!Anti-entrapment function
When the moonroof senses a substantial
enough object trapped between its glass
and the vehicle’s roof during closure, it
automatically moves back to the fully open
position and stops there. The anti-entrap-
ment function may also be activated by a
strong shock on the moonroof even when
there is nothing trapped.
CAUTION
Never attempt to test this function
using fingers, hands or other parts
of your body.NOTEFor the sake of safety, it is recom-
mended that you avoid driving with the
moonroof fully opened.
&Sun shadeYou can slide the sun shade forward or
backward by hand while the moonroof is
closed.
If the moonroof is opened, the sun shade
also moves back.
Keys and doors/Moonroof
2-40

(143,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Ignition switch.........................................................3-4
Conventional type ignition switch........................... 3-5
Push-button ignition switch.................................... 3-6
Hazard warning flasher..........................................3-8
Meters and gauges.................................................3-8
Combination meter illumination.............................. 3-8
Canceling the function for meter/gauge needle
movement upon turning on the ignition switch..... 3-9
Speedometer......................................................... 3-9
Odometer............................................................... 3-9
Double trip meter................................................... 3-9
Tachometer...........................................................3-10
Fuel gauge............................................................3-10
Temperature gauge............................................... 3-11
ECO gauge...........................................................3-12
REV indicator light andbuzzer (STI)...................3-12
Warning and indicatorlights................................3-13
Seatbelt warning light and chime..........................3-14
SRS airbag system warning light...........................3-15
Front passenger’s frontal airbag ON and OFF
indicators...........................................................3-16
CHECK ENGINE warning light/Malfunction
indicator light.....................................................3-16
Charge warning light.............................................3-17
Oil pressure warning light.....................................3-17
Engine low oil level warning indicator
(except STI)........................................................3-17
Windshield washer fluid warning indicator............3-18
AT OIL TEMP warning light (CVT models)..............3-18
Rear differential oil temperature warning light
(STI)...................................................................3-18Low tire pressure warning light
(U.S.-spec. models)............................................3-19
ABS warning light.................................................3-20
Brake system warning light...................................3-21
Electronic parking brake indicator light (models
with electronic parking brake system)................3-23
Low fuel warning light..........................................3-24
Hill start assist warning light/Hill start assist OFF
indicator light (models without electronic
parking brake system).......................................3-24
Auto Vehicle Hold ON indicator light (models with
electronic parking brake system).......................3-24
Auto Vehicle Hold operation indicator light
(models with electronic parking brake system) ... 3-24
Door open warning light.......................................3-25
All-Wheel Drive warning light (if equipped) ............3-25
Power steering warning light (except STI) .............3-25
LED headlight warning light (if equipped)..............3-25
Vehicle Dynamics Control warning light/Vehicle
Dynamics Control operation indicator light........3-26
Vehicle Dynamics Control OFF indicator
light/Traction mode indicator light......................3-27
Warning chimes and warning indicator of the
keyless access with push-button start system
(if equipped)......................................................3-28
Security indicator light..........................................3-33
SI-DRIVE indicator (if equipped)............................3-34
Gear position indicator (MT models)/Shift-up
indicator (STI)....................................................3-34
Select lever/gear position indicator
(CVT models).....................................................
3-34
Turn signal indicator lights...................................3-35
High beam indicator light......................................3-35
Instruments and controls
3

(144,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
High Beam Assist indicator light (green)
(if equipped).......................................................3-35
High Beam Assist warning indicator (yellow)
(if equipped).......................................................3-35
Cruise control indicator........................................3-35
Cruise control set indicator...................................3-35
Automatic headlight beam leveler warning light
(models with LED headlights)..............................3-35
Front fog light indicator light (if equipped) ............3-35
Headlight indicator light........................................3-35
Driver’s control center differential auto indicator
(STI)...................................................................3-36
Driver’s control center differential indicator and
warning (STI)......................................................3-36
REV indicator light (STI)........................................3-37
Steering Responsive Headlight warning indicator/
Steering Responsive Headlight OFF indicator
(if equipped).......................................................3-37
BSD/RCTA warning indicator (if equipped).............3-37
BSD/RCTA OFF indicator (if equipped)..................3-37
RAB warning indicator (if equipped)......................3-37
RAB OFF indicator light (if equipped)....................3-37
Combination meter display (colorLCD).............3-38
Basic operation.....................................................3-39
Welcome screen (opening animation) and
Good-bye screen (ending animation)...................3-39
Warning screen.....................................................3-39
Basic screens.......................................................3-40
Warning indication................................................3-41
Menu screens.......................................................3-41
Multi-function display (colorLCD)......................3-44
Welcome screen...................................................3-45
Self-check screen.................................................3-45
Interruption screen...............................................3-46
Basic operation....................................................3-46
Basic screens.......................................................3-47
Setting screen......................................................3-52
How to get the source code using the open
source...............................................................3-63
Light control switch.............................................3-63
Headlights............................................................3-64
High/low beam change (dimmer) ...........................3-65
Headlight flasher..................................................3-68
Daytime running light system...............................3-69
Steering Responsive Headlight (SRH)
(if equipped).......................................................3-69
To turn on/off the SRH..........................................3-69
Turn signallever...................................................3-70
One-touch lane changer........................................3-70
Illumination brightness control...........................3-71
Automatic dimming function.................................3-71
Auto dimmer cancel function................................3-71
Headlight beam leveler (ifequipped)..................3-71
Automatic headlight beam leveler
(models with LED headlights)............................3-71
Fog light switch (ifequipped)..............................3-72
Wiper and washer.................................................3-72
Windshield wiper and washer switches.................3-74
Instruments and controls

(145,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Mirrors...................................................................3-75
Inside mirror.........................................................3-75
Auto-dimming mirror/compass (if equipped)..........3-75
Auto-dimming mirror/compass with HomeLink
®
(if equipped).......................................................3-76Outside mirrors....................................................3-83
Defogger and deicer.............................................3-84
Tilt/telescopic steeringwheel..............................3-85
Horn.......................................................................3-86
Instruments and controls

(146,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Ignition switchConventional type ignition switchPush-button ignition switch
1) Operation indicator
