1987 SUZUKI GRAND VITARA Service Repair Manual

Fig. 18-6
Fig. 18-7
2)Disconnect combination switch couplers and
remove combination switch.
3) Remove the bolt joining steering shafts in
engine room.
Fig. 18-9
4) Remove steering column ass’y.
NOTE:
l Don’t separate steering column assembly into
steering column and shaft. If column or shaft
is defective, replace as an assembly.
Fig. 18-10
1. Steering column ass’y
Fig. 18-8
18-7

Fig. 18-6
Fig. 18-7
2)Disconnect combination switch couplers and
remove combination switch.
3) Remove the bolt joining steering shafts in
engine room.
Fig. 18-9
4) Remove steering column ass’y.
NOTE:
l Don’t separate steering column assembly into
steering column and shaft. If column or shaft
is defective, replace as an assembly.
Fig. 18-10
1. Steering column ass’y
Fig. 18-8
18-7

Steering Lock
1) After removing steering column, loosen and
remove steering lock mounting bolts. Use care
not to damage aluminum part of steering
lock body with center punch.
Fig. 18-11 1. Center punch (with sharp point)2. Steering lock mounting bolts
2) Remove steering lock assembly from steering
column.
Gear Box
1) Remove joint bolt.
Fig. 18-12
2) Remove radiator under cover, and disconnect
ball stud of drag rod using special tool and
steering damper from pitman arm.
-----‘CA2
@ Special tool (Tie-rod end remover
09913-65210)
18-8
3) Steering gear box is secured in place by
mounting bolts. Remove these bolts and
take down gear box.
Fig. 18-14
Tie Rod and Tie Rod End
1) Hoist car and remove wheels.
2) Remove drag rod castle nut, and then remove
tie rod and tie rod end using special tool.
I I
Fig. 18-15 @ Special tool (Tie-rod end remover
09913-65210)
3) For ease of adjustment after installation,
mark tie rod and tie rod end to indicate lock
nut positions. Then loosen each lock nut and
separate tie rod and tie rod end.
Fig. 18-16
1. Tie rod
2. Turnbackle
3. Tie rod end
4. Locknut
5. Marking to be made
Fig. 18-13

18-5. INSPECTION OF COMPONENTS
Steering Gear Box
[Oil level]
Oil surface should be up to the level as shown
in below figures. If not, add prescribed gear oil,
SAE 90.
Right hand steering vehicle
Fig. 18-17
Left hand steering vehicle
I
35mm(1.4 in.)
Fig. 18-18
[Adjustment of worm shaft starting torque]
The steering gear box is provided with adjust-
ing bolt @ which gives preload to sector shaft.
Fig. 18-19 (1)Adjusting bolt
Make an adjustment according to the following
procedure.
1) Check worm shaft to ensure that it is free
from thrust play.
2) Position pitman arm in parallel with worm
shaft as shown below.
(With pitman arm in this position, front
wheel is in straightforward state.)
Worm shaft
Fig. 18-20
Pitman arm
18-9

3) Measure worm shaft starting torque from its
position in the straightforward state in 2),
using a spring balance and string as shown in
below figure.
StringI
Joint rubber
Spring balance (Use one with a maximummeasurement of around 5 kg (11lb.)
Fig. 18-21
Worm shaft (including
sector shaft) starting
torque (with torque
wrench)
Right-hand steering vehicle
7.5 - 13.0 kg-cm
(0.54 - 0.94 lb-ft)
6.0 - 10.0 kg-cm
(0.43 - 0.72 lb-ft)
Right-hand steering vehicle
Worm shaft (including1.97 - 3.42 kg
sector shaft) starting(4.34 - 7.53 lb)
torque (with spring
I----
balance)-
-
If measured torque is not within the specifi-
cation, carry out adjustment with adjusting
bolt @ to meet specification and check to
confirm it again.
4) If worm shaft starting torque is checked all
right, another check should be carried out on
worm shaft operating torque in its entire
operating range (turning the worm shaft all
the way to the right and left) as shown in
Fig. 18-21.
Right-hand steering vehicle
Worm shaft (includingUnder 13.0 kg-cm
sector shaft) operating(Under 0.94 lb-ft)
torque (with torqueLeft-hand steering vehicle
wrench)Under 12.0 kg-cm
(Under 0.86 lb-ft),
Right-hand steering vehicle
Worm shaft (includingUnder 3.42 kg
sector shaft) operating(Under 7.53 lb)
torque (with spring
l-----i
balance)
6.96lb)
If measured torque does not conform to
specification, readjust worm shaft starting
torque in straightforward state by means of
adjusting bolt 0, and then recheck worm
shaft operating torque.
If the specified value is not attained even
after readjustment, it is advisable to replace
the gear box with a new gear box ass’y.
Fig. 18-22
18-10

18-6. CHECKING STEERING COLUMN
FOR ACCIDENT DAMAGE
Cars involved in accidents resulting in body
damage or where the steering column has been
impacted may also have a damaged or misalign-
ed steering column.
Checking Procedure
1) Check capsules on steering column bracket;
all should be within 1.0 mm (0.039 in) from
the bottom of slots. If not, steering column
assembly should be replaced. Use thickness
gauge for convenience.
1. Capsules
Each capsule should bewithin 0 - 1.0 mm(0 - 0.039 in.) fromthe bottom of slot. Ifnot, replace columnassembly.
2. Within 0 - 1.0 mm (0-0.039 in)3. Thickness gauge
Fig. 18-23
1 “A” j
635.5 mm (25.02 in.)
Fig. 18-24
3) Take measurement “B” of steering lower
shaft as shown. If it is shorter than specified
length, replace it with new one.
(18.98 - 19.05 in.)
Fig. 18-25
4) Check steering shaft joints and shaft for any
damages such as crack, breakage, malfunction
or excessive play. If anything is found faulty,
replace.
2)Take measurement “A” as shown. If it is
shorter than specified length, replace column
assembly with new one.
Fig. 18-26
5) Check steering shaft for smooth rotation. If
found defective, replace as column assembly.
18-11

18-7. IMPORTANT STEPS IN
REINSTALLATION
NOTE:
For installation, it is important that only the
specified screws, bolts, and nuts be used as
designated and that they are tightened to the
specified torque.
Reverse removal procedure for installation,
noting the following.
Steering Lock
1) Position groove of
of hole in column.
steering shaft in the center
Fig. 18-271. Steering column
2. Steering shaft
2) Align hub on steering lock with groove of
steering shaft and rotate shaft to assure that
steering shaft is locked.
Fig. 18-281. Hub2. Groove
Fig. 18-29
4) Turn ignition key to “ACC” or “ON” position
and check to be sure that steering shaft
rotates smoothly. Also check for lock opera-
tion.
5) Install steering column. Refer to p. 18-14.
Steering Gear Box
Put steering gear box bolts through from inside
of car and tighten nuts to specified torque.
Carcenter
frame
Steering gear box nut
tightening torque
l-----i
-N.m
-
.O -
Fig. 18-29-1
3) Tighten 2 new bolts until head of each bolt is
broken off.
18-12

Steering Damper
l install steering damper with larger diameter
hole end directed toward pitman arm and hole
in outer shell downward.
l Install steering damper stay, directing its
circular boss side upward.
l Mount steering damper and steering damper
stay bolts from the top.
l Torque steering damper pin nut and damper
nut to specification while directing steering to
straightforward state (with pitman arm in
parallel with center line of car).
Upward
Steering damper
Fig. 18-29-2
