AM and FM broadcast sound quality is now
crystal clear, with AM sound quality that
virtually matches FM quality of the past,
and FM broadcasts that have near CD-
level sound quality.HD Radio Technology manufactured un-
der license from iBiquity Digital Corpora-
tion. Foreign Patents. HD Radio
TM
and the
HD, HD Radio, and“Arc”logos are
proprietary trademarks of iBiquity Digital
Corp.
FM stations can provide additional digital-only audio programming on HD2/HD3
Channels.
!Available HD Radio
TM
technology (if
equipped)
!Multicast
On the FM radio frequency most digital
stations have“multiple”or supplemental
programs on one FM station.
1. Touch the“Sub CH”key on the control
screen and the following screen will be
displayed.
2. The indication that shows whether the
current broadcast is digital or analog is
displayed on the top right of the control
screen.3. Select the desired channel.
Turning the AUDIO/TUNE knob can also
Audio/Audio set
5-30

(275,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
select the desired multicast channel.NOTE.HD Radio
TM
stations can be preset.
.An orangewill be displayed on the
screen when in digital. The
will first
appear in a gray color indicating the
station is indeed (an analog and) a
digital station. Once the digital signal
is acquired, the logo will change to a
bright orange color.
.The song title and artist name will
appear on the screen when available by
the radio station. The radio station can
send album pictures when available.
.As a user works through the analog
radio stations, (where applicable) the
radio receiver will automatically tune
from an analog signal to a digital signal
within 5 seconds.
!Preserving a music information
Tag information in the music broadcasting
is preserved in the system and transmits to
an iPod.
1. Touch the“Ta g”key in the control
screen while receiving HD Radio, the tag
setting screen will be displayed.2. Connect an iPod. Refer to“Connecting
and disconnecting a USB memory/porta-
ble device”F5-16..Turn on the power of the iPod if it is
not turned on.
.Once an iPod is connected, the
music tag moves from the radio into
the iPod.
.When the iPod is connected to
iTunes, the tagged information of the
songs which were tagged while listen-
ing to the radio can be viewed. Then a
user may decide to purchase the song
or CD/Album which had been listened
to on their radio.
–CONTINUED–
Audio/Audio set
5-31
5

(276,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
In addition, the following messages appear.
Display Message Contents
“Tag storage full”If there is not enough memory in the digital
audio
“Already Stored”If the same information is stored in the digital
audio
“Storing Failed”If the store process in the digital audio failed
“iPod full Tags cannot be stored”If there is not enough memory in the iPod
“Starting to transfer the Tag files.”If the system starts to transmit music informa-
tion to an iPod
“Transferring Failed”If the transmitting process of music information
to an iPod failed
“X Tag(s) Sent”(X = number of transmitted
information) will be displayed.If the transmitting process of music information
to an iPod is successful
NOTE.The tag information can not be
preserved while scanning or caching
the radio station.
.If tagging the music information
fails,“Saving the HD Radio tag was
unsuccessful. (Saving the HD Radio tag
was unsuccessful.)”will be displayed
on the screen. If this occurs, tag the
information again..Program Service Data: Presents song
name, artist, station IDs, and other rele-
vant data streams..iTunes Tagging provides you the op-
portunity to discover a wide range of
content and the means to“tag”that content
for later review and purchase from the
iTunes Store. Also refer to the Apple
Automotive specifications for implement-
ing iTunes Tagging.
Audio/Audio set
5-32

(277,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
.Visual information related to content
being played on your HD Radio receiver,
such as Album Art, historical photographs,
still art from live broadcasts, among other
related content.
–CONTINUED–
Audio/Audio set
5-33
5

(278,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Troubleshooting guide
Experience Cause Action
Mismatch of time alignment - a user may hear a
short period of programming replayed or an
echo, stutter or skip.The radio stations analog and digital volume is
not properly aligned or the station is in ballgame
mode.None, radio broadcast issue. A user can contact the
radio station.
Sound fades, blending in and out.Radio is shifting between analog and digital
audio.Reception issue. May clear-up as the vehicle
continues to be driven. Turning the indicator of the
HD Radio
TM
off will change the radio mode to
analog audio.
Audio mute condition when an HD2/HD3
multicast channel had been playing.The radio does not have access to digital signals
at the moment.This is normal behavior, wait until the digital signal
returns. If out of the coverage area, seek a new
station.
Audio mute delay when selecting an HD2/HD3
multicast channel preset.The digital multicast content is not available until
HD Radio
TM
broadcast can be decoded and
make the audio available. This takes up to 7
seconds.This is normal behavior, wait for the audio to
become available.
Text information does not match the present
song audio.Data service issue by the radio broadcaster.Broadcaster should be notified. Complete the form;
www.ibiquity.com/automotive/report_radio
_station_experiences.
No text information shown for the present
selected frequency.Data service issue by the radio broadcaster.Broadcaster should be notified. Complete the form;
www.ibiquity.com/automotive/report_radio
_station_experiences.
The“Acquiring”caution message appears
when the system attempts to acquire digital
transmission.When acquiring digital data while receiving a
digital broadcast and SPS station..When the reception in digital of the SPS station
is confirmed.
.When the system determined that the SPS
station could not be received.
.When the SPS broadcast is ended (stopped) by
the radio station while receiving SPS.
Audio/Audio set
5-34

(279,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Experience Cause Action
The“HD Channel is unavailable”caution
message appears when digital reception is not
possible..When the system determined that the SPS
station could not be received while receiving
a digital broadcast and SPS station.
.When the SPS broadcast is ended
(stopped) by the radio station while receiv-
ing SPS..When the status is changed to acquiring digital
data because the reception condition of SPS
station has improved.
.When the received station is changed.
–CONTINUED–
Audio/Audio set
5-35
5

(280,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&SiriusXM Satellite Radio (if
equipped)!SiriusXM Data Service
Data service information, which is com-
prised of traffic information and weather
information, can be received via the
SiriusXM Radio.
To receive the data service information in
the vehicle, a subscription to the SiriusXM
Satellite Radio service is necessary.
Content set to use the SiriusXM data
service is reset when personal information
is initialized.!Control screen and audio panel
Control screen
No. Function&1
Perform the SXM setting. See below.
Refer to“
SXM setting”F5-41.
&2
Search for a channel which the
direction of higher frequency from
current frequency. Reproduce the
channel that can receive by 5 sec-
onds.No. Function
&3
A list is displayed. There are three
types of lists (“Presets”,“Categories”
or“All Channels”) available.
.“Presets”: Preset channels are
displayed in a list.
.“Categories”: The channels of
the selected category are dis-
played in a list.
.“All Channels”: All selectable
channels are displayed in a list.
Audio/Audio set
5-36

(281,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
No. Function&4
Display the contents information of a
channel receiving.
&5
Presets list (30 channels max.) is
displayed. Refer to“
Presetting a
channel”F5-39.
&6
Categories list is displayed. Refer to
“Selecting a channel from the list”F5-
40.
&7
All channels list is displayed.
The available received channels are
displayed, and you can select a
channel.
&8
Change to the Direct Tune display.
Refer to“
Direct Tune”F5-41.
&9
Return to the previous display.
&10
Return to the playback display.
Audio panel
No. Function&1
Turn to adjust volume.
Press to turn the audio system on/off.
&2
Press to display the sound setting
screen. Refer to“
Unit settings”F5-18.
&3
Turn right to step up channels and
turn left to step down channels.
Press to select an audio source.
Refer to“
Selecting an audio source”
F5-17.
&4
Press to step up/down channels.
Press and hold to step up/down
channels fast.
