has been parked for a while. Water dripping
from the air conditioner after use is normal. If
you should notice any leaks or if gasoline
fumes are evident, check for the cause and
have it corrected immediately. To ensure smooth, trouble-free, safe and eco-
nomical driving, INFINITI provides two differ-
ent maintenance schedules that may be used,
depending upon the conditions in which you
usually drive. These schedules contain both
distance and time intervals, up to 60,000 miles
(96,000 km)/48 months. For most people, the
odometer reading will indicate when service is
needed. However, if you drive very little, your
vehicle should be serviced at the regular time
intervals shown in the schedule. After 60,000
miles (96,000 km) or 48 months, continue
periodic maintenance at the same
mileage/time intervals.
SCHEDULE 1 Follow Periodic Maintenance Schedule 1 if
your driving habits frequently include one or
more of the following driving conditions:
O repeated short trips of less than 5 miles
(8 km).
O repeated short trips of less than 10 miles
(16 km) with outside temperatures re-
maining below freezing.
O operating in hot weather in stop-and-go
rush hour traffic.
O extensive idling and/or low speed driv-
ing for long distances, such as police,
taxi or door-to-door delivery use. O driving in dusty conditions.
O driving on rough, muddy, or salt spread
roads.
O towing a trailer, using a camper or a
car-top carrier.
SCHEDULE 2 Follow Periodic Maintenance Schedule 2 if
none of the driving conditions shown in Sched-
ule 1 apply to your driving habits.PERIODIC MAINTENANCE
SCHEDULES
Maintenance
9-5
Z 02.7.29/V35-D/V5.0
X

Schedule 1 Abbreviations: R = Replace, I = Inspect. Correct or replace if necessary. [ ]: Perform service at the mileage intervals onlyMAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform at number of miles, kilometers or
months, whichever comes first. Miles x 1,000 3.75 7.5 11.25 15 18.75 22.5 26.25 30 33.75 37.5 41.25 45 48.75 52.5 56.25 60
(km x 1,000) (6) (12) (18) (24) (30) (36) (42) (48) (54) (60) (66) (72) (78) (84) (90) (96)
Months 3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48
EMISSION CONTROL SYSTEM MAINTENANCE
Engine oil RRRRRRRRRRRRRRRR
Engine oil filter (Use Part No. 15208 31U00 or 15208 65F00 or
equivalent) RRRRRRRRRRRRRRRR
Air cleaner filter See NOTE (1) [R] [R]
EVAP vapor lines I* I*
Fuel lines I* I*
Drive belts See NOTE (2) I*
Engine coolant See NOTE (3) R*
Spark plugs (PLATINUM-TIPPED type) Replace every 105,000 miles (169,000 km)
Fuel filter See NOTE (4)
Intake & exhaust valve clearance* See NOTE (5)
NOTE: (1) If operating mainly in dusty conditions, more frequent maintenance may be required.
(2) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) Maintenance-free item (In-tank type fuel filter).
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with ª*º are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order
to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
9-6 Maintenance
Z 02.7.29/V35-D/V5.0
X

Schedule 1 Abbreviations: R = Replace, I = Inspect. Correct or replace if necessary. MAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform at number of miles, kilometers or
months, whichever comes first. Miles x 1,000 3.75 7.5 11.25 15 18.75 22.5 26.25 30 33.75 37.5 41.25 45 48.75 52.5 56.25 60
(km x 1,000) (6) (12) (18) (24) (30) (36) (42) (48) (54) (60) (66) (72) (78) (84) (90) (96)
Months 3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48
CHASSIS AND BODY MAINTENANCE
Brake lines & cables IIII
Brake pads & rotors IIIIIIII
Manual transmission gear oil or automatic trans-
mission fluid & differential gear oil See NOTE (1) IIII
Steering gear & linkage, axle & suspension parts IIIIIIII
Tire rotation See NOTE (2)
Exhaust system IIIIIIII
In-cabin microfilter RRRR
NOTE: (1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km)
or 24 months. Using automatic transmission fluid other than Genuine Nissan ATF Matic Fluid J will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new vehicle limited warranty.
(2) Refer to ªTire rotationº under the ªGeneral maintenanceº heading earlier in this section.
Maintenance
9-7
Z 02.7.29/V35-D/V5.0
X

