2014 NISSAN LEAF Navigation Manual

Black plate (125,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
.[Reset All Navigation Settings to Default]:
Reset all of the settings to default.
“Resetting all navigation settings to
default” (page 3-76)
SPEED LIMIT INDICATION ON MAPGUID-74F952D7-370C-42F5-8BAB-781340471476Turn the [Speed Limit Indication on Map] display
on or off. The indicator light illuminates when the
speed limit display function is set to on.
LNE0224X
1. Touch [Speed Limit Indication on Map] to
toggle the function between on and off. The
indicator light illuminates when the speed
limit display function is set to on.
OTHER NAVIGATION SETTINGSGUID-B70F87A2-B892-4DF9-A90A-268F68B951D1
LNE0225X
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Navigation].
3. Touch [Others].
4. Touch the item you would like to set.
Available settings
. [Audio Display on Map]:
Allows the audio information to be displayed
at all times.
“Displaying audio information on map
screen” (page 3-73)
. [Map Scrolling Information]:
Sets the system so that when the map
scrolls the information about the location
aligned at the center of the cross pointer is
displayed.
“Map scrolling information”
(page 3-13) .
[Customize Nearby Places]:
Set the category of frequently visited nearby
places.
“Customizing Nearby Places”
(page 3-74)
. [Keyboard Type]:
Switches the keyboard layout for the char-
acter input screen.
“Settings keyboard layout of character
input screen” (page 3-74)
. [North Up when Zoomed Out]:
When this setting is ON, the orientation of
the map is automatically changed to North
Up when the widest map scale is selected.
The orientation is changed to North Up even
when Heading Up is set.
. [Adjust Current Location]:
Corrects the position of the current location.
“Adjusting current vehicle location”
(page 3-75)
Displaying audio information on
map screen
GUID-B259E4C6-1EF1-455C-AE6F-FF1453DB4A23The operating status of audio functions can be
displayed on the map screen.
1. Touch [Others].
Navigation3-73
Condition: NAM/

Black plate (126,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-74Navigation
LNE0226X
2. Touch [Audio Display on Map]. The indicatorilluminates when the item is set.
3. Push the MAPbutton to return to the
current location map screen.
LNE0227X
4. On the bottom of the map screen, the
operating status of an audio/visual function
is displayed at all times.
Customizing Nearby PlacesGUID-A4E50221-4823-4EA9-82A7-F33DD5C56E4DThe categories can be customized for searching
places of interest nearby.
The modified list of points of interest can be
used for searching for a location using [Nearby
Points of Interest].
1. Touch [Others].
2. Touch [Customize Nearby Places].
LNE0228X
3. Touch the preferred item. The main categorylist is displayed.
LNE0229X
4. Touch a main category. The sub category listis displayed.
LNE0230X
5. Touch a sub category. The category settingis modified.
Settings keyboard layout of charac-
ter input screen
GUID-015D713B-5749-42AB-A5C8-6F76F2EECE39The keyboard layout of the character input
screen can be set to either the ABC or
QWERTY layout, depending on the user’s
preference.
Example: Switching to the QWERTY layout
1. Touch [Others].
2. Touch [Keyboard Type].
Condition: NAM/

Black plate (127,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
LNE0231X
3. Touch [QWERTY]. The indicator illuminateswhen the item is set.
LNE0233X
QWERTY layout
LNE0232X
ABC layout
Adjusting current vehicle locationGUID-C06E4422-837B-4B6E-A88B-5DF87C6FF47CIf the vehicle icon indicating the current vehicle
location is not in the correct position, the
location of the vehicle icon on the map screen
can be adjusted.
INFO:
. Regardless of the map view setting, the map
is displayed in Plan View when adjusting the
position of the vehicle icon.
. When correcting the position of the vehicle
icon, the map is automatically displayed in
the North Up mode. After finishing the
correction, the map restores the current
orientation setting.
. The position and direction of the vehicle icon
may be misaligned depending on the
external conditions and environment.
. If the vehicle icon is misaligned, drive for a
while in a location where GPS signals can
be received. This may correct the position of
the vehicle icon.
“Vehicle icon” (page 10-10)
1. Touch [Others].
2. Touch [Adjust Current Location]. The current location map screen is displayed.
LNE0234X
3. Adjust the position of the vehicle icon byusing touch panel operation. After adjusting
the position of the vehicle icon, touch [OK].
LNE0235X
4. Adjust the direction of the vehicle icon bytouching [
] or [].
Navigation3-75
Condition: NAM/

