2013 TOYOTA SIENNA Owners Manual

833
6-2. Customization
6
Vehicle specifications
SIENNA_OM_OM45472U_(U)
ItemFunctionDefault settingCustomized
setting
Door lock
(
P. 6 0 ) Unlocking using a key
Drivers door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step
Speed-detecting auto-
matic door lock func-
tion
*
Off On
Opening drivers door
unlocks all doors
*Off On
Shifting gears to P
unlocks all doors
*On Off
Shifting gears to posi-
tion other than P locks
all doors
*
On Off

834 6-2. Customization
SIENNA_OM_OM45472U_(U)
ItemFunctionDefault settingCustomizedsetting
Power
sliding door
(if equipped)
(
P. 67) Operation signal
(buzzer)
Off On
Opening and closing
operation One short push Push and hold
Automatic
light control
system
( P. 268) Time elapsed before
headlights automati-
cally turn off after doors
are closed
*
30 seconds
0 second
60 seconds
90 seconds
Daytime running light
system (U.S.A. only) On Off
Light sensor sensitivity Level 3 Level 1 to 5
Automatic High Beam
(if equipped)
*On Off
Alarm
system
( P. 162) Time elapsed before
the alarm is set
14 seconds 30 seconds
Multi-
information
display
( P. 254) Language selection
*English
French
Spanish

835
6-2. Customization
6
Vehicle specifications
SIENNA_OM_OM45472U_(U)
*: For vehicles with the multi-information display, the setting can be changed by
operating the multi-information display. (
P. 836)
ItemFunctionDefault settingCustomized setting
Illumination
(
P. 580) Time elapsed before
lights turn off
15 seconds7.5 seconds
30 seconds
Operation when the
doors are unlocked On Off
Operation after the
engine switch is turned
to the “LOCK” position On Off
Rear ceiling light On Off
Outer foot lights On Off
Intuitive
parking
assist
(
P. 316) Buzzer volume Max. Min. to Max.
Seat belt
reminder
(
P. 749) Vehicle speed linked
seat belt reminder
buzzer
On Off

836 6-2. Customization
SIENNA_OM_OM45472U_(U)
Customizing the features by using the multi-information display
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 20
seconds, the display will return to
the previous screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, then press
the “SELECT RESET” button to
select.
If you select “Exit” and press the
“SELECT RESET” button, the
display will return to the previous
screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
The illustration assumes that
“Door” was chosen in .
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will return to the “Custom
Settings” screen.
STEP1
STEP2
STEP3
STEP2

837
6-2. Customization
6
Vehicle specifications
SIENNA_OM_OM45472U_(U)
Choose a desired setting by
pressing the “INFO” or “SETUP”
button, then press the “SELECT
RESET” button to select.
If any settings are changed, the
display will revert to the previous
screen.
The illustration assumes that
“Auto Locking” was chosen in
.
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will revert to the previous
screen.
■ Restoring default settings
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 20
seconds, the display will revert to
the previous screen.
STEP4
STEP3
STEP1

838 6-2. Customization
SIENNA_OM_OM45472U_(U)Select “Default Settings” by
pressing the “INFO” or “SETUP”
button, and press the “SELECT
RESET” button.
If you select “Exit” and press the
“SELECT RESET” button, the
display will revert to the previous
screen.
Select “Yes” by pressing the
“INFO” or “SETUP” button, and
press the “SELECT RESET” but-
ton.
“Default Settings Restored” is dis-
played, and the default settings
are restored.
If you select “No” and press the
“SELECT RESET” button, the
display will revert to the “Custom
Settings” screen without restor-
ing the default settings.
STEP2
STEP3
■
If the vehicle is moved while setti ngs are being changed on the multi-
information display
 P. 265

839
6
Vehicle specifications
SIENNA_OM_OM45472U_(U)
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Power sliding door
(if equipped) After reconnecting or changing the
battery
P. 7 4
Power back door
(if equipped) After reconnecting or changing the
battery
P. 8 7
Maintenance data
(U.S.A. only) After the maintenance is performed P. 656
Tire pressure warning
system When changing the tire size P. 690
The following items must be init
ialized for normal system operation
after such cases as the battery being reconnected, or maintenance
being performed on the vehicle.

840 6-3. Initialization
SIENNA_OM_OM45472U_(U)
