ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)14 −11 5
AVENSIS Supplement (RM1045E)
70. REMOVE V −RIBBED BELT TENSIONER ASSY
(a) Remove the 3 bolts and V −ribbed belt tensioner.
71. REMOVE V −RIBBED BELT TENSIONER BRACKET
(a) Remove the bolt and V −ribbed belt tensioner bracket.
72. REMOVE OIL FILTER BRACKET SUB −ASSY
(a) Remove the bolt and 2 nuts, then remove the oil filter
bracket and gasket.
73. REMOVE TURBO INSULATOR NO.2 (See page 13 −12)
74. REMOVE TURBO INSULATOR NO.1 (See page 13 −12)
75. REMOVE EXHAUST MANIFOLD HEAT INSULATOR NO.2 (See page 13 −12)
76. REMOVE EGR PIPE INSULATOR (See page 13 −12)
77. REMOVE EXHAUST GAS TEMPERATURE SENSOR
(a) Remove the 2 nuts, then detach the wire harness from the clamp.
(b) Disconnect the connector.

A85634
SST
A85623
A85914
SST
A85915
A85916
SST
14−11 6− ENGINE MECHANICALPARTIAL ENGINE ASSY (1CD−FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
(c) Using SST, remove the exhaust gas temperature sensor
on up stream.
SST 09023−38400
(d) Remove the 3 nuts, then detach the wire harness from the
clamp.
(e) Disconnect the connector.
(f) Using SST, remove the exhaust gas temperature sensor
on down stream.
SST 09023−38400
78. REMOVE VACUUM TRANSMITTING PIPE SUB−ASSY
NO.1
(a) Remove the bolt.
(b) Using SST, remove the vacuum pipe.
SST 09023−38200

A84380
A84378
14−122−
ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
116. REMOVE FUEL FILTER TO INJECTION PUMP FUEL PIPE
(a) Remove the 3 bolts and fuel pipe.
117. REMOVE CRANKSHAFT POSITION SENSOR
(a) Remove the bolt and crankshaft position sensor.
118. REMOVE CAMSHAFT POSITION SENSOR
(a) Remove the bolt and camshaft position sensor. 119. REM O VE ENG I NE CO O L ANT TEM PERAT URESENSOR
120. REPLACE PARTIAL ENGINE ASSY
121. INSTALL ENGINE COOLANT TEMPERATURE SENSOR Torque: 20 N
m (200 kgf
cm, 14 ft
lbf)
122. INSTALL CAMSHAFT POSITION SENSOR Torque: 8.8 N
m (90 kgf
cm, 78 in.
lbf)
123. INSTALL CRANKSHAFT POSITION SENSOR Torque: 8.8 N
m (90 kgf
cm, 78 in.
lbf)
124. INSTALL FUEL FILTER TO INJECTION PUMP FUEL PIPE
Torque:
8.8 N
m (90 kgf
cm, 78 in.
lbf) for M6
21 N
m (209 kgf
cm, 15 ft
lbf) for M8
125. INSTALL OIL COOLER PIPE
(a) Using a socket wrench for 27 mm, install 2 new gaskets and the oil cooler pipe with the union bolt. Torque: 56 N
m (575 kgf
cm, 42 ft
lbf)
126. INSTALL THERMOSTAT (See Pub. No. RM1018E on page 16 −50)
127. INSTALL WATER INLET (See Pub. No. RM1018E on page 16 −50)
128. INSTALL COMPRESSOR MOUNTING BRACKET NO.1 (W/ AIR CONDITIONING)
Torque: 42 N
m (428 kgf
cm, 31 ft
lbf)
129. INSTALL INJECTION OR SUPPLY PUMP ASSY (See page 11 −58)
130. INSTALL INJECTION PUMP STAY NO.1 (See page 11 −58)
131. INSTALL OIL LEVEL GAGE GUIDE (See page 17 −11 )
132. INSTALL TIMING BELT NO.3 COVER Torque: 7.4 N
m (75 kgf
cm, 65 in.
lbf)

