2019 NISSAN TITAN keyless entry

3 Pre-driving checks and adjustments
Keys.............................................3-2NISSAN Intelligent Key® .......................3-2
NISSAN Vehicle Immobilizer System
keys..........................................3-4
Doors ...........................................3-5
Locking with key ..............................3-6
Locking with inside lock knob ................. 3-7
Locking with power door lock switch ......... 3-7
Rear doors (King Cab® models) ...............3-8
Automatic door locks (if so equipped) ........3-9
Child safety rear door lock
(if so equipped) .............................. 3-10
NISSAN Intelligent Key® ......................... 3-10
Operating range ............................. 3-12
Door locks/unlocks precaution ..............3-12
NISSAN Intelligent Key® Operation ...........3-13
How to use the remote keyless entry
function ..................................... 3-16
Warning signals ............................. 3-21
Troubleshooting guide ......................3-22
Remote Engine Start (if so equipped) ...........3-24
Remote Engine Start operating range .......3-24
Remote starting the vehicle .................3-25Extending engine run time
..................3-25
Canceling a Remote Engine Start ............3-25
Conditions the Remote Engine Start will
notwork .................................... 3-26
Hood ........................................... 3-27
Fuel-filler door .................................. 3-27
Diesel fuel engines .......................... 3-28
Gasoline fuel engines ........................ 3-28
Steering wheel ................................. 3-30
Manual operation (if so equipped) ...........3-31
Automatic operation (if so equipped) ........3-31
Sun visors ...................................... 3-32
Vanity mirrors (if so equipped) ...............3-33
Card holder (driver’s side only) ...............3-33
Mirrors ......................................... 3-33
Manual anti-glare rearview mirror
(if so equipped) .............................. 3-33
Automatic anti-glare rearview mirror
(if so equipped) .............................. 3-34
Outside mirror

s ............................. 3-35
Truck box ....................................... 3-39
Tailgate...................................... 3-39
Tie down hooks ............................. 3-43

If a door handle is pulled while unlocking
the doors, that door may not be unlocked.
Returning the door handle to its original
position will unlock the door. If the door
does not unlock af ter returning the door
handle, push the door handle request
switch to unlock the door.
All doors will be locked automatically un-
less one of the following operations is per-
formed within one minute af ter pushing
the request switch.∙ Opening any door.
∙ Pushing the ignition switch.
The interior light timer illuminates for a pe-
riod of time when a door is unlocked and
the room light switch is in the DOOR posi-
tion.
The interior light can be turned off without
waiting by performing one of the following
operations: ∙ Placing the ignition switch in the ON po- sition.
∙ Locking the doors and tailgate lock (if so equipped) with the remote control.
∙ Switching the room light switch to the OFF position. ∙ Switching the “Auto Room Lamp” to the
OFF position in Vehicle Settings of the
vehicle information display. For addi-
tional information, refer to “Vehicle in-
formation display” in the “Instruments
and controls” section of this manual.
HOW TO USE THE REMOTE
KEYLESS ENTRY FUNCTION
The remote keyless entry function can op-
erate all door locks using the remote key-
less function of the Intelligent Key. The re-
mote keyless function can operate at a
distance of 33 f t (10 m) away from the ve-
hicle. The operating distance depends
upon the conditions around the vehicle.
The remote keyless entry function will not
function under the following conditions:
∙ When the Intelligent Key is not within the operational range.
∙ When the Intelligent Key battery is dis- charged.
∙ When the doors are open or not closed securely.
CAUTION
When locking the doors using the Intel-
ligent Key, be sure not to leave the key in
the vehicle.
3-16Pre-driving checks and adjustments

