23Pictorial index
Meter control switches ....................................................................P.94
Vehicle-to-vehicle distance switch .......................................P.232, 243
Cruise control switches
Dynamic radar cruise control with full-speed range*1......................P.227
Dynamic radar cruise control*1.........................................................P.238
Audio remote control switches*2..................................................P.327
Speed limiter main switch .............................................................P.252
LTA (Lane Tracing Assist) switch*1...............................................P.209
LDA (Lane Departure Alert with steering control) switch*1........P.219
Phone switch*2...............................................................................P.354
Talk switch*2...................................................................................P.354
*1: If equipped
*2: Vehicles with navigation/mu ltimedia system, refer to “Navigation and multimedia
system Owner’s manual” or “Multimedia Owner’s Manual”.
Sport mode switch*........................................................................P.314
VSC OFF switch .............................................................................P.317
Parking brake switch .....................................................................P.173
Precautions for winter season..........................................................P.322
Brake hold switch ..........................................................................P.176
*: If equipped

24Pictorial index
■Interior (right-hand drive vehicles)
SRS airbags ......................................................................................P.35
Floor mats.........................................................................................P.28
Front seats......................................................................................P.126
Head restraints ...............................................................................P.128
Seat belts ..........................................................................................P.31
Console box ...................................................................................P.398
Inside lock buttons ........................................................................ P.116
Cup holders ....................................................................................P.397
Rear seats .......................................................................................P.127

25Pictorial index
■Ceiling (right-hand drive vehicles)
Inside rear view mirror ..................................................................P.132
Sun visors*1....................................................................................P.406
Vanity mirrors .................................................................................P.406
Vanity lights*2.................................................................................P.406
Interior lights/personal lights .......................................................P.394
Moon roof switches*2.....................................................................P.139
“SOS” button....................................................................................P.64
Assist grips ....................................................................................P.407
*1: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE
AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
( P. 5 0 )
*2: If equipped

26Pictorial index

1
27
For safety and security
1
For safety and security
.1-1. For safe use
Before driving ..................... 28
For safe driving ................... 29
Seat belts............................ 31
SRS airbags ....................... 35
Exhaust gas precautions .... 43
1-2. Child safety
Airbag manual on-off system
......................................... 45
Riding with children ............ 46
Child restraint systems ....... 47
1-3. Emergency assistance
eCall ................................... 64
1-4. Theft deterrent system
Engine immobilizer system
......................................... 74
Double locking system ........ 75
Alarm .................................. 76

281-1. For safe use
1-1.For safe use
Use only floor mats designed spe-
cifically for vehicles of the same
model and model year as your vehi-
cle. Fix them securely in place onto
the carpet.
1 Insert the retaining hooks (clips)
into the floor mat eyelets.
2 Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.
Always align the marks .
The shape of the retaining hooks (clips)
may differ from that shown in the illus-
tration.Before driving
Observe the following before
starting off in the vehicle to
ensure safety of driving.
Floor mat
WA R N I N G
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly
interfering with the pedals while driv-
ing. An unexpectedly high speed may result or it may become difficult to
stop the vehicle. This could lead to an
accident, resulting in death or serious
injury.
■When installing the driver’s floor
mat
●Do not use floor mats designed for
other models or different model
year vehicles, even if they are Toyota Genuine floor mats.
●Only use floor mats designed for the driver’s seat.
●Always install the floor mat securely using the retaining hooks (clips)
provided.
●Do not use two or more floor mats
on top of each other.
●Do not place the floor mat bot-
tom-side up or upside-down.
■Before driving
●Check that the floor mat is securely
fixed in the correct place with all the provided retaining hooks (clips). Be
especially careful to perform this
check after cleaning the floor.

29
1
1-1. For safe use
For safety and security
Adjust the angle of the seatback
so that you are sitting straight up
and so that you do not have to
lean forward to steer. ( P.126)
Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. ( P.126)
Lock the head restraint in place
with the center of the head
restraint closest to the top of
your ears. ( P. 1 2 8 )
Wear the seat belt correctly.
( P. 3 1 )
WA R N I N G
●With the engine stopped and the
shift lever in P (Multidrive) or N
(manual transmission), fully depress each pedal to the floor to
make sure it does not interfere with
the floor mat.
For safe driving
For safe driving, adjust the
seat and mirror to an appropri-
ate position before driving.
Correct driving posture
WA R N I N G
■For safe driving
Observe the following precautions.
Failure to do so may result in death or serious injury.

301-1. For safe use
Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle. ( P. 3 1 )
Use a child restraint system appro-
priate for the child until the child
becomes large enough to properly
wear the vehicle’s seat belt.
( P. 4 7 )
Make sure that you can see back-
ward clearly by adjusting the inside
and outside rear view mirrors prop-
erly. ( P.132, 133)
WA R N I N G
●Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
●Do not place a cushion between the driver or passenger and the
seatback.
A cushion may prevent correct pos-
ture from being achieved, and reduce the effectiveness of the seat
belt and head restraint.
●Do not place anything under the
front seats.
Objects placed under the front seats may become jammed in the
seat tracks and stop the seat from
locking in place. This may lead to an accident and the adjustment
mechanism may also be damaged.
●Always observe the legal speed
limit when driving on public roads.
●When driving over long distances,
take regular breaks before you start
to feel tired. Also, if you feel tired or sleepy while
driving, do not force yourself to con-
tinue driving and take a break immediately.
●Take care when adjusting the seat position to ensure that other pas-
sengers are not injured by the mov-
ing seat.
●When adjusting the seat position,
do not put your hands under the seat or near the moving parts to
avoid injury. Fingers or hands may
become jammed in the seat mecha- nism.
Correct use of the seat belts
Adjusting the mirrors
