retractor. See your INFINITI retailer.
O Removal and installation of the pre-
tensioner seat belt system compo-
nents should be done by an autho-
rized INFINITI retailer.
O All seat belt assemblies including re-
tractors and attaching hardware
should be inspected after any colli-
sion by your INFINITI retailer. INFINITI
recommends that all seat belt assem-
blies in use during a collision be
replaced unless the collision was mi-
nor and the belts show no damage and continue to operate properly.
Seat belt assemblies not in use dur-
ing a collision should also be in-
spected and replaced if either dam-
age or improper operation is noted.
O All child restraints and attaching
hardware should be inspected after
any collision. Always follow the re-
straint manufacturer's inspection in-
structions and replacement recom-
mendations. The child restraints
should be replaced if they are dam-
aged. CHILD SAFETY Children need adults to help protect them.
They need to be properly restrained.
The proper restraint depends on the child's
size. Generally, infants (up to about 1 year and
less than 20 lb (9 kg) should be placed in rear
facing child restraints. Front facing child re-
straints are available for children who outgrow
rear facing child restraints. SSS0134 SSS0016
Seats, restraints and supplemental air bag systems
1-27
Z 02.7.29/V35-D/V5.0
X

WARNINGInfants and children need special pro-
tection. The vehicle's seat belts may not
fit them properly. The shoulder belt may
come too close to the face or neck. The
lap belt may not fit over their small hip
bones. In an accident, an improperly
fitting seat belt could cause serious or
fatal injury. Always use appropriate child
restraints. All US states and provinces of Canada require
the use of approved child restraints for infants
and small children. (See ªChild restraintsº later
in this section.)
In addition, there are many types of child
restraints available for larger children which
should be used for maximum protection.
INFINITI recommends that all preteens and
children be restrained in the rear seat if
possible. According to accident statistics,
children are safer when properly restrained
in the rear seat than in the front seat.
This is especially important because your
vehicle has a supplemental restraint sys-
tem (air bag system) for the front passen-
ger. See ªSupplemental Restraint Systemº
earlier in this section for precautions.
Infants and small children INFINITI recommends that infants and small
children be placed in child restraints that com-
ply with Federal Motor Vehicle Safety Stan-
dards or Canadian Motor Vehicle Safety Stan-
dards. You should choose a child restraint that
fits your vehicle and always follow the manu-
facturer's instructions for installation and use. Larger children Children who are too large for child restraint
systems should be seated and restrained by
the seat belts which are provided.
If the child's seating position has a shoulder
belt that fits close to the face or neck, the use
of a booster seat (commercially available) may
help overcome this. The booster seat should
raise the child so that the shoulder belt is
properly positioned across the top, middle
portion of the shoulder and the lap belt is low
on the hips. The booster seat should fit the
vehicle seat and have a label certifying that it
complies with Federal Motor Vehicle Safety
Standards or Canadian Motor Vehicle Safety
Standards. Once the child has grown so the
shoulder belt is no longer on or near the face
and neck, use the shoulder belt without the
booster seat.
WARNING Never let a child stand or kneel on any
seat and do not allow a child in the cargo
areas while the vehicle is moving. The
child could be seriously injured or killed
in an accident or a sudden stop.SSS0014
1-28 Seats, restraints and supplemental air bag systems
Z 02.7.29/V35-D/V5.0
X

PREGNANT WOMEN INFINITI recommends that pregnant women
use seat belts. The seat belt should be worn
snug, and always position the lap belt as low
as possible around the hips, not the waist.
Place the shoulder belt over your shoulder and
across your chest. Never run the lap/shoulder
belt over your abdominal area. Contact your
doctor for specific recommendations.
INJURED PERSONS INFINITI recommends that injured persons
use seat belts, depending on the injury. Check
with your doctor for specific recommendations.
THREE-POINT TYPE SEAT BELT
WITH RETRACTOR
WARNING O Every person who drives or rides in
this vehicle should use a seat belt at
all times.
O Do not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident you could be thrown into it and re-
ceive neck or other serious injuries.
You could also slide under the lap
belt and receive serious internal inju-
ries.
O For the most effective protection
when the vehicle is in motion, the
seat should be upright. Always sit
well back in the seat and adjust the
seat belt properly. SSS0018 SSS0020
Seats, restraints and supplemental air bag systems
1-29
Z 02.7.29/V35-D/V5.0
X