A85921
5mm
(0.20 in.)
A85914
SST
A8592215 mm (0.59 in.)
A87961
SST
14−128−
ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
159. INSTALL EXHAUST GAS TEMPERATURE SENSOR
(a) Temporarily install the 3 nuts and exhaust gas tempera- ture sensor on down stream as shown in the illustration.
NOTICE:
Keep 5 mm (0.20 in.) of the clearance between the exhaust
gas temperature sensor and vacuum transmitting pipe.
(b) Using SST, tighten the sensor on the manifold converter
side.
SST 09023 −38400
Torque:
27 N
m (275 kgf
cm, 20 ft
lbf) with SST
30 N
m (306 kgf
cm, 22 ft
lbf) without SST
HINT:
Use a torque wrench with the fulcrum length of 30 cm (11.81 in.).
(c) Tighten the 3 nuts.
Torque: 6.4 N
m (65 kgf
cm, 57 in.
lbf)
(d) Temporarily install the 2 nuts and exhaust gas tempera- ture sensor on up stream as shown in the illustration.
NOTICE:
Keep 15 mm (0.59 in.) of the clearance between the exhaust
gas temperature sensor and vacuum transmitting pipe.
(e) Using SST, tighten the sensor on the manifold converter side.
SST 09023 −38400
Torque:
27 N
m (275 kgf
cm, 20 ft
lbf) with SST
30 N
m (306 kgf
cm, 22 ft
lbf) without SST
HINT:
Use a torque wrench with the fulcrum length of 30 cm (11.81 in.).
(f) Tighten the 2 nuts.
Torque: 6.4 N
m (65 kgf
cm, 57 in.
lbf)
160. INSTALL EGR PIPE INSULATOR (See page 13 −12)
161. INSTALL EXHAUST MANIFOLD HEAT INSULATOR NO.2 (See page 13 −12)
162. INSTALL TURBO INSULATOR NO.1 (See page 13 −12)
163. INSTALL TURBO INSULATOR NO.2 (See page 13 −12)
164. INSTALL OIL FILTER BRACKET SUB −ASSY
(a) Install a new gasket and the oil filter bracket with the bolt and 2 nuts.
Torque: 34 N
m (347 kgf
cm, 25 ft
lbf)
165. INSTALL V −RIBBED BELT TENSIONER BRACKET
Torque: 20 N
m (204 kgf
cm, 15 ft
lbf)

A87967
Upward90_
Clamp
Bolt
Turbocharger Side:
Air Hose No. 2 Side:
Front 90
_ Clamp Bolt
20.4_
14
−134
−
ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
(b) Tighten the 2 hose clamps as shown in the illustration. Torque: 6.0 N
m (61 kgf
cm, 53 in.
lbf)
(c) Install the air tube No. 1 with the 3 bolts and nut. Torque: 25 N
m (255 kgf
cm, 18 ft
lbf)
208. INSTALL DIFFERENTIAL PRESSURE SENSOR ASSY Torque: 5.5 N
m (56 kgf
cm, 49 in.
lbf)
209. INSTALL RADIATOR ASSY (W/ AIR CONDITIONING) (See Pub. No. RM1018E on page 16 −51)
210. INSTALL ENGINE ROOM RELAY BLOCK NO.3
Torque: 5.3 N
m (54 kgf
cm, 47 in.
lbf)
211. INSTALL FUEL FILTER ASSY (See Pub. No. RM1018E on page 11 −82)
212. INSTALL AIR CLEANER ASSY Torque: 7.0 N
m (71 kgf
cm, 62 in.
lbf)
213. INSTALL BATTERY Torque:
5.0 N
m (51 kgf
cm, 44 in.
lbf) for bolt
3.0 to 4.0 N
m (31 to 41 kgf
cm, 27 to 35 in.
lbf) for nut
5.4 N
m (55 kgf
cm, 48 in.
lbf) for terminal
214. INSTALL ENGINE COVER SUB −ASSY NO.1
Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
215. BLEED CLUTCH PIPE LINE (See Pub. No. RM1018E on page 42 −12)
216. INSTALL FRONT WHEELS
Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
217. ADD MANUAL TRANSAXLE OIL (See Pub. No. RM1018E on page 41 −5)
218. ADD ENGINE OIL (See Pub. No. RM1018E on page 17 −30)
219. ADD ENGINE COOLANT (See page 16 −19)
220. CHECK CLUTCH FLUID LEAKAGE
221. CHECK FLUID LEVEL IN RESERVOIR
222. CHECK BRAKE FLUID LEAKAGE
223. CHECK FOR ENGINE OIL LEAKS
224. CHECK FOR FUEL LEAKS (See page 11 −46)
225. CHECK FOR ENGINE COOLANT LEAKS (See page 16 −15)
226. CHECK FOR EXHAUST GAS LEAKS
227. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (See Pub. No. RM1018E on page 26 −6)

