2023 CADILLAC LYRIC Owners Manual

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
120 Instruments and Controls
system are not fully
operational and may not assist
in maintaining control. Adjust
driving accordingly. If the
condition persists, see your
dealer as soon as possible.
A Driver Information Center
(DIC) message may display.
The light flashes when the
TCS and/or the StabiliTrak/
ESC system is actively
working.
See Traction Control/
Electronic Stability Control
0221.
Driver Mode Control
Light
This light comes on when
Normal Mode is selected.
This light comes on when
Sport Mode is selected.
This light comes on when
Snow/Ice Mode is selected.
This light comes on when My
Mode is selected. See Driver
Mode Control 0223.
Tire Pressure Light
If equipped with the Tire
Pressure Monitor System
(TPMS), this light comes on
briefly when the vehicle is
started. It provides
information about tire
pressures and the TPMS.
When the Light Is On Steady
This indicates that one or
more of the tires are
significantly underinflated.
A Driver Information Center
(DIC) tire pressure message
may also display. Stop as soon
as possible, and inflate the
tires to the pressure value
shown on the Tire and
Loading Information label. See
Tire Pressure 0342.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Instruments and Controls 121
When the Light Flashes First
and Then Is On Steady
If the light flashes for about a
minute and then stays on,
there may be a problem with
the TPMS. If the problem is
not corrected, the light will
come on every time the
vehicle is started. See Tire
Pressure Monitor Operation
0344.
Security Light
The security light should come
on briefly as the vehicle is
started. If it does not come on,
have the vehicle serviced by
your dealer. If the system is
working normally, the indicator
light turns off. If the light stays on and the
vehicle does not start, there
could be a problem with the
theft-deterrent system.
Vehicle Ready Light
The vehicle ready light comes
on whenever the vehicle is
ready to be driven.
One-Pedal Driving
Light
This light comes on when
One-Pedal Driving is active.
See One-Pedal Driving
0214.
High-Beam On Light
This light comes on when the
high-beam headlamps are in
use. See Headlamp High/
Low-Beam Changer 0142.
IntelliBeam Light
If equipped, this light comes on
when the IntelliBeam system is
enabled. See Exterior Lamp
Controls 0139.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
122 Instruments and Controls
Lamps On Reminder
This light comes on when the
exterior lamps are in use,
except when only the Daytime
Running Lamps (DRL) are
active. See Exterior Lamp
Controls0139.
Cruise Control Light
The cruise control light is
white when the cruise control
is on and ready, and turns
green when the cruise control
is set and active.
Adaptive Cruise Control
Light
This light is white when the
Adaptive Cruise Control (ACC,
if equipped) is on and ready,
and turns green when the
ACC is set and active.
Curve Speed Control Light
If equipped, this light may
illuminate green when ACC is
actively controlling the vehicle
speed and detects a sharp
curve on the road ahead. ACC automatically slows the
vehicle down while navigating
the curve and may increase
speed out of the curve, but will
not exceed the set speed.
See Adaptive Cruise Control
(Advanced)
0225.
Super Cruise Light
This light comes on to show
the status of Super Cruise.
See Super Cruise 0236.
Door Ajar Light

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Instruments and Controls 123
This light comes on when a
door is open or not securely
latched. Before driving, check
that all doors are properly
closed.
Information
Displays
Charging
Important Information about
Electric Vehicle Charging
.Charging an electric vehicle
can stress a building’s
electrical system more than
a typical household
appliance.
.Charge cord limits can vary
from vehicle to vehicle, and
increased charging rates can
stress a building’s electrical
system.
.Before plugging into any
electrical outlet, have a
qualified electrician inspect
and verify the electrical
system (electrical outlet,
wiring, junctions, andprotection devices) for
heavy-duty service at a
12 amp continuous load.
.Electrical outlets may wear
out with normal usage or
may be damaged over time,
making them unsuitable for
electric vehicle charging.
.Check the electrical outlet/
plug while charging and
discontinue use if the
electrical outlet/plug is hot,
then have the electrical
outlet serviced by a qualified
electrician.
.When outdoors, plug into an
electrical outlet that is
weatherproof while in use.
.Mount the charging cord to
reduce strain on the
electrical outlet/plug.
.Do not place the charge cord
in a position where it is
expected to be submerged
in water.
{Danger
Improper use of portable
electric vehicle charge cords
may cause a fire, electrical
shock, or burns, and may
result in damage to
property, serious injury,
or death.
.Do not use extension
cords, multi-outlet power
strips, splitters, grounding
adaptors, surge
protectors, or similar
devices.
.Do not use an electrical
outlet that is worn or
damaged, or will not hold
the plug firmly in place.
.Do not use an electrical
outlet that is not properly
grounded.
.Do not use an electrical
outlet that is on a circuit
with other electrical loads.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
124 Instruments and Controls
Charging App
The Charging app gives you
access to features that will
help you better understand
and control how the vehicle
manages energy. Along with
providing a central location to
determine and review your
charging preferences, the
Charging app offers live
information on how the vehicle
is using energy.
To launch the Charging app
from the infotainment home
screen, touch the Charging
icon. There are four selections
to choose from: Charging,
Charge Assist, Schedule, and
Settings. When you launch
Charging for the first time, the
Next Charge screen will
display.
Next Charge
To view the current charging
status in the infotainment
display, touch
C.On the Next Charge screen,
there is a range of information
associated with the next
Charging session, as well as
the ability to specify when you
would like to charge the
vehicle. The choices available
to charge are Charge Now or
Charge Later.
To create a charge schedule
See
“Creating a Charge
Schedule” under“Schedule”
below. The Charging screen
shows and allows you to
determine how the vehicle
charges the next time it is
plugged in.
