2018 SUBARU WRX Owners Manual

(340,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Interior lights
CAUTION
When leaving your vehicle, make
sure the lights are turned off to
avoid battery discharge.&Dome light1) ON
2) DOOR
3) OFFThe dome light switch has the following
three positions.
ON:The light remains on continuously.
OFF:The light remains off.DOOR:The dome light illuminates auto-
matically after any of the following opera-
tions.
.Opening any of the doors.
.Unlocking the doors using the keyless
access function (if equipped). Refer to
“Unlocking”F2-11.
.Unlocking the doors using the remote
keyless entry system. Refer to“Remote
keyless entry system”F2-18.
.Turning the ignition switch from the
“ACC”position to the“LOCK”/“OFF”posi-
tion.
&Map lightsType AType BTo turn on the map light, push the switch.
To turn it off, push the switch again.
Interior equipment/Interior lights
6-2

(341,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Automatic illumination (type A map
lights)
The map lights illuminate automatically in
the following cases.
.Any of the doors is opened.
.The doors are unlocked using the
keyless access function (if equipped).
Refer to“Unlocking”F2-11.
.The doors are unlocked using the
remote keyless entry transmitter.
.The ignition switch is turned from the
“ACC”position to the“LOCK”/“OFF”posi-
tion.&OFF delay timerThe following lights have an automatic
illumination function.
.dome light (when the dome light switch
is in the“DOOR”position)
.map light (type A)
After being illuminated automatically,
these lights remain on for several seconds
and then gradually turn off after all doors
are closed.
While the lights are illuminated, the lights
turn off immediately after any of the
following operations.
.Turning the ignition switch from the
“LOCK”/“OFF”position to the“ACC”or
“ON”position..Locking all doors using the keyless
access function (if equipped).
.Locking all doors using the remote
keyless entry system.
The setting for the period of time in which
the lights remain on (OFF delay timer) can
be changed by a SUBARU dealer. Contact
your SUBARU dealer for details. Also, the
setting can be changed by operating the
multi-function display (color LCD). For
details, refer to“Interior light setting”F3-
61.
Sun visorsTo block out glare, swing down the visors.
To use the sun visor at a side window,
swing it down and move it sideways.
–CONTINUED–
Interior equipment/Sun visors
6-3
6

(342,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Sun visor extension plate
(models with the EyeSight
system)With the sun visor positioned over the side
window, you can use the sun visor exten-
sion plate to prevent glare through the gap
between the sun visor and center pillar. To
use the extension plate, pull it toward the
rear of the vehicle. When you have
finished using it, stow it by pushing it
toward the front of the vehicle.
CAUTION
Do not pull out the extension plate
with the sun visor positioned over
the windshield. The extension plate
would obstruct your view of the rear
view mirror.
&Vanity mirror with light
CAUTION
Keep the vanity mirror cover closed
while the vehicle is being driven to
avoid being temporarily blinded by
the glare of bright light.To use the vanity mirror, swing down the
sun visor and open the vanity mirror cover.
The light beside the vanity mirror illumi-
nates when the mirror cover is opened.NOTEDo not use the vanity mirror light for a
long period of time while the engine is
not running. Doing so can cause bat-
tery discharge.
Interior equipment/Sun visors
6-4

(343,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Storage compartment
CAUTION
.Always keep the storage com-
partment closed while driving to
reduce the risk of injury in the
event of a sudden stop or an
accident.
.Do not store spray cans, contain-
ers with flammable or corrosive
liquids or any other dangerous
items in the storage compart-
ment.
&Glove box1) Rotate the key clockwise to lock.
2) Rotate the key counterclockwise to un-
lock.To open the glove box, pull the handle.
To close it, push the lid firmly upward.NOTE.For models with the“keyless access
with push-button start system”, use the
emergency key to lock or unlock the
glove box.
.The emergency key is directional. If
the key cannot be inserted, change the
direction that the grooved side is facing
and insert it again.
&Center consoleTo open the lid, pull up the lock release.
Interior equipment/Storage compartment
6-5
6

