2023 CADILLAC LYRIC Owners Manual

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
32 Keys, Doors, and Windows
{Warning
The Rear Camera Mirror
(RCM) has a limited view.
Portions of the road,
vehicles, and other objects
may not be seen. Do not
drive or park the vehicle
using only this camera.
Objects may appear closer
than they are. Check the
outside mirrors or glance
over your shoulder when
making lane changes or
merging. Failure to use
proper care may result in
injury, death, or vehicle
damage.
Troubleshooting
See your dealer for service if a
blue screen and
3are
displayed in the mirror, and
the display shuts off. Also,
push the tab as indicated to
return to the automatic
dimming mode.
The Rear Camera Mirror may
not work properly or display a
clear image if:
.There is glare from the sun
or headlamps. This may
obstruct objects from view.
If needed, push the tab to
turn off the display.
.Dirt, snow, or other debris
blocks the camera lens. To
clean the rear camera, see
Windshield Wiper/Washer
0 100 or clean the lens with
a soft damp cloth.
.The camera’s mounting on
the vehicle has been
damaged, and/or the
position or the mounting
angle of the camera has
changed.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Keys, Doors, and Windows 33
Windows{
Warning
Never leave a child, a
helpless adult, or a pet alone
in a vehicle, especially with
the windows closed in warm
or hot weather.
They can be overcome by
the extreme heat and suffer
permanent injuries or even
death from heat stroke.
The vehicle aerodynamics are
designed to improve electric
range performance. This may result in a pulsing sound when
either rear window is down
and the front windows are up.
To reduce the sound, open a
front window.
Power Windows
{Warning
Children could be seriously
injured or killed if caught in
the path of a closing
window. Never leave the
remote key in a vehicle with
children. When there are
children in the rear seat, use
the window lockout switch
to prevent operation of the
windows. See Keys
07.
Press the switch to open the
window. Pull the front of the
switch up to close it.
The window switches on the
driver door control all
windows.
The power windows only
operate with the vehicle on or
in Service Mode, or when
Retained Accessory Power
(RAP) is active.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
34 Keys, Doors, and Windows
Express Window
Operation
The windows have an express
feature which allows the
windows to be lowered or
raised without holding the
switch. To automatically raise
or lower the window, pull a
window switch up or press it
down all the way and release.
Stop the window by pressing
or pulling the switch in the
same direction a second time,
or by briefly operating the
switch to the first position in
either direction.
Remote Window
Operation
If equipped, this feature allows
all the windows to be opened
remotely. If enabled in vehicle
personalization, press and
hold
Kon the remote key. To
view available settings for this
feature, touch the Settings
icon on the infotainment home
page. Select “Vehicle”to display the list of available
options and select
“Remote
Lock, Unlock, Start”.
Safety Function
This is for vehicles with the
express-up feature. If any
object is in the path of the
window when the express-up
feature is active, the window
will stop and auto-reverse to a
preset position. Weather
conditions may cause the
window to auto-reverse. The
window switch may be held up
to the second position to close
the window. The window will
return to normal operation
once the obstruction or
condition is removed.
Safety Function Override
This is for vehicles with the
express-up feature. If the
battery on the vehicle has
been recharged or
disconnected, or is not
working, the windows will need
to be reprogrammed for the
express-up feature to work. Before reprogramming,
replace or recharge the
vehicle's battery.
To program the driver window:
1. Close all doors with the vehicle on or in
Service Mode.
2. Press and hold the power window switch until the
window is fully open.
3. Pull the power window switch up until the window
is fully closed.
4. Continue holding the switch up for approximately
two seconds after the
window is completely
closed.
Window Lockout
This feature prevents the rear
passenger windows from
operating, except from the
driver position.
There is a button on the
infotainment display used to
enable or disable this feature.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Keys, Doors, and Windows 35
Sun Visors
Pull the sun visor down to
block glare. Detach the sun
visor from the center mount to
pivot to the side window or,
if equipped, extend along
the rod.
Visor Vanity Mirror
The vehicle may have vanity
mirrors and card holders on
the back of the sun visors.
Swing down the sun visor to
expose the vanity mirror.
Roof
Sunroof
1. Sunroof Switch
2. Sunshade Switch
If equipped, the sunroof only
operates when the vehicle is
on or in Service Mode or when
Retained Accessory Power
(RAP) is active. See Retained
Accessory Power (RAP)0209 Sunroof Switch
Express-Open/
Express-Close :
To
express-open the sunroof,
fully press and release
j(1).
Press the switch again to stop
it. To express-close the
sunroof, fully press and
release
g(1). Press the
switch again to stop it.
Open/Close (Manual Mode) :
To open the sunroof, press
and hold
j(1) until the
sunroof reaches the desired
position. Press and hold
g(1)
to close it.
Vent : From the closed
position, press
j(1) to vent
the sunroof.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
36 Keys, Doors, and Windows
Sunshade Switch
Express-Open/
Express-Close :To
express-open the sunshade,
fully press and release
r(2).
To express-close the
sunshade, fully press and
release
r(2). Press the
switch again to stop it.
Open/Close : To open the
sunshade, press and
hold
r(2) until the sunshade
reaches the desired position.
Press
r(2) to close the
sunshade.
When the sunroof is opened,
an air deflector will
automatically raise. The air
deflector will retract when the
sunroof is closed.
