1996 FORD AEROSTAR Owners Manual

124
*
[FV05500(ALL)01/89]
Liftgate closing procedure
*
[FV05600(ALL)01/89]
1. To make the liftgate swing downward, reach
up and pull the lower edge of the liftgate (or
the loop handle on the inner trim panel of
vehicles with this option) and pull
downward.
*
[FV05700(ALL)01/89]
2. When you have pulled down the liftgate
enough so that you can reach the license
plate light shield, push the shield down and
forward to close the latch and liftgate. At
this point, the latch is not locked.
[FV05800(ALL)07/95]
3. You can lock the liftgate latch by pushing
down the lock button before you pull down
and close the liftgate. You can also lock the
liftgate latch by inserting your vehicle's door
key and turning it clockwise after you have
closed the liftgate, or by using the power
door locks (if equipped).
*
[FV05900(ALL)12/93]
The liftgate area is only intended for cargo, not
passengers. You can open and close the liftgate
from outside the vehicle. It cannot be opened
from inside the cargo area.
File:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

125 [FV08800(ALL)02/91]
Dual Rear Cargo Door (If equipped)
[FV09300(ALL)05/90]
quarter page art:0020200-A
Opening the right rear door
[FV09400(ALL)06/95]
To open the left rear door, open the right rear
door and then pull up on the tee-shaped handle
located on the inside of the left rear door.
[FV09500(ALL)05/90]
To open the right side cargo door from the
inside of your vehicle, find the slot on the door
and pull the door handle inward.
[FV09600(ALL)05/90]
one third page art:0020249-A
Opening the right side cargo door from the inside
[FV09700(ALL)03/95]
When closing the dual rear cargo doors,
remember to close the left rear door first.
*
[FV09801(ALL)05/95]
RWARNING
Do not operate your vehicle with the rear
double doors open.
File:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

126 %
*
[FV14100(ALL)04/95]
Power Door Locks (If equipped)
[FV14200(ALL)03/91]
The power door lock switches are located in the
front doors. To lock all doors push the switch
marked LOCK. To unlock all doors push the
switch marked UNLOCK.
*
[FV14300(ALL)03/94]
Memory lock (sliding door)
[FV14401(ALL)08/95]
Your vehicle has a sliding door memory lock
feature that does not require the sliding door to
be closed before using the power locks. The
locking function will activate after the door is
closed.
*
[FV14701(ALL)03/91]
The manual door locks will override the power
door lock controls.
[FV14801(ALL)05/91]
quarter page art:0020201-C
Power door lock controls
File:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

127
%*
[FV19250(ALL)02/95]
Windows
[FV20500(ALL)01/89]
Sliding side windows
[FV20700(ALL)08/95]
one third page art:0020207-B
Opening the sliding side window
%*
[FV22901(ALL)03/91]
Using the Power Windows (If equipped)
[FV23001(ALL)06/95]
Each front door has a power control that opens
and closes the window on that door. The
driver's door has a master control switch that
operates both front door windows. You must
place the ignition switch in the ON or ACC
position to use your power window controls.
*
[FV23401(ALL)08/95]
RWARNING
When driving your vehicle make sure that
the liftgate door and window are closed to
prevent exhaust fumes from being drawn
into the vehicle. This will also prevent
cargo from falling out.
*
[FV23501(ALL)07/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
File:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

128 [FV24001(ALL)08/95]
quarter page art:0020201-CPower window controls Ð driver-side shown
%*
[FV24101(ALL)01/95]
Seats
%*
[FV24801(ALL)05/90]
Adjusting the Front Seat Manually
[FV24825(ALL)06/95]
You can move the driver seat forward or
backward. If your vehicle is equipped with the
optional reclining bucket seat, you can also tilt
the seatback up to 30 degrees rearward.
[FV25401(ALL)04/89]
The front passenger seat cannot be adjusted.
[FV25425(ALL)06/95]
one third page art:0095010-A
Seat adjustment levers
*
[FV26001(ALL)05/95]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
File:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

129
*
[FV26100(ALL)05/95]
RWARNING
Do not pile cargo higher than the
seatbacks to avoid injuring people in a
collision or sudden stop.
*
[FV26200(ALL)06/95]
RWARNING
To reduce the risk of serious injury in a
collision, always drive and ride with your
seatback upright and the lap belt snug
and low across the hips.
*
[FV26300(ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[FV26350(ALL)05/95]
To move the seat forward or backward:
[FV26450(ALL)06/95]
one third page art:0095011-AFile:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

130
*
[FV26550(ALL)06/95]
To recline the seatback:
[FV26590(ALL)06/95]
one third page art:0095012-A[FV29801(ALL)09/89]
E-Z Access Operation Ð Passenger Side
Rear Captain's Chair (Optional Quad
Buckets)
[FV29901(ALL)05/89]
To provide easy access to the rear of the vehicle,
the passenger side rear captain's chair can be
tilted forward.
*
[FV30001(ALL)11/93]
To tilt seat forward:
*
[FV30101(ALL)11/93]
1. Put the seatback in the upright position.
[FV30200(ALL)02/92]
2. Lift upward on the lower handle on the
right (outboard) side of the seat.
*
[FV30300(ALL)11/93]
3. The seat can now be tilted forward.
*
[FV30401(ALL)11/93]
To latch the seat in its normal position, push
seatback rearward until it is latched in position.
File:08cpfva.ex
Update:Tue Aug 29 17:41:55 1995

131 %
*
[FV31201(ALL)12/91]
Quick Release Rear Captain Chairs
*
[FV31400(ALL)12/91]
To remove:
[FV31500(ALL)02/92]
1. For right hand seats, lift and rotate the seat
latch handle (located under the seat)
rearward, causing the J hook to disengage
from the front floor well retainer.
[FV31600(ALL)02/92]
For left hand seats, lift and rotate the seat
latch handle (located under the seat)
rearward, causing the J hook to disengage
from the front floor well retainer. Disengage
the lap/shoulder safety belt from the seat by
inserting a key or similar device into the slot
in the detachable anchor and lifting upward.
Stow the tongue end of the detachable
anchor as shown.
[FV31801(ALL)05/89]
2. Push the seat assembly rearward to
disengage the front and rear floor hooks and
lift the seat assembly from the vehicle.
