1998 ACURA INTEGRA Service Repair Manual

Engine Removal/lnstallation
(cont'd)
26. Remove the upper and lower radiator hoses and the
heater hoses.
81881, B18C5 engines:
LOWCR RADIATORHOSE
HEATERHOSE
HEATERHOSE
LOWER RADIATORHOSE, UPPER RADIAToRHOSE
UPPER RADIATOR
,1
ir
..f.
c
5-8
t27. lAutomatic transmission) Remove the ATF cooler
hoses.
Remove the radiator assembly (see page 10-5).
Remove the A,/C compressor.
. Do not disconnect Ay'C hoses.
8 x 1.25 mm24 N.rn 12.4 kgl.m, 17 lbf.ft)
24.
29.
HOSES

7
30.Disconnect the primary heated oxygen sensor(Primary HO2S) connector, then remove exhaust
pipe A.
818C1 engine:PRIMARYHO2S
8 x 1.25 mm24 N.m 12.4 kgl.m.t7 rbt.fttReplace.
GASKETReplace.
Replace.
SELF-LOCKING I{UT8 r 1.25 mm16 N.m (1 .6 kgf .m,
12 tbt.frtBeplace.
EXHAUSTPIPE A
NUT10 x 1.25 mm54 N.m {5.5 kgt'.n, tlo lbt.ft}Replace.
81881, 818C5 engines:
PRIMARYHO25 CONNECTOF
GASKETReplace.
GASKETReplace.
S€LF.LOCKING NUT
8 x 1.25 mm16 N.m (1.6 kgf'm,12 tbt.fr)Replace.f{UT10 x 1.25 mm54 N.m {5.5 kgf'm,40 lbf.ftlReplace.
8 x 1.25 mm24 N.m (2.4 kgt.m,17 lbf.frlReplace.
31. Remove the shift rod and extension rod {Mff).
8 x 1.25 mm22 N'm 12.2 kgl.m, '16 lbt.ttl
32. Remove the shift cable (A,/T).
I x 1.25 mm22 N-l'. 12.2 kgl.m,16 lbf.frl
SHIFT CABLE
CONTROLLEVER
6 x 'l.O mm14 N.m {1.4 kgf.m, 10 lbt.ft}
SHIFT ROD
RETAINER
SHIFT CABLE
LOCK WASHER
{cont'd)
COVER
5-9

Engine Removal/lnstallation
(cont'dl
34.
Remove the damper {ork.
Disconnect the suspension lower arm ball joints
using the special tool. Refer to section '18 for the
proper procedure.
NOTE: Adjust the tool so the jaws are parallel to
each other.
12 x 1.25 mm
5-jl0
\
35. Remove the driveshafts.
CAUTION:
. Do not pull on the driveshaft, the CV joint may
come aoart.
. Use care when prying out the assembly.
Pull it straight to avoid damaging the differential
oil seal or intermediate shaft dust seal.
NOTE: Coat all precision Iinished surfaces with
clean enoine oil.
,{:
DRIVESHAFT/.-:
/

Engine Removal/lnstallation
Engine lnstallation
Installthe engine in the reverse order of removal
Reinstall the mount bolts/nuts in the following
sequence. Failure to follow these procedures may cause
excessive noise and vibration, and reduce bushing life
1. Install the transmission mount, then tighten the
bolvnuts on the tfansmlssion side. Leave the mount
bolt loose.
AIT:
'12 x 1.25 mmg N.m (6.5 kgl'm.
(cont'dl
5-14
47 thl.ftl
/o
llf
MOUNT EOLT
12 x 1.25 mm64 N.m {6.5 kgf.m,47 lbf.fr|
I
I
2. Install the engine side
bolvnuts on the engtne
toose.
M/T:
mo u nt, then tighten the
side. Leave the mount bolt
10 x 1.25 mm52 N.m 15.3 kgf.m,38 tbf.ft,Replace.
3, Tighten the mount bolt on the transmission mount.
AIf l
12 x 1.25 mm
L
\
{
74 N.m 17.5 kgl.m,54 rbf.ftl
12 x 1.25 mm74 N.m (7.5 kgl.m,54 rbf.ftl