Schedule 2 Abbreviations: R = Replace, I = Inspect. Correct or replace if necessary. [ ]: Perform service at the mileage intervals onlyMAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform at number of miles, kilometers or months,
whichever comes first. Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60
(km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96)
Months 6 12 18 24 30 36 42 48
EMISSION CONTROL SYSTEM MAINTENANCE
Engine oil RRRRRRRR
Engine oil filter (Use Part No. 15208 31U00 or 15208 65F00 or equivalent) RRRRRRRR
Air cleaner filter [R] [R]
EVAP vapor lines I* I*
Fuel lines I* I*
Drive belts See NOTE (1) I*
Engine coolant See NOTE (2) R*
Spark plugs (PLATINUM-TIPPED Type) Replace every 105,000 miles (169,000 km)
Fuel filter See NOTE (3)
Intake & exhaust valve clearance* See NOTE (4)
NOTE: (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged.
(2) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(3) Maintenance-free item (In-tank type fuel filter).
(4) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with ª*º are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order
to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
9-8 Maintenance
Z 02.7.29/V35-D/V5.0
X

Schedule 2 Abbreviations: R = Replace, I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform at number of miles, kilometers or months,
whichever comes first. Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60
(km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96)
Months 6 12 18 24 30 36 42 48
CHASSIS AND BODY MAINTENANCE
Brake lines & cables IIII
Brake pads & rotors IIII
Manual transmission gear oil or automatic transmission fluid &
differential gear oil See NOTE (1) IIII
Steering gear & linkage, axle & suspension parts I I
Tire rotation See NOTE (2)
Exhaust system II
In-cabin microfilter RRRRNOTE: (1) Using automatic transmission fluid other than Genuine Nissan ATF Matic Fluid J will cause deterioration in driveability and automatic transmission
durability, and may damage the automatic transmission, which is not covered by the INFINITI new vehicle limited warranty.
(2) Refer to ªTire rotationº under the ªGeneral maintenanceº heading earlier in this section.
Maintenance
9-9
Z 02.7.29/V35-D/V5.0
X

EXPLANATION OF MAINTENANCE
ITEMS Additional information on the following
items with ª*º is found in the ª8. Do-it-
yourselfº section.
Emission control system
maintenance Drive belts*: Check drive belts for wear, fray-
ing or cracking and also for proper tension.
Replace the drive belts if found damaged.
Air cleaner filter: Under normal driving con-
ditions, the air cleaner filter should be replaced
in accordance with the maintenance schedule.
However, driving the vehicle in dusty areas
may cause more rapid clogging of the element.
Consequently, the element may have to be
replaced more frequently.
EVAP vapor lines: Check vapor lines and
connections for failure or looseness. If leaks
are found, replace them.
Fuel lines: Check the fuel hoses, piping and
connections for leaks, looseness or deteriora-
tion. Replace any parts if they are damaged.
Engine coolant*: Drain and flush the cooling
system.
Engine oil & oil filter*: Under normal driving conditions, the engine oil and oil filter should
be replaced in accordance with the mainte-
nance schedule. However, under severe driv-
ing conditions, they may have to be replaced
more frequently.
Spark plugs*: Replace with new plugs having
the correct heat range.
Chassis and body maintenance Brake lines & cables: Check the brake lines
and hoses (including brake booster vacuum
hoses, connections & check valve) and park-
ing brake cables for proper attachment, leaks,
cracks, chafing, abrasion, deterioration, etc.
Brake pads & rotors: Check these and the
other neighboring brake components for wear,
deterioration and leaks. Under severe driving
conditions, they may have to be inspected
more frequently.
Automatic transmission fluid*: Using auto-
matic transmission fluid other than Genuine
Nissan ATF Matic Fluid J will cause deteriora-
tion in driveability and automatic transmission
durability, and may damage the automatic
transmission, which is not covered by the
INFINITI new vehicle limited warranty. If
checking or replacement is required, we rec-
ommend your INFINITI retailer for servicing.
Under severe driving conditions, the fluid should be replaced at the specified interval.
Manual transmission oil & differential gear
oil*: Check the oil level and visually inspect for
signs of leakage.
Under severe driving conditions, the oil should
be replaced at the specified interval.
Steering gear & linkage, axle & suspension
parts: Check for damage, looseness and leak-
age of oil or grease. Under severe driving
conditions, more frequent inspection should be
performed.
Exhaust system: Visually check the exhaust
pipes, muffler, and hangers for proper attach-
ment, leaks, cracks, chafing, abrasion, dete-
rioration, etc. Under severe driving conditions,
inspection should be performed more fre-
quently.
In-cabin microfilter: Under normal condi-
tions, this microfilter should be replaced in
accordance with the maintenance schedule.
However, in some situations, the microfilter
may clog more rapidly (depending on the air
conditioner's working environment). If this hap-
pens, the air flow may decrease, or the win-
dows may fog up easily when the air condi-
tioner is in use, the microfilter should be
replaced immediately at your INFINITI retailer.
9-10 Maintenance
Z 02.7.29/V35-D/V5.0
X

