2005 TOYOTA AVENSIS sensor

A57664
Seal Width
2.2 to 2.5 mm0.5 to 1.0 mm
B12052
B12054
SST
−
COOLING WATER PUMP ASSY (2AZ −FSE)
16 −13
AVENSIS Supplement (RM1045E)
11. INSTALL WATER PUMP ASSY
(a) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contact surfaces of the water
pump assy.
(b) Apply a continuous bead of the seal packing (diameter 2.2 to 2.5 mm (0.09 to 0.10 in.)) as shown in the illustra-
tion.
Seal packing: Part No. 08826 − 00100 or equivalent
NOTICE:
Install the water pump assy within 5 minutes after applying
seal packing. Otherwise the material must be removed and
reapplied.
(c) Install the water pump and wire clamp with 4 bolts and 2 nuts.
Torque: 9.0 N
m (90 kgf
cm, 80 in.
lbf)
(d) Install the crankshaft position sensor wire harness clamp
to the water pump.
(e) I nst all t he cr ankshaf t posit ion s ensor wir e t o t he wir e clamp on the water pump.
12. INSTALL WATER PUMP PULLEY
(a) Using SST, install the pump pulley with 4 bolts. SST 09960 −10010 (09962 −01000, 09963 −00700)
Torque: 26 N
m (265 kgf
cm, 19 ft
lbf)
13. INSTALL GENERATOR ASSY (See page 19 −8)
14. INSTALL FAN AND GENERATOR V BELT (See page 14 −5)
SST 09249 −63010
15. ADD COOLANT (See page 16 −7)
16. CHECK FOR ENGINE COOLANT LEAKS (See page 16 −1)

1509W−02
A85748
30 (302, 22)43 (440, 32)zGasketzGasket
Floor Panel Brace Front Exhaust Pipe Assy Front
Compression Spring
N·m (kgf·cm, ft·lbf)
: Specified torque
zNon−reusable part
43 (440, 32)
Compression Spring
Exhaust Pipe Assy Tail
Air−fuel Ratio Sensor
43 (440, 32)
44 (449, 33)
− EXHAUSTEXHAUST PIPE ASSY (1CD−FTV)(From September,
2003)15−5
AVENSIS Supplement (RM1045E)
EXHAUST PIPE ASSY (1CD−FTV)(From September, 2003)
COMPONENTS

SST
A09582
B07973
Cut PositionPry
SST
A08528
SST
A09583
Angle
SensorInward
14
−178−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
21. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
22. REMOVE TIMING CHAIN COVER PLATE (See page 14 −138)
23. REMOVE TIMING BELT (See page 14 −138)
24. REMOVE CRANKSHAFT TIMING PULLEY
(a) If the timing pulley cannot be removed by hand, use SST to remove the pulley.
SST 09950 − 50013 ( 09951 − 05010, 09952 − 05010,
09953 −05010, 09953 −05020, 09954 −05021)
25. REMOVE CRANKSHAFT SEAL
(a) Using a knife, cut off the oil seal lip.
(b) Using a screwdriver, pry out the oil seal.
NOTICE:
Be careful not to damage the crankshaft. Wrap the tip of the
screwdriver with tape.
26. INSTALL CRANKSHAFT SEAL
(a) Apply multipurpose grease to a new oil seal lip.
NOTICE:
Keep the lip free of foreign objects.
(b) Using SST and a hammer, tap in the oil seal until its sur- face is flush with the oil pump edge.
SST 09316 −60011 (09316 −00011)
27. INSTALL CRANKSHAFT TIMING PULLEY
(a) Align the keyway of the timing pulley with the key located on the crankshaft, then slide the pulley into place.
(b) Using SST and a hammer, tap in the timing pulley with the
angle sensor facing inward.
SST 09223 −46011
28. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
SST 09960 −10010 (09962 −01000, 09963 −01000)
29. INSTALL TIMING BELT (See page 14 −138)
30. CHECK VALVE TIMING (See page 14 −138)

D25834
SST
−
AUTOMATIC TRANSMISSION / TRANS FRONT DIFFERENTIAL OIL SEAL (U151E)
40−25
AVENSIS Supplement (RM1045E)
10. INSTALL DIFFERENTIAL SIDE BEARING RETAINER
OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal. SST 09649 −17010, 09950 −70010 (09951 −07150)
Oil seal drive in depth:
0 á 0.5 mm (0 á 0.020 in.)
(b) Coat the lip of the oil seal with MP grease.
11 . INSTALL FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30 −4)
1 2. INSTALL FRONT DRIVE SHAFT ASSY RH (SEE PAGE 30 −4)
1 3. INSTALL FRONT WHEELS
Torque: 103 N
m( 1,050 kgf
cm, 76 ft
lbf)
1 4. ADD AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE40 −2)
1 5. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE40 −2)
1 6. CHECK ABS SPEED SENSOR SIGNAL
(a) ABS WITH EBD & BA &TRAC & VSC SYSTEM (SEE PUB, NO. RM1018E, PAGE 5 −756)

