2011 Hyundai Accent Owner's Manual - RHD (UK. Australia)

1FEATURES OF YOUR HYUNDAI
94DEMISTING/DEFOGGINGVENTILATIONBI-LEVEL HEATING
B720A01MC-DAT Use the heating/ventilation system to demist or defog the windshield: To remove interior fog on the windshield:
o Set the air flow control to the demist(
) position. (Push the A/C button
to turn the air conditioning system on and set the air intake control to the fresh air (
) position.)
o Set the temperature control to the desired position.
o Set the fan speed control between
"1" and "4" position.
B700B02A-AAT Your Hyundai is equipped with bi-level heating controls. This makes it pos- sible to have cooler air from the dash-board vents and warmer air from the floor outlets at the same time. To use this feature:
o Set the air intake control to the fresh
air (
) position.
o Set the air flow control at the bi-level (
) position.
o Adjust the fan speed control to the
desired speed.
o Set the temperature control between "Cool" and "Warm". B710A01A-AAT To operate the ventilation system:
o Set the air intake control to "Fresh"
mode (
).
o To direct all intake air to the dash-
board vents, set the air flow control to the (
) position.
o Adjust the fan speed control to the
desired speed.
o Set the temperature control between "Cool" and "Warm".
B700B01MC-DB710A01MC-DB720A01MC-D

1
FEATURES OF YOUR HYUNDAI
95
To remove the frost or exterior fog on the windshield:
o Set the air flow control to the demist
(
) position. (Push the A/C button
to turn the air conditioning system on and set the air intake control to the fresh air (
) position.)
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4".
B720A02MC-D B730A01L-AAT Operation Tips
o To keep dust or unpleasant fumes
from entering the car through the ventilation system, temporarily set the air intake control at the (
)
position. Be sure to return the control to the (
) position when the irrita-
tion has passed to keep fresh air in the vehicle. This will help keep thedriver alert and comfortable.
o Air for the heating/cooling system is
drawn in through the grilles just aheadof the windshield. Care should be taken that these are not blocked by leaves, snow, ice or other obstruc-tions.
o To prevent interior fog on the wind-
shield, set the air intake control tothe fresh air (
) position, fan speed
to the desired position, turn on the air conditioning system, and adjust tem-perature control to desired tempera- ture.
NOTE: When the A/C is operated continu- ously on the floor-demist level (
)
or demist level (
), it may cause fog
to form on the exterior windshield. If this occurs, set the air flow control to the face level position (
) and fan
speed control to the low position.

1FEATURES OF YOUR HYUNDAI
96
B740B01MC-DAT Air Conditioning Operation (Cooling) To use the air conditioning to cool the interior:
o Turn on the fan control switch.
o Turn on the air conditioning switch by
pushing in on the switch. The air conditioning indicator light should come on at the same time.
o Set the temperature control to "Cool". ("Cool" provides maximum cooling.The temperature may be moderatedby moving the control toward "Warm".) o Adjust the fan speed control to the
desired speed. For greater cooling, turn the fan speed control to one of the higher speeds or temporarily se- lect the (
) position on the air
intake control.
B740B01MC-D
AIR CONDITIONING SYSTEM
B740A01A-AAT (If Installed) Air Conditioning Switch
The air conditioning is turned on by pushing the A/C button on the heating/ air conditioning control panel.
B740A01MC-D

1
FEATURES OF YOUR HYUNDAI
97
B740D01A-AAT Operation Tips
o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air condition-
ing system, keep all windows closedto keep hot air out.
o When moving slowly, as in heavy
traffic, shift to a lower gear. Thisincreases engine speed, which in turn increases the speed of the air conditioning compressor.
o On steep grades, turn the air condi- tioning off to avoid the possibility ofthe engine overheating.
o During winter months or in periods when the air conditioning is not usedregularly, run the air conditioning onceevery month for a few minutes. This will help circulate the lubricants and keep your system in peak operatingcondition.
B740C01MC-AAT De-Humidified Heating
For dehumidified heating:
o Turn on the fan control switch.
o Turn on the air conditioning switch. The air conditioning indicator light should come on at the same time.
o Set the air intake control to the fresh air (
) position.
o Adjust the fan speed control to the
desired speed.
o For more rapid action, set the fan at one of the higher speeds.
o Adjust the temperature control to provide the desired amount of warmth.
B740C01MC-D

1FEATURES OF YOUR HYUNDAI
98
B760A01MC
CLIMATE CONTROL AIR FIL- TER
!
The climate control air filter is located in the passenger cabin in front of the evaporator unit behind the glove box. It functions to decrease the amount ofpollutants entering the car. To replace the climate control air filter, refer to the page 6-16.
B760A07A-DAT
(For Evaporator and Blower Unit)
CAUTION:
o Replace the filter every 15,000 km (10,000 miles) or once a year. If the car is being driven in severe con-ditions such as dusty, rough roads, more frequent climate con- trol air filter inspections andchanges are required.
o When the air flow rate is de-
creased, it must be checked at anauthorised dealer.
Inside of a vehicle
Evaporator core
Blower
FilterInside air
Outside air

