2018 SUBARU WRX Owners Manual

Black plate (2,1)
Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22
Left Page————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————

(101,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Keys.........................................................................2-2
Models without“keyless access with push-button
start system”....................................................... 2-2
Models with“keyless access with push-button
start system”....................................................... 2-2
Key number plate................................................... 2-3
Door locks...............................................................2-4
Locking and unlocking from the outside................. 2-4
Locking and unlocking from the inside................... 2-5
Battery drainage prevention function...................... 2-6
Power door lockingswitches................................2-7
Key lock-in prevention function.............................. 2-7
Keyless access with push-button start system
(if equipped).........................................................2-8
Safety precautions................................................. 2-8
Locking and unlocking by holding the access key
fob......................................................................2-10
Unlock using PIN Code Access.............................2-12
Power saving function..........................................2-13
Selecting audible signal operation.........................2-14
Warning chimes and warning indicator..................2-14
Disabling keyless access function.........................2-14
When access key fob does not operate properly ... 2-16
Replacing battery of access key fob......................2-16
Replacing access key fob.....................................2-16
Certification for keyless access with push-button
start system........................................................2-16
Tips......................................................................2-17
Remote keyless entrysystem.............................2-18
Locking the doors................................................2-19
Unlocking the doors.............................................2-19
Opening the trunk lid............................................2-20
Vehicle finder function..........................................2-20
Sounding a panic alarm........................................2-20
Selecting audible signal operation (models
without“keyless access with push-button start
system”)............................................................2-20
Replacing the battery............................................2-21
Replacing lost transmitters...................................2-21
Certification for Remote keyless entry system.......2-21
Anti-theft system..................................................2-22
Immobilizer...........................................................2-22
Alarm system.......................................................2-24
Child safety locks.................................................2-31
Windows................................................................2-31
Power window operation by driver........................2-32
Power window operation by passengers...............2-34
Off delay function.................................................2-35
Initialization of power window ...............................2-35
Trunk lid................................................................2-35
To open and close the trunk lid from outside........2-36
To open the trunk lid from inside..........................2-36
Internal trunk lid release handle............................2-36
Moonroof (if equipped).........................................2-38
Moonroof switches...............................................2-39
Sun shade............................................................2-40
Keys and doors
2

(102,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Keys
CAUTION
When traveling in an airplane, do not
press the button of the key. If any
button of the key is pressed, radio
waves are emitted and may affect
the operation of the airplane. When
carrying the key in a bag, take
measures to prevent the buttons
from being pressed accidentally.NOTEPress the buttons of the key to lock/
unlock with the remote keyless entry
system. For details, refer to“Remote
keyless entry system”F2-18.
&Models without“keyless ac-
cess with push-button start
system”1) Master key
2) Submaster key
3) Sub key
4) Key number plateThree types of keys are provided for your
vehicle.
CAUTION
Do not attach a large key holder or
key case to either key. If it bangs
against your knees while you are
driving, it could turn the ignition
switch from the“ON”position to
the“ACC”or“LOCK”position,
thereby stopping the engine.&Models with“keyless access
with push-button start sys-
tem”1) Access key fob (main)
2) Access key fob (sub)
3) Key number plateThe vehicle has two access key fobs and a
Keys and doors/Keys
2-2

(103,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
key number plate. For details about the
key number plate, refer to“Key number
plate”F2-3.
An emergency key is attached to each
access key fob. The emergency key is
used for the following operations.
.Locking and unlocking the driver’s door
.Locking and unlocking the glove box
You cannot unlock the glove box without
using the emergency key. You can keep
the glove box locked when you leave your
vehicle and the access key fob (with the
emergency key removed) at a parking
facility.1) Release button
2) Emergency keyWhile pressing the release button of theaccess key fob, take out the emergency
key.
CAUTION
If the access key fob is dropped, the
integrated emergency key inside
may become loose. Be careful not
to lose the emergency key.NOTE.The access key fob is always com-
municating with the vehicle and is
continuously using the battery.
Although the life of the battery varies
depending on the operating conditions,
it is approximately 1 to 2 years. If the
battery becomes fully discharged, re-
place it with a new one.
.If an access key fob is lost, it is
recommended that the remaining ac-
cess key fobs be reregistered. For
reregistration of an access key fob,
contact a SUBARU dealer.
.Up to 7 access key fobs can be
registered for one vehicle. For a spare
access key fob, contact a SUBARU
dealer.
.Do not leave the access key fob in
the storage spaces inside the vehicle.
Vibrations can damage the key or turn
on the switch, possibly resulting in alockout.
&Key number plate
CAUTION
Carefully store the key number
plate. It is necessary for vehicle
repair and additional registration of
access key fobs.
The key number is stamped on the key
number plate attached to the key set. Write
down the key number and keep it in
another safe place, not in the vehicle. This
number is needed to make a replacement
key if you lose your key or lock it inside the
vehicle. Refer to“Key replacement”F2-
23.
Keys and doors/Keys
2-3
2

