2006 MERCEDES-BENZ CLK COUPE Owner's Manual

264 Controls in detailLoading6Strap
Tighten strap6 by pulling at the loose
end (arrow) until the skis in the ski sack
are tightly secured.7Hook
8Eye

Connect hook7 to eye8 located on
center tunnel in front of rear seat
bench.

Tighten strap by pulling at the loose
end (arrow).Unloading and folding

Loosen both straps.

Disconnect hook7 from eye8.

Unload skis.

Close flap in trunk.

Fold and flatten ski sack lengthwise.

Place folded ski sack inside recess of
backrest.

Fasten hook and loop fastener.

Close ski sack compartment cover.


265 Controls in detail
Loading
Removing the ski sack
You can remove the ski sack for cleaning
or drying.
1Button
2Ski sack frame
3Flap
Open trunk lid.

Press button1.
The flap3 opens downward.

Press button1 firmly until ski sack
frame2 is released.

Pull ski sack frame2 with ski sack
out.Installing the ski sack
Install the ski sack in the reverse order.

Push ski sack frame2 with ski sack
inward until the ski sack frame snaps
into place.

Close flap3.

Close trunk lid.
Split rear bench seat
To expand the cargo area, you can fold
down the left and right rear seat backrests.
The two sections can be folded down
separately.
Warning!
G
Never drive vehicle with trunk open while
the ski sack is removed. Deadly carbon
monoxide (CO) gases may enter vehicle in-
terior, resulting in unconsciousness and
death.iTo prevent unauthorized persons from
access to the trunk, always close the
flap.
Warning!
G
When expanding the luggage compartment,
always fold the seat cushions fully forward.
Unless you are transporting cargo, the back-
rests must remain properly locked in the up-
right position.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.
Always use the cargo tie down rings
(page 268).

266 Controls in detailLoadingFolding the backrest forward
The release handle1 is located in the
trunk.
Pull release handle1.

Fully retract and fold rearward head re-
straint (
page 123).

Pull release handle2.

Fold seat cushion3 forward.

Fold rear seat backrests4 forward.!Always release the seat cushion and
fold it forward before folding the corre-
sponding seat backrest forward. The
covering on the seat backrest may oth-
erwise be damaged.

267 Controls in detail
Loading
Setting up rear seat bench
Fold backrest4 rearward until it en-
gages.

Fold seat cushions3 rearward until it
locks into position.
If a backrest is not locked into position,
ared indicator5 or6 will be visible.

Check for secure locking by pushing
and pulling on the backrest.
Loading instructions
The total load weight including vehicle oc-
cupants and luggage/cargo should not ex-
ceed the load limit or vehicle capacity
weight indicated on the corresponding
placard located on the driver’s door B-pillar
(page 320).
Warning!
G
If a red indicator is visible with the backrest
up, then the backrest is not properly locked
into position.
Always lock backrest in its upright position
when rear seat bench is occupied, or the ex-
tended trunk compartment is not in use.
Check for secure locking by pushing and
pulling on the backrest.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo.iTo prevent unauthorized persons from
access to the trunk, always lock back-
rest in its upright position.

268 Controls in detailLoadingThe handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.
Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible.
The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.
Cargo tie-down rings
The four cargo tie-down rings are located
in the trunk.Cargo tie-down rings
Carefully secure cargo by applying
even load on all rings with rope of
sufficient strength to hold down the
cargo.
Always follow loading instructions
(page 267).
Warning!
G
Always fasten items being carried as secure-
ly as possible using cargo tie-down rings and
fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.iThe trunk is the preferred place to carry
objects.
The enlarged cargo area should only be
used for items which do not fit in the
trunk alone.

269 Controls in detail
Useful features
Useful features
Storage compartments Glove box
1Glove box lid
2Glove box lid release
Opening the glove box

Pull glove box lid release2.
The glove box lid1 opens downward.
Closing the glove box

Push glove box lid1 up to close.Storage box (Center armrest design A)
The storage box is in front of the armrest
storage compartment.
1Storage box
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs.
Parcel nets cannot secure hard or heavy ob-
jects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.
iAudio system/COMAND* with CD
changer*: The CD changer is located in
the glove box.
Warning!
G
Do not use this storage compartment as an
ashtray and/or place hot cigarettes or other
hot smoking materials in the storage box.
Placing such materials in the storage box
may cause vehicle damage and/or poten-
tially cause a vehicle fire.

270 Controls in detailUseful featuresOpening storage box
Pull storage box1 in the direction of
arrow.
Closing storage box

Press storage box1 back until it
engages into place.
Ruffled storage bags
Storage bags are located on the rear side
of the front seats.Parcel net in front passenger footwellA small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.
Warning!
G
The ruffled storage bag is intended for stor-
ing light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
ruffled storage bag. In an accident, during
hard braking, or sudden maneuvers, they
could be thrown around inside the vehicle
and cause injury to vehicle occupants.
The ruffled storage bag cannot protect
transported goods in the event of an
accident.
Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard brak-
ing, or sudden maneuvers, they could be
thrown around inside the vehicle and cause
injury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.

271 Controls in detail
Useful features
Center armrest
Depending on vehicle production date,
your vehicle is equipped with either arm-
rest design A or B.
Armrest design A
1Handle
2Button (passenger side)
3Button (driver side)
4Compartment lock (lock position)
5Compartment lock (unlock position)Opening storage compartment

Pull handle1 and lift armrest.
Closing storage compartment

Press armrest down until it engages
into place.
Opening telephone compartment

Press button3 on driver’s side or
button2 on passenger side and lift
armrest.Closing telephone compartment

Press armrest down until it engages
into place.
Locking compartment

Remove the mechanical key from the
SmartKey (
page 404).

Turn the compartment lock to
position5.
Unlocking compartment

Turn the compartment lock to
position4.

Insert the mechanical key in the
SmartKey.
iThe Roadside Assistance button •
and the Information button¡ are
located in the telephone compartment.
