972. Instrument cluster
2
Instrument cluster
YARIS_F_WE_52G04E
WARNING
■Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ The multi-information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the display monitor may
respond slowly, and display changes may be delayed.

982. Instrument cluster
YARIS_F_WE_52G04E
Fuel consumption infor mation
Navigation/multimedia system
Press the button on the
navigation/multimedia system.
: If equipped
Fuel consumption information can be displayed on the naviga-
tion/multimedia system.
Trip information (navigation/multimedia system)
1

992. Instrument cluster
2
Instrument cluster
YARIS_F_WE_52G04E
Select “Trip information”.
Average vehicle speed since
the engine was started.
Cruising range ( P. 101)
Fuel consumption in the past
15 minutes
Elapsed time since the
engine was started.
Resetting the consumption
data
Vehicles without a smart entry & start system:
Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the engine
switch was last turned to the “ON” position. Use the displayed aver-
age fuel consumption as a reference.
Vehicles with a smart entry & start system:
Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the engine
switch was last turned to IGNITION ON mode. Use the displayed
average fuel consumption as a reference.
This image is an example only.
2
1
2
3
4
5

1002. Instrument cluster
YARIS_F_WE_52G04E
Press the button on the
navigation/multimedia system.
Select “Past record”.
Best recorded fuel consump-
tion
Previous fuel consumption
record
Average fuel consumption
Updating the average fuel
consumption data
Resetting the past record
data
The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.
This image is an example only.
Past record (navigation/multimedia system)
1
2
1
2
3
4
5

1012. Instrument cluster
2
Instrument cluster
YARIS_F_WE_52G04E
■Updating the past record data
Update the average fuel consumption by selecting “Update” to measure the
current fuel consumption again.
■ Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.

1022. Instrument cluster
YARIS_F_WE_52G04E

103
3
Operation of
each component
YARIS_F_WE_52G04E
3-1. Key information
Keys ................................... 104
3-2. Opening, closing
and locking the doors
Side doors.......................... 116
Back door........................... 123
Smart entry &
start system ..................... 129
3-3. Adjusting the seats
Front seats ......................... 140
Rear seats ......................... 143
Head restraints .................. 146
3-4. Adjusting the steering
wheel and mirrors
Steering wheel ................... 148
Inside rear view mirror ....... 150
Outside rear view mirrors... 153
3-5. Opening and closing
the windows
Power windows .................. 156

1043-1. Key information
YARIS_F_WE_52G04E
Keys
The following keys are provided with the vehicle.
Vehicles without a smart entry & start system (type A)
Keys
Key number plate
Vehicles without a smart entry & start system (type B)
Key (with a wireless remote
control function)
Operating the wireless remote con-
trol function ( P. 117)
Key (without a wireless remote
control function)
Key number plate
Vehicles without a smart entry & start system (type C)
Keys
Operating the wireless remote con-
trol function ( P. 117)
Key number plate
The keys
1
2
1
2
3
1
2
