2006 MERCEDES-BENZ E WAGON Owner's Manual

56 Getting startedDrivingIntermittent wiping
Intermittent wiping interval is dependent
on wetness of windshield.
Turn the combination switch to
positionI.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe

Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.Wiping with windshield washer fluid

Push the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system*”
(
page 323).
!Do not leave windshield wipers in
intermittent setting when the vehicle is
taken to an automatic car wash or
during windshield cleaning. Windshield
wipers will operate in the presence of
water sprayed on the windshield, and
windshield wipers may be damaged as
a result.
iIntermittent wiping is interrupted when
the vehicle is at a standstill and a front
door is opened. This protects persons
getting into or out of the vehicle from
being sprayed.
Intermittent wiping will be continued
when

all doors are closed
and


the gear selector lever is in
positionD or R
or


the wiper setting is changed using
the combination switch
iTo prevent smears on the windshield,
wipe with windshield washer fluid every
now and then even when it is raining.

57 Getting started
Driving
Rear window wiper/washer
The button is located on the center con-
sole.
1Intermittent wipe
2Indicator lamp
3Rear window washer system
Switch on the ignition (
page 36)
!If anything blocks the windshield wip-
ers (leaves, snow, etc.), switch them off
immediately.

For safety reasons, stop the vehicle
in a safe location

remove SmartKey from starter
switch
or


turn off the engine by pressing
the KEYLESS-GO* start/stop
button and open the driver’s
door (with the driver’s door
open, starter switch is in
position0, same as with
SmartKey removed from starter
switch)
before attempting to remove any
blockage.


Remove blockage.


Turn the windshield wipers on
again.
If windshield wipers fail to function at
all in switch positionI,


set the combination switch to the
next highest wiper speed


have the windshield wipers
checked at the nearest authorized
Mercedes-Benz Center
iThe rear window wiper engages
automatically if the gear selector lever
is moved to positionR with the
windshield wipers switched on.

58 Getting startedDrivingActivating intermittent wipe
Press upper section1 of the button.
Indicator lamp2 comes on.
Deactivating intermittent wipe

Press upper section1 of the button
again.
Indicator lamp2 goes out.
Wiping with window washer fluid

Press and hold lower half3 of the but-
ton.
The rear window is wiped for a further
5 seconds after the button is released.
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be
operating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an
authorized Mercedes-Benz Center as
soon as possible.
The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.

Stop the vehicle as soon as possible in
a safe location and turn off the engine.
Allow engine and coolant to cool.

Check the coolant level and add cool-
ant if necessary (
page 321).In case of accident
If the vehicle is leaking fuel:

Do not start the engine under any cir-
cumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Center.
If no damage can be determined on the


major assemblies


fuel system


engine mount:

Start the engine in the usual manner.

59 Getting started
Parking and locking
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the
vehicle.Warning!
G
Vehicles with Airmatic*: If you have selected
the Comfort suspension tuning
(page 255), the vehicle lowers slightly
when it is locked. You should therefore
make sure that no one is standing near the
wheel arches or lying underneath the vehi-
cle when it is being locked. Otherwise, per-
sonal injury could result.
Warning!
G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury as a re-
sult of vehicle movement, before turning off
the engine and leaving the vehicle always:

Keep right foot on brake pedal.


Firmly depress parking brake pedal.


Move the gear selector lever to
positionP.


Slowly release brake pedal.


When parked on an incline, turn front
wheel towards the road curb.


Turn the SmartKey to starter switch
position0 and remove, or press
start- / stop button (vehicles with
KEYLESS-GO*).


Take the SmartKey or the SmartKey with
KEYLESS-GO* and lock vehicle when
leaving.!Vehicles with Airmatic*: If you have se-
lected the Comfort suspension tuning
(page 255), the vehicle lowers slight-
ly when you lock it within approximate-
ly 60 seconds after switching off the
engine. When parking, make sure that
your vehicle cannot come into contact
with other objects, such as a curb,
while lowering. Your vehicle could oth-
erwise be damaged.

