera-
ture and drain time. Use these specifi-
cations for reference only. Always use
the dipstick to determine the proper
amount of oil in the engine.
10. Start the engine and check for leakage
around the drain plug and the oil filter.
Correct as required.
11. Turn the engine off and wait more than
15 minutes. Check the oil level with the
dipstick. Add engine oil if necessary.
After the operation GUID-28B45484-D2E9-4712-897E-4EBAD29B4BC7
1. Install the engine undercover into
position as the following steps.
a. Pull the center of the small plastic
clip out.
b. Hold the engine undercover into
position.
c. Insert the clip through the under-
cover into the hole in the frame, then
push the center of the clip in to lock
the clip in place.
d. Install the other bolts that hold the
undercover in place. Be careful not
to strip the bolts or over-tighten
them. 2. Lower the vehicle carefully to the
ground.
3. Dispose of waste oil and filter properly.
WARNING . Prolonged and repeated contact with
used engine oil may cause skin cancer.
. Try to avoid direct skin contact with used
oil. If skin contact is made, wash
thoroughly with soap or hand cleaner
as soon as possible.
. Keep used engine oil out of reach of
children.
Maintenance and do-it-yourself
8-13

Black plate (420,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8-14 Maintenance and do-it-yourself GUID-ABB7B99A-4CD8-484D-A111-E2B0D9730B70
When checking or replacement is required,
we recommend an INFINITI retailer for
servicing.
CAUTION. Use only Genuine NISSAN Matic S ATF.
Do not mix with other fluids.
. Using automatic transmission fluid other
than Genuine NISSAN Matic S ATF will
cause deterioration in driveability and
automatic transmission durability, and
may damage the automatic transmis-
sion, which is not covered by the INFINITI
new vehicle limited warranty. GUID-D565E040-B16F-4851-A817-C2480F2A6602
SDI1765A
Check the fluid level in the reservoir.
The fluid level should be checked using the
HOT range (
* 1
: HOT MAX.,
* 2
: HOT MIN.)
at fluid temperatures of 122 to 176 8 F (50
to 80 8 C) or using the COLD range (
* 3
:
COLD MAX.,
* 4
: COLD MIN.) at fluid
temperatures of 32 to 86 8 F (0 to 30 8 C).
If the fluid is below the MIN line, add
Genuine NISSAN PSF or equivalent. Re-
move the cap and fill through the opening. CAUTION . Do not overfill.
. Use Genuine NISSAN PSF or equivalent.
AUTOMATIC TRANSMISSION FLUID POWER STEERING FLUID

Black plate (421,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-7601D96E-EEDD-44AF-87A6-218F86572DA1
For further brake and clutch fluid informa-
tion, see “ Capacities and recommended
fuel/lubricants ” (P.9-2) of this manual.
WARNING. Use only new fluid from a sealed
container. Old, inferior or contaminated
fluid may damage the brake system. The
use of improper fluids can damage the
brake system and affect the vehicle ’ s
stopping ability.
. Clean the filler cap before removing.
. Brake fluid is poisonous and should be
stored carefully in marked containers out
of the reach of children.
CAUTIONDo not spill the fluid on painted surfaces.
This will damage the paint. If fluid is spilled,
wash the surface with water. SDI2025
BRAKE FLUID GUID-99026060-C0AC-4F76-8C26-6B47003C3E51
Check the fluid level in the reservoir. If the
fluid is below the MIN line
* 2
or the brake
warning light comes on, add Genuine
NISSAN Super Heavy Duty Brake Fluid or
equivalent DOT 3 fluid up to the MAX line
* 1
. If fluid must be added frequently, the
system should be checked by an INFINITI
retailer. SDI1906A
CLUTCH FLUID (if so equipped) GUID-27C4E9C5-6E75-49DB-A514-FE503E946A9F
Check the fluid level in the reservoir. If the
fluid level is below the MIN line
* 1
, add
Genuine NISSAN Super Heavy Duty Brake
Fluid or equivalent DOT 3 fluid up to the
MAX line
* 2
. If fluid must be added
frequently, the system should be checked
by an INFINITI retailer.
Maintenance and do-it-yourself
8-15BRAKE AND CLUTCH FLUID

