2019 NISSAN TITAN Owner´s Manual

95,000 Miles (152,000 km) or 114
Months
Dealer Name:
Date:
Mileage:
Dealer
Stamp:100,000 Miles (160,000 km) or
120 Months
Dealer Name:
Date:
Mileage:
Dealer
Stamp:105,000 Miles (168,000 km) or 126
Months
Dealer Name:
Date:
Mileage:
Dealer
Stamp:
110,000 Miles (176,000 km) or 132
Months
Dealer Name:
Date:
Mileage:
Dealer
Stamp: 115,000 Miles (184,000 km) or 138
Months
Dealer Name:
Date:
Mileage:
Dealer
Stamp:120,000 Miles (192,000 km) or 144
Months
Dealer Name:
Date:
Mileage:
Dealer
Stamp:
9-20
Maintenance and schedules

MEMO
Maintenance and schedules9-21

10 Technical and consumer information
Recommended fluids/lubricants and
capacities...................................... 10-2
Fuel recommendation ....................... 10-5
Engine oil and oil filter
recommendations (for gas engine only) .....10-7
Air conditioner system refrigerant and
oil recommendations .......................10-8
Specifications ................................. 10-10
Engine ..................................... 10-10
Wheels and tires ............................. 10-11
Dimensions and weights ...................10-12
When traveling or registering in another
country ........................................ 10-18
Vehicle identification .......................... 10-18
Vehicle Identification Number (VIN)
plate ....................................... 10-18
Vehicle identification number
(chassis number) ........................... 10-18
Engine serial number ....................... 10-19
F.M.V.S.S./C.M.V.S.S. certification label ........10-20
Emission control information label .........10-20
Tire and Loading Information label .........10-21
Air conditioner specification label ...........10-21
Installing front license plate ....................10-22Vehicle loading information
...................10-23
Terms ...................................... 10-23
Vehicle load capacity ....................... 10-24
Securing the load ........................... 10-26
Utili-track® channel system
(if so equipped) ............................. 10-27
Loading tips ................................ 10-35
Truck-camper loading information ............10-36
Crew cab models ........................... 10-36
King Cab® models .......................... 10-36
Special Body vehicles ....................... 10-36
Location for center of gravity ...............10-36
Vehicle load weight capacity ...............10-37
Measurement of weights ...................10-37
Towing a trailer ................................ 10-38
Maximum load limits ....................... 10-38
T

owing load/specification ..................10-42
Towing safety .............................. 10-47
Flat towing for 2-Wheel Drive (2WD)
vehicle (if so equipped) .....................10-63
Flat towing for 4-Wheel Drive (4WD)
vehicle (if so equipped) .....................10-63
Snowplow .................................... 10-63
Uniform tire quality grading ....................10-64

Emission control system warranty.............10-65
Reporting safety defects ......................10-66
Readiness for Inspection/Maintenance (I/M)
test (gas engine only) .......................... 10-67Event Data Recorders (EDR)
....................10-67
Owner’s Manual/Service Manual order
information ................................... 10-68

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure
described in the “Do-it-yourself ” section to determine the proper refill capacity.
Fluid typeCapacity (approximate) Recommended Fluids/Lubricants
Metric
Measure US
Measure Imperial
Measure
Fuel VK56VD
98.4 L 26 gal 21-5/8 gal • For additional information, refer to “Fuel recommendation” in this
section.
Cummins 5.0 L ———• For additional information, refer to “Recommended fluids/
lubricants and capacities” chart of the Titan Diesel Owner’s Manual.
Engine oil *1
Drain and refill
*1 For additional
information, refer to
“Changing engine
oil” in the “Do-it-
yourself ” section of
this manual. VK56VD
With oil
filter
change 6.5 L 6-7/8 qt 5-3/4 qt Gasoline engine models:
• Genuine “Nissan Motor Oil 0W-20” (or equivalent) is recommended.
• If the above motor oil (or engine oil) is not available, a synthetic
0W-20 GF-5 SN motor oil (or engine oil) may be used. Damage
caused by the use of motor oil (or engine oil) other than as recom-
mended is not covered under NISSAN’s/INFINITI’s New Vehicle Lim-
ited Warranty. For additional information, refer to “Engine oil and oil
filter recommendations (for gas engine only)” in this section.
Without
oil filter
change 6.2 L 6-1/2 qt 5-1/2 qt
Cummins 5.0 L ———Diesel engine models:
• For additional information, refer to “Recommended fluids/
lubricants and capacities” chart of the Titan Diesel Owner’s Manual.
Engine coolant
with reservoir VK56VDNon-XD
model 13.4 L 3-1/2 gal 3 gal
• Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or
equivalent
XD
model 13.2 L 3-1/2 gal 2-7/8 gal
Cummins 5.0 L ———• For additional information, refer to “Recommended fluids/
lubricants and capacities” chart of the Titan Diesel Owner’s Manual.
RECOMMENDED FLUIDS/
LUBRICANTS AND CAPACITIES
10-2Technical and consumer information

