2007 MERCEDES-BENZ SL65AMG Owner's Manual

144 Controls in detailControl system
Menu 6
Menu 7
Menu 8
Menu 9
Vehicle status
message memory
1
Settings
Trip computer
Telephone*
(page 152)
(page 153)
(page 163)
(page 165)
Commands/submenus
Calling up vehicle mal-
function, warning and
system status messag-
es stored in memory
Resetting to factory set-
tings
Fuel consumption sta-
tistics after start
Loading phone book
Instrument cluster
submenu
Fuel consumption sta-
tistics since the last re-
set
Searching for name in
phone book
Time submenu
Distance to empty
Lighting submenuVehicle submenuConvenience submenu
1You will only see the message memory menu if there is a message.i
The headings used in the menus table are
designed to facilitate navigation within the sys-
tem and are not necessarily identical to those
shown in the control system displays. The first function displayed in each menu will au-
tomatically show you which part of the system
you are in.

145 Controls in detail
Control system
Standard display menu
1Main odometer
2Outside temperature
3Current gear selector lever position
4Trip odometer
5Automatic transmission program mode
Press button è or ÿ repeatedly
until you see the standard display
menu in the multifunction display.You can modify the standard display menu.
Instead of outside temperature 2, you
can choose the digital speedometer to be
displayed in the left multifunction display
by changing the setting in the
Select dis-
play
function of the
Inst. cluster
sub-
menu (
page 157).

Press button k or jto select
the functions in the standard display
menu.
The following functions are available:Display digital speedometer or outside
temperature

Press button k or juntil the
digital speedometer or, depending on
the chosen setting, the outside temper-
ature appears in the right multifunction
display.
Function
Page
Calling up digital speedometer
145
Calling up maintenance service
indicator
320
Checking tire inflation pressure
292
Checking engine oil level
276
i
If you have selected the digital speedometer
for the standard display (
page 157), select the
outside temperature display here.

146 Controls in detailControl systemAMG menu
The main screen of the AMG menu shows
you the gear currently engaged as well as
the engine oil temperature.
Press button è or ÿ repeatedly
until you see the AMG menu.
1Engine oil temperature
2Gear indicatorUse buttons k or j to select the fol-
lowing functions in the AMG menu:Vehicle supply voltage

Press button è or ÿ repeatedly
until you see the AMG menu.

Press button j repeatedly until you
see the vehicle supply voltage.
1Vehicle supply voltage
2Gear indicator
i
This function is only available in AMG
vehicles.
i
The engine oil temperature symbol flashes if
the engine oil temperature has not yet reached
80°C. During this time, avoid driving at full
engine speed.
Function
Page
Vehicle supply voltage
146
RACETIMER
147
Overall analysis
148
Lap analysis
149
i
If the engine reaches the overspeed range in
the manual shift program, the menu will be
shown in red. In addition, you will see UP next to
gear indicator 2 as a reminder to upshift.

147 Controls in detail
Control system
RACETIMER
The RACETIMER allows you to time and
save driving stretches in hours, minutes
and seconds.
Press button è or ÿ repeatedly
until you see the AMG menu.

Press button j repeatedly until you
see the RACETIMER.
1Lap
2RACETIMER
3Gear indicatorStarting the RACETIMER

Press button æ.
The timer starts.
Displaying intermediate time

Press button ç while the timer is
running.
The intermediate time is shown for
5 seconds.Stopping the RACETIMER

Press button æ.
The timer stops.
Saving lap time and starting a new lap

Press button ç while the timer is
running.
The intermediate time will be shown for
5 seconds.
i
You can start the RACETIMER when the
engine is running or the starter switch is in
position2 (
page 39).
i
While the RACETIMER is being displayed,
you cannot adjust the volume using
buttonsæ or ç.
i
When you stop the vehicle and turn the
Smartkey to position 1 (
page 40) or, in vehi-
cles with KEYLESS-GO*, turn off the engine and
do not open the driver’s door, the RACETIMER
stops timing. Timing is resumed when you
switch the ignition back on (page 39) or
restart the engine (
page 52) and then press
the æbutton.
i
You can save up to nine laps.


148 Controls in detailControl system
Press button ç within the next
5 seconds.
The intermediate time shown will be
saved as a lap time.
The RACETIMER begins timing the new
lap. The new lap begins to be timed as
soon as the intermediate time is called
up.
1Best lap time
2Lap number
3RACETIMER
4Gear indicatorResetting current lap

Press button æ while the timer is
running.
The timer stops.

