456 Practical hintsFlat tire
Insert wheel bolts and tighten them
slightly.

Unscrew the alignment bolt, install last
wheel bolt and tighten slightly.Vehicles with collapsible tire
(E 63 AMG only):

Continue the procedure by following
the instructions under “Inflating the
collapsible tire” (
page 456) and then
“Lowering the vehicle” (
page 458).
Vehicles with Minispare wheel
(except E 63 AMG):

Continue the procedure by following
the instructions under “Lowering the
vehicle” (
page 458).Inflating the collapsible tire
(E 63 AMG only)

Take the electric air pump out of the
trunk (
page 432).
Warning!
G
Only use Genuine equipment
Mercedes-Benz wheel bolts. Other wheel
bolts may come loose.
Do not tighten the wheel bolts when the ve-
hicle is raised. Otherwise the vehicle could
fall off the jack.
Warning!
G
Inflate collapsible tire only after the wheel is
properly mounted.
Inflate the collapsible tire using the electric
air pump before
lowering the vehicle.
Warning!
G
Observe instructions on air pump label.!
Do not lower the vehicle before inflating the
collapsible tire. Otherwise the rim may be dam-
aged.


457 Practical hints
Flat tire
1Flap
2On/off switch
3Electrical plug
4Air hose with pressure gauge and vent
screw
5Union nut
Open flap 1 on electric air pump.

Pull out electrical plug 3 and air hose
with pressure gauge 4.

Remove the valve cap from the
collapsible tire valve.

Screw union nut5 onto the collaps-
ible tire valve.

Insert electrical plug 3 into vehicle
cigarette lighter socket.

Turn the SmartKey in the starter switch
to position1.

PressI on electric air pump switch 2.
The electric air pump should now
switch on and inflate the collapsible
tire.

Inflate the tire to approximately 51 psi
(3.5 bar).
This takes about 5 minutes for the col-
lapsible tire. Air hose 4 and union
nut5 can become hot during infla-
tion. Exercise proper caution to avoid
burning yourself when using the equip-
ment.

Press0 on electric air pump switch 2.

Turn the SmartKey in the starter switch
to position0.

If the tire pressure is above 51 psi
(3.5 bar), release excess tire pressure
using the vent screw.

Detach the electric air pump.
!
Do not operate the electric air pump longer
than 8 minutes without interruption. Otherwise it
may overheat.
You may operate the electric air pump again af-
ter it has cooled off.
Warning!
G
Follow recommend tire inflation pressures.
Do not overinflate tires. Overinflating tires
can result in sudden deflation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes,
etc.
Do not underinflate tires. Underinflated tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.


458 Practical hintsFlat tire
Store the electrical plug 3 and the air
hose 4 behind the flap 1 and place
the electric air pump back in the desig-
nated storage space underneath the
trunk floor (
page 432).
Lowering the vehicle

Lower vehicle by turning crank coun-
terclockwise until vehicle is resting ful-
ly on its own weight.

Remove the jack.
1-5 Wheel bolts

Tighten the five wheel bolts evenly, fol-
lowing the diagonal sequence illustrat-
ed (1 to 5), until all bolts are tight.
Observe a tightening torque of 96 lb-ft
(130 Nm).
Before storing the jack, it should be fully
collapsed, with handle folded in (storage
position).

Store the jack and the other vehicle
tools in the designated storage space
underneath the trunk floor
(page 432).
Warning!
G
Have the tightening torque checked after
changing a wheel. The wheels could come
loose if they are not tightened to a torque of
96 lb-ft (130 Nm).
i
Wrap the damaged wheel in the protective
film that comes with the spare wheel and put the
wheel in the trunk.
You can also place the damaged wheel down into
the spare wheel well. In this case, you must stow
the holder from the spare wheel well in the trunk.
Vehicles with Advanced TPMS* (Canada only):
Do not activate the tire inflation pressure moni-
tor until a full size wheel/tire with functioning
sensor has been placed back into service on the
vehicle.


459 Practical hints
Bleeding the fuel system (diesel engine only)
Bleeding the fuel system (diesel engine only)
Driving the vehicle until the fuel tank is
empty is not recommended. Otherwise, air
may be sucked into the fuel system. If this
happens, theú malfunction indicator
lamp (USA only) or the ±malfunction
indicator lamp (Canada only) comes on
and the engine may not start immediately
after refueling the vehicle.
After refueling:
Make sure the gear selector lever is set
to P.

Do not depress the accelerator.

Turn the SmartKey in the starter switch
to position2 (
page 38) for at least
10 seconds.

Return the SmartKey in the starter
switch to position0 (
page 38).

Turn the SmartKey in the starter switch
to position3 (
page 38) and hold it
there for a maximum of 40 seconds or
until the engine runs surge-free.If the engine does not start:

Wait for approximately 2 minutes.

Turn the SmartKey in the starter switch
to position3 (
page 38) and hold it
there for a maximum of 40 seconds or
until the engine runs surge-free.
If the engine still does not start, do not
make any further attempts to start the en-
gine. Contact an authorized
Mercedes-Benz Center or call Roadside
Assistance (
page 297).
i
Where theú malfunction indicator lamp
(USA only) or the± malfunction indicator
lamp (Canada only) in the instrument cluster has
been illuminated for the above condition, it will
remain illuminated until the engine was cycled
on and off four times in a row.