NOTE:
If the ignition switch is in the OFF posi-
tion, the park lights will turn off af ter the
events above occur. If ignition switch is
in the ON position, lights will stay on for
45 seconds af ter trailer light check. If the
trailer lights do not work properly, check
the connections and bulbs. If the vehicle
lights do not turn on, check the bulbs. If
the trailer light check routine fails to
start, ensure the following vehicle condi-
tions:∙ The vehicle is NOT moving, 0 mph (0 km/h)
∙ Brake switch is NOT depressed
∙ Lef t or right flasher is OFF
∙ Trailer light check configuration is NOT disabled and available in the meter
towing settings
∙ The hazard switch is NOT turned ON
∙ The shif t position is fully in P (Park) posi- tion
∙ Vehicle is within Remote Keyless Entry range
Answer back horn feature
If desired, the answer back horn feature
can be deactivated using the Intelligent
Key. When it is deactivated and the
LOCK
button is pressed, the hazard
indicator lights flash twice. When the
UNLOCK
button is pressed, neither
the hazard indicator lights nor the horn
operates. NOTE:
If you change the answer back horn and
light flash feature with the Intelligent
Key while the ignition is in the ON posi-
tion, the vehicle information display
screen will show the previous mode. The
vehicle information display screen will
show the current mode af ter the ignition
switch has been cycled from the OFF to
the ON position. The vehicle information
display screen can also be used to
change the answer back horn mode. For
additional information refer to “Vehicle
information display ” in the “Instruments
and controls” section of this manual.
To deactivate:
Press and hold the
andbuttonsfor at least 2 seconds.
The hazard indicator lights will flash three
times to confirm that the answer back
horn feature has been deactivated.
To activate: Press and hold the
andbuttonsfor at least 2 seconds
once more.
The hazard indicator lights will flash once
and the horn will sound once to confirm
that the horn beep feature has been reac-
tivated.
LPD2878
3-20Pre-driving checks and adjustments

SYSTEM MAINTENANCE
The sonar sensors1are located on the
front and rear bumpers. Always keep the
area near the sonar sensors clean.
The sonar sensors may be blocked by tem-
porary ambient conditions such as splash-
ing water, mist or fog.
The blocked condition may also be caused
by objects such as ice, frost or dirt ob-
structing the sonar sensors.
Check for and remove objects obstructing
the area around the sonar sensors. Do not attach stickers (including transpar-
ent material), install accessories or apply
additional paint near the sonar sensors.
Do not strike or damage the area around
the sonar sensors. It is recommended that
you consult a NISSAN dealer if the area
around the sonar sensors is damaged due
to a collision.
FREEING A FROZEN DOOR LOCK
To prevent a door lock from freezing, apply
de-icer through the key hole. If the lock
becomes frozen, heat the key before in-
serting it into the key hole or use the re-
mote keyless entry key fob.
ANTIFREEZE
In the winter when it is anticipated that the
temperature will drop below 32°F (0°C),
check the antifreeze to assure proper win-
ter protection. For additional information,
refer to “Engine cooling system” in the “Do-
it-yourself ” section of this manual.
BATTERY
If the battery is not fully charged during
extremely cold weather conditions, the
battery fluid may freeze and damage the
battery. To maintain maximum efficiency,
the battery should be checked regularly.
For additional information, refer to “Battery”
in the “Do-it-yourself ” section of this
manual.
LSD2471
COLD WEATHER DRIVING
5-68Starting and driving

Front air bag system
(See supplemental restraint
system)..................1-60, 1-75
Front and rear sonar system ........5-63
Front-door pocket ...............2-71
Front power seat adjustment ........1-5
Frontseats....................1-2
Fuel Capacities and recommended
fuel/lubricants...............10-2
Fuel economy ...............5-44
Fuel gauge ..................2-9
Fueloctanerating.............10-7
Fuel recommendation ..........10-5
Loose fuel cap warning .........2-40
Fuel Cell Vehicle (FCV) System Tire pressure ................8-35
Fuelefficientdrivingtips...........5-43
Fuel-filler door .................3-27
Fuel gauge ....................2-9
Fuses .......................8-23
Fusiblelinks...................8-25
G
Garage door opener, HomeLink® Universal
Transceiver . .2-89, 2-90, 2-91, 2-92, 2-92, 2-93
Gauge Automatic transmission fluid
temperature gauge ............2-10
Engine coolant temperature gauge . .2-8
Engine oil pressure gauge .....2-10,2-11
Fuel gauge ..................2-9
Odometer ..................2-7
Speedometer ................2-7 Tachometer
.................2-8
Trip odometer ................2-7
Voltmeter ..................2-11
General maintenance .............9-2
Glovebox....................2-75
Grocery hooks .................2-81
H
Hazard warning flasher switch ........6-2
Headlightaimingcontrol ..........2-52
Headlight and turn signal switch ......2-49
Headlightcontrolswitch...........2-49
Headlights ...................8-29
Headlights,aimingcontrol..........2-52
Headrestraints................ .1-10
Heatedrearseats...............2-57
Heatedseats..................2-56
Heated steering wheel switch .......2-59
Heater Heater and air conditioner (automatic)
(if so equipped) ..............4-38
Heater and air conditioner controls . .4-39
Heater operation ..........4-31, 4-40
Heater and air conditioner (automatic) . .4-38
Hill descent control switch ..........2-61
Hill descent control system .........5-61
Hill start assist system ............5-62
HomeLink® Universal Transceiver . .2-89, 2-90, 2-91, 2-92, 2-92, 2-93
Hood .......................3-27
Hook Luggage hook ...............2-82
Horn.......................2-54 I
Ignition switch Push-button ignition switch .......5-11
Immobilizer system ..........2-44,5-14
Important vehicle information label . . .10-20
In-cabinmicrofilter ..............8-21
Increasing fuel economy ..........5-44
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) .................2-17,2-23
Informationdisplay............. .2-26
Inside automatic anti-glare mirror .....3-34
Instrument brightness control .......2-53
Instrument panel .............0-8,2-4
Instrument paneldimmer

