2006 MERCEDES-BENZ CLK COUPE Owner's Manual

408 Practical hintsResetting activated head restraintsResetting activated head restraints
If the active head restraints have been trig-
gered in a rear-end collision, the active
head restraints must be reset. Otherwise,
the active head restraints cannot offer any
additional protection in the event of anoth-
er rear-end collision.
1Head restraint cushion
2Head restraint cover
3Reset tool
4Hole

Take the reset tool3 out of the
Mercedes-Benz vehicle literature
pouch.

Guide reset tool3 into the hole4 be-
tween the rear head restraint cover2
and the head restraint cushion1.

Press the reset tool3 downward until
you hear the active head restraint re-
lease mechanism audibly engage.

Pull out reset tool3.

Firmly press the head restraint
cushion1 back toward the rear head
restraint cover2 until it engages.

Repeat this procedure on the active
head restraint for the second front
seat.

After resetting the active head re-
straints store the reset tool3 in the
Mercedes-Benz vehicle literature
pouch.
For information on active head restraints,
see “Active head restraints” (
page 73).
For information on head restraint adjust-
ment, see “Seats” (
page 37).
iFor your convenience, we recommend
that you have this work carried out by
an authorized Mercedes-Benz Center.
You will find the reset tool for manually
operating the active head restraints in
the Mercedes-Benz vehicle literature
pouch.Warning!
G
When pushing back the head restraint cush-
ion, take care that your fingers do not be-
come caught between the head restraint
cushion and the cover. Failing to do so may
lead to injury.
!Be careful not to damage upholstery.

409 Practical hints
Replacing SmartKey batteries
Replacing SmartKey batteries
If the batteries in the SmartKey or the
SmartKey with KEYLESS-GO* are dis-
charged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an
authorized Mercedes-Benz Center.Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.Warning!
G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen inserting the batteries, make
sure they are clean and free of lint.
iWhen changing batteries, always
replace both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.

410 Practical hintsReplacing SmartKey batteriesSmartKey
Replacement batteries: Lithium, type
CR 2025 or equivalent.
Remove the mechanical key
(page 404).
1Mechanical key
2Slide
3Battery compartment

Insert the mechanical key 1 in direc-
tion of arrow in side opening.

Using mechanical key1, push gray
slide2 to unlatch battery
compartment3.

Pull battery compartment3 out of the
housing in the direction of arrow.
4Battery
5Contact spring

Remove the batteries4 in direction of
arrow.

Using a lint-free cloth, insert new
batteries4 under the contact
spring5 with the positive terminal (+)
side facing up.

Return battery compartment 3 into
housing until it locks into place.

Slide mechanical key 1 back into the
SmartKey.

Check the operation of the SmartKey.

411 Practical hints
Replacing SmartKey batteries
SmartKey with KEYLESS-GO*
Replacement batteries: Lithium, type
CR 2025 or equivalent.
Remove the mechanical key
(page 404).

Insert the mechanical key in side open-
ing and push grey slide (
page 410).
The battery compartment is unlatched.

Pull the battery compartment out of the
housing (
page 410).1Battery
2Tilt battery up
3Mechanical key

Using mechanical key3, apply
pressure to position2.
Battery1 tilts up slightly.

Pull batteries1 out in the direction of
arrow.

Using a lint-free cloth, insert new
batteries1 under the contact spring
with the positive terminal (+) side
facing up.

Return battery compartment into hous-
ing until it locks into place.

Slide mechanical key 3 back into the
SmartKey.

Check the operation of the SmartKey
and the KEYLESS-GO*.

412 Practical hintsReplacing bulbsSafe vehicle operation depends on proper
exterior lighting and signaling. It is there-
fore essential that all bulbs and lamp
assemblies are in good working order at all
times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. See an authorized
Mercedes-Benz Center for headlamp
adjustment.
Bulbs Front lamps
iIf the headlamps or front fog lamps are
fogged up on the inside as a result of
high humidity, driving the vehicle a
distance with the lights on should clear
up the fogging.iBack-up bulbs will be brought into use
when lamps malfunction. Observe the
messages in the multifunction display
(page 391).
Lamp
Type
1
Additional turn signal
lamp
LED
2
Turn signal lamp
1156 NA
3
Halogen headlamp:
Low beam
Bi-Xenon* headlamp:
Low and high beam
1
1Vehicles with Bi-Xenon headlamps* do not replace
the Bi-Xenon bulbs yourself.
H7 (55 W)
D2S-35 W
4
Halogen headlamp:
High beam/high beam
flasher
Bi-Xenon* headlamp:
High beam flasher
H7 (55 W)
H7 (55 W)
Parking and standing
lamp
W 5 W
5
Front fog lamp
Corner-illuminating
front fog lamp*
H11 (55 W)
H11 (55 W)
6
Side marker lamp
W 5 W

413 Practical hints
Replacing bulbs
Rear lamps Notes on bulb replacement


Only use 12 volt bulbs of the same type
and with the specified watt rating.


