2006 MERCEDES-BENZ E WAGON Owner's Manual

128 Controls in detailLocking and unlockingLocking and unlocking from the inside
You can lock or unlock the doors and the
tailgate from inside using the central lock-
ing switch. This can be useful, for example,
if you want to lock the vehicle before start-
ing to drive.
The fuel filler flap cannot be locked or un-
locked with the central locking switch.The switch is located in the center console.
Central locking switch1Locking
2UnlockingLocking

Press lower half 1 of the central lock-
ing switch.
If all doors are closed, the vehicle
locks.
Unlocking

Press upper half2 of the central lock-
ing switch.
The vehicle unlocks.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and / or serious personal
injury.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked using the SmartKey, it will not
unlock using the central locking switch.
If the vehicle was previously locked
with the central locking switch

while in the selective remote con-
trol mode, only the front door
opened from the inside is unlocked.


while in the global remote control
mode, the vehicle is unlocked com-
pletely when a front door is opened
from the inside.

129 Controls in detailSeats
Seats
For more information on seat adjustment,
see the “Getting started” section
(page 41).
Front seat active head restraints
You cannot remove the active head re-
straint on the driver’s and passenger’s
seats.For removal of the active head restraints
we recommend that you contact an autho-
rized Mercedes-Benz Center.
For information on head restraint adjust-
ment, see “Seats” (
page 42).
For information on active head restraints,
see “Active head restraints” (
page 76).
Rear seat head restraints
Folding head restraints back
The rear seat head restraints can be folded
backward for increased visibility.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
iAdjust the head restraint in such a way
that it is as close to the head as possi-
ble.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.

130 Controls in detailSeatsFolding head restraints back with switch
in the center console
1Head restraint release switch
Switch on the ignition (
page 36).

Press the symbol-side on switch1 to
release the head restraints.
The head restraints will fold backward.Folding head restraints back manually
(rear outer seats only)
1Release button

Push release button1 and fold the
head restraints backward.Placing head restraints upright

Pull the head restraint forward until it
locks into position.!Make sure the head restraints engage
when placing them upright. Otherwise
their protective function cannot be as-
sured.

131 Controls in detailSeats
Head restraint height
(rear outer seats only)
1Release button
Raising:
Manually adjust the height of the head
restraint by pulling it upward.
If the head restraint is fully retracted,
push release button1 and pull the
head restraint out.Lowering:

To lower the head restraint, push
release button1 and push down on
the head restraint.Head restraint tilt
(rear outer seats only)
Two different head restraint angle
positions are available.
1Release button

Press the release button1 and tilt the
head restraint to the desired position.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the head
restraint supports the back of the head at
eye level. This will reduce the potential for
injury to the head and neck in the event of
an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are
intended to help reduce injuries during an
accident.

132 Controls in detailSeatsRemoving and installing rear seat head
restraints
1Release button
Removing rear seat head restraints

Fold back head restraint (
page 129).

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.Installing rear seat head restraints

Insert head restraint and push it down
until it engages.

Push button1 and adjust head
restraint to desired position.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an ac-
cident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.
!When installing the head restraints,
make sure that:

The proper head restraint for each
seat is installed. The bars of the
head restraint designed for the mid-
dle rear seat are of even length and
shorter than those designed for use
on the outer rear seats.


The head restraints engage fully.

133 Controls in detailSeats
Lumbar support
The curvature of the driver’s seat can be
adjusted to help enhance lower back sup-
port and seating comfort.
1Adjustment lever
Move adjustment lever1 in direction
of the arrows until you have reached a
comfortable seating position.Drive - Dynamic seat* with multicon-
tour features
The Drive - Dynamic seat automatically ad-
justs the lateral support provided by the
backrest to your driving style.
The Drive - Dynamic seat electronically
controls the air pressure in the air cham-
bers of the backrest side bolsters. This
function improves driving comfort and
pleasure.
In addition, the Drive-Dynamic seat has a
movable seat cushion and inflatable air
cushions built into the backrest to provide
additional lumbar and side support.
The seat cushion movement, backrest
cushion height and curvature can be con-
tinuously varied with switches on the right
side of the seat on the driver side, or the
left side of the seat on the passenger side
after turning the SmartKey in the starter
switch to position2 or pressing the KEY-
LESS-GO* start/stop button twice.1Backrest center
2Backrest bottom
3Seat cushion depth
4Activate drive dynamic function
5Backrest side bolsters
6Massage function

Switch on the ignition (
page 36).

134 Controls in detailSeatsMulticontour features
Seat cushion depth
Adjust the seat cushion depth to the
length of your upper leg using
switch3.
Backrest contour

Move the backrest support to the bot-
tom by using button2 or to the center
by using button1.

Adjust the contour of the backrest to
the desired position using æ or
ç.
Backrest side bolsters

Adjust the side bolsters so that they
provide good lateral support using
switch5.Drive-dynamic features
Activating

Press button4 (
page 133).
The indicator lamp on the button
comes on and the following display ap-
pears in the multifunction display for
about 5 seconds.
Deactivating

Press button4 (
page 133) again.
The indicator lamp on the button goes
out.Massage function (PULSE)
The massage function can help prevent
muscle tension during long drives.

Press button6 (
page 133).
The indicator lamp on the button
comes on. The air cushions in the lum-
bar area pulsate.
iYou can adjust the characteristics of
the Drive - Dynamic seat using the con-
trol system (
page 179).
iWhen the engine is turned off, the last
cushion setting is retained in memory.
The cushion is automatically adjusted
to this setting when the engine is re-
started.iThe massage function turns off auto-
matically after approximately
5minutes.

135 Controls in detailSeats
Seat heating*
Both switches for the front seats are locat-
ed in the center console. The red indicator
lamps in the switch come on to show
which heating level you have selected.
1Seat heating switch

Switch on the ignition (
page 36).
Switching seat heating on

Press switch1 repeatedly until the
desired heating level is set.
One or more red indicator lamps on the
switch show the selected heating level.Switching seat heating off

Press switch1 repeatedly until all in-
dicator lamps go out.
Level3
Three indicator lamps on
(highest level)
The seat heating automatically
switches to level2 after approxi-
mately 5 minutes.
2
Two indicator lamps on
The seat heating automatically
switches to level1 after approxi-
mately 10 minutes.
1
One indicator lamp on
(lowest level)
The seat heating automatically
switches off after approximately
20 minutes.
off
No indicator lamp on
iIf one or more of the lamps on the seat
heating switch are flashing, there is in-
sufficient voltage available since too
many electrical consumers are turned
on. The seat heating switches off auto-
matically.
The seat heating will switch back on
again automatically as soon as suffi-
cient voltage is available.
