DIESEL PARTICULATE FILTER (DPF)
SYSTEM
Your vehicle is equipped with a diesel par-
ticulate filter in the exhaust system. The
diesel particulate filter reduces carbon
emissions by trapping exhaust particu-
lates (soot) before they reach the tailpipe.
You must properly maintain your diesel
particulate filter in order for it to function
properly. Regeneration of the diesel par-
ticulate filter occurs automatically during
operation above 5 mph (8 km/h) and re-
quires no actions from the driver. If you do a
lot of idling or stop and go driving, pay at-
tention to maintenance messages that
alert you when you need to drive to acti-
vate the automatic regeneration process.
For additional information, refer to the “Au-
tomatic regeneration” in the “Do-it-
yourself ” section of this manual.
SELECTIVE CATALYTIC REDUCTION
SYSTEM
Your vehicle is equipped with a selective
catalytic reduction system designed to re-
duce emission levels of nitrogen oxides
from the exhaust of your diesel engine. This
system relies on the use of Diesel Exhaust
Fluid (DEF) that you must replenish at cer-
tain intervals. Failure to maintain proper
DEF levels or if the DEF becomes contami-
nated will result in vehicle speed limitation
to 5 mph. For additional information, refer
to “Meters and gauges” in the “Instrument
panel” section and “Recommended
fluids/lubricants and capacities” in the “Ca-
pacities and specifications” section of this
manual.
1-4Introduction

NISSAN CARES . . .
Both NISSAN and your NISSAN dealer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your
NISSAN dealer are our primary concerns. YourNISSAN dealer is always available to assist you with all your automobile sales and service
needs.
However, if there is something that your
NISSAN dealer cannot assist you with or
you would like to provide NISSAN directly
with comments or questions, please con-
tact the NISSAN Consumer Affairs Depart-
ment using our toll-free number:
For U.S. customers
1-800-NISSAN-1
(1-800-647-7261)
For Canadian customers 1-800-387-0122 The Consumer Affairs Department will ask
for the following information:
– Your name, address, and telephone
number
– Vehicle identification number (attached to the top of the instrument panel on the
driver’s side)
– Date of purchase
– Current odometer reading
– Your NISSAN dealer’s name
– Your comments or questions
OR You can write to NISSAN with the informa-
tion at:
For U.S. customers
Nissan North America, Inc.
Consumer Affairs Department
P.O. Box 685003
Franklin, TN 37068-5003
or via e-mail at:
[email protected]
For Canadian customers Nissan Canada Inc.
5290 Orbitor Drive
Mississauga, Ontario L4W 4Z5
or via e-mail at:
[email protected]
If you prefer, visit us at:
www.nissanusa.com (for U.S. customers)
or
www.nissan.ca (for Canadian customers)
We appreciate your interest in NISSAN and thank you for buying a quality NISSAN vehicle.
NISSAN CUSTOMER CARE PROGRAM

2 Instrument Panel
Meters and gauges..............................2-2
Warnings lights, indicator lights, meters
and gauges ..................................2-2 Vehicle information display warnings
and indicators
................................2-4
Resetting the oil control system ..............2-8

WARNINGS LIGHTS, INDICATOR
LIGHTS, METERS AND GAUGES
These lights, meters and gauges are spe-
cific to the diesel engine.1. Low Diesel Exhaust Fluid (DEF) warning
light
2. Diesel Particulate Filter (DPF) warning light
3. Vehicle information display 4. Water in Fuel warning light
5. Malfunction warning light (red)
LIC3469
METERS AND GAUGES
2-2Instrument Panel

