2006 MERCEDES-BENZ CLK COUPE washer fluid

ContentsDriving systems ................................. 254
Cruise control............................... 254
Parktronic system
(Parking assist)*, Canada only ..... 258
Loading .............................................. 262
Roof rack ...................................... 262
Ski sack* (Canada only) ............... 263
Split rear bench seat .................... 265
Loading instructions ..................... 267
Cargo tie-down rings .................... 268
Useful features .................................. 269
Storage compartments................. 269
Center armrest ............................. 271
Armrest in the
rear passenger compartment ....... 272
Cup holders .................................. 273
Ashtrays ....................................... 274
Cigarette lighter ........................... 276
Power outlet in the
rear passenger compartment ....... 277
Floormats* ................................... 277
Telephone*................................... 278
Tele Aid ........................................ 279
Garage door opener* ................... 287
Operation......................................... 293
The first 1 000 miles (1 500 km)......... 294
Driving instructions............................ 295
Drive sensibly – save fuel ............. 295
Drinking and driving ..................... 295
Pedals .......................................... 295
Power assistance ......................... 295
Brakes .......................................... 296
Driving off .................................... 297
Parking ......................................... 297
Tires ............................................. 298
Hydroplaning ................................ 299
Tire traction.................................. 299
Tire speed rating .......................... 300
Winter driving instructions ........... 300
Standing water ............................. 301
Passenger compartment .............. 302
Driving abroad.............................. 302
Control and operation
of radio transmitters .................... 302
Catalytic converter ....................... 303
Emission control .......................... 303
Coolant temperature .................... 304At the gas station .............................. 305
Refueling ...................................... 305
Check regularly
and before a long trip................... 307
Engine compartment ......................... 308
Hood ............................................ 308
Engine oil ..................................... 309
Transmission fluid level................ 313
Coolant ........................................ 314
Battery ......................................... 315
Windshield washer system and
headlamp cleaning system*......... 316
Tires and wheels................................ 317
Important guidelines .................... 317
Tire care and maintenance........... 318
Direction of rotation..................... 320
Loading the vehicle ...................... 320
Recommended
tire inflation pressure ................... 326
Checking tire inflation pressure ... 328
MOExtended system* .................. 332
Tire labeling ................................. 332
Load identification ....................... 336
DOT, Tire Identification Number
(TIN) ............................................. 337
Maximum tire load ....................... 338

ContentsTowing the vehicle ............................. 432
Towing the vehicle........................ 432
Installing towing eye bolt.............. 434
Fuses ................................................. 436
Aids for replacing fuses ................ 436
Main fuse box in passenger
compartment................................ 437
Fuse box in engine compartment . 437
Fuse box in trunk.......................... 438
Technical data................................. 439
Parts service ...................................... 440
Warranty coverage............................. 441
Loss of Service and Warranty
Information Booklet ..................... 441
Identification labels ........................... 442
Layout of poly-V-belt drive ................. 443
CLK 350 ....................................... 443
CLK 500 ....................................... 443
Engine................................................ 444
Rims and tires.................................... 445
Same size tires ............................. 447
Mixed size tires ............................ 448
Minispare wheel ........................... 449
Electrical system ............................... 450
Main dimensions and weights............ 451
Main dimensions .......................... 451
Weights ........................................ 451Fuels, coolants, lubricants, etc. ......... 452
Capacities .................................... 452
Engine oils ................................... 454
Engine oil additives ...................... 454
Air conditioning refrigerant .......... 454
Brake fluid.................................... 454
Premium unleaded gasoline ......... 455
Fuel requirements ........................ 455
Gasoline additives ........................ 456
Coolants ...................................... 457
Windshield washer system and
headlamp cleaning system*......... 459
Technical terms............................... 461Index................................................. 467

53 Getting started
Driving

Push combination switch in the direc-
tion of arrow1.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 24).
Turn signals
The combination switch is located on the
left of the steering column.Combination switch1Turn signals, right
2Turn signals, left

Press combination switch in the direc-
tion of arrow1or2.
The corresponding turn signal indicator
lampLorK in the instrument
cluster flashes (
page 24).
The combination switch resets automati-
cally after major steering wheel move-
ments.
Windshield wipers
The combination switch is located on the
left of the steering column.Combination switch1Single wipe
Wiping with windshield washer fluid
2Switching on windshield wipers
Switch on the ignition (
page 34).
iTo signal minor directional changes
such as changing lanes, press combi-
nation switch only to the point of resis-
tance and release. The corresponding
turn signals will flash three times.

54 Getting startedDrivingSwitching on windshield wipers
Turn the combination switch to the de-
sired position depending on the
intensity of the rain.
0Windshield wipers off
IIntermittent wiping
IINormal wiper speed
IIIFast wiper speedIntermittent wiping
Intermittent wiping interval is dependent
on wetness of windshield.