Fastening the seat belts 1. Adjust the seat.
2. Slowly pull the seat belt out of the retractor
and insert the tongue into the buckle until it
clicks.
The retractor is designed to lock during a
sudden stop or on impact. A slow pulling
motion will permit the belt to move, and
allow you some freedom of movement in
the seat.
If the seat belt cannot be pulled from its fully
retracted position, firmly pull the belt and re-
lease it. Then smoothly pull the belt out of the
retractor. 3. Position the lap belt portion low and snug
on the hips as shown.
4. Pull the shoulder belt portion toward the
retractor to take up extra slack.
The front passenger and rear seat belts have a
cinching mechanism for child restraint installa-
tion. It is referred to as the automatic locking
mode.
When the cinching mechanism is activated the
seat belt cannot be withdrawn again until the
seat belt tongue is detached from the buckle
and fully retracted. For additional information,
see ªChild restraintsº later in this section. The automatic locking mode should be
used only for child restraint installation.
During normal seat belt use by a passen-
ger, the locking mode should not be acti-
vated. If it is activated it may cause uncom-
fortable seat belt tension.
WARNING When fastening the seat belts, be certain
that seatbacks are completely secured
in the latched position. If they are not
completely secured, passengers may be
injured in an accident or sudden stop.SSS0102 SSS0061
1-30 Seats, restraints and supplemental air bag systems
Z 02.11.1/V35-D/V5.0
X

Unfastening the seat belts To unfasten the belt, press the button on the
buckle. The seat belt will automatically retract.
Checking seat belt operation Your seat belt retractors are designed to lock
belt movement using two separate methods:
O when the belt is pulled quickly from the
retractor.
O when the vehicle slows down rapidly.
You can check their operation as follows:
O grasp the shoulder belt and pull quickly forward. The retractor should lock and re-
strict further belt movement.
If the retractor does not lock during this check
or if you have any questions about belt opera-
tion, see your INFINITI retailer.
Shoulder belt height adjustment
(For Sedan front seats) The shoulder belt anchor height should be
adjusted to the position best suited for you.
(See ªPrecautions on seat belt usageº earlier
in this section.) To lower, pull the release
button, and then move the shoulder belt an-
chor to the desired position, so that the belt
passes over the shoulder. Release the adjust-
ment button to lock the shoulder belt anchor
into position.
To raise, move the adjuster up to the desired
position while pulling the button.SSS0021 SPA0739
Seats, restraints and supplemental air bag systems
1-31
Z 02.7.29/V35-D/V5.0
X

WARNINGO After adjustment, release the adjust-
ment button and try to move the
shoulder belt down to make sure it is
securely fixed in position.
O The shoulder belt anchor height
should be adjusted to the position
best for you. Failure to do so may
reduce the effectiveness of the entire
restraint system and increase the
chance or severity of injury in an
accident.
Shoulder belt guide (Coupe) The shoulder arm can be adjusted to allow
easier access to the shoulder belt. The arm
can also be folded down to allow rear seat
passengers easier access.
SEAT BELT EXTENDERS If, because of body size or driving position, it is
not possible to properly fit the lap-shoulder belt
and fasten it, an extender is available which is
compatible with the installed seat belts. The
extender adds approximately 8 inches (200
mm) of length and may be used for either the
driver or front passenger seating position. See your INFINITI retailer for assistance if the
extender is required.
WARNING O Only INFINITI belt extenders, made by
the same company which made the
original equipment belts, should be
used with INFINITI belts.
O Adults and children who can use the
standard seat belt should not use an
extender. Such unnecessary use
could result in serious personal in-
jury in the event of an accident.
O Never use seat belt extenders to in-
stall child restraints. If the child re-
straint is not secured properly, the
child could be seriously injured in a
collision or a sudden stop.
SEAT BELT MAINTENANCE O To clean the seat belt webbings, apply a
mild soap solution or any solution recom-
mended for cleaning upholstery or carpets.
Then brush the webbing, wipe it with a cloth
and allow it to dry in the shade. Do not allow SSS0222
1-32 Seats, restraints and supplemental air bag systems
Z 02.7.29/V35-D/V5.0
X

