2006 MERCEDES-BENZ E WAGON Owner's Manual

168 Controls in detailControl systemInstrument cluster submenu
Access the
Instr. cluster
submenu via
the
Settings
menu. Use the
Instr. clus-
ter
submenu to change the instrument
cluster display settings. The following
functions are available:Selecting speedometer display mode

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Display unit
Speed-/odometer appears in the multi-
function display.
The selection marker is on the current
setting.

Press button æ or ç to set
speedometer unit to
km or
miles
.Selecting language

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Language
appears in
the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the language to be used for the multi-
function display messages.
Function
Page
Select speedometer display
mode
168
Select language
168
Select display (speed display or
outside temperature) for status
display
169
Select display (speed display or
outside temperature) for basic
display
169

169 Controls in detail
Control system
Available languages:

German (
Deutsch
)


English (
English
)


French (
Français
)


Italian (
Italiano
)


Spanish (
Español
)


Dutch (
Nederlands
)


Danish (
Dansk
)


Swedish (
Svenska
)


Portuguese (
Português
)


Turkish (
Türkçe
)Selecting display (speed display or out-
side temperature) for status display

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Status line dis-
play
appears in the multifunction dis-
play.
The selection marker is on the current
setting.

Press buttonæ orç to select
the status line to
Speed
or
Outside
temp.
.Selecting display (speed display or out-
side temperature) for basic display

Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until the message
Basic display
ap-
pears in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the display permanently shown in the
multifunction display.iYou will see the status indicator when
you have called up a different display
from the standard display.

170 Controls in detailControl systemTime / Date submenu
Access the
Time/Date
submenu via the
Settings
menu. Use the
Time/Date
sub-
menu to change the time and date display
settings. The following functions are avail-
able:Synchronizing the time
This function can only be seen on vehicles
with COMAND and navigation module*.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Time sync. with
head unit
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired setting.Set time (hours)
This function can only be seen when time
synchronization is switched off.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Clock, hours
ap-
pears in the multifunction display.
The selection marker is on the hour set-
ting.

Press buttonæ orç to set the
hours.

Confirm by pressing reset button
(page 151).
Function
Page
Synchronizing the time
170
Set time (hours)
170
Set time (minutes)
171
Set date (month)
171
Set date (day)
171
Set date (year)
172
iInformation on setting the time, refer to
separate COMAND instructions.

171 Controls in detail
Control system
Set time (minutes)
This function can only be seen when time
synchronization is switched off.
Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Clock, minutes
ap-
pears in the multifunction display.
The selection marker is on the minute
setting.

Press buttonæ orç to set the
minutes.

Confirm by pressing reset button
(page 151).Set date (month)

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Set date month
ap-
pears in the multifunction display.
The selection marker is on the month
setting.

Press buttonæ orç to set the
month.Set date (day)

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Set date day
ap-
pears in the multifunction display.
The selection marker is on the day
setting.

Press buttonæ orç to set the
day.

172 Controls in detailControl systemSet date (year)
Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Set date year
ap-
pears in the multifunction display.
The selection marker is on the year
setting.

Press buttonæ orç to set the
year.Lighting submenu
Access the
Lighting
submenu via the
Set-
tings
menu. Use the
Lighting
submenu
to change the lamp and lighting settings on
your vehicle. The following functions are
available:Setting daytime running lamp mode
(USA only)

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until the message
Lamp circuit head-
lamp
appears in the multifunction dis-
play.
The selection marker is on the current
setting.
Function
Page
Set daytime running lamp mode
(USA only)
172
Setting locator lighting
173
Setting ambient lighting
174
Setting headlamps delayed
shut-off
174
Setting interior lighting delayed
shut-off
175
iThis function is not available in coun-
tries where the daytime running lamp
mode is mandatory and therefore in a
constant mode.

173 Controls in detail
Control system

Press buttonæ orç to select
manual operation (
manual
) or daytime
running lamp mode (
constant
) activat-
ed.
With daytime running lamp mode activated
and the exterior lamp switch at
positionM orU, the low beam
headlamps are switched on when the en-
gine is running.
In low ambient light conditions the follow-
ing lamps will switch on additionally:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps
For more information on the daytime run-
ning lamp mode, see “Lighting”
(
page 143).Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on during darkness when the vehi-
cle is unlocked using button Πon the
SmartKey or SmartKey with
KEYLESS-GO*:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.

Move the selection marker with
buttonæ orç to the
Lighting

submenu.
iFor safety reasons, resetting the Lighting
submenu to factory settings
while driving (
page 166) will not de-
activate the daytime running lamp
mode.
The following message appears in the
multifunction display:
Lighting - Can-
not be completely reset to factory
settings while driving.


174 Controls in detailControl system
Press buttonj ork repeatedly
until the message
Function Surround
lighting
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the locator lighting function
on or
off
.

Turn the exterior lamp switch to
positionU when exiting the vehicle.
The locator lighting feature is activat-
ed.Setting ambient lighting
Use this function to adjust the brightness
of the ambient lighting.

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until the message
Ambient light Lev-
el
appears in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired brightness of the ambient
lighting.
The setting
1 represents the darkest
level and setting
5 the brightest level.
The ambient light is switched off at set-
ting
0.Setting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether you would
like the exterior lamps to remain on for
15 seconds during darkness after exiting
the vehicle and closing all doors.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on
when the engine is turned off:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.


175 Controls in detail
Control system

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Headlamps delayed
shut-off
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Headlamps delayed shut-off
on or
off
.

Turn the exterior lamp switch to
positionU before turning off the
engine.
You can temporarily deactivate the de-
layed shut-off feature:

Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.

Then turn it to position2 and back to
position0.
The delayed shut-off feature is deacti-
vated. It will reactivate as soon as you
reinsert the SmartKey in the starter
switch.
Vehicles with KEYLESS-GO*:

Press the KEYLESS-GO start / stop but-
ton on the gear selector lever
(page 38).Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain lit for
10 seconds during darkness after you have
removed the SmartKey from the starter
switch.

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Interior lighting
delayed shut-off appears in the mul-
tifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Interior lighting delayed shut-off

on or
off
.
iYou can reactivate this function within
10 minutes by opening a door.