Turn the combination switch to
positionI.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
!Do not operate the windshield wipers
when the windshield is dry. Dust that
accumulates on a windshield might
scratch the glass and/or damage the
wiper blades when wiping occurs on a
dry windshield. If it is necessary to op-
erate the windshield wipers in dry
weather conditions, always operate the
windshield wipers with windshield
washer fluid (
page 55).
!Do not leave windshield wipers in
intermittent setting when the vehicle is
taken to an automatic car wash or
during windshield cleaning. Windshield
wipers will operate in the presence of
water sprayed on the windshield, and
windshield wipers may be damaged as
a result.!If you have set intermittent wiping, dirt
on the surface of the rain sensor or op-
tical effects may cause the windshield
wipers to wipe in an undesired fashion.
This could then damage the windshield
wiper blades or scratch the windows.
You should therefore switch off the
windshield wipers when weather condi-
tions are dry.
iIntermittent wiping is interrupted when
the vehicle is at a standstill and a door
is opened. This protects persons get-
ting into or out of the vehicle from be-
ing sprayed.
Intermittent wiping will be continued
when

all doors are closed
and


the gear selector lever is in position
D or R
or


the wiper setting is changed using
the combination switch.

55 Getting started
Driving
Single wipe
Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.
Wiping with windshield washer fluid

Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system*”
(
page 316).iTo prevent smears on the windshield,
wipe with windshield washer fluid every
now and then even when it is raining.
!If anything blocks the windshield
wipers (leaves, snow, etc.), switch
them off immediately.

For safety reasons, stop the vehicle
in a safe location and,

remove SmartKey from starter
switch
or


turn off the engine by pressing
the KEYLESS-GO* start/stop
button and open the driver’s
door (with the driver’s door
open, starter switch is in posi-
tion 0, same as with SmartKey
removed from starter switch)
before attempting to remove any
blockage.


Remove blockage.


Turn the windshield wipers on
again.
If windshield wipers fail to function at
all in combination switch positionI,


set the combination switch to the
next higher wiper speed


have the windshield wipers
checked at the nearest authorized
Mercedes-Benz Center.

180 Controls in detailGood visibilityFor information on the windshield wipers,
see “Windshield wipers” (
page 53).
Headlamp cleaning system*
The button is located on the left side of the
dashboard.
1Headlamp washer button
Switch on the ignition (
page 36).

Press button1.
The headlamps are cleaned with a
high-pressure water jet.For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system*”
(
page 459).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 43).
Interior rear view mirror, antiglare
position
1Lever

Tilt the mirror to the antiglare position
by moving lever1 towards the wind-
shield.
The interior rear view mirror is dimmed.
iThe headlamps will automatically be
cleaned when you have

switched on the headlamps
and


operated the windshield wipers
with windshield washer fluid fifteen
times
When you switch off ignition, the
counter resets.

307 Operation
At the gas station
Check regularly and before a long tripEngine compartment (CLK 500, example)1Coolant level
2Brake fluid (fuse box cover removed)
3Windshield washer and headlamp
cleaning system*Coolant
For normal replenishing, use water (pota-
ble water quality). For more information,
see “Coolant” (
page 314) and see “Fu-
els, coolants, lubricants, etc.”
(
page 452).
Brake fluid
Removing fuse box cover,
see (page 437).Windshield washer and headlamp
cleaning system*
For more information on filling up the
washer reservoir, see “Windshield washer
system and headlamp cleaning system*”
(
page 316).
Engine oil level
For more information on engine oil, see
“Engine oil” (
page 309).
Vehicle lighting
Check function and cleanliness. For more
information on replacing light bulbs, see
“Replacing bulbs” (
page 412).
For more information, see “Exterior lamp
switch” (
page 52).
Tire inflation pressure
For more information, see “Checking tire
inflation pressure” (
page 328).
iOpening the hood, see (
page 308).
!If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately.
Notify an authorized Mercedes-Benz
Center immediately. Do not add brake
fluid as this will not solve the problem.
For more information, see also “Practi-
cal hints” (
page 361).

316 OperationEngine compartmentWindshield washer system and headlamp cleaning system*
The windshield washer reservoir is located
in the engine compartment.
1Washer fluid reservoir cap
Fluid for the windshield washer system and
the headlamp cleaning system* is supplied
from the windshield washer reservoir. It
has a capacity of approx. 6.4 US qt (6 l).
During all seasons, add MB Windshield
Washer Concentrate “MB SummerFit” to
water. Premix the windshield washer fluid
in a suitable container.

Refill the reservoir with MB Windshield
Washer Concentrate “MB SummerFit”
and water (or commercially available
premixed windshield washer
solvent / antifreeze, depending on am-
bient temperatures).
Always use washer solvent/antifreeze
where temperatures may fall below the
freezing point. Failure to do so could
result in damage to the washer
system/reservoir.For more information, see “Windshield
washer system and headlamp cleaning
system*” (
page 459).
Warning!
G
Washer solvent/antifreeze is highly flam-
mable. Do not spill washer
solvent/antifreeze on hot engine parts,
because it may ignite and burn. You could be
seriously burned.
!Only use washer fluid which is suitable
for plastic lenses. Improper washer
fluid can damage the plastic lenses of
the headlamps.