60 Getting startedParking and lockingParking brake
1Parking brake pedal
2Release handle
Step firmly on parking brake pedal1.
When the engine is running, the warn-
ing lamp ; (USA only) or 3
(Canada only) in the instrument cluster
will be illuminated.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could release the parking brake and/or
move the gear selector lever from
positionP, either of which could result in an
accident and/or serious injury.
Warning!
G
Getting out of your vehicle with the gear se-
lector lever not fully engaged in positionP is
dangerous. Also, when parked on an incline,
positionP alone may not prevent your vehi-
cle from moving, possibly hitting people or
objects.
Always set the parking brake in addition to
shifting to positionP.
When parked on an incline, turn front wheels
towards the road curb.

61 Getting started
Parking and locking
Switching off headlamps
Turn the exterior lamp switch toM
(page 54).
For more information, see the “Controls in
detail” section (
page 143).
Turning off engine
Move the gear selector lever to
positionP.

Apply the parking brake (
page 60).Turning off with the SmartKey

Turn the SmartKey in the starter switch
(page 36) to position0 and remove
it.
The immobilizer is activated.Turning off with KEYLESS-GO*

Place the gear selector lever inP.

Press the KEYLESS-GO start/stop but-
ton to shut off the engine.
With the driver’s door closed, the start-
er switch is now in position1. With the
driver’s door opened, the starter switch
is set to position0, same as SmartKey
removed from starter switch
(page 36).
iAlways set the parking brake in addi-
tion to shifting to positionP.
On slopes, turn the front wheels to-
wards the road curb.
iThe SmartKey can only be removed
from the starter switch with the gear
selector lever in positionP.
!If you hear a warning signal, you have
either

forgotten to switch off the vehicle’s
exterior lamps before opening the
driver’s door,
or


tried to turn off the engine while the
gear selector lever is not inP.
Turn off the lights or place the gear se-
lector lever inP.

62 Getting startedParking and lockingReleasing seat belts
Press the seat belt release button
(page 48).
Allow the retractor to completely re-
wind the seat belt by guiding the latch
plate.
Locking

Exit the vehicle and close all doors and
the tailgate.
!Make sure the seat belt retracts fully so
that the seat belt and/or latch plate
cannot get caught or pinched in the
door or in the seat mechanism. This
can damage the seat belt and impair
the effectiveness of the seat belt,
and/or cause damage to the door
and/or door trim panel. Such damage
is not covered by the Mercedes-Benz
Limited Warranty.
Damaged seat belts must be replaced.
Contact an authorized Mercedes-Benz
Center.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the door
openings when closing the doors. Be espe-
cially careful when small children are
around.
Before closing doors, make sure that there
is no possibility of someone getting caught
in a door during closing.Warning!
G
When leaving the vehicle, always take the
SmartKey or the SmartKey with
KEYLESS-GO* with you, and lock the vehi-
cle. Do not leave children unattended in the
vehicle, or with access to an unlocked vehi-
cle. Unsupervised use of vehicle equipment
may cause an accident and/or serious per-
sonal injury.
iA warning sounds and the message Switch off lights
appears in the mul-
tifunction display if the vehicle’s exteri-
or lamps are not switched off


with the SmartKey removed from
the starter switch and the driver’s
door open


with the engine turned off using the
KEYLESS-GO* start/stop button
and the driver’s door open (same as
SmartKey removed from starter
switch)
Switch off the exterior lamps.

63 Getting started
Parking and locking
Locking with the SmartKey
After exiting the vehicle, press lock
button‹ on the SmartKey
(page 34).


All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).
For more information, see “Factory
setting” (
page 108).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
For more information, see the “Controls in
detail” section (
page 106).Locking with KEYLESS-GO*
1Lock button

After exiting the vehicle, press lock
button1 on an outside door handle or
on the tailgate.

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).
For more information, see “Factory
setting” (
page 114).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
For more information, see the “Controls in
detail” section (
page 111).