the seat belts to retract until they are com-
pletely dry.
O If dirt builds up in the shoulder belt guide of
the seat belt anchors, the seat belts may
retract slowly. Wipe the shoulder belt guide
with a clean, dry cloth.
O Periodically check to see that the seat
belt and the metal components such as
buckles, tongues, retractors, flexible wires
and anchors work properly. If loose parts,
deterioration, cuts or other damage on the
webbing is found, the entire belt assembly
should be replaced. PRECAUTIONS ON CHILD
RESTRAINTS
WARNING O Infants and small children should al-
ways be placed in an appropriate
child restraint while riding in the ve-
hicle. Failure to use a child restraint
can result in serious injury or death.
O Infants and small children should
never be carried on your lap. It is not
possible for even the strongest adult
to resist the forces of a severe acci-
dent. The child could be crushed be-
tween the adult and parts of the ve-
hicle. Also, do not put the same seat
belt around both your child and your-
self.
O Never install a rear facing child re-
straint in the front seat. An inflating
supplemental air bag could seriously
injure or kill your child. A rear facing
child restraint must only be used in
the rear seat. O INFINITI recommends that the child
restraint be installed in the rear seat.
According to accident statistics, chil-
dren are safer when properly re-
strained in the rear seat than in the
front seat.
O An improperly installed child re-
straint could lead to serious injury or
death in an accident.
In general, child restraints are designed to be
installed with the lap portion of a three-point
type seat belt. In addition, this vehicle is
equipped with a universal child restraint lower
anchor system, referred to as the LATCH
(Lower Anchors and Tether for Children) sys-
tem. Some child restraints include two rigid or
webbing-mounted attachments that can be
connected to these lower anchors. For details,
see ªLATCH (Lower Anchors and Tether for
Children) SYSTEMº later in this section.
Child restraints for infants and children of
various sizes are offered by several manufac-
turers. When selecting any child restraint,
keep the following points in mind:
O Choose only a restraint with a label certify-
ing that it complies with Federal MotorCHILD RESTRAINTS
Seats, restraints and supplemental air bag systems
1-33
Z 02.7.29/V35-D/V5.0
X

Vehicle Safety Standard 213 or Canadian
Motor Vehicle Safety Standard 213.
O Check the child restraint in your vehicle to
be sure it is compatible with the vehicle's
seat and seat belt system.
O If the child restraint is compatible with your
vehicle, place your child in the child re-
straint and check the various adjustments
to be sure the child restraint is compatible
with your child. Always follow all recom-
mended procedures.
All US states and Canadian provinces re-
quire that infants and small children be
restrained in approved child restraints at
all times while the vehicle is being oper-
ated.
WARNINGO Improper use of a child restraint can
result in increased injuries for both
the infant or child and other occu-
pants in the vehicle.
O Follow all of the child restraint manu-
facturer's instructions for installation
and use. When purchasing a child restraint, be sure to select one which
will fit your child and vehicle. It may
not be possible to properly install
some types of child restraints in your
vehicle.
O If the child restraint is not anchored
properly, the risk of a child being
injured in a collision or a sudden stop
greatly increases.
O Adjustable seatbacks should be posi-
tioned to fit the child restraint, but as
upright as possible.
O After attaching the child restraint,
test it before you place the child in it.
Tilt it from side to side. Try to tug it
forward and check to see if the belt
holds the restraint in place. The child
restraint should not move more than
1 inch. If the restraint is not secure,
tighten the belt as necessary, or put
the restraint in another seat and test
it again.
O For a front facing child restraint,
check to make sure the shoulder belt
does not go in front of the child's face or neck. If it does, put the shoulder
belt behind the child restraint. If you-
must install a front facing child re-
straint in the front seat, see instruc-
tions later in this section.
O When your child restraint is not in
use, store it in the trunk or keep it
secured with a seat belt to prevent it
from being thrown around in case of
a sudden stop or accident.
CAUTION Remember that a child restraint left in a
closed vehicle can become very hot.
Check the seating surface and buckles
before placing your child in the child
restraint.
1-34 Seats, restraints and supplemental air bag systems
Z 02.11.1/V35-D/V5.0
X
