1996 FORD AEROSTAR Owners Manual

55 [SR30350(ALL)08/95]
10. Pull the shoulder belts out to ensure that the
crotch safety belt buckle is securely fastened.
Adjust the lap and shoulder belts by pulling
firmly on the adjustment belt. Refer to
Figure 9.
[SR30360(ALL)05/95]
half page art:0095056-A
Figure 9: Checking for securely latched buckle and locked
retractor
[SR30370(ALL)08/95]
11. If the shoulder belts are pulled too tight,
pull on the lap and shoulder belts cinch
release strap to loosen the shoulder belts on
the child's shoulders. Refer to Figure 4. Then
retighten the lap and shoulder adjustment
belt per Step 10 above.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

56
*
[SR30380(ALL)05/95]
To remove the child from the built-in child
seat:
[SR30390(ALL)06/95]
1. Squeeze the tabs on the top and bottom of
the chest clip and pull the halves apart to
open the chest clip. Refer to Figure 8.
*
[SR30400(ALL)06/95]
2. Press the release button on the crotch safety
belt buckle.
[SR30410(ALL)05/95]
3. Slide the shoulder belts off the child's
shoulders and remove the child. Refer to
Figure 6.
*
[SR30420(ALL)06/95]
To stow the built-in child seat:
[SR30430(ALL)05/95]
1. Return the child seat cushion to the upright
position and lift the protector flap toward
the headrest.
[SR30440(ALL)05/95]
2. Fasten the snaps securely.
[SR30450(ALL)05/95]
3. Pull on the headrest release strap and rotate
the headrest downward until it latches
against the child seat cushion.
[SR30460(ALL)05/95]
RWARNING
Always fasten the protector flap snaps
when stowing your child seats to prevent
the child seat cushion from rotating
forward in a collision.
[SR30470(ALL)05/95]
The seat can now be used by an adult.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

57
*
[SR30480(ALL)05/95]
Inspection after a collision
*
[SR30490(ALL)06/95]
RWARNING
All built-in child restraints, including
seats, buckles, retractors, seat latches,
interlocks, and attaching hardware should
be inspected by a qualified dealer
technician after any collision.
*
[SR30495(ALL)08/95]
If the child seat was in use during a collision,
Ford recommends replacing it. However, if the
collision was minor and a qualified technician
finds that the child restraints do not show
damage and continue to operate properly, they
do not need to be replaced. If there is any
bending of the vehicle seatback or seat structure,
it should also be replaced. Built-in child seats
not in use during a collision should also be
inspected and replaced if either damage or
improper operation is noted.
*
[SR30500(ALL)05/95]
Built-in child seat maintenance
*
[SR30510(ALL)05/95]
Regularly inspect the lap and shoulder belts
system of your child seat. See your Ford dealer
if the shoulder belt webbing is frayed, or if the
buckle and tongue are damaged and/or do not
function properly.
%*
[SR30520(ALL)05/95]
Cleaning
*
[SR30530(ALL)08/95]
Your Built-In Child Seat may be cleaned with
mild soap and water. Do not use household
cleaners as they may weaken the webbing or
damage the plastic parts. For your convenience,
the liner can be removed, machine-washed, and
air-dried.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

58 %
*
[SR30540(ALL)07/95]
Safety Belts for Children
*
[SR30550(ALL)07/95]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SR30560(ALL)07/95]
RWARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SR30570(ALL)07/95]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
*
[SR30580(ALL)07/95]
To improve the fit of lap and shoulder belts on
children who have outgrown child safety seats,
Ford recommends use of a belt-positioning
booster seat that is labelled as conforming to all
Federal motor vehicle safety standards.
Belt-positioning booster seats raise the child and
provide a shorter, firmer seating cushion that
encourages safer seating posture and better fit of
lap and shoulder belts on the child. A
belt-positioning booster should be used if the
shoulder belt rests in front of the child's face or
neck, or if the lap belt does not fit snugly on
both thighs, or if the thighs are too short to let
the child sit all the way back on the seat cushion
when the lower legs hang over the edge of the
seat cushion. You may wish to discuss the
specific needs of your child with your
pediatrician.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

59
*
[SR30590(ALL)07/95]
RWARNING
Do not use a belt-positioning booster with
a lap-only belt.
*
[SR30600(ALL)07/95]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
*
[SR30610(ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

61
Starting Your Aerostar
*
[ST01700(ALL)03/95]
Ignition
%*
[ST01800(ALL)01/95]
Understanding the Positions of the Ignition
*
[ST02000(ALL)05/90]
quarter page art:0020004-B
The positions of the key in the ignition lock cylinder.
%*
[ST02100(ALL)07/95]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
*
[ST02500(ALL)08/95]
LOCK locks the steering wheel and gearshift
lever.
*
[ST02700(ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[ST02800(ALL)05/95]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
*
[ST02850(ALL)03/95]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
File:04cpsta.ex
Update:Tue Aug 29 17:35:31 1995

62
*
[ST02900(ALL)05/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST02950(ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
%*
[ST03000(ALL)02/95]
Removing the Key From the Ignition
*
[ST03400(ALL)06/95]
1. Put the gearshift in P (Park).
*
[ST03500(ALL)03/91]
2. Set the parking brake fully before removing
your foot from the service brake. (This will
avoid ªbindingº or ªloadingº the park gear
if you park on a grade.)
*
[ST03600(ALL)03/95]
3. Turn the ignition key to LOCK.
*
[ST03700(ALL)03/95]
4. Remove the key.
File:04cpsta.ex
Update:Tue Aug 29 17:35:31 1995

63
*
[ST04625(ALL)06/95]
RWARNING
Always set the parking brake fully and
make sure the gearshift is securely latched
in P (Park).
*
[ST04750(ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
%*
[ST04775(ALL)03/91]
Ignition Key Buzzer or Chime
*
[ST04780(ALL)03/91]
The buzzer or chime will sound if you open the
driver's door while the key is in the ignition.
Never leave your vehicle unattended with the
key in the ignition.
%
*
[ST04800(ALL)03/95]
Fuel-Injected Engines
*
[ST04900(ALL)03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
File:04cpsta.ex
Update:Tue Aug 29 17:35:31 1995
