2007 MERCEDES-BENZ E550 4MATIC Owner's Manual

56 Getting startedDrivingAfter a cold start, the automatic transmis-
sion shifts at a higher engine revolution.
This allows the catalytic converter
(gasoline engine) or the oxidation catalyst
(diesel engine) to reach its operating tem-
perature earlier.
For more information on driving, see “Driv-
ing instructions” (
page 309).
Switching on headlamps
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.Exterior lamp switch1Off
2Low beam headlamps on
Turn the exterior lamp switch to
positionB.
The low beam headlamps and the low
beam headlamp indicator lampB in
the instrument cluster come on
(page 26).
!
If you hear a warning signal and the mes-
sage Release parking brake
appears in the
multifunction display when driving off, you have
forgotten to release the parking brake.
Release the parking brake (
page 62).
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.
Warning!
G
It is dangerous to shift the gear selector le-
ver out ofP orN if the engine speed is high-
er than idle speed. If your foot is not firmly
on the brake pedal, the vehicle could accel-
erate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.!
Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake and
drivetrain wear.


57 Getting started
Driving
High beam
The combination switch is located on the
left of the steering column.Combination switch1High beam
2High beam flasher
Push the combination switch in direc-
tion of arrow1.
The high beam headlamps and the high
beam headlamp indicator lampA in
the instrument cluster come on
(page 142).
For more information on headlamps, see
“Lighting” (
page 137).
Turn signals
The combination switch is located on the
left of the steering column.Combination switch1Turn signals, right
2Turn signals, left
Press the combination switch in direc-
tion of arrow1 or2.
The corresponding turn signal indicator
lamp L or K in the instrument
cluster flashes (
page 27).The combination switch resets automati-
cally after major steering wheel move-
ments.
i
To signal minor directional changes such as
changing lanes, press combination switch only
to point of resistance and release. The corre-
sponding turn signals will flash three times.

58 Getting startedDrivingWindshield wipers
The combination switch is located on the
left of the steering column.Combination switch1Switching on windshield wipers
2Single wipe
Wiping with windshield washer fluid
Switch on the ignition (
page 37).Switching on/off windshield wipers

Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wiping
!
Do not operate the windshield wipers when
the windshield is dry. Dust that accumulates on
a windshield might scratch the glass and/or
damage the wiper blades when wiping occurs on
a dry windshield. If it is necessary to operate the
windshield wipers in dry weather conditions, al-
ways operate the windshield wipers with wind-
shield washer fluid (
page 59).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.


For safety reasons, stop the vehicle in a safe
location and

remove SmartKey from starter switch
or


turn off the engine by pressing the
KEYLESS-GO* start/stop button and
open the driver’s door (with the driver’s
door open, starter switch is in
position0, same as with SmartKey re-
moved from starter switch)
before attempting to remove any blockage.


Remove blockage.


Turn the windshield wipers on again.If windshield wipers fail to function at all in com-
bination switch positionU or V,


set the combination switch to the next high-
er wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center.
i
When the windshield wipers are switched on
and you brake the vehicle to a stop, the time in-
terval between wiper operations is increased.

59 Getting started
Driving
Intermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.
Turn the combination switch to
positionU or V.
The wipers move across the wind-
shield. Afterward, the wiping intervals
are determined by the wetness of the
windshield.After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe

Press the combination switch briefly in
direction of arrow2 (
page 58) to
the resistance point.
The windshield wipers wipe one time
without washer fluid.Wiping with windshield washer fluid

Push the combination switch in direc-
tion of arrow2 (
page 58) past the
resistance point.
The windshield wipers operate with
washer fluid.
For information on filling up the windshield
washer reservoir, see “Windshield washer
system and headlamp cleaning system*”
(
page 332).
!
Do not leave windshield wipers in
intermittent setting when the vehicle is taken to
an automatic car wash or during windshield
cleaning. Windshield wipers will operate in the
presence of water sprayed on the windshield,
and windshield wipers may be damaged as a re-
sult.
!
If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
i
Intermittent wiping is interrupted when the
vehicle is at a standstill and a door is opened.
This protects persons getting into or out of the
vehicle from being sprayed.
Intermittent wiping will be continued when


all doors are closed
and


the gear selector lever is in positionD or R
or


the wiper setting is changed using the com-
bination switch
i
To prevent smears on the windshield or
noisy/chattering wiper blades, wipe with wind-
shield washer fluid every now and then even
when it is raining.

