1996 FORD AEROSTAR Owners Manual

80
*
[LG05300(ALL)05/95]
one inch art:0020048-A
Check engine warning light symbol
[LG05525(ALL)03/94]
Electronic 4-Wheel Drive Warning Light
(If equipped)
[LG05550(ALL)03/95]
The Electronic 4-Wheel Drive Warning Light
turns on when the Electronic 4-Wheel Drive
system is not working properly. This light comes
on briefly when you turn the ignition key to the
ON position, but should turn off when the
engine starts. If the light does not come on when
you turn the ignition to the ON position, or if it
comes on and stays on when you are driving,
have your vehicle serviced as soon as possible.
[LG05560(ALL)03/94]
The 4WD light will go off after a few seconds
and stay off if all systems are operating
correctly. If a problem is detected, the 4WD
warning light will flash a certain number of
times indicating the location of the problem. The
flashing will continue until the problem is
corrected. Each time the ignition key is turned
on the controller will detect the problem and
flash the signal. The 4WD system remains safe to
operate and the vehicle should be returned for
service.
[LG05575(ALL)03/94]
one inch art:0020529-B
Electronic 4-wheel drive warning light
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

81 %
*
[LG05900(ALL)01/95]
Charging System Light
*
[LG06000(ALL)03/95]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[LG06050(ALL)05/95]
one inch art:0095040-A
Charging system light
*
[LG06100(ALL)07/95]
This light comes on every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[LG06300(ALL)01/95]
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
%*
[LG06305(ALL)06/93]
Supplemental Air Bag Readiness Light and
Tone Generator
*
[LG06310(ALL)06/93]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
*
[LG06315(ALL)05/95]
one inch art:0020778-B
Supplemental air bag readiness light
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

82 %
*
[LG06400(ALL)05/94]
Battery Voltage Gauge (Voltmeter)
*
[LG06601(ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG06700(ALL)11/89]
If you are running electrical accessories (when
the engine is off, or idling at a low speed), the
pointer may move toward the lower end of the
normal band. If it stays outside the normal band
area, have your vehicle's electrical system
checked as soon as it is safely possible.
*
[LG06701(ALL)05/95]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[LG06750(ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
*
[LG06900(ALL)03/93]
quarter page art:0020052-D
Battery voltage gauge
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

83 %
*
[LG07500(ALL)05/94]
Engine Oil Pressure Gauge
*
[LG07601(ALL)06/93]
This gauge indicates the engine's oil pressure,
not the oil level. However, if your engine's oil
level is low, it could affect the oil pressure. With
the engine running, the pointer should move
into the NORMAL band. If the pointer drops
below the NORMAL band while the engine is
running, you have lost oil pressure and
continued operation will cause severe engine
damage.
*
[LG07701(ALL)03/95]
If you lose engine oil pressure:
*
[LG07801(ALL)03/95]
1. Pull off the road as soon as safely possible.
*
[LG07901(ALL)04/95]
2. Shut off the engine immediately or severe
engine damage could result.
*
[LG08001(ALL)02/95]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil. Refer toEngine oilin the Index. If you
do not follow these instructions, you or
others could be injured. To assure an
accurate reading, your vehicle should be on
level ground.
*
[LG08051(ALL)03/93]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
*
[LG08200(ALL)03/93]
quarter page art:0020057-D
Engine oil pressure gauge
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

84 %
*
[LG08900(ALL)01/95]
High Beam Light
*
[LG09001(ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
*
[LG09025(ALL)11/89]
one inch art:0020537-B
High beam indicator light
%*
[LG09300(ALL)05/95]
Chime for Headlamps On
[LG09400(ALL)07/95]
This chime sounds if the driver or passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
[LG09450(ALL)12/91]
NOTE: The chime will not sound when the
autolamp has activated the shutoff
delay.
%*
[LG09500(ALL)01/95]
Fuel Gauge
*
[LG09700(ALL)06/93]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON.
*
[LG09850(ALL)01/95]
For a proper fuel gauge indication after adding
fuel, the ignition switch should be in the OFF
position while the vehicle is being refueled.
*
[LG09900(ALL)01/95]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. An accurate reading
may be obtained with the vehicle on smooth,
level ground.
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

85 [LG10000(ALL)05/91]
one inch art:0020061-C
Fuel gauge
%*
[LG11100(ALL)01/95]
Engine Coolant Temperature Gauge
*
[LG11201(ALL)03/95]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
*
[LG11301(ALL)08/95]
The pointer moves from the C (cold) mark into
the Normal band as the engine coolant warms
up. It is acceptable for the pointer to fluctuate
within the Normal band under normal driving
conditions. Under certain driving conditions,
such as heavy stop and go traffic or driving up
hills in hot weather, the pointer may move to
the top of the Normal band.
*
[LG11401(ALL)05/95]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine coolant is
overheating and continued operation may cause
engine damage.
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

86
*
[LG11501(ALL)01/95]
If your engine coolant overheats:
*
[LG11601(ALL)03/95]
1. Pull off the road as soon as it is safely
possible.
*
[LG11701(ALL)01/95]
2. Turn off the engine.
*
[LG11801(ALL)05/95]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[LG11901(ALL)04/95]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. Refer toEngine coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
[LG12325(ALL)03/93]
quarter page art:0020541-B
Engine coolant temperature gauge
File:05cplga.ex
Update:Tue Aug 29 17:36:50 1995

87 %
*
[LG12601(ALL)01/95]
Speedometer
*
[LG12700(ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[LG12750(ALL)08/95]
Your vehicle contains a speedometer which
receives its input from the Anti-Lock brake
sensor. The speedometer is also used to provide
a speed signal for correct operation of the
vehicle's Powertrain Control Module (PCM),
electronic transmission, and speed control (if so
equipped). Because of this, it is very
IMPORTANT to change the speedometer's
internal conversion constant if the size of the
tires on the vehicle is changed. Changing the
conversion constant to the proper value when
the tires are changed will also ensure that the
speedometer retains the original factory-set
accuracy.
[LG12752(ALL)08/95]
NOTE: The conversion constant can only be
changed six times once the vehicle
leaves the factory. Your Ford dealership
service personnel can change the
conversion constant.
*
[LG12753(ALL)08/95]
Some vehicles are equipped with a vehicle speed
(mph/km/h) limiting device that is contained
within the Powertrain Control Module (PCM).
The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle
speed limits may vary based on engine
displacement.)