Fluid typeCapacity (approximate) Recommended Fluids/Lubricants
Metric
Measure US
Measure Imperial
Measure
Automatic Trans-
mission Fluid (ATF) 6-speed (Diesel en-
gine only)
——— • Genuine NISSAN Matic K ATF
• Using automatic transmission fluid that is not equivalent to Genu-
ine NISSAN Matic K ATF may damage the transmission or impact
transmission durability. Damage caused by the use of fluid other
than as recommended is not covered under the NISSAN New Ve-
hicle Limited Warranty.
7-speed (Gasoline en- gine only) • Genuine NISSAN Matic S ATF
• NISSAN recommends using Genuine NISSAN Matic S ATF ONLY in
NISSAN automatic transmissions. Do not mix with other fluids. Using
fluids that are not equivalent to Genuine NISSAN Matic S ATF may
damage the automatic transmission. Damage caused by the use of
fluid other than as recommended is not covered under the NISSAN
New Vehicle Limited Warranty.
Differential gear oil Front
Non-XD
model 1.25 L 2-5/8 pt 2-1/4 pt • Genuine NISSAN Differential Oil Hypoid Super-CT Synthetic GL-5
75W-90
• NISSAN recommends using Genuine NISSAN Differential Oil Hypoid
Super-CT Synthetic GL-5 75W-90 ONLY in final drive.
Do not mix with other fluids. Using fluids that are not equivalent to
Genuine NISSAN Differential Oil Hypoid Super-CT Synthetic GL-5
75W-90 may damage the differential gear. Damage caused by the
use of fluids other than as recommended is not covered under the
NISSAN’s New Vehicle Limited Warranty.
XD
model 1.51 L 3-1/4 pt 2-5/8 pt
Rear Non-XD
model 2.3 L 4-7/8 pt 4 pt
XD
model 2.6 L 5-1/2 pt 4-5/8 pt
Transfer fluid Non-XD model 1.5 L 1-5/8 qt 1-3/8 qt
• Genuine NISSAN ATF D3M
• Using fluid other than Genuine NISSAN ATF D3M (or equivalent)
may cause deterioration in driveability and transfer durability, and
may damage the transfer. Damage caused by fluids other than as
recommended is not covered by the NISSAN’s New Vehicle Limited
Warranty.
XD model
1.8 L 1-7/8 qt 1-5/8 qt
Power Steering Fluid (PSF) ——— • Genuine NISSAN PSF II or equivalent.
Technical and consumer information10-3

Fluid typeCapacity (approximate) Recommended Fluids/Lubricants
Metric
Measure US
Measure Imperial
Measure
Brake fluid ———• Genuine NISSAN Super Heavy Duty Brake Fluid *2 or equivalent
DOT 3.
*2 Available in mainland USA through a NISSAN dealer.
Multi-purpose grease ——— • NLGI No. 2 (Lithium Soap base) (or equivalent).
Air conditioning system refrigerant ———• HFO-1234yf (R-1234yf ) (or equivalent).
• For additional information, refer to “Air conditioner system refriger-
ant and oil recommendations” in this section.
Air conditioning system oil ———• Genuine NISSAN A/C System Oil Type PAG or equivalent
• For additional information, refer to “Air conditioner system refriger-
ant and oil recommendations” in this section.
Windshield-washer fluid 4.5 L 1-1/4 gal 1 gal• Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-
freeze fluid or equivalent.
10-4Technical and consumer information

FUEL RECOMMENDATION
Gas engine only
Use unleaded regular gasoline with an oc-
tane rating of at least 87 AKI (Anti-Knock
Index) number (Research octane number
91).
CAUTION
∙ Using a fuel other than that specifiedcould adversely affect the emission
control system, and may also affect
the warranty coverage.
∙ Under no circumstances should a leaded gasoline be used, because this
will damage the three-way catalyst.
∙ Do not use E-15 or E-85 fuel in your vehicle. Your vehicle is not designed to
run on E-15 or E-85 fuel. Using E-15 or
E-85 fuel in a vehicle not specifically
designed for E-15 or E-85 fuel can ad-
versely affect the emission control
devices and systems of the vehicle.
Damage caused by such fuel is not
covered by the NISSAN New Vehicle
Limited Warranty. ∙ Do not use fuel that contains the oc-
tane booster methylcyclopentadienyl
manganese tricarbonyl (MMT). Using
fuel containing MMT may adversely
affect vehicle performance and ve-
hicle emissions. Not all fuel dispens-
ers are labeled to indicate MMT con-
tent, so you may have to consult your
gasoline retailer for more details.
Note that Federal and California laws
prohibit the use of MMT in reformu-
lated gasoline.
∙ U.S. government regulations require ethanol dispensing pumps to be iden-
tified by a small, square, orange and
black label with the common abbre-
viation or the appropriate percentage
for that region.
Diesel engine only
For additional information, refer to “Fuel
recommendation” in the Titan Diesel Own-
er’s Manual.
Gasoline specifications
NISSAN recommends using gasoline that
meets the World-Wide Fuel Charter (WWFC)
specifications where it is available. Many of
the automobile manufacturers developed
this specification to improve emission con- trol system and vehicle performance. Ask
your service station manager if the gaso-
line meets the WWFC specifications.
Reformulated gasoline
Some fuel suppliers are now producing re-
formulated gasolines. These gasolines are
specially designed to reduce vehicle emis-
sions. NISSAN supports efforts towards
cleaner air and suggests that you use re-
formulated gasoline when available.
Gasoline containing oxygenates
Some fuel suppliers sell gasoline contain-
ing oxygenates such as ethanol, Methyl
Tert-butyl Ether (MTBE) and methanol with
or without advertising their presence.
NISSAN does not recommend the use of
fuels of which the oxygenate content and
the fuel compatibility for your NISSAN can-
not be readily determined. If in doubt, ask
your service station manager.
If you use oxygenate-blend gasoline,
please take the following precautions as
the usage of such fuels may cause vehicle
performance problems and/or fuel system
damage.
Technical and consumer information10-5