1
FEATURES OF YOUR HYUNDAI
99
B750A01L
STEREO SOUND SYSTEM
Ionosphere
AM reception
Mountains
Buildings Unobstructed
area
FM radio station
B750A03L
Ionosphere
FM receptionObstructed area
Iron bridges
FM broadcasts are transmitted at high frequencies and do not bend to follow the earth's surface. Because of this, FM broadcasts generally begin to fadeat short distances from the station. Also, FM signals are easily affected by buildings, mountains, or other obstruc-tions. These can result in certain listen- ing conditions which might lead you to believe a problem exists with your ra-dio. The following conditions are normal and do not indicate radio trouble:
AM broadcasts can be received at greater distances than FM broadcasts. This is because AM radio waves are transmitted at low frequencies. Theselong, low frequency radio waves can follow the curvature of the earth rather than travelling straight out into the at-mosphere. In addition, they curve around obstructions so that they can provide better signal coverage.
B750A02A-AAT How Car Audio Works
AM and FM radio signals are broadcast from transmitter towers located around your city. They are intercepted by theradio antenna on your car. This signal is then received by the radio and sent to your car speakers.When a strong radio signal has reached your vehicle, the precise engineering of your audio system ensures the bestpossible quality reproduction. Howev- er, in some cases the signal coming to your vehicle may not be strong andclear. This can be due to factors such as the distance from the radio station,
B750A02L
closeness of other strong radio stations or the presence of buildings, bridges orother large obstructions in the area.

1FEATURES OF YOUR HYUNDAI
100
!
B750B02Y-DAT Using a mobile phone or a two- way radio When a mobile phone is used inside the vehicle, noise may be produced fromthe audio equipment. This does not mean that something is wrong with the audio equipment. In such a case, usethe mobile phone at a place as far as possible from the audio equipment.
!
CAUTION:
When using a communication sys- tem such as a mobile phone or aradio inside the vehicle, a separate external antenna must be fitted. When a mobile phone or a radio set is usedwith an internal antenna alone, it may interfere with the vehicle's elec- trical system and adversely affectsafe operation of the vehicle.
WARNING:
Don't use a mobile phone when youare driving. Stop at a safe place to use a mobile phone.
o Station Swapping - As an FM signal
weakens, another more powerful sig- nal near the same frequency may begin to play. This is because your radio is designed to lock onto theclearest signal. If this occurs, select another station with a stronger sig- nal.
o Multi-Path Cancellation - Radio sig- nals being received from several di-rections can cause distortion or flut-tering. This can be caused by a direct and reflected signal from the same station, or by signals from twostations with close frequencies. If this occurs, select another station until the condition has passed.
o Fading - As your car moves away
from the radio station, the signal willweaken and sound will begin to fade. When this occurs, we suggest that you select another stronger station.
o Flutter/Static - Weak FM signals or large obstructions between the trans-mitter and your radio can disturb thesignal causing static or fluttering noises to occur. Reducing the treble level may lessen this effect until thedisturbance clears.
B750A04LB750A05L

1
FEATURES OF YOUR HYUNDAI
101CARE OF DISCS
Storage When not in use, place your discs in their individual cases and store them ina cool place away from the sun, heat, and dust. Do not grip or pull out the disc with yourhand while the disc is being pulled into the unit by the self loading mechanism. Keep Your Discs Clean
B850A02F-DAT Proper Handling
Handle your disc as shown. Do not drop the disc. Hold the disc so you will not leave fingerprints on the surface. If thesurface is scratched, it may cause the pickup to skip signal tracks. Do not affix tape, paper, or gummed labels onthe disc. Do not write on the disc. Damaged Disc Do not attempt to play damaged, warped or cracked discs. These could severelydamage the playback mechanism.
B850A01L
B850A02L
Fingerprints, dust, or foreign material on the surface of a disc could cause the pickup to skip signal tracks. Wipe the surface clean with a clean soft cloth.If the surface is heavily soiled, dampen a clean soft cloth in a solution of mild neutral detergent to wipe it clean.
CARE OF CASSETTE TAPES
B860A01A-DAT Proper care of your cassette tapes will extend the tape life and increase your listening enjoyment. Always protectyour tapes and cassette cases from direct sunlight, severely cold and dusty conditions.When not in use, cassettes should always be stored in the original protec- tive cassette case. When the vehicle isvery hot or cold, allow the interior tem- perature to become more comfortable before listening to your cassettes.
o Never leave a cassette inserted in the player when not being played. This could damage the tape player unit and the cassette tape.
B860A01L
