北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
&Warning and indicator lights
Mark Name Page
Seatbelt warning light 3-14Front passenger’s
seatbelt warning light3-14SRS airbag system
warning light3-15
/
Front passenger’s
frontal airbag ON in-
dicator3-16
/
Front passenger’s
frontal airbag OFF in-
dicator3-16CHECK ENGINE
warning light/Mal-
function indicator light3-16Charge warning light 3-17Oil pressure warning
light3-17Engine oil level warn-
ing indicator (except
STI)3-17AT OIL TEMP warning
light (CVT models)3-18Mark Name Page
Rear differential oil
temperature warning
light (STI)3-18ABS warning light 3-20Brake system warning
light3-21Electronic parking
brake indicator light
(models with electro-
nic parking brake
system)3-23
/
Door open warning
light3-25AWD warning light
(if equipped)3-25Power steering warn-
ing light (except STI)3-25Hill start assist warn-
ing light/Hill start as-
sist OFF indicator light
(models without elec-
tronic parking brake
system)3-24Auto Vehicle Hold ON
indicator light (models
with electronic park-
ing brake system)3-24Mark Name Page
Auto Vehicle Hold op-
eration indicator light
(models with electro-
nic parking brake
system)3-24Vehicle Dynamics
Control warning light/
Vehicle Dynamics
Control operation in-
dicator light3-26Vehicle Dynamics
Control OFF indicator
light3-27Turn signal indicator
lights3-35LED headlight warn-
ing light (if equipped)3-25High beam indicator
light3-35High beam assist in-
dicator (green)3-35High beam assist
warning indicator
(yellow)3-35Automatic headlight
beam leveler warning
light (if equipped)3-35Front fog light indica-
tor light (if equipped)3-35
–CONTINUED–
25
0

(143,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
Ignition switch.........................................................3-4
Conventional type ignition switch........................... 3-5
Push-button ignition switch.................................... 3-6
Hazard warning flasher..........................................3-8
Meters and gauges.................................................3-8
Combination meter illumination.............................. 3-8
Canceling the function for meter/gauge needle
movement upon turning on the ignition switch..... 3-9
Speedometer......................................................... 3-9
Odometer............................................................... 3-9
Double trip meter................................................... 3-9
Tachometer...........................................................3-10
Fuel gauge............................................................3-10
Temperature gauge............................................... 3-11
ECO gauge...........................................................3-12
REV indicator light andbuzzer (STI)...................3-12
Warning and indicatorlights................................3-13
Seatbelt warning light and chime..........................3-14
SRS airbag system warning light...........................3-15
Front passenger’s frontal airbag ON and OFF
indicators...........................................................3-16
CHECK ENGINE warning light/Malfunction
indicator light.....................................................3-16
Charge warning light.............................................3-17
Oil pressure warning light.....................................3-17
Engine low oil level warning indicator
(except STI)........................................................3-17
Windshield washer fluid warning indicator............3-18
AT OIL TEMP warning light (CVT models)..............3-18
Rear differential oil temperature warning light
(STI)...................................................................3-18Low tire pressure warning light
(U.S.-spec. models)............................................3-19
ABS warning light.................................................3-20
Brake system warning light...................................3-21
Electronic parking brake indicator light (models
with electronic parking brake system)................3-23
Low fuel warning light..........................................3-24
Hill start assist warning light/Hill start assist OFF
indicator light (models without electronic
parking brake system).......................................3-24
Auto Vehicle Hold ON indicator light (models with
electronic parking brake system).......................3-24
Auto Vehicle Hold operation indicator light
(models with electronic parking brake system) ... 3-24
Door open warning light.......................................3-25
All-Wheel Drive warning light (if equipped) ............3-25
Power steering warning light (except STI) .............3-25
LED headlight warning light (if equipped)..............3-25
Vehicle Dynamics Control warning light/Vehicle
Dynamics Control operation indicator light........3-26
Vehicle Dynamics Control OFF indicator
light/Traction mode indicator light......................3-27
Warning chimes and warning indicator of the
keyless access with push-button start system
(if equipped)......................................................3-28
Security indicator light..........................................3-33
SI-DRIVE indicator (if equipped)............................3-34
Gear position indicator (MT models)/Shift-up
indicator (STI)....................................................3-34
Select lever/gear position indicator
(CVT models).....................................................
3-34
Turn signal indicator lights...................................3-35
High beam indicator light......................................3-35
Instruments and controls
3