switch.....2-53
Intelligent Around View Monitor .......4-11
Intelligent Key system Key operating range ............3-12
Key operation ................3-13
Mechanical key ...............3-4
Remote keyless entry operation ....3-16
Troubleshooting guide ..........3-22
Warning signals ..............3-22
Interiorlight...................2-87
ISOFIX child restraints .............1-29
J
Jumpstarting..............6-14,8-18
K
Key.........................3-2
11-3

Key fob battery replacement........8-27
Keyless entry With Intelligent Key system
(See Intelligent Key system) .......3-16
Keys NISSAN Intelligent Key® .......3-2,3-10
NISSAN Vehicle Immobilizer System
keys......................3-4
L
Labels Air conditioner specification label . . .10-21
C.M.V.S.S. certification label .......10-20
Emission control information label . .10-20
Engine serial numbe r..........10-19
F.M.V.S.S. certification label .......10-20
Tire and Loading Information label . .10-21
Vehicle identification number (VIN) . .10-18
Vehicle identification number (VIN)
plate.....................10-18
Warning labels (for SRS) .........1-80
LATCH (Lower Anchors and Tethers for
CHildren)System............... .1-29
License plate Installing the license plate .......10-22
Light Airbagwarninglight........1-81, 2-22
Brakelight(Seestoplight)........8-32
Bulb check/instrument panel ......2-17
Bulb replacement .............8-32
Charge warning light ...........2-19
Console light ................2-88
ExteriorandInteriorlights........8-32 Foglights..................8-29
Foglightswitch..............2-54
Headlight and turn signal switch
....2-49
Headlightcontrolswitch.........2-49
Headlights .................8-29
Interiorlight.................2-87
Lightbulbs.................8-29
Low tire pressure warning light .....2-20
Low windshield-washer fluid warning
light......................2-38
Passenger air bag and status light . . .1-63
Personal lights ...............2-89
Security indicator light ..........2-25
Warning/indicator lights and audible
reminders ...............2-17,2-23
Lights......................8-29 Maplights..................2-88
Lock Child safety rear door lock ........3-10
Door locks ................3-5,3-6
Power door locks ..............3-7
Loose fuel cap warning ...........2-40
Lowfuelwarninglight.........2-22,2-37
Low tire pressure warning light .......2-20
Low windshield-washer fluid warning
light........................2-38
Luggage hook .................2-82
Luggage
(See vehicle loading information) .....10-23
M
Maintenance General maintenance ...........9-2 Insidethevehicle..............9-3
Maintenance precautions
.........8-2
Outsidethevehicle.............9-2
Seat belt maintenance ..........1-23
Under the hood and vehicle .......9-4
Maintenance log ................9-18
Maintenance requirements ..........9-2
Maintenance schedules ............9-7
Malfunctionindicatorlight......2-22,2-24
Manual front seat adjustment ........1-4
Maplights....................2-88
Map pocket ...................2-72
Memory Seat ..............3-43,3-45
Meters and gauges ...........2-6,2-10
Instrument brightness control .....2-53
Mirror Automatic anti-glare inside mirror. . .3-34
Outsidemirrors..............3-35
Rearview...................3-33
Vanitymirror................3-33
Mirrors......................3-33
Moving Object Detection (MOD) ......4-24
N
NissanConnect® Owner's Manual ......
4-
2
NISSAN Intelligent Key® .........3-2,3-10
NISSAN Vehicle Immobilizer
System..................2-44,5-14
O
Octane rating (See fuel octane rating) . . .10-7
Odometer ....................2-7
11-4
