2014 NISSAN LEAF Navigation Manual

Black plate (29,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
LNC0200X
3. Confirm the contents of the message, thentouch [Yes].
LNC0029X
4.Touch [Map]. The current location map
screen is displayed.
LNC0030X
5. If necessary, adjust your home location by
touch panel operation.
6. After adjusting the location, touch [OK]. A message is displayed and your home loca-
tion is stored in the Address Book.
LNC0031X
7. Adjust the location of a stored item and editthe contents of a stored item as necessary.
8. Touch [OK] to return to the Destination screen.
INFO:
You can also perform the same setting by
pushing the MENUbutton and selecting [Set-
tings].
“Storing location” (page 3-38)
CONNECTING CELLULAR PHONEGUID-0E418F5B-07F0-4047-977C-447142C17340Your vehicle is equipped with Bluetooth®
Hands-Free Phone System. If you are an owner
of a compatible Bluetooth®enabled cellular
phone, you can set up the wireless connection
between your cellular phone and the in-vehicle
phone module. With Bluetooth
®wireless tech-
nology, you can make or receive a telephone call
with your cellular phone in your pocket.
LNC0032X
1. Push thebutton and touch [Connect
Phone].
Getting Started1-13
Condition: NAM/

Black plate (30,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
1-14Getting Started
LNC0033X
2. When a PIN code appears on the screen,operate the compatible Bluetooth®cellular
phone to enter the PIN code.
The procedure for cellular phone connection
varies according to each cellular phone.
Refer to the cellular phone Owner’s Manual
for the details.
You can also visit www.nissanusa.com/blue-
tooth or call NISSAN Consumer Affairs
Department for instructions on pairing
NISSAN recommended cellular phones.
When the connection process is completed,
the screen will return to the Phone menu
screen.
Some cellular phones or other devices may
cause interference or a buzzing noise to
come from the audio system speakers.
Storing the device in a different location
may reduce or eliminate the noise.
INFO:
The cellular phone connection can also be set
by performing the following procedure.
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Bluetooth Connections].
3. Touch [Connect Bluetooth].
DISPLAY ADJUSTMENTGUID-6BF6BB79-7BC5-47FC-AE67-09BC1505C4C5This menu turns on and off the display and
adjusts the image quality of the navigation
screen.
LNC0034X
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Display].
3. Touch the preferred adjustment item and adjust to the preferred setting. Available settings
.
[Display]:
Turn on or off the screen.
“Display” (page 1-14)
. [Brightness]:
Adjust the screen brightness.
“Brightness” (page 1-15)
. [Contrast]:
Adjust the screen contrast.
“Contrast” (page 1-15)
. [Background Color]:
Set the background color.
“Background color” (page 1-15)
DisplayGUID-7C252615-E2C6-447B-8887-BFBEBB0E6F12
LNC0035X
To turn off the display, touch [Display].
The display can also be turned off by pushing
and holding the
button for more than 2
seconds.
Condition: NAM/

Black plate (31,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
LNC0036X
When any button is pushed with the display off,
the display turns on. The display will automati-
cally turn off when there is no switch operation
for 5 seconds.
To turn on the display, push the
button.
BrightnessGUID-2879B020-3DC2-405E-82FA-E10F80586C2C
LNC0037X
1. Touch [Brightness].
2. Adjust the display brightness by touching[+] or [-].
ContrastGUID-D109E07C-6E82-4966-A2BF-B086F27D282D
LNC0038X
1. Touch [Contrast].
2. Adjust the display contrast by touching [+]or [-].
Background colorGUID-E394FC85-8919-4E4D-A990-4DCE6F6F5100
LNC0039X
1. Touch [Background Color].
2. Touch [Day] or [Night]. The indicator of theselected color illuminates.
LNC0040X
Day screen
LNC0041X
Night screen
INFO:
The background color setting can also be
changed by pushing the
button.
Getting Started1-15
Condition: NAM/

Black plate (32,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
1-16Getting Started
VOLUME SETTINGSGUID-210F184A-892E-4546-8D2A-0868DA7C4F52This turns on and off, as well as adjusts, the
phone function (ringer, incoming and outgoing
volume) , the voice guide function and the beep
function.
LNC0042X
1. Push theMENUbutton and touch [Set-
tings].
2. Touch [Volume & Beeps].
3. Touch the item you would like to adjust.
Available settings
. [Audio Volume]:
Adjust the volume level of the audio system
by touching [+] or [-].
. [Guidance Volume]:
Adjust the volume level of voice guidance by
touching [+] or [-].
. [Ringtone]:
Adjust the volume level of the ringtone by
touching [+] or [-]. .
[Incoming Call]:
Adjust the incoming call volume by touching
[+] or [-].
. [Outgoing Call]:
Adjust the outgoing call volume by touching
[+] or [-].
. [CARWINGS Volume]:
Adjust the volume level of the CAR-
WINGS
TMinformation channel by touching
[+] or [-].
. [Switch Beeps]:
Select to toggle the beep function between
ON and OFF. The indicator light illuminates
when the beep function is set to ON. The
beep sounds when pushing and holding a
button or when a prohibited operation is
performed.
. [Guidance Voice]:
Select to toggle the voice guidance function
between ON and OFF. The indicator light
illuminates when the voice guidance func-
tion is set to ON.
CLOCK SETTINGSGUID-6FB05DB7-7A72-4B43-A7A5-4796C1370711This changes the clock settings.
LNC0043X
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Others].
3. Touch [Clock].
4. Touch the item you would like to adjust.
5. Adjust the preferred setting. Touch the item to set ON or OFF.
Available settings
. [On-screen Clock]:
Select to toggle the clock display located in
the top right corner of the display between
ON and OFF. The indicator light illuminates
when the clock display is set to ON.
. [Clock Format (24h)]:
Select the clock format between 12-hour
and 24-hour times. The indicator light
Condition: NAM/

