2003 INFINITI G35 Owners Manual

CHECKING ENGINE OIL LEVEL 1. Park the vehicle on a level surface and
apply parking brake.
2. Run the engine until it reaches operating
temperature.
3. Turn off the engine. Wait more than 10
minutes for the oil to drain back into the
oil pan.
4. Remove the dipstick and wipe it clean.
Reinsert it all the way. 5. Remove the dipstick again and check the
oil level. It should be between the H and L
marks. If the oil level is below the L mark,
remove the oil filler cap and pour recom-
mended oil through the opening. Do not
overfill.
6. Recheck oil level with dipstick.
It is normal to add some oil between oil
maintenance intervals or during the
break-in period, depending on the severity
of operating conditions. CAUTION Oil level should be checked regularly.
Operating with insufficient amount of oil
can damage the engine, and such dam-
age is not covered by warranty.SDI1386 SDI1402
ENGINE OIL
Do-it-yourself
8-7
Z 02.7.29/V35-D/V5.0
X

CHANGING ENGINE OIL AND
FILTER Change the engine oil and filter according to
the maintenance intervals shown in the ª9.
Maintenanceº section.
Vehicle set-up 1. Park the vehicle on a level surface and
apply the parking brake.
2. Run the engine until it reaches operating
temperature.
3. Turn the engine off and wait more than 10
minutes.
4. Raise and support the vehicle using a suit-
able floor jack and safety jack stands.
O Place the safety jack stands under the
vehicle jack-up points.
O A suitable adapter should be attached to
the jack stand saddle.
5. Remove the plastic engine undercover.
a. Remove the small plastic clip at the center
point of the undercover.
b. Then remove the other bolts that hold the
undercover in place. CAUTION Make sure the correct lifting and support
points are used to avoid vehicle dam-
age.
Engine oil and filter 1. Place a large drain pan under the drain
plug.
2. Remove the oil filler cap.
3. Remove the drain plug with a wrench and
completely drain the oil.
CAUTION Be careful not to burn yourself, as the
engine oil is hot.
O Waste oil must be disposed of properly. SDI1520
8-8 Do-it-yourself
Z 02.7.29/V35-D/V5.0
X

O Check your local regulations.
4. Loosen the oil filter with an oil filter wrench.
Remove the oil filter by turning it by hand.
5. Wipe the engine oil filter mounting surface
with a clean rag.
Be sure to remove any old rubber gasket
remaining on the mounting surface of
the engine.
6. Coat the gasket on the new filter with clean
engine oil.
7. Screw in the oil filter clockwise until a slight
resistance is felt, then tighten additionally
more than 2/3 turn.
Oil filter tightening torque:
11 to 15 ft-lb
(14.7 to 20.5 N z m)
8. Clean and re-install the drain plug with a
new washer. Securely tighten the drain plug
with a wrench.
Drain plug tightening torque:
22 to 29 ft-lb
(29 to 39 N z m)
Do not use excessive force.
9. Refill engine with recommended oil and
install the cap securely. CAUTION The dipstick must be inserted in place to
prevent oil spillage from the dipstick
hole while filling the engine with oil.
See ªCapacities and recommended fuel/
lubricantsº in the ª9. Technical and con-
sumer informationº section for drain and
refill capacity. The drain and refill capacity
depends on the oil temperature and drain
time. Use these specifications for reference
only. Always use the dipstick to determine
the proper amount of oil in the engine.
CAUTION When filling oil, do not pull out the
dipstick.
10.Start the engine and check for leakage
around the drain plug and the oil filter.
Correct as required.
11.Turn the engine off and wait more than 10
minutes. Check the oil level with the dip-
stick. Add engine oil if necessary. After the operation 1. Install the engine undercover into position
as the following steps.
a. Pull the center of the small plastic clip out.
b. Hold the engine undercover into position.
c. Insert the clip through the undercover into
the hole in the frame, then push the center
of the clip in to lock the clip in place.
d. Install the other bolts that hold the under-
cover in place. Be careful not to strip the
bolts or over-tighten them.
2. Lower the vehicle carefully to the ground.
3. Dispose of waste oil and filter properly.
WARNING O Prolonged and repeated contact with
used engine oil may cause skin can-
cer.
O Try to avoid direct skin contact with
used oil. If skin contact is made, wash
thoroughly with soap or hand cleaner
as soon as possible.
Do-it-yourself
8-9
Z 02.7.29/V35-D/V5.0
X

O Keep used engine oil out of reach of
children. If checking or replacement is required, we
recommend your INFINITI retailer for servic-
ing.
CAUTION O Use only Genuine Nissan ATF Matic
Fluid J. Do not mix with other fluids.
O Using automatic transmission fluid
other than Genuine Nissan ATF Matic
Fluid J will cause deterioration in
driveability and automatic transmis-
sion durability, and may damage the
automatic transmission, which is not
covered by the INFINITI new vehicle
limited warranty.
The specified automatic transmission fluid is
also described on caution labels located in the
engine compartment. Check the fluid level in the reservoir tank.
The fluid level should be checked using the
HOT range at fluid temperatures of 122 to
176ÉF (50 to 80ÉC) or using the COLD range at
fluid temperatures of 32 to 86ÉF (0 to 30ÉC).
CAUTION O Do not overfill.
O Use Genuine Nissan PSF II or equiva-
lent. SDI1408
AUTOMATIC TRANSMISSION
FLUID POWER STEERING FLUID
8-10 Do-it-yourself
Z 02.7.29/V35-D/V5.0
X