60 Getting startedDrivingProblems while driving
The engine runs erratically and misfires

An ignition cable may be damaged
(gasoline engine only).


The engine electronics may not be op-
erating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it
(gasoline engine only).

Give very little gas.

Have the problem repaired by an
authorized Mercedes-Benz Center as
soon as possible.The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.

Stop the vehicle as soon as possible in
a safe location and turn off the engine.
Allow engine and coolant to cool off.

Check the coolant level and add cool-
ant if necessary (
page 330).In case of accident
If the vehicle is leaking fuel:

Do not start the engine under any cir-
cumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Center.
If no damage can be determined on the


major assemblies


fuel system


engine mount:

Start the engine in the usual manner.

61 Getting started
Parking and locking
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle.Warning!
G
Vehicles with Airmatic: If you have selected
the Comfort suspension tuning
(page 265), the vehicle lowers slightly
when it is locked. You should therefore
make sure that no one is standing near the
wheel arches or lying underneath the vehi-
cle when it is being locked. Otherwise, per-
sonal injury could result.
Warning!
G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury, or
damage to the vehicle drivetrain, as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:

Keep right foot on brake pedal.


Firmly depress parking brake pedal.


Move the gear selector lever to
positionP.


Slowly release brake pedal.


When parked on an incline, turn front
wheel towards the road curb.


Turn the SmartKey to starter switch
position0 and remove, or press
start / stop button (vehicles with
KEYLESS-GO*).


Take the SmartKey or the SmartKey with
KEYLESS-GO* and lock vehicle when
leaving.
!
Vehicles with Airmatic: If you have selected
the Comfort suspension tuning (
page 265),
the vehicle lowers slightly when you lock it within
approximately 60 seconds after switching off the
engine. When parking, make sure that your vehi-
cle cannot come into contact with other objects,
such as a curb, while lowering. Your vehicle
could otherwise be damaged.

62 Getting startedParking and lockingParking brake
1Release handle
2Parking brake pedal

Step firmly on parking brake pedal2.
When the engine is running, the warn-
ing lamp ; (USA only) or 3
(Canada only) in the instrument cluster
will be illuminated.
Warning!
G
Engaging the parking brake while the vehicle
is in motion can cause the rear wheels to
lock up. You could lose control of the vehicle
and cause an accident. In addition, the vehi-
cle’s brake lights do not light up when the
parking brake is engaged. Make sure not to
endanger any other road users when you en-
gage the parking brake.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could release the parking brake and/or
move the gear selector lever from
positionP, either of which could result in an
accident and/or serious personal injury.

63 Getting started
Parking and locking
Switching off headlamps
Turn the exterior lamp switch toM
(page 56).
For more information, see “Lighting”
(
page 137).
Turning off engine
Move the gear selector lever to
positionP.

Apply the parking brake (
page 62).Turning off with the SmartKey

Turn the SmartKey in the starter switch
(page 38) to position0 and remove
it.
The immobilizer is activated.
Warning!
G
Getting out of your vehicle with the gear se-
lector lever not fully engaged in positionP is
dangerous. Also, when parked on an incline,
positionP alone may not prevent your vehi-
cle from moving, possibly hitting people or
objects.
Always set the parking brake in addition to
shifting to positionP.
When parked on an incline, turn front wheels
towards the road curb.
i
Always set the parking brake in addition to
shifting to positionP.
On slopes, turn the front wheels towards the
road curb.
i
The SmartKey can only be removed from the
starter switch with the gear selector lever in
positionP.