Charge Now
Charge Now is the default
charging mode for your
vehicle. The vehicle begins
charging immediately when it
is plugged in and
authenticated at the preferred
charging location.
With Charge Now selected,
the Charging screen displays:
.Text explaining that the
vehicle will charge
immediately when
plugged in.
.Charge Complete by/in: The
estimated time at which the
vehicle will reach the desired
Charge Level. The words by
and in will change depending
on how much time is
remaining —over an hour,
or less than an hour.
.Target Charge Level Gauge:
Sets the percentage at
which the vehicle will stop
charging. The gauge also
displays an estimate of the
vehicle's range upon
completing the charging
session.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Instruments and Controls 125
{Warning
Do not charge your vehicle’s
battery above an 80%
charge if you are going to
drive down long, steep
grades such as mountain
passes. This provides room
in the battery for
regenerative braking to
supplement your
conventional brakes during
the descent. This is
especially important when
towing a trailer, which puts
additional stress on your
vehicle’s braking system.
See Hill and Mountain Roads
0200 for important
information about driving on
grades.
The default charge level is
100% when plugged in. To set
a different charge level, drag
the circular marker on the
Target Charge Level Gauge to
the preferred value. To lower
the desired Charge Level, drag the Charge Level marker
counterclockwise, and to
increase it drag the marker
clockwise. The Charge Level
can also be changed by
tapping
«andªinside the
gauge on the screen. The
multifunction controller (MCF)
on the center console can also
be used to set the Charge
Level by rotating clockwise or
counterclockwise when the
Target Charge Level Gauge is
highlighted. The Range
estimate updates once the
desired Charge Level is set.
To optimize battery health, the
minimum allowable Charge
Level is determined by the
vehicle. Charge Later
Instead of charging
immediately to a desired
Charge Level, you may choose
to delay the charge to the
vehicle and have it complete
by your desired departure
time. This may be a more
economical choice and a more
efficient use of energy when
charging at home. To use this
mode, touch the Charge Later
tab from the Charging screen.
With Charge Later selected,
the Charging screen displays:
.Text explaining that your
vehicle will delay the planned
charge to be ready by the
time specified.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
126 Instruments and Controls
.Time Selector: Used to set
the desired time at which
the vehicle will finish
charging and be ready for
departure.
.Target Charge Level Gauge:
Sets the percentage at
which the vehicle will stop
charging. The gauge also
displays an estimate of the
vehicle's range upon
completing the charging
session.
.Cabin Pre-Conditioning:
Allows the vehicle to heat or
cool the cabin to your
desired temperature using
energy from the charger.
This means energy from the
battery is not used to
condition the cabin, ensuring
the vehicle gets the greatest
range from the charging
session. Cabin
pre-conditioning happens at
the end of the charge, and
right before the
departure time.To set the time at which the
vehicle will complete the
charge and be ready for
departure:
Swipe up or down on each
value within the Time Selector
until the preferred time is
selected. The time selector
can also be modified using the
multifunction controller (MCF)
on the center console by
turning the knob when the
preferred value is highlighted.
If the desired Charge Level
cannot be reached by the
selected time, a message will
display that one of the two
preferences will need to be
adjusted.
To adjust desired Charge
Level in Charge Later mode,
see
“Charge Now” earlier in
this section.
Setting the Cabin
Pre-Conditioning preference:
Touch the switch to turn on
Cabin Pre-conditioning. Cabin
Pre-Conditioning temperature
can be adjusted in Settings, or by touching Cabin
Pre-Conditioning on this
screen.
Active ChargingDuring an active charging
session, the Charging screen
displays and continuously
updates the following items:
.Text indicating the vehicle’s
current charging status.
.Current Range: The range
the vehicle is capable of
driving at the current charge
level.
.Range Increase Rate: How
much range is accumulating
per hour of charging.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Instruments and Controls 127
.Charge Complete at/in: The
estimated time at which the
vehicle will reach the desired
Charge Level. The words at
and in will change depending
on how much time is
remaining—over an hour,
or less than an hour.
.Target Charge Level Gauge:
During an Active Charge, the
gauge displays the vehicle's
current Charge Level as
a percentage and a colored
section of the circular gauge
to represent this value.
To update the desired Charge
Level for the active charging
session, drag the marker on
the Target Charge Level
Gauge.
Touching the Stop Charge
button at any time ends the
active charging session and
presents a summary of the
current vehicle Range, Charge
Level, and amount of Range
Gained during the charging session. For information on
beginning a charging session,
see Plug-In Charging
0285.
For Level 1 chargers, you can
also select the appropriate
Charge Cord Limit of either
8 amps or 12 amps. This
determines how much current
can flow from an electrical
outlet to the vehicle battery.
It also ensures proper charge
time estimates.
When the Charge Cord Limit is
changed from 8 amps to
12 amps on a 120V circuit a
notification is displayed.
If no Home Charge Location is
set, the Level 1 Cord Limit will
revert to 8 amps every time
the vehicle is shifted out
of (P) Park.
Range and charge time
estimates fluctuate depending
on a number of factors such
as Charge Cord Level/Limit,
battery temperature, and
outside air temperature. To learn more about the vehicle
battery see Plug-In Charging
0
285.
The peek-in charging screen
can be used to monitor your
vehicle’s charge status
remotely, see Instrument
Cluster 0108. To monitor the
charging status from outside
the vehicle, download the
myCadillac app on your mobile
device.
DC Fast Charging
The vehicle will immediately
begin charging when plugged
into a DC fast charging
station. While DC Fast
Charging, the vehicle will
bypass any schedule or
departure time selection. See
Plug-In Charging 0285.
All the Active Charging screen
information will be present.
The Charge Level Gauge will
allow you to set your desired
Charge Level for the DC fast
charge.
