2007 MERCEDES-BENZ E550 4MATIC Owner's Manual

464 Practical hintsJump starting
If the battery is discharged, the engine can
be started with jumper cables and the bat-
tery of another vehicle. Observe the follow-
ing:

Jump starting should only be performed
when the engine and catalytic
converter
1 are cold.


Do not start the engine if the battery is
frozen. Let the battery thaw out first.


Only jump start from batteries with the
same voltage rating (12 V). Jump start-
ing with a higher voltage battery could
damage the vehicle’s electrical system,
which will not be covered by the
Mercedes-Benz Limited Warranty.


Only use jumper cables with sufficient
cross-section and insulated terminal
clamps.


Always make sure the jumper cables
are not on or near pulleys, fans or other
parts that move when the engine is
started or running.
Warning!
G
Failure to follow these directions will cause
damage to the electronic components, and
can lead to a battery explosion and severe
injury or death.
Never lean over batteries while connecting
or jump starting, you might get injured.
Battery fluid contains sulfuric acid. Do not
allow this fluid to come in contact with eyes,
skin or clothing. In case it does, immediately
flush affected area with water, and seek
medical help if necessary.
A battery will also produce hydrogen gas,
which is flammable and very explosive. Keep
flames or sparks away from battery, avoid
improper connection of jumper cables,
smoking, etc.
Attempting to jump start a frozen battery
can result in it exploding, causing personal
injury.
Read all instructions before proceeding.
!
Do not tow-start the vehicle.
!
Avoid repeated and lengthy starting at-
tempts.
Do not attempt to start the engine using a bat-
tery quick charge unit.
If the engine does not run after several unsuc-
cessful starting attempts, have it checked at the
nearest authorized Mercedes-Benz Center.
Excessive unburned fuel generated by repeated
failed starting attempts may damage the
catalytic converter
1.
Make sure the jumper cables do not have loose
or missing insulation.
Make sure the cable clamps do not touch any
other metal part while the other end is still at-
tached to a battery.
1Vehicles with gasoline engine only.

465 Practical hints
Jump starting
The battery is located in the trunk under-
neath the luggage box (
page 433). Only
jump start the vehicle from the battery in
the trunk.

Make sure the two vehicles do not
touch.

Turn off all electrical consumers.

Apply the parking brake (
page 62).

Make sure the gear selector lever is set
to positionP.

Open the trunk.1Positive terminal of discharged battery
2Negative terminal of discharged bat-
tery
3Positive terminal of charged battery
4Negative terminal of charged battery

Connect positive terminals1 and3
of the batteries with the jumper cable.
Clamp cable to charged battery3
first.

Start engine of the vehicle with the
charged battery and run at idle speed.

Connect negative terminals4 and2
of the batteries with the second jumper
cable. Clamp the cable to negative
terminal4 of the charged battery
first.

Start the engine of the disabled vehi-
cle.
You can now turn on the electrical con-
sumers. Do not switch on the headlamps
under any circumstances.

Remove the jumper cables first from
negative terminals2 and4 and then
from positive terminals1 and3.
You can now switch on the headlamps.

Have the battery checked at the near-
est authorized Mercedes-Benz Center.
Warning!
G
Keep flames or sparks away from battery.
Do not smoke.
Observe all safety instructions and precau-
tions when handling automotive batteries
(page 331).
!
Never invert the terminal connections!

466 Practical hintsTowing the vehicleMercedes-Benz recommends that the vehi-
cle be transported with all wheels off the
ground using flatbed or appropriate wheel
lift/dolly equipment. This method is pref-
erable to other types of towing.When circumstances do not permit the
recommended towing methods, the vehi-
cle may be towed with all wheels on the
ground or front wheels raised (except vehi-
cles with 4MATIC) only so far as necessary
to have the vehicle moved to a safe loca-
tion where the recommended towing
methods can be employed.!
Do not tow-start the vehicle.
!
Use flatbed or wheel lift/dolly equipment
with SmartKey in starter switch turned to
position0.
Do not tow with sling-type equipment. Towing
with sling-type equipment over bumpy roads will
damage radiator and supports.
To prevent damage during transport, do not tie
down vehicle by its chassis or suspension parts.
Switch off the tow-away alarm and the automatic
central locking.
!
Vehicles with 4MATIC:
Do not tow with one axle raised. Doing so could
damage the transfer case, which is not covered
by the Mercedes-Benz Limited Warranty.
All wheels must be on or off the ground. Observe
instructions for towing the vehicle with all
wheels on the ground.
Warning!
G
If circumstances require towing the vehicle
with all wheels on the ground, always tow
with a tow bar if:

the engine will not run


there is a malfunction in the brake
system


there is a malfunction in the power sup-
ply or in the vehicle’s electrical system
as that will be necessary to adequately con-
trol the towed vehicle.
Prior to towing the vehicle with all wheels on
the ground, make certain the SmartKey is in
starter switch position2.
If the SmartKey is left in the starter switch
position0 for an extended period of time, it
can no longer be turned in the switch. In this
case, the steering is locked. To unlock, re-
move SmartKey from starter switch and re-
insert.