Low Diesel Exhaust Fluid (DEF)
warning light
When this warning light illuminates, the
DEF fluid needs to be topped off.
For additional information, refer to the “Fuel
and refueling” section of this manual.
Diesel Particulate Filter (DPF)
warning light
When the warning light illuminates, it indi-
cates that particulate matter is accumu-
lated to the specified amount of the limit in
the filter and the filter needs to regenerate.
For additional information, refer to “Diesel
Particulate Filter (DPF)” in the “Maintenance”
section of this manual.
CAUTION
If you continue driving with the DPF
warning light on without performing
the filter regeneration, this will lead to
particle matter overload in the filter. If
this happens, the Malfunction Indicator
Light (MIL) will turn on to indicate the
necessity that a NISSAN or qualified
dealer performs the service regenera-
tion. The performance of the engine
might be limited to protect the DPF
system.
Vehicle information display
The vehicle information display shows vari-
ous meters and gauges that pertain to the
diesel engine. The information that can be
found within the vehicle information dis-
play is as follows:
Exhaust temperature gauge
The exhaust temperature gauge is part of
the Auxiliary Gauges in the vehicle informa-
tion display.
Turbo meter
The turbo meter shows the amount of en-
gine boost.Diesel Exhaust Fluid (DEF) LEVEL
This gauge indicates the level of DEF in the
diesel system.
The DEF LEVEL information screen can be
turned on or off in the vehicle information
display. For additional information, refer to
“How to use the vehicle information dis-
play” in the “Vehicle information display”
section of the Titan Owner’s Manual.
Water in Fuel warning light
If this light illuminates, pull off of the road in
a safe area, stop the engine and immedi-
ately drain the water from the fuel sedi-
ment filter. For additional information, refer
to “Draining water” in the “Do-it-yourself ”
section of this manual.
Malfunction warning light (red)
If the warning light illuminates this indi-
cates either coolant temperature is above
a critical threshold or the exhaust tem-
peratures are above a critical threshold.
When illuminated this lamp indicates the
need to stop the engine as soon as it can
be safely done. The engine must remain
shut down until the engine can be repaired.
Instrument Panel2-3

VEHICLE INFORMATION DISPLAY
WARNINGS AND INDICATORS
1. DEF Low XX% Refill Soon
2. DEF Low XX% Limited Engine PowerSoon 3. DEF Low Limited Engine Power In XX
Miles
4. DEF Empty 5mph Limit Soon See Own- er’s Manual
5. DEF Empty Refill DEF See Owner’s Manual 6. DEF System Error See Dealer
7. DEF System Error 5MPH Speed Limit
XXX Miles
8. DEF System Error 5MPH Speed Limit Soon
LIC4100
2-4Instrument Panel

9. DEF System Error 5MPH Speed LimitSee Dealer
10. Exhaust Filter Overloaded See Owner’s Manual For Drive Pattern
11. Exhaust Filter Regeneration Started
12. Exhaust Filter Overloaded Engine Power Reduced See Owner’s Manual
13. Exhaust Filter Overloaded Immediate Service Required
14. Engine Warming Keep Foot on Brake
15. Engine Shutdown Stop Safely
16. Engine Power Reduced
17. Service Air Filter
18. Engine Oil Service Due XX
19. Coolant Level Low: See Owner’s Manual
20. Low Fuel Pressure: See Owner’s Manual
DEF Low XX% Refill Soon
This message appears when the DEF be-
comes low. It is recommended that the
DEF be topped off. For additional informa-
tion, refer to “Diesel Exhaust Fluid (DEF)” in
the “Fueling and refueling” section of this
manual. DEF Low XX% Limited Engine Power
Soon
This message appears as the DEF be-
comes low. Engine power will be limited
soon. It is recommended that the DEF be
topped off. For additional information, refer
to “Diesel Exhaust Fluid (DEF)” in the “Fueling
and refueling” section of this manual.
DEF Low Limited Engine Power In XX
Miles
This message appears when the DEF be-
comes low. Engine power will be limited in
the approximate distance shown. It is rec-
ommended that the DEF be topped off. For
additional information, refer to “Diesel Ex-
haust Fluid (DEF)” in the “Fueling and refuel-
ing” section of this manual.
DEF Empty 5mph Limit Soon See Own-
er’s Manual
This message appears when the DEF be-
comes empty. It is recommended that the
DEF be refilled as soon as possible. The
following conditions will limit the vehicle
speed when this message is shown:
∙ Engine shutdown and restart
∙ Engine is idled for approximately 1 hour ∙ Control module detects a fuel level in-
crease For additional information, refer
to “Diesel Exhaust Fluid (DEF)” in the “Fu-
eling and refueling” section of this
manual.
DEF Empty Refill DEF See Owner’s
Manual
This message appears when the DEF is
empty and the vehicle speed is reduced to
a maximum of 5 mph. It is recommended
that the DEF be refilled as soon as possible.
For additional information, refer to “Diesel
Exhaust Fluid (DEF)” in the “Fueling and re-
fueling” section of this manual.
DEF System Error See Dealer
This message appears when the DEF sys-
tem encounters an error. It is recom-
mended that you have the system
checked by a NISSAN dealer or other quali-
fied technician. For additional information,
refer to “Diesel Exhaust Fluid (DEF)” in the
“Fueling and refueling” section of this
manual.
Instrument Panel2-5