Black plate (128,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-76Navigation
LNE0236X
5. After adjusting the direction of the vehicleicon, touch [OK]. A message is displayed,
and the adjusted vehicle location is stored.
RESETTING ALL NAVIGATION SET-
TINGS TO DEFAULT
GUID-70BDDBEB-12DC-49D8-AE82-AEEC91A2A13AThis restores various settings (display, volume
level, etc.) to the default settings.
INFO:
The memory contents, such as the stored
locations, will not be deleted.
1. Push the MENUbutton and touch [Set-
tings].
2. Touch [Navigation].
LNE0237X
3. Touch [Reset All Navigation Settings to
Default].
LNE0238X
4. A confirmation message is displayed. Con-
firm the contents of the message, then touch
[Yes].
Condition: NAM/

Black plate (129,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
4 Audio system
Audio operation precautions...
................................................... 4-2
Radio ...
........................................................................\
............... 4-2
Compact Disc (CD) player ...
................................................ 4-3
USB (Universal Serial Bus) ...
............................................... 4-4
iPod
®player and iPhone®...
................................................. 4-5
Compressed Audio Files (MP3/WMA) ...
.......................... 4-7
Bluetooth
®streaming audio ...
........................................... 4-10
FM-AM-SAT radio with compact disc (CD) player ...
........ 4-10
Audio main operation ...
....................................................... 4-10 FM-AM-SAT radio operation
...
........................................ 4-11
Compact Disc (CD) player operation ...
........................ 4-13
iPod
®player operation ...
.................................................. 4-15
Pandora®operation (if so equipped) ...
........................ 4-16
USB memory operation ...
................................................. 4-18
Bluetooth
®streaming audio operation ...
...................... 4-19
Auxiliary input jack ...
.......................................................... 4-22
Steering wheel switches for audio control ...
.............. 4-23
Condition: NAM/

Black plate (130,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
4-2Audio system
GUID-B0DBBB37-B849-425F-902A-DDABE30FE9B4
RADIOGUID-2E7BDA12-EFEE-40F2-BD7E-0C1AD5ECA109Push the power switch to the ACC or ON
position and push the radio band select button
to turn on the radio. If you listen to the radio with
the READY to drive indicator light is OFF, the
power switch should be pushed to the ACC
position.
Radio reception is affected by station signal
strength, distance from radio transmitter, build-
ings, bridges, mountains and other external
influences. Intermittent changes in reception
quality normally are caused by these external
influences.
Using a cellular phone in or near the
vehicle may influence radio reception
quality.
Radio receptionGUID-89FE3704-0B57-4447-88CD-7BD9D337A7DCYour NISSAN radio system is equipped with
state-of-the-art electronic circuits to enhance
radio reception. These circuits are designed to
extend reception range, and to enhance the
quality of that reception.
However there are some general characteristics
of both FM and AM radio signals that can affect
radio reception quality in a moving vehicle, even
when the finest equipment is used. These
characteristics are completely normal in a given
reception area, and do not indicate any mal-function in your NISSAN radio system.
Reception conditions will constantly change
because of vehicle movement. Buildings, terrain,
signal distance and interference from other
vehicles can work against ideal reception.
Described below are some of the factors that
can affect your radio reception.
Some cellular phones or other devices may
cause interference or a buzzing noise to come
from the audio system speakers. Storing the
device in a different location may reduce or
eliminate the noise.
While charging the vehicle, radio programs may
not be tuned in to because the reception of the
radio becomes weak.
FM radio receptionGUID-275BC1BF-3C52-437B-9A90-2B55439E4402
LNF0001X
Range: FM range is normally limited to 25 to 30
miles (40 to 48 km) , with monaural (single
station) FM having slightly more range than
stereo FM. External influences may sometimes
interfere with FM station reception even if the
FM station is within 25 miles (40 km). The
strength of the FM signal is directly related to the
distance between the transmitter and receiver.
FM signals follow a line-of-sight path, exhibiting
many of the same characteristics as light. For
example they will reflect off objects.
Fade and drift: As your vehicle moves away from
a station transmitter, the signals will tend to fade
and/or drift.
Static and flutter: During signal interference from
buildings, large hills or due to antenna position,
usually in conjunction with increased distance
from the station transmitter, static or flutter can
be heard. This can be reduced by lowering the
treble setting to reduce the treble response.
Multipath reception: Because of the reflective
characteristics of FM signals, direct and re-
flected signals reach the receiver at the same
time. The signals may cancel each other,
resulting in momentary flutter or loss of sound.
AUDIO OPERATION PRECAUTIONS
Condition: NAM/

