[SR09805(ALL)07/95]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
%*
[SR09825(ALL)06/95]
Cleaning the Safety Belts
*
[SR09850(ALL)06/95]
Clean the safety belts with any mild soap
solution that is recommended for cleaning
upholstery or carpets. Do not bleach or dye the
belt webbing because this may weaken it.
%*
[SR09875(ALL)08/95]
How to Untwist or Unjam a Safety Belt
Retractor
*
[SR09900(ALL)08/95]
If you should jam the lap belt retractor by
allowing the belt to retract when it is twisted,
you can free the webbing with this procedure:
*
[SR09925(ALL)08/95]
1. Pull on the belt with both hands to tighten it
on the retractor spool.
*
[SR09950(ALL)08/95]
2. Feed the belt back into the retractor until it
is completely retracted. Repeat previous step
if necessary.
*
[SR09975(ALL)08/95]
3. Pull the belt out of its holder as far as it will
go and untwist the belt or remove the object
that is jamming the belt. Let the belt retract.
*
[SR09985(ALL)08/95]
4. Then, pull the belt out and let it retract
several times to make sure that the belt
works properly.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

24 [SR10000(ALL)08/95]For Twisted Rear Outboard Combination
Lap and Shoulder Safety Belts Ð
Detachable Anchor
[SR10020(ALL)08/95]
Disengage the detachable anchor tongue from
the detachable anchor, remove the twist and
re-install the detachable anchor tongue end into
the detachable anchor until you hear a snap and
feel the latch engage.
*
[SR10040(ALL)08/95]
Procedure to Correct a Twisted Safety Belt
at the ªDº Ring (if so equipped) Front
and/or Rear Outboard Seating Positions
*
[SR10060(ALL)08/95]
NOTE: The restraint system shown in the
following figures may be different than
the restraint system in your vehicle.
However, use these figures and this
procedure to correct a twisted safety
belt at any outboard seating position
that has a ªDº ring.
*
[SR10080(ALL)08/95]
half page art:0060598-C
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

25
*
[SR10100(ALL)05/95]
1. Grasp the belt webbing at the ªDº ring. See
Figure 2.
*
[SR10120(ALL)08/95]
half page art:0060599-D
*
[SR10140(ALL)05/95]
2. Rotate and fold the belt webbing over itself
as required to remove the twist.
*
[SR10160(ALL)08/95]
3. Feed the folded portion of the belt through
the ªDº ring.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

26
*
[SR10180(ALL)05/95]
4. When completed, the safety belt should look
like Figure 3.
*
[SR10200(ALL)08/95]
half page art:0060600-D
%*
[SR10300(ALL)06/95]
Air Bag Supplemental Restraint
System (SRS)
*
[SR10600(ALL)05/95]
The driver air bag is a Supplemental Restraint
System (SRS), provided in addition to the driver
lap/shoulder belt, and is designed to
supplement the protection provided to a
properly belted driver in moderate to severe
frontal collisions. The supplemental air bag
system does not provide restraint to the lower
body.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

27 %
*
[SR10650(ALL)05/95]
The Importance of Wearing Safety Belts
*
[SR10700(ALL)06/95]
RWARNING
Safety belts must be worn by all vehicle
occupants to be properly restrained and
help reduce the risk of injury in a
collision.
*
[SR10750(ALL)05/95]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, even when an air bag Supplemental
Restraint System is provided.
*
[SR10900(ALL)01/95]
There are four very important reasons to use
safety belts even with an air bag system. Use
your safety belts to:
*
[SR11000(ALL)01/95]
q
help keep you in the proper position (away
from the air bag) when it inflates
*
[SR11100(ALL)01/95]
q
reduce the risk of harm in rollover, side or
rear impact collisions, because an air bag is
not designed to inflate in such situations
*
[SR11200(ALL)01/95]
q
reduce the risk of harm in frontal collisions
that are not severe enough to activate the
supplemental air bag
*
[SR11300(ALL)01/95]
q
reduce the risk of being thrown from your
vehicle
%*
[SR11400(ALL)01/95]
The Importance of Being Properly Seated
*
[SR11500(ALL)05/95]
In a collision, the air bag must inflate extremely
fast to help provide additional protection for
you. In order to do this, the air bag must inflate
with considerable force. If you are not seated in
a normal riding position with your back against
the seatback, the air bag may not protect you
properly and could possibly hurt you as it
inflates.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

28
*
[SR11600(ALL)08/95]
RWARNING
If a passenger is not properly seated and
restrained, an inflating air bag could cause
serious injury.
*
[SR11640(ALL)07/95]
RWARNING
Do not place objects or mount equipment
on or near the air bag cover on the
steering wheel or in front seat areas that
may come in contact with a deploying air
bag. Failure to follow this instruction may
increase the risk of personal injury in the
event of a collision.
*
[SR11650(ALL)07/95]
For further information about the proper
mounting of equipment in the front seat of this
vehicle, please refer to Ford's brochure entitled
Some Important Information About Air Bag
Supplemental Restraint Systemwhich can be
obtained by calling Helm Inc. at 1-800-782-4356.
Ask for brochure FPS-8602.
*
[SR11660(ALL)08/95]
For additional important safety information on
the proper use of seat belts, child seats, and
infant seats, please read the other sections of this
chapter of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats
for Children.
%*
[SR11800(ALL)01/95]
How the Air Bag Supplemental Restraint
System Operates
[SR11850(ALL)05/95]
The Air Bag Supplemental Restraint System
consists of the driver air bag, impact sensor, a
system diagnostic module, a readiness light and
tone, and the electrical wiring which connects
the components.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

29 [SR12000(ALL)05/94]
half page art:0020842-C
The location of the air bag and warning label
*
[SR12010(ALL)07/95]
If a collision occurs, the sensors sense the
severity of the impact and activate the air bags if
necessary. The air bag system is designed to
deploy in frontal and front-angled collisions
more severe than hitting a parked vehicle (of
similar size and weight) head-on at about
28 mph (45 km/h). Because the system senses
the crash severity rather than vehicle speed,
some frontal collisions at speeds above 28 mph
(45 km/h) will not inflate the air bag.
*
[SR12020(ALL)07/95]
When the sensors activate the system, the air
bags inflate rapidly, filling with non-toxic
nitrogen gas in a fraction of a second.
Immediately after inflation, the air bags deflate
by releasing the nitrogen gas through vent holes.
The whole process takes place in a matter of
seconds.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995

30
*
[SR12030(ALL)07/95]
RWARNING
Air bag system components get hot after
inflation. Do not touch them after
inflation.
*
[SR12040(ALL)06/95]
half page art:0011063-A
Inflated driver-side air bag
*
[SR12060(ALL)07/95]
RWARNING
If the air bag is inflated, THE AIR BAG
WILL NOT FUNCTION AGAIN AND
MUST BE REPLACED IMMEDIATELY. If
the air bag is not replaced, the unrepaired
area will increase the risk of injury in a
collision.