(344,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Cup holders
CAUTION
Take care to avoid spills. Beverages,
if hot, might burn you and/or your
passengers. Spilled beverages may
also damage upholstery, carpets or
audio equipment.&Front passenger’s cup holder
CAUTION
Do not pick up a cup from the cup
holder or put a cup in the holder
while driving. Doing so can distract
you and lead to an accident.!Except STI
Type AType BA dual cup holder is built into the center
console.!STI
The dual cup holder is built into the center
console near the parking brake lever.To access the cup holder, pull the lid
toward the rear.
Interior equipment/Cup holders
6-6

(345,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
You can pull out the divider in the cup
holder and insert it in a different position
(further toward the front or rear) to enable
cups of different sizes to be held.
NOTEWith the divider taken out, you can use
the cup holder as a storage box.&Rear passenger’s cup holder!Type A
CAUTION
When not in use, always keep the
cup holder stored while driving to
reduce the risk of injury in the event
of a sudden stop or an accident.A dual cup holder is located at the back of
the center console. To use the cup holder,
open the lid by pulling its upper edge.!Type B
A dual cup holder is built into the armrest.
CAUTION
When a cup containing a beverage is
in the cup holder, do not fold down
the rear seats. Otherwise, the bev-
erage could spill while driving, and if
the beverage is hot, it could burn
you and/or your passengers.Interior equipment/Cup holders
6-7
6

(346,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Bottle holders
CAUTION
.Do not pick up a bottle from the
bottle holder or put a bottle in the
holder while driving. Doing so
can distract you and lead to an
accident.
.When placing a beverage in a
bottle holder, make sure it is
capped. Otherwise, the beverage
could spill when opening/closing
the door or while driving and, if
the beverage is hot, it could burn
you and/or your passengers.You can use the bottle holder equipped oneach door trim to hold a beverage bottle
and other items.
Accessory power outletsPower outlet below the climate control
dialsPower outlet in the center consoleAccessory power outlets are provided
Interior equipment/Bottle holders
6-8

(347,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
below the climate control dials and in the
center console. Electrical power (12V DC)
from the battery is available at any of the
outlets when the ignition switch is in either
the“ACC”or“ON”position.
You can use an in-vehicle electrical appli-
ance by connecting it to an outlet.
The maximum power rating of an appli-
ance that can be connected is120W.Do
not use an appliance which exceeds the
indicated wattage for each outlet.
When using appliances connected to two
or more outlets simultaneously, the total
power consumed by them must not ex-
ceed 120W.
CAUTION
.Do not attempt to use a cigarette
lighter in the accessory power
outlets.
.Do not place any foreign objects,
especially metal ones such as
coins or aluminum foil, into the
accessory power outlet. That
could cause a short circuit. Al-
ways put the cap on the acces-
sory power outlet when it is not in
use.
.Use only electrical appliances
which are designed for 12V DC.
The maximum power rating of anappliance that can be connected
is 120W. Do not use an appliance
which exceeds the indicated wat-
tage for each outlet.
When using appliances con-
nected to two or more outlets
simultaneously, the total power
consumed by them must not
exceed 120W. Overloading the
accessory power outlet can
cause a short circuit. Do not use
double adapters or more than
one electrical appliance.
.If the plug on your electric appli-
ance is either too loose or too
tight for the accessory power
outlet, this can result in a poor
contact or cause the plug to get
stuck. Only use plugs that fit
properly.
.Use of an electric appliance in the
accessory power outlet for a long
period of time while the engine is
not running can cause battery
discharge.
.Before driving your vehicle, make
sure that the plug and the cord on
your electrical appliance will not
interfere with your shifting gears
and operating the accelerator
and brake pedals. If they do, donot use the electrical appliance
while driving.
&Use with a cigarette lighter (if
equipped)To use the accessory power outlet as a
cigarette lighter socket, purchase the
cigarette lighter plug, which is an optional
accessory. A cigarette lighter plug is
available from your SUBARU dealer.
The cigarette lighter operates only when
the ignition switch is in the“ON”or“ACC”
position.
To use the cigarette lighter, push in the
knob and wait a few moments. It will
automatically spring up when ready for
use.
WARNING
To avoid being burned, never grasp
the lighter by the end with the
heating element. Doing so could
result in injury and could also da-
mage the heating element.
–CONTINUED–
Interior equipment/Accessory power outlets
6-9
6