(155,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
NOTEEven if the REV alarm system is not set,
the REV indicator light will flash when-
ever the engine speed enters the red
zone of the tachometer.
To change the REV indicator settings,
perform the procedures described in
“REV settings (STI)”F3-43.
Warning and indicator lightsSeveral of the warning and indicator lights
illuminate when you initially turn the igni-
tion switch to the“ON”position. This
permits checking the operation of the
bulbs.
Apply the parking brake and turn the
ignition switch to the“ON”position. For
the system check, the following lights
illuminate and then turn off after several
seconds or after the engine has started.: Seatbelt warning light
(The seatbelt warning light turns off
only when the driver fastens the seat-
belt.): Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.): SRS airbag system warning light
ON /
: Front passenger’s frontal airbag
ON indicator light
/
: Front passenger’s frontal airbag
OFF indicator light
: CHECK ENGINE warning light/Mal-
function indicator light
: Charge warning light: Oil pressure warning light: REV indicator light (STI): AT OIL TEMP warning light
(CVT models): Rear differential oil temperature warn-
ing light (STI): Low tire pressure warning light
(U.S.-spec. models)/
: ABS warning light
/
: Brake system warning light: Electronic parking brake indicator
light (models with the electronic
parking brake system)
: Low fuel warning light: Hill start assist warning light/Hill start
assist OFF indicator light (models
without electronic parking brake sys-
tem): Door open warning light: AWD warning light (if equipped): Power steering warning light (except
STI)
–CONTINUED–
Instruments and controls/Warning and indicator lights
3-13
3

(159,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
NOTEThis light also illuminates when the fuel
filler cap is not tightened until it clicks.
If you have recently refueled your vehicle,
the cause of the CHECK ENGINE warning
light/malfunction indicator light illuminating
could be a loose or missing fuel filler cap.
Remove the cap and retighten it until it
clicks. Make sure nothing is interfering with
the sealing of the cap. Tightening the cap
will not make the CHECK ENGINE warn-
ing light/malfunction indicator light turn off
immediately. It may take several driving
trips. If the light does not turn off, take your
vehicle to your authorized SUBARU dealer
immediately.
!If the light is blinking
If the light is blinking while driving, an
engine misfire condition has been de-
tected which may damage the emission
control system.
To prevent serious damage to the emis-
sion control system, you should do the
following.
.Reduce vehicle speed.
.Avoid hard acceleration.
.Avoid steep uphill grades.
.Reduce the amount of cargo, if possi-
ble.The CHECK ENGINE warning light may
stop blinking and illuminate steadily after
several driving trips. You should have your
vehicle checked by an authorized
SUBARU dealer immediately.
&Charge warning lightIf this light illuminates when the engine is
running, it may indicate that the charging
system is not working properly.
If the light illuminates while driving or does
not turn off after the engine starts, stop the
engine at the first safe opportunity and
check the alternator belt. If the belt is
loose, broken or if the belt is in good
condition but the light remains illuminated,
contact your nearest SUBARU dealer
immediately.&Oil pressure warning
lightIf this light illuminates when the engine is
running, it may indicate that the engine oil
pressure is low and the lubricating system
is not working properly.
If the light illuminates while driving or does
not turn off after the engine starts, stop the
engine at the first safe opportunity and
check the engine oil level. If the oil level is
low, add oil immediately. If the engine oil is
at the proper level but the light remainsilluminated, contact your nearest
SUBARU dealer immediately.
For details about checking the engine oil
level or adding the engine oil, refer to
“Engine oil”F11-13.
CAUTION
Do not operate the engine with the
oil pressure warning light on. This
may cause serious engine damage.&Engine low oil level
warning indicator
(except STI)This indicator appears when the engine oil
level decreases to the lower limit.
If the engine low oil level warning indicator
appears while driving, park the vehicle in a
safe and level location, and then check the
engine oil level. When the engine oil level
is not within the normal range, refill with
engine oil. Refer to“Engine oil”F11-13.
If the warning indicator does not disappear
after refilling the engine oil, or the warning
indicator appears even though the engine
oil level is within the normal range, have
the vehicle checked by a SUBARU dealer.
–CONTINUED–
Instruments and controls/Warning and indicator lights
3-17
3