(104,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Door locks&Locking and unlocking from
the outside
NOTEIf you unlock the driver’s door with a
key (including an emergency key) and
open the door while the alarm system is
armed, the alarm system is triggered
and the vehicle’s horn sounds. In this
case, perform any of the following
operations:
Models with“keyless access with
push-button start system”:
.Press any button on the access key
fob (except when the battery of the
access key fob is discharged).
.Turn the push-button ignition switch
to the“ACC”position.
Models without“keyless access with
push-button start system”:
.Press any button on the remote
transmitter (except when the transmit-
ter battery is discharged).
.Insert the key into the ignition switch
and turn the ignition switch to the“ON”
position.
For details about the alarm system,
refer to“Alarm system”F2-24.
To lock the driver’s door from the outside
with the key, turn the key toward the front.
To unlock the door, turn the key toward the
rear. Pull the outside door handle to open
an unlocked door.
NOTEThe emergency key is directional. If the
key cannot be inserted, change the
direction that the grooved side is facing
and insert it again.
To lock the door from outside without the
key, the following methods are available.
Keys and doors/Door locks
2-4

(105,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Locking using lock lever
1) Rotate the lock lever forward.
2) Close the door.
Locking using power door locking switch
1) Press the front side (lock side) of the
power door locking switch.
2) Close the door.In this case, all closed doors are locked at
the same time.
Always make sure that all doors and the
trunk lid are locked before leaving your
vehicle.NOTEMake sure that you do not leave the key
inside the vehicle when locking the
doors from the outside without the key.
&Locking and unlocking from
the inside1) Unlock
2) LockTo lock the door from the inside, rotate the
lock lever forward. To unlock the door from
the inside, rotate the lock lever rearward.
The red mark on the lock lever appears
when the door is unlocked.
Pull the inside door handle to open an
unlocked door.
Always make sure that all doors and the
trunk lid are closed before starting to drive.
–CONTINUED–
Keys and doors/Door locks
2-5
2

(106,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
WARNING
Keep all doors locked when you
drive, especially when small chil-
dren are in your vehicle.
Along with the proper use of seat-
belts and child restraints, locking
the doors reduces the chance of
being thrown out of the vehicle in an
accident.
It also helps prevent passengers
from falling out by preventing a door
from being accidentally opened, and
intruders from unexpectedly open-
ing doors and entering your vehicle.&Battery drainage prevention
functionIf a door is not completely closed, the
interior lights will remain illuminated as a
result. However, several lights will be
automatically turned off by the battery
drainage prevention function to prevent
the battery from discharging. The following
interior lights will be affected by this
function.
ItemSwitch
positionAutomatically turning
off
Map lights* OFF*Approximately 20
minutes later
Dome light DOORApproximately 20
minutes later
Ignition
switch light—Approximately 20
minutes later
Trunk light—Approximately 20
minutes later
*: The battery drainage prevention function
affects only the map lights on models with the
moonroof, and only when the map light switches
are in the OFF position. The map lights on
models without the moonroof do not turn off
automatically, so push the light switches manu-
ally to turn them off.
The operational/non-operational setting of
this function can be changed by a
SUBARU dealer. Contact your SUBARU
dealer to change the setting.
NOTE.The factory setting (default setting)
for this function is set as“operational”.
.When leaving the vehicle, make sure
that all doors and the trunk lid are
completely closed.
.The battery drainage prevention
function does not operate while the
key is in the ignition switch.
Keys and doors/Door locks
2-6

(107,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Power door locking switches1) Lock
2) UnlockAll doors can be locked and unlocked by
the power door locking switches located at
the driver’s side and the front passenger’s
side doors.
To lock the doors, push the front side of the
switch.
To unlock the doors, push the rear side of
the switch.
When you close the doors after you set the
door locks, the doors remain locked.
NOTEMake sure that you do not leave the key
inside the vehicle before locking the
doors from the outside using the power
door locking switches.&Key lock-in prevention func-
tionThis function prevents the doors from
being locked under the following condi-
tions.
.The key is still in the ignition switch
(models without“keyless access with
push-button start system”)
.The ignition switch is in the“ON”
position (models with“keyless access with
push-button start system”)
This function’s operational/non-opera-
tional setting can be changed by a
SUBARU dealer. Contact a SUBARU
dealer for details.NOTE.The factory setting (default setting)
for this function is set as“operational”.
.When leaving the vehicle, make sure
you are holding the key before locking
the doors.!Behavior with key lock-in preven-
tion function operational
With the driver’s door open, the doors are
automatically kept unlocked even if the
front side of the power door locking switch
is pressed.
!Behavior with key lock-in preven-
tion function non-operational
.If the lock lever is turned to the front
(“LOCK”) position with the driver’s door
open and the driver’s door is then closed
with the lock lever in that position, the
driver’s door is locked.
.If the spare key is used to lock the
driver’s door from the outside of the
vehicle, the door is locked.
Keys and doors/Power door locking switches
2-7
2