Press button ç.
The lap time is reset to “0”.
Deleting all laps

Press button æ while the timer is
running.
The timer stops.

Press the reset button twice
(page 27).

Press button æ.
The timer starts. The saved laps are de-
leted.Overall analysis

Press button è or ÿ repeatedly
until you see the AMG menu.

Press button j repeatedly until you
see the overall analysis.
1Overall analysis of RACETIMER
2Overall driving time
3Maximum speed
4Average speed
5Overall distance driven
i
It is not possible to delete a single saved lap.
i
When you switch off the engine, the
RACETIMER will be reset to“0” after 30 seconds.
All laps are deleted.
i
These functions are only available if you
have saved at least one lap and have stopped the
RACETIMER.


149 Controls in detail
Control system
Lap analysis
Press button è or ÿ repeatedly
until you see the AMG menu.

Press button j repeatedly until you
see the lap analysis.
1Lap number
2Lap time
3Maximum speed
4Average speed during lap
5Lap length

Press button j or k to see other
lap analyses.
AUDIO menu
The functions in the
AUDIO
menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO OFF
appears in the
right multifunction display.
The following functions are available:Selecting radio station

Turn on COMAND and select radio. Re-
fer to the separate operating instruc-
tions.

Press button è or ÿ repeatedly
until you see the currently tuned sta-
tion in the right multifunction display.
1Waveband setting
2Station frequency

Press button k or j repeatedly
until the desired station is found.
i
These functions are only available if you
have saved at least two laps and have stopped
the RACETIMER.
i
Each lap is shown in its own submenu. The
fastest lap is indicated by flashing symbol 1.
Function
Page
Selecting radio station
149
Selecting satellite radio station
(USA only)
150
Operating CD player
150
i
You can only store new stations using the
designated feature on the radio. Refer to the
separate operating instructions.

150 Controls in detailControl systemSelecting satellite radio station
(USA only)
The satellite radio is treated as a radio ap-
plication.
Select satellite radio with the corre-
sponding key on the COMAND control
panel (SAT).

Press button è or ÿ repeatedly
until you see the currently tuned sta-
tion in the right multifunction display.
1SAT mode
2Channel name or number

Press button k or j repeatedly
until the desired channel is found.Operating the CD player
Selecting CD track

Turn on COMAND and select CD. Refer
to the separate COMAND operating in-
structions.

Press button è or ÿ repeatedly
until the settings for the CD currently
being played appear in the right multi-
function display.
1Current CD (with additional number
from 1 to 6 when running from CD
changer)
2Current track

Press button k or j repeatedly
until the desired track is selected.
i
Additional optional satellite radio equipment
and a subscription to satellite radio service pro-
vider are required for satellite radio operation.
Contact an authorized Mercedes-Benz Center
for details and availability for your vehicle.
For more information, refer to separate
COMAND operating instructions.

151 Controls in detail
Control system
Selecting MP3-CD track
Turn on COMAND and select MP3-CD.
Refer to the separate COMAND operat-
ing instructions.

Press button è or ÿ repeatedly
until the settings for the MP3-CD cur-
rently being played appear in the right
multifunction display.
1Current track

Press button k or j repeatedly
until the desired track is selected.
NAV menu
The
NAV
menu contains the functions need-
ed to operate your navigation system.

Press button è or ÿ repeatedly
until you see the message
NAV
in the
left multifunction display.
The message shown in the multifunction
display depends on the status of the navi-
gation system:


With COMAND switched off, the mes-
sage
NAV off
appears in the
multifunction display.


With COMAND switched on but route
guidance not activated, the direction of
travel and, if applicable, the name of
the street currently traveled on appear
in the multifunction display.


With COMAND switched on and route
guidance activated, the direction of
travel and maneuver instructions ap-
pear in the multifunction display.Please refer to the COMAND manual for in-
structions on how to activate the route
guidance system.
Distronic* menu
Use the
Distronic
menu (
page 217) to
display the current settings for your Dis-
tronic system. The information shown in
the multifunction display depends on
whether the Distronic system is activated
or deactivated.
Please refer to the “Driving systems” sec-
tion of this manual (
page 213) for in-
structions on how to activate Distronic.

Press button è or ÿ repeatedly
to select the
Distronic
menu in the
multifunction display.