BRAKE FLUID Check the fluid level in the reservoir. If the fluid
is below the MIN line or the brake warning light
comes on, add DOT 3 fluid up to the MAX line.
If fluid must be added frequently, the system
should be thoroughly checked by your
INFINITI retailer.
WARNINGUse only new fluid. Old, inferior, or con-
taminated fluid may damage the brake system. Do not add synthetic brake
fluid. The use of improper fluids can
damage the brake system and affect the
vehicle's stopping ability.
CAUTION Do not spill the fluid on painted sur-
faces. This will damage the paint. If fluid
is spilled, wash with water.
CLUTCH FLUID Check the fluid level in the reservoir. If the fluid
level is below the MIN. line, add Genuine
Nissan Brake Fluid or equivalent DOT 3 fluid
up to the MAX. line.
If fluid is added frequently, the system should
be thoroughly checked by your INFINITI re-
tailer.SDI0847 SDI1478
BRAKE AND CLUTCH FLUID
Do-it-yourself
8-11
Z 02.7.29/V35-D/V5.0
X

WARNINGUse only new fluid from a sealed con-
tainer. Old, inferior or contaminated fluid
may damage the clutch system.
CAUTIONDo not spill the fluid on painted sur-
faces. This will damage the paint. If fluid
is spilled, wash the surface with water.
Add fluid when the low washer fluid warning
light comes on. Add a washer solvent to the
water for better cleaning. In the winter season,
add a windshield washer anti-freeze. Follow
the manufacturer's instructions for the mixture
ratio. WARNING Anti-freeze is poisonous and should be
stored carefully in marked containers
out of the reach of children.
CAUTION Do not substitute engine anti-freeze
coolant for window washer solution.
This may result in damage to the paint. SDI1388
WINDOW WASHER FLUID
8-12 Do-it-yourself
Z 02.7.29/V35-D/V5.0
X

O Keep the battery surface clean and dry. Any
corrosion should be washed off with a
solution of baking soda and water.
O Make certain the terminal connections are
clean and securely tightened.
O If the vehicle is not to be used for 30 days or
longer, disconnect the (Ð) negative battery
terminal cable to prevent discharging it.
Coupe
CAUTIONWhen the battery cable is removed from
the battery terminal, do not close either
of front doors. The automatic window
adjusting function will not work, and the
side roof panel may be damaged.
To disconnect the negative (þ) battery ter-
minal, perform the procedure in the follow-
ing order. Otherwise, the window and the
side roof panel may contact and be dam-
aged.
1. Close the windows.
2. Open the hood.
3. Close and lock all the doors. 4. Disconnect the negative (þ) battery ter-
minal.
5. Securely close the hood.
To connect the negative (þ) battery termi-
nal, perform the procedure in the following
order. Otherwise, the window and the side
roof panel may contact and be damaged.
1. Unlock and open the driver side door.
Do not close the door.
2. Open the hood.
3. Connect the negative (þ) battery termi-
nal. Then close the hood.
4. Fully open the driver side door window.
5. Close the driver side door and the win-
dow.
Sedan and coupe
WARNING O Do not expose the battery to flames
or electrical sparks. Hydrogen gas
generated by battery action is explo-
sive. Do not allow battery fluid to
contact your skin, eyes, fabrics, or painted surfaces. After touching a
battery or battery cap, do not touch or
rub your eyes. Thoroughly wash your
hands. If you get acid on your eyes,
skin or clothing, immediately flush
with water for at least 15 minutes and
seek medical attention.
O Do not operate the vehicle if the bat-
tery fluid is low. Low battery fluid can
cause a higher load on the battery
which can generate heat, reduce bat-
tery life, and in some cases lead to an
explosion.
O When working on or near a battery,
always wear suitable eye protection
and remove all jewelry.
O Battery posts, terminals and related
accessories contain lead and lead
compounds. Wash hands after han-
dling.
O Keep the battery out of the reach of
children.BATTERY
Do-it-yourself
8-13
Z 02.7.29/V35-D/V5.0
X

Check the fluid level in each cell. It should be
between the MAX and MIN lines.
If it is necessary to add fluid, add only distilled
water to bring the level to the indicator in each
filler opening. Do not overfill.
Vehicles operated in high temperatures or
under severe conditions require frequent
checks of the battery fluid level.
1. Remove the cell plugs.
2. Add distilled water up to the MAX level.
3. Tighten cell plugs. JUMP STARTING If jump starting is necessary, see ªJump start-
ingº in the ª6. In case of emergencyº section. If
the engine does not start by jump starting, the
battery may have to be replaced. Contact your
INFINITI retailer. 1. Power steering fluid pump
2. Fan
3. Alternator
4. Crankshaft pulley
5. Air conditioner compressor
. : Tension checking points
WARNING Be sure the ignition key is in the OFF or
LOCK position. The engine could rotateDI0137M SDI1480 SDI1389
DRIVE BELTS
