2018 SUBARU WRX Owners Manual

(132,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Power window operation by
driver!Driver’s side power window
switches1) Lock switch
2) For driver’s window (with one-touch auto
up and down feature)
3) For front passenger’s window (with one-
touch auto up and down feature)
4) For rear left window
5) For rear right windowYou can control all the door windows by the
power window switch cluster at the driver
side door.!Operating the driver’s/front pas-
senger’s window
1) Automatically open/close
2) Open/closeTo open:
Press the switch down lightly and hold it.
The window will open as long as the switch
is held.
Press the switch down until it clicks and
release it, and the window will fully open.
To stop the window halfway, pull the switch
up lightly.
To close:
Pull the switch up lightly and hold it. The
window will close as long as the switch is
held.
Pull the switch up until it clicks and release
it, and the window will fully close. To stopthe window halfway, press the switch down
lightly.
NOTEWhen the following operations are
performed, the power window breaker
will operate and it may not be possible
to open or close the window.
.After the driver’s or front passen-
ger’s window is fully closed or fully
opened, the switch is continuously
operated in the same direction for a
few seconds.
.After the windows for three or more
seats are fully closed or fully opened,
each switch is continuously operated
in the same direction simultaneously
for a few seconds.
In this case, after the breaker recovers,
be sure to initialize the power windows.
If they are not initialized, the one-touch
auto up/down function will not operate.
Refer to“Initialization of power win-
dow”F2-35.
Keys and doors/Windows
2-32

(133,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Anti-entrapment function
CAUTION
.Never attempt to test this func-
tion using fingers, hands or other
parts of your body.
.The anti-entrapment function
may not operate properly if some
object gets trapped just before
the window fully closes.NOTE.If a window detects an impact similar
to that caused by trapping an object (for
example, when the vehicle encounters
a deep pothole), the anti-entrapment
function may operate.
.The window cannot be operated for a
few seconds after the anti-entrapment
function operates.
While closing the driver’s or front passen-
ger’s window automatically, if the window
senses a substantial enough object
trapped between the window and the
window frame, it automatically moves
down slightly and stops.!Operating the rear windows
To open:
Press the appropriate switch down and
hold it until the window reaches the desired
position.
To close:
Pull the switch up and hold it until the
window reaches the desired position.!Locking the passengers’windows
1) Lock
2) UnlockTo lock:
Press the lock switch. When the lock
switch is in the lock position, the passen-
gers’windows cannot be opened or
closed.
To unlock:
Press the lock switch again.
–CONTINUED–
Keys and doors/Windows
2-33
2

(134,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Power window operation by
passengers!Passenger’s side power window
switchesEach passenger window can be controlled
by the power window switch located on the
door.!Operating the front passenger’s
window
1) Automatically open/close
2) Open/closeTo open:
Press the switch down lightly and hold it.
The window will open as long as the switch
is held.
Press the switch down until it clicks and
release it, and the window will fully open.
To stop the window halfway, pull the switch
up lightly.
To close:
Pull the switch up lightly and hold it. The
window will close as long as the switch is
held.
Pull the switch up until it clicks and release
it, and the window will fully close. To stopthe window halfway, press the switch down
lightly.
!Anti-entrapment function
Refer to“Anti-entrapment function”F2-
33.
!Operating the rear passenger’s
windows
To open:
Press the switch down and hold it until the
window reaches the desired position.
To close:
Pull the switch up and hold it until the
window reaches the desired position.
When the lock switch on the power window
switch cluster, located on the driver’s side
door, is in the lock position, the passen-
gers’windows cannot be operated with the
Keys and doors/Windows
2-34

(135,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
passengers’switches.&Off delay functionYou can operate the front windows for
approximately 42 seconds even after turn-
ing the ignition switch from the“ON”
position to the“ACC”or“OFF”position. If
a front door is opened within 42 seconds,
the off delay function is canceled.&Initialization of power windowIf the vehicle’s battery is disconnected due
to situations such as battery or fuse
replacement, the following functions will
be deactivated.
.One-touch auto up/down function
.Anti-entrapment function
Initialize the driver’s and front passenger’s
power window using the following proce-
dure to reactivate these functions.
1. Close the door.
2. Turn the ignition switch to the“ON”
position.
3. Open the window halfway by pressing
down the power window switch.
4. Pull up the power window switch and
close the window completely. Continue
pulling up the switch for approximately 1
second after the window is closed com-
pletely.5. Open the window completely by fully
pressing down the power windows switch.
It is necessary to repeat the same initi-
alization procedure for both driver’s and
front passenger’s window switches.
Trunk lid
WARNING
.To prevent dangerous exhaust
gas from entering the vehicle,
always keep the trunk lid closed
while driving.
.Help prevent children, adults or
animals from locking themselves
in the trunk. On hot or sunny
days, the temperature in the trunk
could quickly become high en-
ough to cause death or serious
heat-related injuries including
brain damage to anyone locked
inside, particularly for small chil-
dren.
.When leaving the vehicle, close
all windows and lock all doors.
Also make certain that the trunk
is closed.
–CONTINUED–
Keys and doors/Trunk lid
2-35
2