467 Practical hints
Towing the vehicle
Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle. Adapt your driving accordingly.!
If the vehicle is towed with the front axle
raised (not permissible for vehicles with
4MATIC), the gear selector lever must be in
positionN and the engine must be shut off
(SmartKey in starter switch position0 or1).
Active braking action through the ESP
® may
otherwise seriously damage the brake system.
When towing the vehicle with all wheels on the
ground, the gear selector lever must be in
positionN and the SmartKey must be in starter
switch position2.
When towing the vehicle with all wheels on the
ground or the front axle raised, the vehicle may
be towed only for distances up to 30 miles
(50 km) and at a speed not to exceed 30 mph
(50 km/h).
!
Towing of the vehicle should only be done
using the properly installed towing eye bolt.
Never attach tow cable, tow rope or tow rod to
the vehicle chassis, frame or suspension parts.
i
When towing the vehicle with all wheels on
the ground, please note the following:
With the automatic central locking activated and
the SmartKey in starter switch position2, or
KEYLESS-GO
* start/stop button in position2,
the vehicle doors lock if the left front wheel as
well as the right rear wheel are turning at vehicle
speeds of approximately 9 mph (15 km/h) or
more.
To prevent the vehicle door locks from locking,
deactivate the automatic central locking
(
page 127).
i
To signal turns while being towed with the
hazard warning flasher in use, turn SmartKey in
starter switch to position2 and activate the
combination switch for the left or right turn sig-
nal in the usual manner – only the selected turn
signal will operate.
Upon canceling the turn signal, the hazard warn-
ing flasher will operate again.
i
The gear selector lever will remain locked in
positionP and the SmartKey will not turn in the
starter switch if the battery is disconnected or
discharged. For more information see “Batter-
ies” (page 460) or “Jump starting”
(
page 464).
For information on manual unlocking of the gear
selector lever, see (
page 438).

468 Practical hintsTowing the vehicleInstalling towing eye bolt
Front of vehicle
1Cover on right side of front bumper
To remove cover:
Press mark on cover1 in direction of
arrow.

Lift cover1 off to reveal the threaded
hole for towing eye bolt.
The towing eye bolt is supplied with the
tool kit (located in the storage compart-
ment under the trunk floor).

Screw towing eye bolt in to its stop and
tighten with lug wrench.
To reinstall cover:

Fit cover1 and snap into place.
Rear of vehicle
2Cover on right side of rear bumper
To remove cover:

Pull cover2 in direction of arrow.

Fold cover2 down to reveal the
threaded hole for the towing eye bolt.The towing eye bolt is supplied with the
tool kit (located in the storage compart-
ment under the trunk floor).

Screw towing eye bolt in to its stop and
tighten with lug wrench.
To reinstall cover:

Fit cover2 and snap into place.

469 Practical hintsFuses
Fuses
The electrical fuses in your vehicle serve to
switch off malfunctioning power circuits.
If a fuse is blown, the components and sys-
tems secured by that fuse will stop operat-
ing.If a newly inserted fuse blows again, have
the cause determined and rectified by an
authorized Mercedes-Benz Center.
The following aids are available to help you
replace fuses.


Fuse chart
The fuse chart is located in the fuse box
in the passenger compartment
(page 470). The fuse chart explains
the fuse allocation and fuse amperag-
es.


Spare fuses
Spare fuses are located in the vehicle
tool kit in the trunk (
page 434).


Fuse extractor
The fuse extractor is located in the ve-
hicle tool kit in the trunk (
page 434).The electrical fuses are located in different
fuse boxes:


in the passenger compartment on the
driver’s side (
page 470)


in the trunk (
page 470)
Before replacing fuses:

Apply the parking brake (
page 62).

Make sure the gear selector lever is set
to position P (
page 184).

Turn off all electrical consumers.

Turn off the engine (
page 63).

Remove the SmartKey from the starter
switch.
Vehicles with KEYLESS-GO*:
Open the driver’s door.
Warning!
G
Only use fuses approved by Mercedes-Benz
with the specified amperage for the system
in question and do not attempt to repair or
bridge a blown fuse. Using other than ap-
proved fuses or using repaired or bridged
fuses may cause an overload leading to a
fire, and/or cause damage to electrical
components and/or systems. Have the
cause determined and remedied by an
authorized Mercedes-Benz Center.i
A blown fuse must be replaced by an appro-
priate spare fuse (recognizable by its color or the
fuse rating given on the fuse) of the amperage
recommended in the fuse chart.
Any Mercedes-Benz Center will be glad to advise
you on this subject.

470 Practical hintsFusesFuse box in passenger compartment
The fuse box is located behind a cover in
the dashboard on the driver’s side.
1Cover
2Recess in the coverOpening

Open the driver’s door.

Insert flat, blunt object as a lever in
recess2 on the edge of cover1.

Loosen cover1 from the dashboard
using lever.

Using your hands, pull cover1 in di-
rection of arrow and remove.
Closing

Hook cover1 into the opening at the
front.

Press cover1 back on until it engag-
es.
Fuse box in trunk
The fuse box is located behind the
left-hand trim panel in the trunk.
Fuse box cover design may vary depending
on vehicle equipment. Cover with turn catches shown1Catches
2Cover
Opening cover (with turn catches)
Turn catches1 counter-clockwise.
and remove cover2.
!
Do not use sharp objects such as a screw
driver to open the fuse box cover1 in the dash-
board, as this could damage it.
!
The cover1 must be properly positioned
as described to prevent moisture or dirt from en-
tering the fuse box and possibly impairing fuse
operation.

471 Practical hintsFuses
Closing cover (with turn catches)
Install cover2 (
page 470).

Turn catches1 (
page 470) clock-
wise.
Opening cover (without turn catches)

Hold cover at recess, press cover
slightly together to release tabs from
behind trim panel and then pull off cov-
er.Closing cover (without turn catches)

Install cover with tabs on one side of
trim panel, then press cover slightly to-
gether to install cover on other side of
trim panel.