40188−01
C91925
D30865
AT0103
C91927
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
40−19
AVENSIS Supplement (RM1045E)
TRANSMISSION VALVE BODY ASSY (U151E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER LH
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug.
Torque: 47 N
m (479 kgf
cm, 35 ft
lbf)
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
NOTICE:
Some fluid will remain in the oil pan. Remove all of the oil
pan bolts, and carefully remove the oil pan assembly.
(b) Remove the 2 magnets from the oil pan.
(c) Examine the particles in the oil pan.
(1) Collect any steel chips with the removed magnets.
Look at the chips and particles in the pan and on the
magnets carefully to see the type of wear which
might be found in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. DISCONNECT TRANSMISSION WIRE
(a) Disconnect the 7 shift solenoid valve connectors.
(b) Remove the bolt and lock plate, and disconnect the ATF
temperature sensor.

C91933
A
B
CB
B
B
A
CCC
L
L
C
B
C91932
C91931
C91927
40−22
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
AVENSIS Supplement (RM1045E)
(c) Align the groove of the manual valve with the pin of the
lever.
(d) Install the 17 bolts.
Torque:11N
m(110 kgf
cm, 8 ft
lbf)
NOTICE:
SPush the valve body against the accumulator piston
spring and the check ball body to install it.
SFirst, temporarily tighten those bolts marked byLin
the illustration because they are positioning bolts.
Bolt length:
Bolt A: 25 mm (0.984 in.)
Bolt B: 57 mm (2.244 in.)
Bolt C: 41mm (1.614 in.)
8. INSTALL VALVE BODY OIL STRAINER ASSY
(a) Coat a new O−ring with ATF.
(b) Install the O−ring to the oil strainer.
(c) Install the oil strainer with the 3 bolts.
Torque:11N
m(110 kgf
cm, 8 ft
lbf)
9. INSTALL TRANSMISSION WIRE
(a) Coat an O−ring with ATF.
(b) Install the ATF temperature sensor with the lock plate and
bolt.
Torque: 6.6 N
m (67 kgf
cm, 58 in.
lbf)
(c) Connect the 7 shift solenoid valve connectors.

40187−01
C91925
D30865
AT0103
C91927
40−16
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION WIRE (U151E)
AVENSIS Supplement (RM1045E)
TRANSMISSION WIRE (U151E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER LH
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug.
Torque: 47 N
m (479 kgf
cm, 35 ft
lbf)
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
NOTICE:
Some fluid will remain in the oil pan. Remove all of the oil
pan bolts, and carefully remove the oil pan assembly.
(b) Remove the 2 magnets from the oil pan.
(c) Examine the particles in the oil pan.
(1) Collect any steel chips with the removed magnets.
Look at the chips and particles in the pan and on the
magnets carefully to see the type of wear which
might be found in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. DISCONNECT TRANSMISSION WIRE
(a) Disconnect the 7 shift solenoid valve connectors.
(b) Remove the bolt and lock plate, and disconnect the ATF
temperature sensor.

D30866
D30867
D30866
C91927
D30865
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION WIRE (U151E)
40−17
AVENSIS Supplement (RM1045E)
5. REMOVE TRANSMISSION WIRE
(a) Disconnect the transmission wire connectors.
(b) Remove the bolt and transmission wire.
6. INSTALL TRANSMISSION WIRE
(a) Coat an O−ring of the transmission wire connector with
AT F.
(b) Install the transmission wire and bolt.
Torque: 5.4 N
m (55 kgf
cm, 48 in.
lbf)
7. CONNECT TRANSMISSION WIRE
(a) Coat an O−ring of the ATF temperature sensor with ATF.
(b) Install the ATF temperature sensor with the lock plate and
bolt.
Torque: 6.6 N
m (67 kgf
cm, 58 in.
lbf)
(c) Connect the 7 shift solenoid valve connectors.
8. INSTALL AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Install the 2 magnets in the oil pan.
(b) Apply seal packing to the 18 bolts.
Seal packing:
THREE BOND1344 or equivalent
