2007 MERCEDES-BENZ E550 4MATIC Owner's Manual

496 Technical dataFuels, coolants, lubricants etc.Premium unleaded gasoline (gasoline engine)
Fuel requirements
Gasoline engine
Only use premium unleaded fuel:

The octane number (posted at the
pump) must be 91 min. It is an average
of both the Research Octane Number
(RON) and the Motor Octane Number
(MON): (RON+MON)/2. This is also
known as the ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not
exceed 10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional cosolvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains
10% ethanol and 90% unleaded gasoline,
can be used.
Warning!
G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious
personal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid in-
haling fumes and skin or clothing contact,
extinguish all smoking materials.
Direct skin contact with fuels and the inha-
lation of fuel vapors can damage your
health.
!
To maintain the engine’s durability and per-
formance, premium unleaded gasoline must be
used. If premium unleaded gasoline is not avail-
able and low octane fuel is used, follow these
precautions:


Have the fuel tank only partially filled with
unleaded regular gasoline and fill up with
premium unleaded gasoline as soon as
possible.


Avoid full throttle driving and abrupt
acceleration.


Do not exceed an engine speed of 3 000 rpm
if the vehicle is loaded with a light load such
as two persons and no luggage.


Do not exceed
2/3 of maximum accelerator
pedal position if the vehicle is fully loaded or
operating in mountainous terrain.

497 Technical data
Fuels, coolants, lubricants etc.
These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.
Diesel engine
Only use commercially available vehicular
ULTRA-LOW SULFUR DIESEL FUEL
(15 ppm SULFUR MAXIMUM).
To prevent malfunctions, diesel fuel with
improved cold flow characteristics is of-
fered in the winter months. Check with
your fuel retailer.
Gasoline additives (gasoline engine)
A major concern among engine
manufacturers is carbon build-up caused
by gasoline. Mercedes-Benz recommends
only the use of quality gasoline containing
additives that prevent the build-up of
carbon deposits.
After an extended period of using fuels
without such additives, carbon deposits
can build up, especially on the intake
valves and in the combustion area, leading
to engine performance problems such as:

Warm-up hesitation


Unstable idle


Knocking/pinging


Misfire


Power lossIn areas where carbon deposits may be
encountered due to lack of availability of
gasolines which contain these additives,
Mercedes-Benz recommends the use of
additives approved by us for use on
Mercedes-Benz vehicles. Refer to Factory
Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center for a listing of
approved product(s). Follow directions on
product label.
Do not blend other fuel additives with fuel.
This only results in unnecessary cost and
may be harmful to the engine operation.
!
Do not fill the tank with gasoline. Do not
blend diesel fuel with gasoline or kerosene. The
fuel system and engine will otherwise be
damaged, which is not covered by the
Mercedes-Benz Limited Warranty.
!
Damage or malfunction resulting from poor
fuel quality or from blending additional fuel
additives other than those tested and approved
by us for use on Mercedes-Benz vehicles are not
covered by the Mercedes-Benz Limited
Warranty.
For a listing of approved products, refer to the
Factory Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center.

498 Technical dataFuels, coolants, lubricants etc.Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which pro-
vides:

Corrosion protection


Freeze protection


Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -35°F (-37°C) and corro-
sion protection.
If the antifreeze mixture is effective to
-35°F (-37°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for re-
placement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification are used to
renew the coolant concentration or bring it
back up to the proper level.
For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Center.
To provide important corrosion protection,
the solution must be at least 50% anticor-
rosion/antifreeze (equivalent to freeze
protection to approximately -35°F
[-37°C]). If you use a solution that is more than 55%
anticorrosion/antifreeze (freeze protec-
tion to approximately -49°F [-45°C]), the
engine temperature will increase due to
the lower heat transfer capability of the so-
lution. Therefore, do not use more than
this amount of anticorrosion/antifreeze.
If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage). Please make sure the
mixture is in accordance with label instruc-
tions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Center.
!
Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the Mercedes-Benz
Limited Warranty.

499 Technical data
Fuels, coolants, lubricants etc.
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be
specifically formulated to protect the aluminum parts. Failure to use such
anticorrosion/antifreeze coolant will
result in a significantly shortened service
life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantityModel
Approx. freeze protection-35°F (-37°C)
-49°F (-45°C)
E 320 BLUETEC
6.9 US qt (6.5 l)
7.6 US qt (7.2 l)
E 350/E 350 4MATIC
5.3 US qt (5.0 l)
5.9 US qt (5.5 l)
E 550/E 550 4MATIC
6.0 US qt (5.7 l)
6.6 US qt (6.2 l)
E63AMG
6.2 US qt (5.9 l)
6.9 US qt (6.5 l)

500 Technical dataFuels, coolants, lubricants etc.Windshield washer system and head-lamp cleaning system*
Both the windshield washer system and
headlamp cleaning system* are supplied
from the windshield washer reservoir.
The windshield washer reservoir has a ca-
pacity of approximately:

6.9 US qt (6.5 l) in vehicles with a
headlamp cleaning system*


4.8 US qt (4.5 l) in vehicles without a
headlamp cleaning system*

Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer sol-
vent/antifreeze, depending on ambient
temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:


1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] water).
For temperatures below freezing point use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer
solvent/antifreeze:


1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent).
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

501 Index
A
ABS 97
Indicator lamp 380
Messages in display 398, 413
Accelerator position, automatic
transmission 188
Accessory weight 359
Accident 60
Active Bi-Xenon headlamps* see Head-
lamps
Active head restraints 87
Adaptive Damping System see ADS
ADS 265
Air bags 70
Children 71
Front, Driver 74
Front, Passenger 74
Safety guidelines 72
Side impact 75
Window curtain 75
Air conditioning refrigerant 495
Air conditioning system see Climate con-
trol system
Air conditioning, Cooling 217, 233
Air distribution 211, 228
Air pressure 359Air pressure see Tire inflation
pressure 342
Air pump, electric
Turning on 457
Air recirculation mode 214, 231
Air vents 211, 228
Air volume 212, 229
Airmatic DC (Dual Control)
Messages in display 430
Suspension tuning 265
Airmatic DC (Dual Control) 265
Vehicle level control 266
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 434, 455
AMG menu 157
Anticorrosion/antifreeze 499
Antilock Brake System see ABS
Anti-theft systems 106
Anti-theft alarm system 106
Immobilizer 106
Aquaplaning see Hydroplaning
Ashtrays 287
Aspect ratio 359AUDIO menu 161
Operating CD player 162
Selecting radio station 161
Selecting satellite radio* station 161
Audio search function 177
Audio system
CD mode 162
Auto-dimming
Rear view mirrors 198
Automatic central locking, Control
system 176
Automatic headlamp mode 138
Automatic lighting control, Interior
lighting 145
Automatic locking when driving 176
Automatic shift program 190

502 IndexAutomatic transmission
Accelerator position 188
Automatic shift program 190
Emergency operation (Limp-Home
Mode) 197
Gear ranges 189
Gear selector lever 184
Gear selector lever control one-touch
gearshifting 191
Gear selector lever positions 186
Gear shifting malfunctions 197
Kickdown 188
Kickdown, manual shift program
E63AMG 196
Manual shift program E 63 AMG 194
Program mode selector switch 190
Shifting procedure 185
Starting engine 52
Steering wheel gearshift control
one-touch gearshifting* 192
B
BabySmart
TM
Air bag deactivation system 81
Self-test 81Backrest 277
Seat 43
Seat, multicontour* 131
Backup lamps
Messages in display 422
Replacing bulbs 443
Bar 360
BAS 99
Batteries, SmartKey
Checking battery condition 119
Replacing 441
Batteries, SmartKey with KEYLESS-GO*
Checking battery condition 119
Replacing 441
Batteries, Vehicle
Charging 462
Disconnecting 461
Jump starting 464
Messages in display 412
Reconnecting 463
Reinstalling 462
Removing 462
Bead 360
Beverage holder see Cup holders
Bi-Xenon headlamps* see Headlamps
Bleeding the fuel system 459Block heater* (Canada only) 365
Brake fluid
Checking 324
Messages in display 413
Brake lamp
Cleaning lenses 372
Replacing bulbs 443
Brake pads
Message in display 412
Brakes 310
High-performance brake system
(E 63 AMG only) 312
Warning lamp 383
Break-in period 308
Bulbs see Replacing bulbs
C
California retail buyers and lessees, impor-
tant notice for 11
Can holder see Cup holders
Capacities and recommended
fuel/lubricants 491
Cargo area see Trunk
Cargo tie-down rings 280
Carpets, cleaning 376
Catalytic converter (gasoline
engine) 318

503 Index
CD player 162
Center console
Lower part 30
PASS AIR BAG OFF indicator
lamp 393
Upper part 29
Central locking
Automatic 127, 176
Locking/unlocking from inside 127
Central locking switch 127
Certification label 476
Checking
Oil level 327
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 345
Children in the vehicle 88
Air bags 71
Blocking of rear window operation 95
Indicator lamp, front passenger front
air bag 81
Infant and child restraint systems 89
LATCH-type child seat anchors 94
Cigarette lighter 288Climate control system
4-zone automatic climate
control 220
Air conditioning refrigerant 495
Air conditioning, Cooling 217, 233
Air distribution 211, 228
Air recirculation mode 214, 231
Air volume 212, 229
Automatic mode 209, 226
Control panel, Rear 219, 235
Deactivating system 209, 225
Dual-zone automatic climate
control 204
Front defroster 212, 229
Maximum cooling MAX COOL 214,
230
Rear climate control 235
Residual engine heat (REST) 218,
234
Clock 27, 171
Setting time 172
Cockpit 24
Cold tire inflation pressure 360
Collapsible tire 487
Collapsible wheel chock 434COMAND see separate COMAND operat-
ing instructions
Combination filter with pollutant-sensitive
air-recirculation mode 233
Combination switch 57, 141
Control system 151
Multifunction display 151
Multifunction steering wheel 152
Resetting to factory settings 166
Control system menus 154
AMG 157
AUDIO 161
Distronic* 163
NAV* 163
Settings 166
Standard display 157
TEL* 181
Trip computer 179
Vehicle status message memory 164
Control system submenus 153
Convenience 178
Instrument cluster 169
Lighting 173
Time/Date 171
Vehicle 176