Black plate (131,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
AM radio receptionGUID-F3C8ECE4-EFC7-4ED4-9553-9C805FE5ED54AM signals, because of their low frequency, can
bend around objects and skip along the ground.
In addition, the signals can bounce off the
ionosphere and be bent back to earth. Because
of these characteristics, AM signals are also
subject to interference as they travel from
transmitter to receiver.
Fading: Occurs while the vehicle is passing
through freeway underpasses or in areas with
many tall buildings. It can also occur for several
seconds during ionospheric turbulence even in
areas where no obstacles exist.
Static: Caused by thunderstorms, electrical
power lines, electric signs and even traffic lights.
Satellite radio receptionGUID-2273FD6D-FB06-452C-998D-A63512E7162FWhen the satellite radio is used for the first time
or the battery has been replaced, the satellite
radio may not work properly. This is not a
malfunction. Wait more than 10 minutes with the
satellite radio ON and the vehicle outside of any
metal or large building for the satellite radio to
receive all of the necessary data.
The satellite radio mode requires an active
SiriusXM Satellite Radio subscription. The sa-
tellite radio is not available in Alaska, Hawaii and
Guam.
The satellite radio performance may be affectedif cargo carried on the roof blocks the satellite
radio signal.
If possible, do not put cargo near the satellite
antenna.
A build up of ice on the satellite radio antenna
can affect satellite radio performance. Remove
the ice to restore satellite radio reception.
COMPACT DISC (CD) PLAYERGUID-DC5E2611-026D-452C-A4AC-47F0F8806FC5
NAI0802
.
Do not force a compact disc into the CD
insert slot. This could damage the CD and/
or CD player.
. Trying to load a CD with the CD door closed
could damage the CD and/or CD player.
Audio system4-3
Condition: NAM/

Black plate (132,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
4-4Audio system
.During cold weather or rainy days, the player
may malfunction due to the humidity. If this
occurs, remove the CD and dehumidify or
ventilate the player completely.
. The player may skip while driving on rough
roads.
. The CD player sometimes cannot function
when the passenger compartment tempera-
ture is extremely high. Decrease the tem-
perature before use.
. Only use high quality 4.7 in (12 cm) round
discs that have the "COMPACT disc DIGI-
TAL AUDIO" logo on the disc or packaging.
. Do not expose the CD to direct sunlight.
. CDs that are of poor quality, dirty, scratched,
covered with fingerprints, or that have pin
holes may not work properly.
. The following CDs may not work properly:
— Copy control compact discs (CCCD)
— Recordable compact discs (CD-R)
— Rewritable compact discs (CD-RW)
. Do not use the following CDs as they may
cause the CD player to malfunction.
— 3.1 in (8 cm) discs
— CDs that are not round
— CDs with a paper label — CDs that are warped, scratched, or have
abnormal edges
. This audio system can only play prerecorded
CDs. It has no capabilities to record or burn
CDs.
. If the CD cannot be played, one of the
following messages will be displayed.
CHECK DISC:
— Confirm that the CD is inserted correctly
(the label side is facing up, etc.).
— Confirm that the CD is not bent or warped and it is free of scratches.
PUSH EJECT:
This is an error due to the temperature inside
the player being too high. Remove the CD
by pushing the
button, and after a short
time reinsert the CD. The CD can be played
when the temperature of the player returns
to normal.
UNPLAYABLE:
The file is unplayable in this audio system
(the system only supports CDs containing
MP3 or WMA files) .
USB (Universal Serial Bus)GUID-B14770CC-B357-4196-BAA4-5BEF948ED871
WARNING
Do not connect, disconnect or operate
the USB device while driving. Doing so
can be a distraction. If distracted you
could lose control of your vehicle and
cause an accident or serious injury.
CAUTION
. Do not force the USB device into the
USB port. Inserting the USB device
tilted or up-side-down into the port
may damage the port. Make sure
that the USB device is connected
correctly into the USB port.
. Do not grab the USB port cover
when pulling the USB device out of
the port. This could damage the port
and the cover.
. Do not leave the USB cable in a
place where it can be pulled unin-
tentionally. Pulling the cable may
damage the port.
The vehicle is not equipped with a USB device.
Condition: NAM/
