2004 TOYOTA TUNDRA Owners Manual

’04 TUNDRA_U (L/O 0309)
88
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
(C) Booster seat(A) INFANT SEAT INSTALLATION
An infant seat must be used in rear
facing position only.
With the child restraint system installed,
check that your driving position is satis-
factory and that the child restraint system
does not interfere with your driving.
If your driving position is not satisfactory,
or the child restraint system interferes
with your driving, install it at another posi-
tion.
CAUTION
Ignoring the above instructions may
result in a serious injury in case of
an accident.
—Installation with 2point
type seat belt

’04 TUNDRA_U (L/O 0309)
89
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
CAUTION
Never install a rearfacing child re-
straint system on the front seat with
the passenger airbag manual onoff
switch in the “ON” position. In the
event of an accident, the force of the
rapid inflation of the front passenger
airbag can cause death or serious in-
jury to the child if the rearfacing
child system is installed on the front
passenger seat.
When you install a rearfacing child re-
straint system on the front seat, turn
the passenger airbag manual onoff
switch counterclockwise to the “OFF”
position. (For details, see “SRS driver
airbag and front passenger airbag” in
this Section.)
The indicator light comes on when the
system is off.
CAUTION
If you must install a rearfacing child
restraint system on the front seat,
make sure the passenger airbag
manual onoff switch is in the “OFF”
position and that the indicator light is
on.

’04 TUNDRA_U (L/O 0309)
90
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
CAUTION
Do not install a child restraint sys-
tem on the rear seat if it interferes
with the lock mechanism of the
front seats. Otherwise, the child or
front seat occupants, may be killed
or seriously injured in case of sud-
den braking or a collision.
If the driver ’s seat position does
not allow sufficient space for safe
installation, install the child re-
straint system on the rear right
seat.
1. Run the center lap belt through or
around the infant seat following the
instructions provided by its manufactur-
er and insert the tab into the buckle
taking care not to twist the lap belt.
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from death or serious injury.
Contact your Toyota dealer immedi-
ately. Do not install the child
restraint system on the seat until
the seat belt is fixed.

’04 TUNDRA_U (L/O 0309)
91
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
2. While pressing the infant seat firmly
against the seat cushion and seatback,
tighten the lap belt by pulling its free
end to hold the infant seat securely.CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
3. To remove the infant seat, press thebuckle release button.

’04 TUNDRA_U (L/O 0309)
92
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
(B) CONVERTIBLE SEAT INSTALLATION
A convertible seat must be used in for-
wardfacing or rearfacing position de-
pending on the age and size of the
child. When installing, follow the
manufacturer ’s instruction about the ap-
plicable age and size of the child as
well as directions for installing the
child restraint system.
With the child restraint system installed,
check that your driving position is satis-
factory and that the child restraint system
does not interfere with your driving.
If your driving position is not satisfactory,
or the child restraint system interferes
with your driving, install it at another posi-
tion.
CAUTION
Ignoring the above instructions may
result in a serious injury in case of
an accident.
CAUTION
Rearfacing child restraint system:
Never install a rearfacing child re-
straint system on the front seat with
the passenger airbag manual onoff
switch in the “ON” position. In the
event of an accident, the force of the
rapid inflation of the front passenger
airbag can cause death or serious in-
jury to the child if the rearfacing
child system is installed on the front
passenger seat.

’04 TUNDRA_U (L/O 0309)
93
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
When you install a rearfacing child re-
straint system on the front seat, turn
the passenger airbag manual onoff
switch counterclockwise to the “OFF”
position. (For details, see “SRS driver
airbag and front passenger airbag” in
this Section.)
The indicator light comes on when the
system is off.
CAUTION
If you must install a rearfacing child
restraint system on the front seat,
make sure the passenger airbag
manual onoff switch is in the “OFF”
position and that the indicator light is
on.
CAUTION
Forwardfacing child restraint system:
A forwardfacing child restraint sys-
tem should never be installed on the
front passenger seat with the passen-
ger airbag manual onoff switch in
the “ON” position, because the force
of the deploying airbag could cause
death or serious injury to the child in
forward seating position.

’04 TUNDRA_U (L/O 0309)
94
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
CAUTION
Do not install a child restraint sys-
tem on the rear seat if it interferes
with the lock mechanism of the
front seats. Otherwise, the child or
front seat occupants, may be killed
or seriously injured in case of sud-
den braking or a collision.
If the driver ’s seat position does
not allow sufficient space for safe
installation, install the child re-
straint system on the rear right
seat.
1. Run the center lap belt through or
around the convertible seat following
the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
lap belt.
CAUTION
After inserting the tab, make sure
the tab and buckle are locked and
that the lap belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from death or serious injury.
Contact your Toyota dealer immedi-
ately. Do not install the child
restraint system on the seat until
the seat belt is fixed.

’04 TUNDRA_U (L/O 0309)
95
2004 TUNDRA from Sep. ’03 Prod. (OM34426U)
2. While pressing the convertible seat
firmly against the seat cushion and
seatback, tighten the lap belt by pulling
its free end to hold the convertible seat
securely.CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
3. To remove the convertible seat, pressthe buckle release button.
