Page 257 of 578
(266,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!“Speed Volume Control”
The system adjusts to the optimum volume
and tone quality according to vehicle
speed to compensate for increased vehi-
cle noise.
1. Touch the right side key of the“Speed
Volume Control”key.
2. Select the desired item. The“High”key
comes to have a bigger effect. When the
“OFF”key is selected, speed volume
control function is cancelled.
!“Graphic Equalizer”
You can adjust the sound quality by
increasing/decreasing the gain for each
frequency range.
1. Touch the“Set”key of the“Graphic
Equalizer”key.
2. In this mode, 6 preset equalizer pat-
terns (the“Bass”,“Treble”,“Acoustic”,
“Impact”,“Smooth”and“Flat”key) and 3
customized patterns (the“SET 1”-“SET 3”
key) are available.
3. When customizing the equalizer pat-
tern, touch among“SET 1”,“SET 2”or
“SET 3”and then touch the“Adjust”key.
4. Adjust the level of each frequency
band by touching“
”or“
”key.
Audio/Audio set
5-22
Page 258 of 578
(267,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!“Sound Restorer”
You can play compressed audio data with
a sound quality that is close to the original
sound.
Select the“ON”or“OFF”key by the right
side key of the“Sound Restorer”key.
!“Volume Smoother”
This function reduces the difference in
volume among the sound sources to be
played.
1. Touch the right side key of the“Volume
Smoother”key.
2. Select the“OFF”,“Low”,“Mid”or“High”
key. The“High”key comes to have a
bigger effect. When the“OFF”key is
selected, the volume smoother function is
cancelled.
!“Virtual Bass”
This function enables you to adjust the
bass tone.
1. Touch the right side key of the“Virtual
Bass”key.
2. Select the“OFF”,“Low”,“Mid”or“High”
key. The“High”key comes to have a
bigger effect. When the“OFF”key is
selected, the virtual bass function is
cancelled.!“Vocal Image Control”
Refer to““Balance/Fader””F5-21.
–CONTINUED–
Audio/Audio set
5-23
5
Page 259 of 578

(268,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Display settings
Touch the
tab to set display.
Item Function
Day/Night
ModeThe“Auto”,“Day”or“Night”key
can be selected on the pop-up
screen.
When the“Auto”key is selected,
the screen changes to day or
night mode depending on the
position of the headlight switch.
BrightnessTouch“+”or“ ”to adjust the
brightness.
NOTE.When the screen is viewed through
polarized sunglasses, a rainbow pat-
tern may appear on the screen due to
optical characteristics of the screen. If
this is disruptive, please operate thescreen without polarized sunglasses.
.If the screen is set to“Day”mode
with the headlight switch turned on,
this condition is memorized even with
the engine turned off.
!How to adjust the rear view image
In the camera display, the brightness, tint,
color and black level of the screen can be
adjusted.
1. Depress the brake pedal fully and stop
the vehicle.
2. While the vehicle is stopped, set the
shift lever (MT models) or select lever
(CVT models) in the“R”position, and then
touch the display.
3. Touch the“Display Adjustment”key.
4. Touch the items to adjust the rear
camera screen.
Camera display
WARNING
When adjusting camera display
screen, make sure to depress the
brake pedal fully to avoid the vehicle
from moving. Failure to do so may
lead to a serious accident.NOTEThe camera display can be accessed
when the rear camera monitor is dis-
played.
Audio/Audio set
5-24
Page 260 of 578

(269,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!SUBARU STARLINK settings (if
equipped)
Touch the
tab to change the SUBARU
STARLINK settings.
Item Function
Browser
cacheSelect to initialize cache files that
the browser stores. If the con-
firmation screen appears and the
“OK”key is selected, the cache
files will be deleted.
&SUBARU STARLINK (if
equipped)The SUBARU STARLINK function allows
the system to link with a smartphone using
Bluetooth.
!How to use SUBARU STARLINK
1. Connect to the audio system. Use a
USB port for an iPhone or iPod touch and
Bluetooth for Android devices.
.For details about connecting an
iPhone/iPod touch: Refer to“Connect-
ing and disconnecting a USB memory/
portable device”F5-16.
.For details about registering or con-
necting an Android device: Refer to
“Registering/connecting Bluetooth
®
device”F5-64.
2. Press the HOME button, and then
touch the“APPS”key, or press the APPS
button on the audio panel. The APPS
screen is displayed.
3. Touch the“SUBARU STARLINK”key
on the APPS screen. The disclaimer
screen or the error screen is displayed.
4. Touch the“Check”key on the disclai-
mer screen and then the APPS main
screen will appear. If you touch the
“Cancel”key, the disclaimer screen dis-
appears and the previous screen will be
displayed again.NOTE.The SUBARU STARLINK connection
error screen will be displayed due to
one of the following possible reasons.
–Your smartphone and the system
has not been connected via USB (for
iPhone) or Bluetooth (for Android).
–SUBARU STARLINK APPS has
not been activated.
–CONTINUED–
Audio/Audio set
5-25
5
Page 261 of 578

