2007 MERCEDES-BENZ SL65AMG Owner's Manual

176 Controls in detailAutomatic transmissionThe following instructions describe opera-
tion of the steering wheel gearshift control
when driving in the automatic program
modeC orS.
For instructions on operating the steering
wheel gearshift control and gear selector
lever in the program mode MANUAL, see
“Manual shift program
(SL55AMGandSL65AMG only)”
(page 177).Downshifting

Briefly pull left shift paddle1
(page 175).
The transmission will shift to the next
lower gear as permitted by the shift
program. This action simultaneously limits
the gear range of the transmission
(
page 172).Upshifting

Briefly pull right shift paddle2
(page 175).
The transmission will shift to the next
higher gear as permitted by the shift
program. This action simultaneously
extends the gear range of the transmission
(
page 172).
Canceling gear range limit

Pull and hold right shift paddle2
(page 175) until
D reappears in the
right multifunction display.
The transmission will shift from the current
gear range directly to gear rangeD.
Shifting into optimal gear range

Pull and hold left shift paddle1
(page 175).
The transmission will automatically select
the gear range suited for optimal
acceleration and deceleration. This will
involve shifting down one or more gears.
i
You cannot shift with the steering wheel
gearshift paddle when the gear selector lever is
in positionP,N orR.
The last selected program mode (CorS) is
switched on when the engine is restarted.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.

177 Controls in detail
Automatic transmission
Manual shift program (SL 55 AMG and SL 65 AMG only)
In addition to the automatic shift
programC orS, your vehicle is equipped
with the manual shift program MANUAL.
In the MANUAL program mode,
system-controlled automatic gearshifting
is switched off and you need to change the
gears by manually upshifting or downshift-
ing using the steering wheel gearshift pad-
dles (
page 175) or the gear selector
lever.The program mode selector switch is
located on the lower part of the center
console.
Example illustration SL 65 AMG1Program mode selector switch
MANUAL For manual gear shifting
C Comfort For comfort driving
S Sport For standard drivingThe current gear selector lever position
and the selected program mode (
M/C/S)
are indicated in the right multifunction
display (
page 169).
!
Allow engine to warm up under low load use.
Do not place full load on the engine until the op-
erating temperature has been reached.
Shift into reverse gearR or parking positionP
only when the vehicle is stopped.
Avoid spinning of a drive wheel for an extended
period when driving off on slippery road
surfaces. This may cause serious damage to
the drivetrain which is not covered by the
Mercedes-Benz Limited Warranty.
i
For information on automatic program
modesC orS, see “Automatic shift program”
(
page 173), “Gear selector lever one-touch
gearshifting” (
page 174), and “Steering wheel
gearshift control one-touch gearshifting”
(
page 175).

178 Controls in detailAutomatic transmissionActivating manual shift program
Press program mode selector
switch1 repeatedly until the
M for
MANUAL program mode appears in
the right multifunction display.
The transmission switches to the
MANUAL program mode. Automatic
shifting is switched off. The gear range
is not limited.
You can change the gears manually when
the gear selector lever is in positionD. You
can upshift or downshift through the gears
in succession.Upshifting

Briefly press the gear selector lever to
the right in theD+direction.
or

Briefly pull right shift paddle2
(page 175).
The transmission shifts to the next
higher gear.If, instead of the manual program mode
symbol
M, the symbolp appears in the
right multifunction display (
page 169),
shift to the next higher gear. The fuel
supply will otherwise be interrupted to
prevent the engine from overrevving.
i
The MANUAL program mode will not be
stored. When the engine is turned off with the
MANUAL program mode selected, the transmis-
sion will go to the automatic program mode
(CorS) when the engine is restarted.
!
In the MANUAL program mode, the trans-
mission will not upshift, even if the engine has
reached its overrevving range. Shift up to the
next gear before the engine has reached its over-
revving range. Make absolutely certain that the
engine speed does not reach the red marking on
the tachometer (
page 26). Otherwise the en-
gine could be damaged which is not covered by
the Mercedes-Benz Limited Warranty.
i
If you have selected the AMG menu in the
control system and the engine reaches the over-
speed range in the manual shift program, the col-
or of the display will switch to red and
UP
appears after the gear indicator, advising you to
upshift.

179 Controls in detail
Automatic transmission
Downshifting
Briefly press the gear selector lever to
the left in theD-direction.
or

Briefly pull left shift paddle1
(page 175).
The transmission shifts to the next
lower gear.Kickdown
Using the kickdown when driving in the
MANUAL program mode is not possible.
Deactivating manual shift program

Press the program mode selector
switch (
page 177) repeatedly
until
Cor
S appears in the right
multifunction display.
or

Restart the engine.
The transmission will go to the
automatic program mode (C orS).
The MANUAL program mode is not
stored.Emergency operation
(Limp-Home Mode)
If vehicle acceleration becomes less re-
sponsive or sluggish or the transmission
no longer shifts, the transmission is most
likely operating in limp-home (emergency
operation) mode. In this mode only second
gear and reverse gear can be activated.
Stop the vehicle in a safe location.