Black plate (422,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8-16 Maintenance and do-it-yourself GUID-9300F307-19B1-4EC9-B93C-3421C155DC4A
SDI2027
WARNINGAntifreeze is poisonous and should be
stored carefully in marked containers out
of the reach of children.
Fill the window washer fluid reservoir
periodically. Add window washer fluid
when the low window washer fluid warning
light comes on.
To fill the window washer fluid reservoir,
lift the cap off the reservoir tank and pour
the window washer fluid into the tank
opening. Add a washer solvent to the washer for
better cleaning. In the winter season, add a
windshield washer antifreeze. Follow the
manufacturer ’ s instructions for the mixture
ratio.
Refill the reservoir more frequently when
driving conditions require an increased
amount of window washer fluid.
Recommended fluid is Genuine NISSAN
Windshield Washer Concentrate Cleaner &
Antifreeze or equivalent.
CAUTION . Do not substitute engine anti-freeze
coolant for window washer solution. This
may result in damage to the paint.
. Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
. Pre-mix washer fluid concentrates with
water to the manufacturer ’ s recom-
mended levels before pouring the fluid
into the window washer reservoir tank. Do not use the window washer reservoir
tank to mix the washer fluid concentrate
and water.
WINDOW WASHER FLUID

Black plate (423,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-0812140C-014D-49D8-A9C2-56A09433296D
. Keep the battery surface clean and dry.
Clean the battery with a solution of
baking soda and water.
. Make certain the terminal connections
are clean and securely tightened.
. If the vehicle is not to be used for 30
days or longer, disconnect the negative
( − ) battery terminal cable to prevent
discharging it.
COUPE GUID-00B900F7-3B34-4FD5-A774-AFF428AF9228
CAUTIONWhen the battery cable is removed from the
battery terminal, do not close either of front
doors. The automatic window adjusting
function will not work, and the side roof
panel may be damaged.
To disconnect the negative ( − ) battery
terminal, perform the procedure in the
following order. Otherwise, the window
and the side roof panel may contact and
be damaged.
1. Close the windows.
2. Open the hood.
3. Close and lock all the doors. 4. Disconnect the negative ( − ) battery
terminal.
5. Securely close the hood.
To connect the negative ( − ) battery term-
inal, perform the procedure in the follow-
ing order. Otherwise, the window and the
side roof panel may contact and be
damaged.
1. Unlock and open the driver side door.
Do not close the door.
2. Open the hood.
3. Connect the negative ( − ) battery term-
inal. Then close the hood.
4. Fully open the driver side door window.
5. Close the driver side door and the
window.
SEDAN AND COUPE GUID-58FD0A1C-91D1-47E9-8C3E-221C89D57EFE
WARNING . Do not expose the battery to flames or
electrical sparks. Hydrogen gas gener-
ated by the battery is explosive. Do not
allow battery fluid to contact your skin,
eyes, fabrics, or painted surfaces. After
touching a battery or battery cap, do not
touch or rub your eyes. Thoroughly wash your hands. If the acid contacts your
eyes, skin or clothing, immediately flush
with water for at least 15 minutes and
seek medical attention.
. Do not operate the vehicle if the fluid in
the battery is low. Low battery fluid can
cause a higher load on the battery which
can generate heat, reduce battery life,
and in some cases lead to an explosion.
. When working on or near a battery,
always wear suitable eye protection and
remove all jewelry.
. Battery posts, terminals and related
accessories contain lead and lead com-
pounds. Wash hands after handling.
. Keep the battery out of the reach of
children.
Maintenance and do-it-yourself
8-17BATTERY