(136,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
CAUTION
TYPE RA:
.Make sure to press the trunk lid
lightly on its outer surface.
.Do not hold or push the rear wing
when closing the trunk lid.&To open and close the trunk
lid from outsideTo open the trunk lid from outside, use the
keyless access function or remote keyless
entry system. For details, refer to the
following section.
.For models with“keyless access with
push-button start system”, refer to“Open-
ing trunk”F2-11.
.For models without“keyless access
with push-button start system”, refer to
“Opening the trunk lid”F2-20.
To close the trunk lid, lightly press the trunk
lid down until the latch engages.
NOTE.Do not leave your valuables in the
trunk when you leave your vehicle.
.You can disable the“
”button on
the access key fob/transmitter. Contact
your SUBARU dealer to change the
setting.
&To open the trunk lid from
insideTrunk opener switchPress the trunk opener switch for more
than 1 second.NOTEThe trunk lid will not open when the
select lever is in a position other than
the“P”position (CVT models) or thevehicle is moving.
&Internal trunk lid release
handleThe internal trunk lid release handle is a
device designed to open the trunk lid from
inside the trunk. In the event children or
adults become locked inside the trunk, the
handle allows them to open the lid. The
handle is located on the inside of the trunk
lid.To open the trunk lid from inside the trunk,
pull the yellow handle as indicated by the
arrow on the handle. This operation
unlocks the trunk lid. Then, push up the lid.
The handle is made of material that
remains luminescent for approximately
an hour in the dark trunk space after it is
Keys and doors/Trunk lid
2-36

(137,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
exposed to ambient light even for a short
time.
WARNING
Never allow any child to get in the
trunk and play with the release
handle. If the driver starts the vehi-
cle without knowing that a child is
inside the trunk and the child opens
the lid using the release handle, the
child could fall out and be killed or
seriously injured.
CAUTION
.Do not close the lid while gripping
the release handle. The handle
may be damaged.
.Do not use the handle as a hook
to fasten straps or ropes to
secure your cargo in the trunk.
Such use may result in damage of
the handle.
.Load the trunk so that cargo
cannot strike the release handle.
If the cargo hits the handle while
the vehicle is being driven, the
handle may be pulled and the
trunk lid may open. That may
cause cargo to fall out of the
trunk, which could create a trafficsafety hazard.
!Inspection
Perform the following steps at least twice a
year to check the release handle for
correct operation.
1. Open the trunk lid.
2. Use a flat-head screwdriver with a thin
blade. Slide the flat-head screwdriver
blade from the slit aperture of the lock
assembly fully to the end until you hear a
click.
This places the latch in the locked position.3. Move the release handle, from outside
the vehicle, in the direction of the arrow to
check if the latch is released.
If the latch is not released, contact your
–CONTINUED–
Keys and doors/Trunk lid
2-37
2

(138,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
SUBARU dealer.
In that case, use the key to release the
latch, then close the trunk lid.
Also, if the movement of the release
handle feels restricted or not entirely
smooth during operation, or the handle
and/or handle base is cracked, contact
your SUBARU dealer.
Moonroof (if equipped)
WARNING
Never let anyone’s hands, arms,
head or any objects protrude from
the moonroof. A person could be
seriously injured if the vehicle stops
suddenly or turns sharply or if the
vehicle is involved in an accident.
To avoid serious personal injury
caused by accidental, child’s mis-
chief, or improper operation, the
driver is responsible for obeying
the following instructions without
exception.
.Before closing the moonroof,
make sure that no one’s hands,
arms, head or other objects will
be accidentally caught in the
moonroof.
.Always carry the key when you
leave the vehicle for safety rea-
sons and never allow an unat-
tended child to remain in the
vehicle. Failure to follow this
procedure could result in injury
to a child operating the moon-
roof.
.Never try to check the anti-en-trapment function by deliberately
placing part of your body in the
moonroof.
CAUTION
.Do not sit on the edge of the open
moonroof.
.Do not operate the moonroof if
falling snow or extremely cold
conditions have caused it to
freeze shut.
.The anti-entrapment function
does not operate when the moon-
roof is being tilted down. Be sure
to confirm that it is safe to do so
before tilting the moonroof down.
.If the moonroof does not close,
we recommend that you have the
system checked by a SUBARU
dealer.
The moonroof has both tilting and sliding
functions.
The moonroof operates only when the
ignition switch is in the“ON”position.
Keys and doors/Moonroof
2-38

(139,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Moonroof switches!Tilting moonroof1) Raise
2) LowerThe tilting function is activated only when
the moonroof is fully closed.
To raise:
Press and hold the rear side of the“UP/
DOWN”switch for a short time. The
moonroof raises completely.
To lower:
Press and hold the front side of the“UP/
DOWN”switch until the preferred position
has reached.
Release the switch after the moonroof has
been raised or has been lowered comple-tely. Pressing the switch continuously may
cause damage to the moonroof.
NOTEOne-touch operation does not take
place when the moonroof is lowered.
Press the switch continuously to lower
the moonroof.
!Sliding moonroof1) Open
2) CloseTilt down the moonroof completely before
performing the sliding operation.
To open:
Press the rear side of the“OPEN/CLOSE”
switch. The sun shade will also be opened
together with the moonroof. The moonroof
will stop once at a midway position. Pressthe rear side of the switch again to open
the moonroof completely.
To close:
Press the front side of the“OPEN/CLOSE”
switch.
To stop the moonroof at a selected mid-
way position while opening or closing it,
momentarily push the switch to the
“OPEN”side or“CLOSE”side.
After washing the vehicle or after it rains,
wipe away water on the roof prior to
opening the moonroof to prevent drops of
water from falling into the passenger
compartment.
NOTEDriving with the moonroof fully open
can cause an annoying sound to be
generated at high speeds. If this oc-
curs, use the moonroof at the midway
stop position when the moonroof is
opened.
–CONTINUED–
Keys and doors/Moonroof
2-39
2