Automatic Reversal
System
The sunroof has an automatic
reversal system that is only
active when the sunroof is
operated in
express-close mode. If an object is in the path while
express closing, the reversal
system will detect an object,
stop, and open the sunroof
again slightly.
If frost or other conditions
prevent closing, override the
feature by closing the sunroof
in manual mode. To stop
movement,release the switch.
In the event of closing
difficulties like frost or other
conditions, it is possible to
override the reversal system.
To override the reversal
system, close in manual mode.
To stop the movement,
release the switch.
Dirt and debris may collect on
the sunroof seal or in the
track. This could cause an
issue with sunroof operation
or noise. It could also plug the
water drainage system.
Periodically open the sunroof
and remove any obstacles or
loose debris. Wipe the sunroof
seal and roof sealing area
using a clean cloth, mild soap,
and water. Do not remove
grease from the sunroof.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Seats and Restraints 37
Seats and
Restraints
Head Restraints
Head Restraints . . . . . . . . . . . . . 38
Front Seats
Power Seat Adjustment . . . 39
Reclining Seatbacks . . . . . . . . 40
Lumbar Adjustment . . . . . . . . . 41
Massage . . . . . . . . . . . . . . . . . . . . . . . . 41
Memory Seats . . . . . . . . . . . . . . . 42
Heated and VentilatedFront Seats . . . . . . . . . . . . . . . . . 45
Rear Seats
Rear Seats . . . . . . . . . . . . . . . . . . . . 47
Heated Rear Seats . . . . . . . . . 49
Seat Belts
Seat Belts . . . . . . . . . . . . . . . . . . . . . 50
Buckle To Drive . . . . . . . . . . . . . . . 51
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . 52
Lap-Shoulder Belt . . . . . . . . . . 54
Seat Belt Use During Pregnancy . . . . . . . . . . . . . . . . . . . 57
Seat Belt Extender . . . . . . . . . 58
Safety System Check . . . . . . 58
Seat Belt Care . . . . . . . . . . . . . . . 58 Replacing Seat Belt
System Parts after a
Crash . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Airbag System
Airbag System . . . . . . . . . . . . . . . 59
Where Are the Airbags? . . . 61
When Should an AirbagInflate? . . . . . . . . . . . . . . . . . . . . . . . 63
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . 64
How Does an Airbag Restrain? . . . . . . . . . . . . . . . . . . . . 64
What Will You See after an Airbag Inflates? . . . . . . . . 65
Passenger Sensing System . . . . . . . . . . . . . . . . . . . . . . . 66
Servicing the Airbag-Equipped
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 71
Adding Equipment to the Airbag-Equipped
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 71
Airbag System Check . . . . . . 72
Replacing Airbag System Parts after a Crash . . . . . . . 72
Child Restraints
Older Children . . . . . . . . . . . . . . . . 73
Infants and YoungChildren . . . . . . . . . . . . . . . . . . . . . . . 75 Child Restraint Systems . . . 77
Where to Put the
Restraint . . . . . . . . . . . . . . . . . . . . . 79
Lower Anchors and Tethers for Children
(LATCH System) . . . . . . . . . . . 80
Replacing LATCH System Parts After a Crash . . . . . . . 88
Securing Child Restraints (With the Seat Belt in the
Rear Seat) . . . . . . . . . . . . . . . . . . . 88
Securing Child Restraints (With the Seat Belt in the
Front Seat) . . . . . . . . . . . . . . . . . . 90

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
38 Seats and Restraints
Head Restraints
Front Seats
{Warning
With head restraints that
are not installed and
adjusted properly, there is a
greater chance that
occupants will suffer a neck/
spinal injury in a crash. Do
not drive until the head
restraints for all occupants
are installed and adjusted
properly.
The vehicle's front seats have
adjustable head restraints in
the outboard seating
positions.
Adjust the head restraint so
that the top of the restraint is
at the same height as the top
of the occupant's head. This
position reduces the chance of
a neck injury in a crash.
The height of the head
restraint can be adjusted.To raise or lower the head
restraint, press the button
located on the side of the
head restraint, and pull up or
push the head restraint down,
and release the button. Pull
and push on the head restraint
after the button is released to
make sure that it is locked in
place.
The front seat outboard head
restraints are not removable.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Seats and Restraints 39
Rear Seats
Adjusting the Rear Head
Restraint
The vehicle's rear seats have
adjustable head restraints in
all three seating positions.
The height of the head
restraint can be adjusted. Pull
the head restraint up to raise
it. Try to move the head
restraint to make sure that it
is locked in place.
To lower the head restraint,
press the button, located on
the top of the seatback, and
push the head restraint down.Try to move the head restraint
after the button is released to
make sure that it is locked in
place.
Always adjust the head
restraint so that the top of the
restraint is at the same height
as the top of the
occupant's head.
Rear head restraints are not
removable.
If you are installing a child
restraint in the rear seat, see
“Securing a Child Restraint
Designed for the LATCH
System”
under Lower Anchors
and Tethers for Children
(LATCH System) 080.
Front Seats
Power Seat
Adjustment
{Warning
You can lose control of the
vehicle if you try to adjust a
driver seat while the vehicle
is moving. Adjust the driver
seat only when the vehicle is
not moving.
{Warning
The power seats will work
with the vehicle off. Children
could operate the power
seats and be injured. Never
leave children alone in the
vehicle.