(160,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
NOTE.After replacing or adding the engine
oil, if the engine oil level is within the
normal range when restarting the en-
gine on a level surface, the warning
indicator will be off.
.The warning indicator may appear
temporarily in the following conditions
because a low oil level may be detected
as a result of significant oil movement
in the engine.
–when the vehicle is considerably
inclined on an uphill or steep slope
–when the vehicle has continu-
ously accelerated and decelerated
–when the vehicle is continuously
turned
–when the vehicle is driven on a
road that alternates continuously
between uphill and downhill&Windshield washer
fluid warning indicatorThis indicator appears when the fluid level
in the windshield washer fluid tank de-
creases to the lower limit (approximately
1.1 US qt, 1.0 liter, 0.9 Imp qt).
&AT OIL TEMP warning
light (CVT models)If this light illuminates when the engine is
running, it may indicate that the transmis-
sion fluid temperature is too hot.
If the light illuminates while driving, im-
mediately stop the vehicle in a safe place
and let the engine idle until the warning
light turns off.
!Transmission control system warn-
ing
If the“AT OIL TEMP”warning light flashes
after the engine has started, it may indicate
that the transmission control system is not
working properly. Contact your nearest
SUBARU dealer for service immediately.&Rear differential oil
temperature warning
light (STI)
CAUTION
If the R.DIFF TEMP warning light
illuminates, reduce vehicle speed
and stop the vehicle in a safe loca-
tion as soon as possible. Continuing
to drive with this light illuminated
may damage the rear differential and
other parts of the powertrain.If this light illuminates when the engine is
running, it may indicate that the rear
differential oil temperature is too hot.
At this time, the driver’s control center
differential will automatically cancel the
current torque-distribution ratio setting and
adopt its minimum ratio.
If the light illuminates while driving, reduce
vehicle speed and stop the vehicle in the
nearest safe location. Park the vehicle for
several minutes. After the light turns off,
you can start driving.
If the light does not turn off, contact the
nearest SUBARU dealer for service.
NOTE.If the tire pressures are not correct
and/or the tires are not all the same size
and brand, the rear differential will be
heavily loaded when the vehicle is
driven, resulting in an abnormally high
oil temperature.
.The rear differential oil will deterio-
rate if its temperature increases en-
ough for the rear differential oil tem-
perature warning light to illuminate. It is
advisable to have the rear differential
oil replaced as soon as possible.
Instruments and controls/Warning and indicator lights
3-18

(191,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Triple meter screenTriple meter screen (display example)From the following pieces of information,
you can select up to three items to be
displayed.
Item Details
Engine oil temperature (except
STI)Average vehicle speedAccelerator opening ratioItem Details
Vehicle postureAverage fuel consumption cor-
responding to the driving dis-
tance of the odometerBoost pressureJourney distance (the distance
that has been driven since the
ignition switch was turned to
the“ON”position)Average fuel consumption for
the entire driving distance from
when the ignition switch was
turned to the“ON”position
!Prevention safety screen1) Telltale screen
2) Steering angle
3) Vehicle posture
4) Running conditionFor functions that are operating, the
corresponding indicator will illuminate or
flash.NOTEThe vehicle posture indication may
differ from the actual vehicle posture.
–CONTINUED–
Instruments and controls/Multi-function display (color LCD)
3-49
3