10 Technical and consumer information Capacities and recommended fuel/lubricants/
fluids ........................................................................ 10-2
Fuel recommendation ......................................... 10-3
Engine oil and oil filter recommendation ............ 10-5
Recommended SAE viscosity number ............... 10-6
Air conditioning system refrigerant and lubricant
recommendations ............................................... 10-6
Specifications .......................................................... 10-7
Engine ................................................................ 10-7
Wheels and tires ................................................ 10-8
Dimensions and weights .................................... 10-8
When traveling or registering your vehicle in
another country ....................................................... 10-9
Vehicle identification ............................................... 10-9
Vehicle identification number (VIN) plate ........... 10-9
Vehicle identification number
(Chassis number) ............................................... 10-9
Engine serial number ....................................... 10-10
F.M.V.S.S. certification label ............................ 10-10
Emission control information label ................... 10-11
Tire placard ...................................................... 10-11
Air conditioner specification label ..................... 10-12
Installing front bumper cover................................. 10-12
Installing front license plate................................... 10-13 Vehicle loading information ................................... 10-14
Terms ............................................................... 10-14
Determining vehicle load capacity.................... 10-14
Loading tips ...................................................... 10-15
Towing a trailer ..................................................... 10-15
Maximum load limits ......................................... 10-16
Towing safety ................................................... 10-17
Uniform tire quality grading ................................... 10-19
Emission control system warranty ........................ 10-20
Reporting safety defects (US only) ....................... 10-21
Readiness for inspection/maintenance (I/M) test
(US only) ............................................................... 10-21
Owner's Manual/Service Manual order
information............................................................. 10-22
In the event of a collision ................................. 10-22
Z 02.7.29/V35-D/V5.0
X

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure
instructed in the ª8. Do-it-yourselfº section to determine the proper refill capacity. Capacity (Approximate)
Recommended
specificationsUS
measure Imp
measure Liter
Fuel 20 gal 16-5/8 gal 76 Unleaded gasoline with an octane rating of at least 91 AKI (RON 96)*1
Engine oil*7
Drain and refill
With oil filter change 5 qt 4-1/8 qt 4.7 O API Certification Mark*2, *3
O API grade SG/SH, Energy Conservin gI&IIorAPI grade SJ or SL, Energy
Conserving*2, *3
O ILSAC grade GF-I, GF-II, GF-III*2, *3Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system Sedan AT 9 qt 7-1/2 qt 8.5
With reservoir Coupe, Sedan MT 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN anti-freeze coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid Ð Ð Ð Genuine Nissan ATF Matic Fluid J*4
Manual transmission gear oil Ð Ð Ð API GL-4, Viscosity SAE 75W-85
Differential gear oil Ð Ð Ð API GL-5, Viscosity SAE 80W-90*5
Power steering fluid
Refill to the proper oil level according to the instruc-
tions in the ª8. Do-it-yourselfº section. Genuine Nissan PSFII or equivalent*9
Brake and clutch fluid Genuine Nissan Brake Fluid*6 or equivalent DOT 3 (U.S. FMVSS No. 116)
Multi-purpose grease Ð Ð Ð NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant Ð Ð Ð HFC-134a (R-134a)*8
Air conditioning system lubricants Ð Ð Ð Nissan A/C System Oil Type S or exact equivalent
*1: For additional information, see later in this section for fuel recommendation.
*2: For additional information, see later in this section for engine oil and oil filter recommendation.
*3: For additional information, see later in this section for recommended SAE viscosity number.
*4: Using automatic transmission fluid other than Genuine Nissan ATF Matic Fluid J will cause deterioration in driveability and automatic transmission durability, and
may damage the automatic transmission, which is not covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures always above 0ÉC (32ÉF).
*6: Available in mainland US through your INFINITI retailer.
*7: For additional information, see ªEngine oilº in the ª8. Do-it-yourselfº section for changing engine oil.
*8: For additional information, see ªVehicle identificationº in this section for air conditioner specification label.
*9: Genuine Nissan PSF, Canada Nissan Automatic Transmission fluid, Dexron TM
III/Mercon TM
or equivalent ATF may also be used.CAPACITIES AND
RECOMMENDED
FUEL/LUBRICANTS/FLUIDS
10-2 Technical and consumer information
Z 02.11.15/V35-D/V5.0
X