(270,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
.You can also switch to aha or
Pandora (if equipped) from the APPS
screen.
!APPS main screenNo. Function&1
Select to go to the Music APPS
screen.
&2
Select to go to the News APPS
screen.
&3
Select to go to the Calender APPS
screen.
&4
Select to go to the iHeartRadio
APPS screen.
&5
Select to go to the Weather APPS
screen.
NOTE.The error screen will be displayed
while using SUBARU STARLINK due to
one of the following possible reasons.
–When your smartphone has no
service or the Bluetooth communi-
cation is not possible.
–When your smartphone is turned
off.
–When the SUBARU STARLINK
APPS is quit.
–When connection to the SUBARU
STARLINK server is not possible.
–When a problem occurs other
than a server error.
.When using the SUBARU STARLINK
function, a disclaimer screen will be
displayed. Be sure to fully read the
contents before using the function.
.Supported devices
–iPhone: iPhone 4/iPhone 4s/
iPhone 5 (iOS Ver. 5.1 or later)/
iPhone 5c/iPhone 5s
–Android: (OS Ver. 4.0 or later)
Audio/Audio set
5-26
Page 262 of 578

(271,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&AM/FM radio!Control screen and audio panelNo. Function&1
Select to display the audio source
selection screen.
&2
Select to change the band.
&3
The HD Radio indicator on the top
right of the screen changes accord-
ing to the reception condition of HD
Radio (if equipped).
&4
Select to display a station list (if
equipped). Refer to“
Selecting a sta-
tion from the list”F5-28.
No. Function&5
Select to scan radio channels.
This function enables searching for
receivable stations automatically,
and tunes in to a frequency for 5
seconds if a station is found. When
the 5-second period has elapsed, the
system searches for the next recei-
vable station again, and tunes in to
the frequency for 5 seconds.
&6
Select to open the“Option”screen.
Refer to“
Radio settings”F5-29.
&7
When you touch a key, the system
tunes to the stored frequency.
When you touch and hold a key, the
system stores the frequency to the
selected preset channel. Refer to
“Presetting a station”F5-28.
No. Function&8
Turn to adjust volume.
Press to turn the audio system on/off.
&9
Turn to step up/down frequencies.
Turn to move up/down the list. Also,
the knob can be used to enter
selections on the list screens by
pressing.
Press to select an audio mode. For
details, refer to“
Selecting an audio
source”F5-17.
&10
Press to display the sound setting
screen. Refer to“
Unit settings”F5-18.
&11
Press to seek for a station/channel.
Press and hold for continuous seek.
NOTE.Although FM is normally static free,
reception can be affected by the sur-
rounding area, atmospheric condi-
tions, station strength and transmitter
distance. Buildings or other obstruc-
tions may cause momentary static,
flutter or station interference. If recep-
tion continues to be unsatisfactory,
switch to a stronger station.
.The radio automatically changes to
stereo reception when a stereo broad-
cast is received.
–CONTINUED–
Audio/Audio set
5-27
5
Page 263 of 578

(272,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
.The radio automatically blends to an
HD Radio signal (if equipped) in AM or
FM where available.
!How to change the source
Select the“AM”or“FM”key on the source
select screen. Refer to“Selecting an audio
source”F5-17.
!Presetting a station
In total 18 stations can be set for the FM
band (6 each for FM1, FM2 and FM3) and
12 stations can be set for the AM band (6
each for AM1 and AM2).
1. Tune in the desired station.
2. If you touch and hold a key, the system
stores the frequency to the selected preset
channel.
!Selecting a station from the list (if
equipped)
A station list can be displayed.
1. Touch the
tab.
2. Touch the
tab and the station list will
appear.
3. Select the desired station.
!Update the station list
Touch the“Update Station List”key on the
station list screen and the following screen
will be displayed.
Item Function
OKSelect to execute the manual
update.
CancelSelect to cancel the manual
update.
NOTE.The audio system sound is muted
during refresh operation.
.In some situations, it may take some
time to update the station list.
!Bookmark the list
You can store and call up the received data
(images, song titles, artist names, etc.).
The stored data is displayed as a list.
1. Touch the
tab on the station list
screen and the following screen will be
Audio/Audio set
5-28
Page 264 of 578

(273,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
displayed.2. Select an item from the bookmark list,
the following image will be displayed.3. When you call up bookmark informa-
tion, a QR code converted from the book-
mark information will be displayed on thescreen. You can access a URL by reading
the QR code using a smartphone, etc.
!Delete bookmark from the list
1. Touch the“Delete Bookmark”key on
the station list screen and the following
screen will be displayed.
2. If you select an item from the bookmark
list, the item will be deleted from the
bookmark list.
3. Touch the“Delete All”key. If the
confirmation screen appears and the
“OK”key is selected, all bookmark items
in the list will be deleted.
!Radio settings
You can perform various radio settings.
1. Touch the
tab.2. Select the desired item from the
following table.
Item Function
HD (if
equipped)Select to turn HD radio on/off.
PTY Select
(if
equipped)Select to set the PTY group.
Auto StoreSelect to detect 6 radio stations
with strong frequencies automa-
tically and to store them in the
order of frequency.
!About HD Radio
TM
technology (if
equipped)
HD Radio
TM
Technology is the digital
evolution of analog AM/FM radio. Your
radio product has a special receiver which
allows it to receive digital broadcasts
(where available) in addition to the analog
broadcasts it already receives. Digital
broadcasts have better sound quality than
analog broadcasts as digital broadcasts
provide free, crystal clear audio with no
static or distortion. For more information,
and a guide to available radio stations and
programming, refer to www.hdradio.com.
–CONTINUED–
Audio/Audio set
5-29
5