−
ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)14 −135
AVENSIS Supplement (RM1045E)
228. INSPECT ENGINE IDLE SPEED (See page 14 −87)
229. CHECK ABS SPEED SENSOR SIGNAL (See Pub. No. RM1018E on page 05 −756)

141NB−01
−
ENGINE MECHANICAL CYLINDER HEAD GASKET (2AZ −FSE)
14 −79
AVENSIS Supplement (RM1045E)
REPLACEMENT
1. DISCHARGE FUEL SYSTEM PRESSURE (See page 11 −4)
2. REMOVE FRONT WHEEL RH
3. REMOVE RADIATOR SUPPORT OPENING COVER (See page 14 −23)
4. REMOVE ENGINE ROOM COVER SIDE (See page 14 −23)
5. REMOVE ENGINE UNDER COVER LH (See page 14 −23)
6. REMOVE ENGINE UNDER COVER NO.4 RH (See page 14 −23)
7. REMOVE ENGINE UNDER COVER RH (See page 14 −23)
8. DRAIN COOLANT (See page 16 −7)
9. DRAIN ENGINE OIL (See page 17 −6)
10. REMOVE ENGINE COVER SUB −ASSY NO.1 (See page 14 −45)
11. REMOVE FUEL PRESSURE PULSATION DAMPER ASSY
12. SEPARATE FUEL TUBE SUB −ASSY (See page 11 −4)
13. REMOVE FUEL PIPE SUB −ASSY NO.1 (See page 11 −24)
SST 09023 −12900
14. REMOVE FUEL PUMP ASSY (See page 11 −24)
15. REMOVE FAN AND GENERATOR V BELT (See page 14 −5)
SST 09249 −63010
16. REMOVE GENERATOR ASSY (See page 19 −8)
17. REMOVE EXHAUST PIPE ASSY FRONT (See page 15 −2)
18. SEPARATE VANE PUMP ASSY (See page 14 −45)
19. REMOVE IGNITION COIL ASSY (See page 14 −45)
20. SEPARATE RETURN TUBE SUB −ASSY (See page 14 −45)
21. SEPARATE COOLER REFRIGERANT SUCTION HOSE NO.1 (LHD STEERING POSITION TYPE) (See page 14 −45)
22. REMOVE VANE PUMP OIL RESERVOIR ASSY (See page 14 −45)
23. REMOVE OIL RESERVOIR BRACKET NO.1 (See page 14 −45)
24. SEPARATE ENGINE WIRE (See page 14 −23)
25. REMOVE COOLER BRACKET (LHD STEERING POSITION TYPE) (See page 14 −45)
26. REMOVE ENGINE SERVICE COVER BRACKET RH (RHD STEERING POSITION TYPE)
(See page 14 −45)
27. REMOVE CYLINDER HEAD COVER SUB −ASSY (See page 14 −45)
28. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −45)
29. REMOVE ENGINE MOUNTING BRACKET NO.2 RH (See page 14 −45)
30. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING INSULATOR (See page 14 −45)
31. REMOVE CRANKSHAFT PULLEY (See page 14 −45)
SST 09213 −54015 (91651 −60855), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05021)
32. REMOVE CHAIN TENSIONER ASSY NO.1 (See page 14 −45)
33. REMOVE CRANKSHAFT POSITION SENSOR (See page 14 −45)
34. REMOVE OIL PAN SUB −ASSY (See page 14 −45)
SST 09032 −00100
35. REMOVE V −RIBBED BELT TENSIONER ASSY (See page 14 −45)
36. REMOVE TIMING CHAIN OR BELT COVER SUB −ASSY (See page 14 −45)
37. REMOVE CRANKSHAFT POSITION SENSOR PLATE NO.1 (See page 14 −45)
38. REMOVE CHAIN TENSIONER SLIPPER (See page 14 −45)
39. REMOVE CHAIN VIBRATION DAMPER NO.1 (See page 14 −45)
40. REMOVE TIMING CHAIN GUIDE (See page 14 −45)
41. REMOVE CHAIN SUB −ASSY (See page 14 −45)