(360,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
.The camera unit is a waterproof
structure. Do not attempt to re-
move, disassemble or modify the
unit.
.Do not rub strongly or polish the
camera lens with a hard brush or
abrasive compounds. The lens
may be scratched resulting in an
adverse effect to the camera
image.
.The camera lens is made of glass
or plastic. Do not allow any
organic solvent, body wax, oil
film remover or glass coating
agent to become attached on the
lens surface. If any becomes
attached, remove it immediately.
.Do not expose the camera lens to
any sudden temperature change,
for example, spraying hot water
on it in cold weather.
.Do not apply the water jet of a
high pressure washer to the cam-
era or the surrounding area when
cleaning the vehicle. The impact
by the strong water pressure may
cause the camera to come off.
Also, water may enter inside the
camera and cause a malfunction.
.If the camera is exposed to any
impact, it may lead to malfunctionof the camera. Have the camera
inspected by your SUBARU deal-
er as soon as possible.
.Do not use a steam cleaner under
any circumstances. Some types
of steam cleaners inject hot
steam.
.The camera surface may be da-
maged by a flying stone.
NOTEIf the camera lens is contaminated, no
sharp image is available. When the
camera is contaminated with water
drops, snow or mud, wash it with water
and wipe away any moisture with a soft
cloth. If it heavily gets dirty, wash it with
a neutral detergent.
Interior equipment/Front View Monitor
6-22

(446,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
conditions than a two wheel drive vehicle.
There is little difference in handling, how-
ever, during extremely sharp turns or
sudden braking. Therefore, when driving
down a slope or turning corners, be sure to
reduce your speed and maintain an ample
distance from other vehicles.
.Always check the cold tire pressure
before starting to drive. The recommended
tire pressure is provided on the tire
placard, which is located under the door
latch on the driver’s side.
.Frequent driving of an AWD vehicle
under hard-driving conditions such as
steep hills or dusty roads will necessitate
more frequent replacement of the follow-
ing items than that specified in the“War-
ranty and Maintenance Booklet”.
–Engine oil
–Brake fluid
–Rear differential gear oil
–Manual transmission oil (MT mod-
els)
–Continuously variable transmission
fluid (CVT models)
–Front differential gear oil (CVT
models)
.There are some precautions that you
must observe when towing your vehicle.
For detailed information, refer to“Towing”
F9-21.
Driving precautionWater entering the engine air intake or the
exhaust pipe or water splashing onto
electrical parts may damage your vehicle
and may cause it to stall. Never attempt to
drive through rushing water; regardless of
its depth, it can wash away the ground
from under your tires, resulting in possible
loss of traction and even vehicle rollover.
Winter driving&Operation during cold weath-
erCarry some emergency equipment, such
as a window scraper, a bag of sand, flares,
a small shovel and jumper cables.
Check the battery and cables. Cold tem-
peratures reduce battery capacity. The
battery must be in good condition to
provide enough power for cold winter
starts.
It normally takes longer to start the engine
in very cold weather conditions. Use an
engine oil of a proper grade and viscosity
for cold weather. Using heavy summer oil
will make it harder to start the engine.
Keep the door locks from freezing by
squirting them with deicer or glycerin.
Forcing a frozen door open may damage
or separate the rubber weather strips
around the door. If the door is frozen, use
hot water to melt the ice, and afterwards
thoroughly wipe the water away.
Use a windshield washer fluid that con-
tains an antifreeze solution. Do not use
engine antifreeze or other substitutes
because they may damage the paint of
the vehicle.
Driving tips/Driving precaution
8-6
