2006 MERCEDES-BENZ CLK COUPE Owner's Manual

160 Controls in detailControl systemLighting submenu
Access the
Lighting
submenu via the
Set-
tings
menu. Use the
Lighting
submenu
to change the lamp and lighting settings on
your vehicle.
The following functions are available:Setting daytime running lamp mode
(USA only)

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until the message
Lamp circuit
headlamp
appears in the multifunction
display.The selection marker is on the current
setting.

Press buttonæ orç to select
manual operation (
manual
) or daytime
running lamp mode (
constant
) activat-
ed.
With daytime running lamp mode activated
and the exterior lamp switch in
positionM or U the low beam
headlamps are switched on when the
engine is running.
In low ambient light conditions the
following lamps will switch on additionally:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps
Function
Page
Setting daytime running lamp
mode (USA only)
160
Setting locator lighting
161
Exterior lamps delayed
switch-off
162
Interior lighting delayed
switch-off
163
iThis function is not available in
countries where the daytime running
lamp mode is mandatory and therefore
in a constant mode.

161 Controls in detail
Control system
For more information on the daytime run-
ning lamp mode, see “Lighting”
(page 131).Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on during darkness when the vehi-
cle is unlocked with the SmartKey:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.
To activate locator lighting:

Make sure the function surround light-
ing is set to
on, see (
page 161).

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Function Surround
lighting
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the locator lighting function
on.

Turn the exterior lamp switch to
position U when exiting the vehicle
(page 131).
The locator lighting feature is
activated.
iIf you turn the exterior lamp switch to
another position, the corresponding
lamp(s) will switch on.
For safety reasons, resetting the Lighting
submenu to factory settings
(
page 153) while driving will not
deactivate the daytime running lamp
mode.
The following message appears in the
multifunction display:
Lighting – Cannot be completely
reset to factory settings while
driving
.

162 Controls in detailControl systemSetting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether you would
like the exterior lamps to illuminate during
darkness after exiting the vehicle and all
doors closed.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on
for 15 seconds when the engine is turned
off:

Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Headlamps delayed
shut-off
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the headlamps delayed shut-off feature on or
off
.

Turn the exterior lamp switch to
position U before turning off the
engine (
page 131).
The headlamps delayed shut-off
feature is activated.
You can temporarily deactivate the de-
layed shut-off feature:

Before leaving the vehicle, turn the
SmartKey in the starter switch to
position0.

Then turn it to position2 and back
to0.
The delayed shut-off feature is
deactivated. It will reactivate as soon
as you reinsert the SmartKey in the
starter switch.
iYou can reactivate this function within
ten minutes by opening a door.

163 Controls in detail
Control system
Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain lit during
darkness after you have removed the
SmartKey from the starter switch. If acti-
vated it remains lit for 10 seconds.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Interior lamp de-
layed shut-off appears in the
multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the interior delayed shut-off feature
on
or
off
.Vehicle submenu
Access the
Vehicle
submenu via the
Settings
menu. Use the
Vehicle
submenu
to make general vehicle settings.
The following functions are available:
Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked at
vehicle speeds of approximately 9 mph
(15 km/h).

Move the selection marker with
buttonæ orç to the
Vehicle

submenu.

Press buttonj ork repeatedly
until the message
Automatic door
lock
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the automatic central locking
on or
off
.
Function
Page
Setting automatic locking
163

164 Controls in detailControl systemConvenience submenu
Access the
Convenience
submenu via the
Settings
menu. Use the
Convenience
sub-
menu to change the settings for a number
of convenience features.
The following functions are available:
Activating easy-entry/exit feature
Use this function to activate and deacti-
vate the easy-entry/exit feature
(
page 42).

Move the selection marker with
buttonæ orç to the

Convenience
submenu.

Press buttonj ork repeatedly
until the message Function Easy-entry feature

appears in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the easy-entry/exit feature
on or
off
.
Setting parking position for exterior rear
view mirror
Use the
Mirror adjustment parking aid

function to select whether the passen-
ger-side exterior rear view mirror should be
turned downward during parking maneu-
vers, when reverse gearR is engaged. For
additional information, see “Activating ex-
terior rear view mirror parking position”
(
page 182).
Function
Page
Activating easy-entry/exit
feature
164
Setting parking position for exte-
rior rear view mirror
164
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To cancel steering wheel movement, do one
of the following:

Move the steering column stalk
(page 41).


Press the memory position switch
(page 128).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

165 Controls in detail
Control system

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Mirror adjustment
parking aid
appears in the multifunc-
tion display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
function
on or
off
.
Trip computer menu
Use the trip computer menu to call up sta-
tistical data on your vehicle.
The following information is available:
Fuel consumption statistics after start
Press buttonÿ orè repeatedly
until the first function of the trip com-
puter menu appears in the multifunc-
tion display.

Press buttonj ork repeatedly
until the message
After start
appears
in the multifunction display.1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since start
Function
Page
Fuel consumption statistics after
start
165
Fuel consumption statistics
since last reset
166
Call up range (distance to empty)
166
iAll statistics stored since the last
engine start will be reset approximately
four hours after the SmartKey in the
starter switch is turned to position0 or
removed from the starter switch.
Resetting will not occur if you turn the
SmartKey back to position1 or2
within this time period.

166 Controls in detailControl systemFuel consumption since last reset
Press buttonÿ orè repeatedly
until the first function of the trip com-
puter menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
After reset
appears
in the multifunction display.
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last re-
setResetting fuel consumption statistics

Press buttonÿ orè repeatedly
until the first function of the trip com-
puter menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the reading that you want to reset
appears in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 140) until
the value is reset to 0.Distance to empty

Switch on the ignition (
page 36).

Press buttonÿ orè repeatedly
until the first function of the trip com-
puter menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
Range
appears in the
multifunction display.
The calculated range based on the
current fuel tank level appears in the
multifunction display.

167 Controls in detail
Control system
TEL menu*
You can use the functions in the
TEL
menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.

Switch on the telephone and Audio or
COMAND*.

Press buttonÿ orè on the
steering wheel repeatedly until the
message
TEL
appears in the
multifunction display.Which messages will appear in the
multifunction display depends on whether
your telephone is switched on or off:


If the telephone is off, the message TEL OFF
appears in the multifunction
display.


If the telephone is on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network, the message
READY
appears in
the multifunction display.
This standby message indicates that your
telephone is ready for use and you can
operate it using the control system.
Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we
recommend that you pull over to a safe
location and stop before placing or taking a
telephone call. If you choose to use the
telephone while driving, please use the
hands-free device and only use the tele-
phone when weather, road and traffic
conditions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a
vehicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system,
possibly resulting in an accident and /or
personal injury.