Move gear selector lever toP.

Turn off the engine.

Wait at least 10 seconds before
restarting.

Restart the engine.

Move gear selector lever to drive
positionD (for second gear) or reverse
gearR.

Have the transmission checked at an
authorized Mercedes-Benz Center as
soon as possible.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.i
When you brake or stop, the transmission
shifts down to a gear from which you can easily
accelerate or take off.

180 Controls in detailGood visibilityFor information on windshield wiper opera-
tion, see “Windshield wipers” (
page 57).
Headlamp cleaning system
The button is located on the left side of the
dashboard.
1Headlamp washer button
Switch on the ignition (
page 39).

Press button1.
The headlamps are cleaned with a
high-pressure water jet.
For information on filling up the washer flu-
id reservoir, see “Windshield washer sys-
tem and headlamp cleaning system”
(
page 282).
Rear view mirrors
For information on setting the rear view
mirrors, see “Mirrors” (
page 47).
Auto-dimming rear view mirrors
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when


the ignition is switched on
and


incoming light from headlamps falls on
the sensor in the interior rear view mir-
ror.
The interior rear view mirror will not react if


reverse gear is engaged


the interior lighting is switched on
i
The headlamps will automatically be
cleaned when you have


switched on the headlamps
and


operated the windshield wipers with wind-
shield washer fluid fifteen times
When you switch off the ignition, the counter re-
sets.

181 Controls in detail
Good visibility
Warning!
G
The auto-dimming function does not react if
incoming light is not aimed directly at sen-
sors in the interior rear view mirror.
The interior rear view mirror and the exterior
rear view mirror on the driver’s side do not
react, for example, if the wind screen is in-
stalled.
Light hitting the mirror(s) at certain angles
(incident light) could blind you. As a result,
you may not be able to observe traffic con-
ditions and could cause an accident.
Warning!
G
In case of an accident liquid electrolyte may
escape from the mirror housing if the mirror
glass breaks.
Electrolyte has an irritating effect. Do not al-
low the liquid to come into contact with
eyes, skin, clothing, or respiratory system.
In case it does, immediately flush affected
area with water, and seek medical help if
necessary.
Warning!
G
Exercise care when using the passen-
ger-side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
terior rear view mirror or glance over your
shoulder before changing lanes.!
Electrolyte drops coming into contact with
the vehicle paint finish can be completely re-
moved only while in the liquid state by applying
plenty of water.

182 Controls in detailGood visibilitySun visors
The sun visors protect you from sun glare
while driving.
1Mounting
2Vanity mirror cover
3Vanity mirror lamp
4Holder for gas cards
Glare through the windshield

Make sure the sun visor is properly
engaged in mounting 1.

Swing the respective sun visor down.

When you do not experience glare any-
more, swing the sun visor up.Glare through a door window

Swing respective sun visor down.

Disengage the sun visor from
mounting1.

Pivot the sun visor to the side.
Vanity mirror

Swing respective sun visor down.

Flip up vanity mirror cover2 to access
the vanity mirror.
Vanity mirror lamp 3 comes on.

After using the vanity mirror, flip down
vanity mirror cover 2.

Swing the sun visor up.
Warning!
G
Do not use the driver’s-side vanity mirror
while driving.
Keep the vanity mirrors in the sun visors
closed while vehicle is in motion. Reflected
glare can endanger you and others.
i
When the sun visor is disengaged from
mounting1, vanity mirror lamp3 switches
off.
!
To avoid damage to vanity mirror cover 2,
make sure it is closed before pivoting the sun
visor to the side.

183 Controls in detail
Good visibility
Rear window defroster
The rear window defroster uses a large
amount of power. To keep the battery
drain to a minimum, switch off the defrost-
er as soon as the rear window is clear. The
defroster is automatically deactivated af-
ter approximately 6 to 17 minutes of oper-
ation depending on the outside
temperature.
Switch on the ignition (
page 39).
Activating

Press button F on the automatic cli-
mate control panel (
page 185).
The indicator lamp on the button
comes on.Deactivating

Press button F (
page 185) once
more.
The indicator lamp on the button goes
out.
Warning!
G
Any accumulation of snow and ice should be
removed from the rear window before driv-
ing. Visibility could otherwise be impaired,
endangering you and others.
!
The rear window defroster cannot be
switched on when the retractable hardtop is
open. The indicator lamp will start flashing if the
hardtop is open.


Close the retractable hardtop.
The rear window defroster can then be switched
on.
!
If the rear window defroster switches off too
soon and the indicator lamp starts flashing, too
many electrical consumers are operating simul-
taneously and there is insufficient voltage in the
battery. The system responds automatically by
switching the rear window defroster off.
As soon as the battery has sufficient voltage, the
rear window defroster automatically switches
back on automatically.