A83481
−
ENGINE MECHANICAL CYLINDER HEAD GASKET (2AZ −FSE)
14 −83
AVENSIS Supplement (RM1045E)
(i) Install the water by −pass pipe with a bolt.
Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
64. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSY
65. INSTALL CAMSHAFT (See page 14 −64)
66. INSTALL NO.2 CAMSHAFT (See page 14 −64)
67. INSTALL EXHAUST MANIFOLD CONVERTER SUB −ASSY (See page 14 −23)
68. INSTALL EXHAUST MANIFOLD HEAT INSULATOR NO.1 (See page 14 −23)
69. INSTALL INTAKE MANIFOLD (See page 11 −13)
70. INSTALL THROTTLE BODY ASSY (See page 10 −8)
71. INSTALL AIR CLEANER ASSEMBLY WITH HOSE (See page 14 −23)
72. INSTALL BATTERY
Torque:
5.0 N
m (51 kgf
cm, 44 in.
lbf) for Bolt
3.5 N
m (36 kgf
cm, 31 in.
lbf) for Nut
73. INSTALL CHAIN VIBRATION DAMPER NO.1 (See page 14 −45)
74. INSTALL CHAIN SUB −ASSY (See page 14 −45)
75. INSTALL TIMING CHAIN GUIDE (See page 14 −45)
76. INSTALL CHAIN TENSIONER SLIPPER (See page 14 −45)
77. INSTALL CRANKSHAFT POSITION SENSOR PLATE NO.1 (See page 14 −45)
78. INSTALL TIMING CHAIN OR BELT COVER SUB −ASSY (See page 14 −45)
79. INSTALL V −RIBBED BELT TENSIONER ASSY (See page 14 −45)
80. INSTALL OIL PAN SUB −ASSY (See page 14 −45)
81. INSTALL CRANKSHAFT POSITION SENSOR (See page 14 −45)
82. INSTALL CRANKSHAFT PULLEY (See page 14 −45)
SST 09213 −54015 (91651 −60855), 09330 −00021
83. INSTALL CHAIN TENSIONER ASSY NO.1 (See page 14 −45)
84. INSTALL TRANSVERSE ENGINE ENGINE MOUNTING INSULATOR
Torque: 52 N
m (530 kgf
cm, 38 ft
lbf)
85. INSTALL ENGINE MOUNTING BRACKET NO.2 RH (See page 14 −45)
86. INSTALL CYLINDER HEAD COVER SUB −ASSY (See page 14 −45)
87. INSTALL COOLER BRACKET (LHD STEERING POSITION TYPE)
Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
88. INSTALL ENGINE SERVICE COVER BRACKET RH (RHD STEERING POSITION TYPE) Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
89. INSTALL OIL RESERVOIR BRACKET NO.1 Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
90. INSTALL COOLER REFRIGERANT SUCTION HOSE NO.1 (LHD STEERING POSITION TYPE)
91. INSTALL RETURN TUBE SUB −ASSY
Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
92. INSTALL IGNITION COIL ASSY
Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
93. INSTALL FUEL PUMP ASSY (See page 11 −24)