460 Practical hintsBatteryThe battery is located on the right hand
side of the trunk under the luggage box
(page 433).
Vehicles with spare wheel1Positive terminal
2Negative terminal
3Battery bracket
4Battery ventilation hose
Warning!
G
Failure to follow these instructions can re-
sult in severe injury or death.
Observe all safety instructions and precau-
tions when handling automotive batteries
(page 331).
Never lean over batteries while connecting,
you might get injured.
Battery fluid contains sulfuric acid. Do not
allow this fluid to come in contact with eyes,
skin or clothing. In case it does, immediately
flush affected area with water and seek
medical help if necessary.
A battery will also produce hydrogen gas,
which is flammable and explosive. Keep
flames or sparks away from battery, avoid
improper connection of jumper cables,
smoking etc.
!
Depending on vehicle production date, the
battery is a V
alve-R
egulated L
ead A
cid (VRLA)
battery, also referred to as “fleece” battery:
Such batteries do not require topping-up of the
electrolyte level. VRLA batteries therefore do not
have cell caps and the battery cover is non-re-
movable. Do not attempt to open the battery as
otherwise the battery will be damaged.
Even though VRLA batteries do not require top-
ping-up of the electrolyte level and cannot be
opened to check the electrolyte level, the bat-
tery condition must be checked periodically by
performing a battery conductance test. Refer to
Maintenance Booklet for battery condition test-
ing intervals.
The factory-equipped VRLA battery is
leak-proofed. Only use a battery as replacement
that has the same security features and is of
identical size, voltage, and capacity as the
factory-equipped battery.

461 Practical hints
Battery
Disconnecting the battery
Apply the parking brake (
page 62).

Make sure the gear selector lever is set
to positionP.

Turn off all electrical consumers.
!
As with any other battery, disconnect the
battery if you do not intend to operate your vehi-
cle for an extended period of time to prevent bat-
tery discharge or connect an accessory battery
charge unit expressly approved by
Mercedes-Benz for your vehicle model to main-
tain the battery charge. Contact an authorized
Mercedes-Benz Center for further information.
The battery, the battery ventilation hose and the
lateral plug must always be securely installed
when the vehicle is in operation.
!
Never loosen or detach battery terminal
clamps while the engine is running or the
SmartKey is in the starter switch. Otherwise the
alternator and other electronic components
could be severely damaged.
Have the battery checked regularly by an autho-
rized Mercedes-Benz Center.
Refer to Maintenance Booklet for maintenance
intervals or contact an authorized
Mercedes-Benz Center for further information.
Warning!
G
Do not place metal objects on the battery as
this could result in a short circuit.
Use leak-proof batteries only to avoid the
risk of acid burns in the event of an acci-
dent.
Warning!
G
With a disconnected battery

you will no longer be able to turn the
SmartKey in the starter switch and
pressing the KEYLESS-GO* start/stop
button on the gear selector lever will
have no effect


the gear selector lever will remain
locked in positionP
!
Always disconnect the battery in the order
described below. Otherwise the vehicle’s
electronics can be damaged.


462 Practical hintsBattery
Remove SmartKey from starter switch.
Vehicles with KEYLESS-GO*:
Press the start/stop button until
the engine shuts off.

Open the driver’s door.

Open the trunk.

Read and observe safety instructions
and precautions (
page 331) and
(
page 460).

Remove the luggage box (
page 433).

Disconnect the negative lead from neg-
ative terminal2 (
page 460).

Remove cover1 (
page 460) from
the positive terminal.

Disconnect the positive lead.
Removing the battery
Remove the screw-nuts securing the
battery.

Remove the battery bracket3
(page 460).

Pull out the battery ventilation hose4
(page 460) from the battery (de-
pending on battery arrangement in
your vehicle model, the ventilation
hose is located either on the left or
right side of the battery).

Take out the battery.
Charging and reinstalling the batteryWarning!
G
Never charge a battery while still installed in
the vehicle unless the accessory battery
charge unit* approved by Mercedes-Benz is
being used. Gases may escape during charg-
ing and cause explosions that may result in
paint damage, corrosion or personal injury.
An accessory battery charge unit* specially
adapted for Mercedes-Benz vehicles and
tested and approved by Mercedes-Benz is
available, permitting the charging of the bat-
tery in its installed position. Contact an au-
thorized Mercedes-Benz Center for
information and availability. Charge battery
in accordance with the separate instruc-
tions for the accessory battery charger.


463 Practical hints
Battery

Charge battery in accordance with the
instructions of the battery charger
manufacturer.

Reinstall the charged battery. Follow
the previously described steps in re-
verse order.
Reconnecting the battery
Turn off all electrical consumers.

Connect the battery positive lead and
fasten its cover.

Connect the battery negative lead.

Install the luggage box (
page 433).
!
The battery and the battery ventilation hose
must always be securely installed when the vehi-
cle is in operation.
!
Always connect the battery in the order de-
scribed below. Otherwise the vehicle’s electron-
ics can be damaged.
!
Never invert the terminal connections!
i
The following procedures must be carried
out following any interruption of battery power
(e.g. due to reconnection):


Set the clock (
page 171) (see COMAND
operator’s manual).


Synchronize the side windows
(page 239).


Synchronize the tilt/sliding sunroof
(page 244) or the tilt/sliding panel*
(page 248).
