1987 SUZUKI GRAND VITARA Service Repair Manual

1. Front brake disc
2.Wheel bearing
3. Axle shaft drive flange4.Wheel hub
5.Dust cover6.Oil seal7.King pin8. King pin bearing
9.Oil seal
10.Steering knuckle
11. Disc brake holder12. Disc brake caliper
13.Shock absorber
14.Spring bumper
15. Axle shaft joint16.Leaf spring
17-3
Fig. 17-1-2

BARFIELD JOINT CONSTRUCTION AND OPERATION
The major parts of the Barfield joint are the outer race (integral with wheel spindle, to which the wheel
disc is splined), inner race (splined to the live axle shaft), six steel balls disposed between the two races,
and cage (holding the steel balls in a single row lying in a plane).
Spindle shaft
IInner raceSteel ball
The balls are fitted in two groups of raceways; one group is on the outer race and the other group on the
inner race. Each ball is in its own raceways as if it were locked between the two races in the direction of
rotation. The outer race with its wheel spindle is capable of angling and, when it so angles with respect to
the axis of axle shaft, the row of steel balls angles just half as much, that is, the plane including this row
tilts by an angle equal to one-half of the spindle angle. This relationship is illustrated in Fig. 17-1-4.
CageOuter race
Steel ball
17-4
Fig. 17-1-3
Fig. 17-1-4

REMOVAL
Shock Absorber
The shock absorber is non-adjustable, non-
refillable, and cannot be disassembled.
The only service the shock absorber requires is
replacement when it has lost its resistance, is
damaged, or leaking fluid.
1. Hoist car.
2. Loosen lower and upper mounting nuts and
remove shock absorber.
7Shacklepin
Washer
Fig. 17-1-6
Washer
Washer
by
D
Nut
Stabilizer
1. Hoist car.
2. Remove stabilizer bolts.
3. After removing stabilizer mount bush
bracket bolts, remove stabilizer.
Fig. 17-1-5
Leaf Spring
1. Raise car. In this operation, garage jack or
hoist must not be positioned against front
suspension related parts. When garage jack
is used, place safety stands under chassis to
support raised body.
2. Remove front wheel.
3. Remove stabilizer bolt.
4. Remove U-bolt nuts.
5. Remove shackle nuts and leaf spring nut.
NOTE:
Removal of leaf spring causes axle housing to
hang. Support it with safety stand to prevent it
from damaging universal joint of propeller shaft
and others.
Stabilizer
F
fBracket boltFig. 17-1-7
6. Pull out leaf spring bolt and remove leaf
spring from shackle pin.
17-5

Front Wheel Hub 81 Bearing
1. Loosen the five nuts securing the wheel.
Raise the front end by jacking.
Rest the machine steady on safety stands.
2. Remove the five nuts and take off the wheel.
Fig. 17-1-8
3. Remove the caliper with carrier by loosen-
ing carrier bolts.
NOTE:
Hang removed caliper with a wire hook or the
like so as to prevent brake hose from bending
and twisting excessively or being pulled.
Don’t operate brake pedal with caliper removed.
Fig. 17-1-9
4. Remove brake disc.
NOTE:
If brake disc can not be removed by hand, use
8 mm bolts as shown below.
f
@

[For car equipped with free wheeling hub]
5. Remove free wheeling hub cover and circlip.
Fig. 17-1-12-1 @ Circlip remover (09900-06107)
6. Remove free wheeling hub body.
Fig. 17-1-10
17-6Fig. 17-1-12-2
8mm BoltFig. 17-1-11

[For car not equipped with free wheeling hub]
5. Remove the front axle shaft cap.
6. Remove the circlip retaining the front axle
shaft drive flange on front drive shaft, using
the circlip remover @.
Fig. 17-1-12-3 @ Circlip Remover
7. Loosen securing bolts of front axle shaft
drive flange and take off drive flange.
Fig. 17-1-13
8. Straighten bent part of lock washer and
remove wheel bearing lock nut with special
tool @I.
Fig. 17-1-15 Special tool @
(Front Wheel Bearing Nut Socket
Wrench 09941-58010)
9. After loosening front wheel bearing nut
with the same special tool @I as mentioned
in the foregoing step 8, take nut and washer
off the front wheel spindle.
\
Fig. 17-1-16
10. Pull front wheel hub off the front wheel
spindle.
Fig. 17-1-17
17-7Fig. 17-1-14

11. Remove oil seal and outer race of inner
bearing or outer bearing from wheel hub.
Fig. 17-1-18
Steering Knuckle
1. Remove front wheel hub, referring to steps 1
to 10 of foregoing front wheel hub and
bearing removal.
2. Loosen bolts securing kingpins (upper &
lower). At this point, king pins mustn’t be
removed.
Fig. 17-1-19
3. Remove disc dust cover, caliper holder and
wheel spindle.
Fig. 17-1-20
4.Remove tie rod end castle nut and disconnect
tie rod end from steering knuckle with
special tool @.
Fig. 17-1-21 Special tool @ (Tie Rod End
Remover 09913-65210)
5. Remove joint seal bolts. Then remove oil seal
cover, pad, oil seal and retainer from knuckle.
Fig. 17-1-22 17-8

6. Remove lower and upper kingpins.
NOTE:
l Upper and lower kingpins, when removed,
must be marked off one from the other.
l Also make sure to check the number of
kingpin shims that were fitted on each side.
Front Axle Shaft Joint
1. To remove axle shaft joint, carry out steps 1
through 7 of steering knuckle removal (p.
17-8 and 17-9) and then follow steps 2 and
3 given below.
2. Drain oil from differential housing by loosen-
ing drain plug.
Fig. 17-1-23
7. Pull off steering knuckle,
NOTE:
When steering knuckle is pulled, lower king-
pin bearing sometimes falls off. So remove
bearing while pulling off the knuckle gradual-
ly.
Upper and lower kingpin bearings must be
also marked off one from the other.
Fig. 17-1-25
3. Pull axle shaft joint off front axle housing.
Fig. 17-1-26
Fig. 17-1-24
17-9

INSPECTION OF COMPONENT
Stabilizer and its Bush
Inspect stabilizer for damage or deformation.
If defective, replace.
Inspect bushes for damage, wear or deteriora-
tion. If defective, replace.
8

Barfield Joint
To be checked on this joint is its axial play,
which shows up when a push-and-pull motion is
given to live axle shaft and wheel spindle held in
both hands, as shown in figure. There should be
no play at all but a play of up to 1.5 mm (0.06
in.) is permissible. If play exceeds service limit,
replace it.
\/
Leaf Spring Bushes
Inspect for wear and breakage. If found defec-
tive, replace.
Front Wheel Bearing
Check front wheel bearing rollers for damage.
If anything is found wrong, replace bearing with
a new one.

17-10
Fig. 17-1-27
Fig. 17-1-28
Fig. 17-1-30
Fig. 17-1-29