Switch lights off before changing a bulb
to prevent short circuits.


Always use a clean lint-free cloth when
handling bulbs.


Your hands should be dry and free of oil
and grease.


If the newly installed bulb does not
come on, visit an authorized
Mercedes-Benz Center.
Have the LEDs and bulbs for the following
lamps replaced by an authorized
Mercedes-Benz Center.


Additional turn signal lamps in the exte-
rior rear view mirrors


High mounted brake lamp


Bi-Xenon* lamps


Front fog lamps


Front side marker lamps
Lamp
Type
7
High mounted brake
lamp
LED
8
Brake lamp
P 21 W
9
Turn signal lamp
P 21 W
a
Tail, parking and stand-
ing lamp, side marker
P 21/4 W
W 5 W
b
Backup lamp
P 21 W
c
License plate lamps
C 5 W
d
Rear fog lamp, driver’s
side, Tail lamp
P 21/4 W
Warning!
G
Keep bulbs out of reach of children.
Bulbs and bulb sockets can be very hot. Al-
low the lamp to cool down before changing
a bulb.
Halogen lamps contain pressurized gas. A
bulb can explode if you:

touch or move it when hot


drop the bulb


scratch the bulb
Wear eye and hand protection.
Because of high voltage in Xenon lamps, it is
dangerous to replace the bulb or repair the
lamp and its components. We recommend
that you have such work done by a qualified
technician.iHave the headlamp adjustment
checked regularly.

414 Practical hintsReplacing bulbsReplacing bulbs for front lamps
Before you start to replace a bulb for a
front lamp, do the following first:
Turn the exterior lamp switch to
positionM (
page 131).

Open the hood (
page 308).
Front lamps halogen-type
1Housing cover for low beam headlamp
2Housing cover for high beam head-
lamp, parking and standing lamp3Bulb socket for turn signal lamp bulb
4Bulb holder of low beam bulb
5Bulb holder of high beam bulb
6Bulb socket for parking and standing
lamp bulb
Low beam bulb

Turn housing cover1 counterclock-
wise and remove it.

Turn bulb holder4 with the bulb coun-
terclockwise and remove it.

Pull the bulb at its socket out of bulb
holder4.

Insert the new bulb so that its socket
locates in the recess of bulb holder4
and is level to it.

Reinsert bulb holder4 with the bulb in
the lamp and turn clockwise.

Align housing cover1 and turn it
clockwise.
High beam bulb

Turn housing cover2 counterclock-
wise and remove it.

Turn bulb holder5 with the bulb coun-
terclockwise and remove it.

Pull the bulb at its socket out of bulb
holder5.

Insert the new bulb so that its socket
locates in the recess of bulb holder5
and is level to it.

Reinsert bulb holder5 with the bulb in
the lamp and turn clockwise.

Align housing cover2 and turn it
clockwise.

415 Practical hints
Replacing bulbs
Front turn signal lamp bulb
Turn bulb socket3 counterclockwise
and remove it.

Press gently onto the bulb and turn
counterclockwise out of bulb
socket3.

Press the new bulb gently into bulb
socket3 and turn clockwise until it
engages.

Place bulb socket3 back into the
lamp and turn it clockwise.
Parking and standing lamp bulb

Turn housing cover2 counterclock-
wise and remove it.

Pull out bulb socket6 with the bulb.

Pull the bulb out of the bulb socket6.

Press the new bulb into bulb socket6.

Press bulb socket6 back into the
lamp.

Align housing cover2 and turn it
clockwise.Front lamps Bi-Xenon*-type
1Bulb socket for turn signal lamp
2Housing cover for high beam flasher,
parking and standing lamp
3Housing cover for Bi-Xenon* headlamp4Bulb holder for high beam flasher bulb
5Bulb socket for parking and standing
lamp bulb
Warning!
G
Do not remove the cover 3 for the Bi-Xe-
non* headlamp. Because of high voltage in
Xenon lamps, it is dangerous to replace the
bulb or repair the lamp and its components.
We recommend that you have such work
done by a qualified technician.