Black plate (33,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
illuminates when the clock is set to the 24-
hour format.
. [Offset (hour)]:
Touch [+] or [−] to adjust the offset value
(between −12 and +12).
. [Offset (min)]:
Touch [+] or [−] to adjust the offset value
(between −59 and +59).
. [Daylight Savings Time]:
Select to toggle the daylight savings time
setting between ON and OFF. The indicator
light illuminates when the daylight savings
time setting is set to ON.
. [Time Zone]:
Select an appropriate time zone from the list
that appears when this item is highlighted.
LANGUAGE AND UNIT SETTINGSGUID-D7E9171E-3B1C-414A-AD30-925AD34D89F6This changes the language and measurement
unit used in the system.
Language settingsGUID-156161A7-0FF9-43D8-A93F-D698B21DD9CB
LNC0044X
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Others].
3. Touch [Language & Units].
4. Touch [Select Language].
LNC0189X
5. Touch the item you would like to set. The indicator light of the selected item illumi-
nates. Available languages
.English
.Franc¸ ais
.Espan
˜
ol
INFO:
Do not push power switch while changing the
language.
Unit settingsGUID-D5F5F04F-B331-4D52-AB86-F6014727C6F5
LNC0046X
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Others].
3. Touch [Language & Units].
4. Touch [Select Units].
Getting Started1-17
Condition: NAM/

Black plate (34,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
1-18Getting Started
LNC0047X
5. Touch the preferred unit. The indicator of theselected unit illuminates.
Available units
.US: mile, 8F, mile/kWh
.Metric: km, 8C, km/kWh
6. Push the MAPbutton to return to the
current location map screen.
Condition: NAM/

Black plate (35,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
2 Unique EV functions
Zero Emission menu screen...
................................................... 2-2
Displaying estimated driving range and charging
station information ...
..................................................................... 2-3
Displaying estimated driving range ...
................................. 2-3
Displaying charging station icons on map ...
.................... 2-5
Confirming charging station availability ...
.......................... 2-6
Updating charging station information ...
........................... 2-7
Energy information display ...
....................................................... 2-8
Viewing energy economy information ...
............................. 2-8 Viewing energy economy history
...
................................... 2-9
Viewing energy usage information ...
................................ 2-9
Timer function operation ...
...................................................... 2-10
Setting timer charge ...
...................................................... 2-10
Setting Climate Ctrl. Timer ...
........................................... 2-12
Unique EV function settings ...
................................................ 2-14
Setting messages that are displayed on screen ...
.... 2-15
Battery and power information ...
.................................... 2-16
Condition: NAM/

Black plate (36,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
2-2Unique EV functions
GUID-C21D2150-F7F0-4C39-BE4B-58106A8753F0Push the(Zero Emission menu) button to
display the menu that includes useful functions
for electric vehicle driving.
LND0093X
Available settings
. [Driving Range]:
The estimated driving area within range,
including the current position is displayed on
the map screen.
“Displaying estimated driving range”
(page 2-3)
. [Nearby Stations]:
Charging station information for the current
position area is displayed.
“Finding charging station” (page 3-25)
. [Update Stations]:
Charging station information is updated
through connection to the NISSAN CARW-
INGS Data Center.
“Updating charging station informa-
tion” (page 2-7) .
[Energy Info]:
Energy information is displayed on the
screen.
“Energy information display”
(page 2-8)
. [Charging Timer]:
The timer charge function can be set.
“Setting timer charge” (page 2-10)
. [Climate Ctrl. Timer]:
The Climate Ctrl. Timer function can be set.
“Setting Climate Ctrl. Timer”
(page 2-12)
. [CARWINGS]:
Information feeds are displayed and settings
for CARWINGS
TMcan be performed.
“5. CARWINGSTM”
. [Settings]:
Set messages that are displayed on the
screen and email messages that can by
received using a personal computer or
cellular phone.
“Unique EV function settings”
(page 2-14) NOTE:
.
Establishing the CARWINGS
TMservice
is necessary before using this service.
. To check the Li-ion battery charging
status or to use the remote heater and
air conditioner using an internet en-
abled smart phone or personal compu-
ter, the following conditions must be
met:
—The vehicle must be located in a
cellular phone or smart phone cov-
erage area.
— The internet enabled cellular phone
or smart phone must be located in a
cellular phone or smart phone cov-
erage area.
— The computer must be connected to
the internet.
— A cellular phone must be used to
communicate with the vehicle.
— A cellular phone capable of text
messaging must be used to receive
text message regarding vehicle
charge status.
. When the remote heater and air condi-
tioner is set, the system operates the
heater and air conditioner to adjust the
in-cabin temperature to a set tempera-
ture.
ZERO EMISSION MENU SCREEN
Condition: NAM/
