2011 Hyundai Accent Owner's Manual - RHD (UK. Australia)

1FEATURES OF YOUR HYUNDAI
6
!
OMC025006R
B040D01MC-DAT Locking From the Inside
To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. NOTE:
o When the door is locked, the red mark on the switch is not visible.
o The driver's door can be opened by pulling the inside door handle even if the lock switch is de- pressed. B040E04A-DAT CHILD-PROTECTOR REAR DOOR LOCK (4 Door) Your Hyundai is equipped with a "child- protector" rear door lock assembly.
NOTE:
o If your vehicle is equipped with
central door locking system, the door will not lock if the key is leftin the ignition switch when the front doors are closed.
o When locking the door this way, be careful not to lock the door withthe ignition key left in the vehicle.
o To protect against theft, always remove the ignition key, close allwindows, and lock all doors and the boot lid(4 Door)/tail gate(3 Door)when leaving your vehicle unat- tended.
LOCK
UNLOCK
B040E01MC
WARNING:
Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can beopened and you may be ejected from the vehicle and can be injured or killed.

1
FEATURES OF YOUR HYUNDAI
7
!
B040G01MC-DAT Central Door Lock (If Installed) The central door locking switch is lo- cated on the driver's arm rest. It is operated by depressing the door lockswitch. NOTE:
o When pushing the front portion of
the driver's door lock switch, all vehicle doors will lock. If any door is open when the switch is depressed, the door will remainlocked when closed.
OMC029047R o When pushing the rear portion of
the switch, all vehicle doors will unlock.
o The central door locking is oper-
ated by turning the key in thedriver's door lock toward the front or rear of the vehicle.
o The driver's door can be opened by pulling the inside door handleeven if the lock switch is de- pressed.
o If the door is locked/unlocked mul- tiple times in rapid succession with either the vehicle key or doorlock switch, the system may stop operating temporarily in order to protect the circuit and prevent damage to system components.
LOCK
UNLOCK
When the lock mechanism is engaged, the rear door cannot be opened from inside. Its use is recommended when-ever there are small children in the rear seat. To engage the child-protector feature so the door cannot be opened from the inside, move the child-protector leverto the "
" position and close the door.
Move the lever to the "
" position
when normal door operation is desired. The outside door handle will function normally, regardless of the position of the child protector door lock.
WARNING:
Be careful not to pull the inside doorhandle while driving. If you pull theinside door handle, the door can be opened and you may be ejected from the vehicle and can be injured orkilled.

1FEATURES OF YOUR HYUNDAI
8THEFT-ALARM SYSTEM
Park the car and stop the engine. Arm the system as described in the follow- ing paragraph.
1) Remove the ignition key from theignition switch.
2) Make sure that all doors, boot lid (4 Door) / tail gate (3 Door) and engine bonnet are closed and latched.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once to indicate that the system is armed.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s) remains in the car, the alarm may beactivated when the remaining passenger(s) leave the car.
B070A01A-DAT (If Installed) This system is designed to provide protection from unauthorised entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal lights.
B070B02MC-DAT Armed StageB070B01MCRNOTE:
1) If any door, boot lid (4 Door)/ tail
gate (3 Door) or engine bonnet remains open, the system will notbe armed. If this happens, rearm the system as previously described.
2) Once the system is armed, only the boot lid (4 Door) may be un-locked using the ignition key with-out disarming the system.

1
FEATURES OF YOUR HYUNDAI
9
B070D03MC-DAT Disarmed Stage
B070C02MC-DATAlarm Stage The alarm will be activated if any of the following occurs while the car is parked and the system is armed.
1) Any door, tail gate (3 Door) included,
is opened without using the trans- mitter.
2) The boot lid (4 Door) is opened with-
out using the ignition key.
3) The engine bonnet is opened. The alarming horn will sound and the turn signal lights will blink continuouslyfor 27 seconds. To turn off the system, unlock the door with the transmitter. The system will be disarmed when the driver's or passenger's door is un- locked by depressing the button on thetransmitter after the system was armed. After completion of the step above, the turn signal lights will blink twice to indicate that the system is disarmed. If any door, boot lid(4 Door)/tail gate (3 Door) included, is not opened within 30 seconds, the system will be re-armed. NOTE: When the system is disarmed with the interior light switched to "DOOR",the interior light will illuminate for 30 seconds.
B070D02AMCCAUTION:
Only the transmitter can disarm the armed stage. If the transmitter doesnot disarm the system, it is neces- sary to take the following steps; 1. Unlock and open the door with the key, which will cause the alarm to be activated.
2. Insert the key in the ignition key cylinder and turn the ignition keyto "START" position.
After completing the steps above,the system will be disarmed.
!
CAUTION:
Do not change, alter or adjust the theft-alarm system because it couldcause the theft-alarm system to mal- function and should only be ser- viced by an authorised Hyundaidealer. Malfunctions caused by improper alterations, adjustments or modifi-cations to the theft-alarm system are not covered by your vehicle manu- facturer warranty.
!

1FEATURES OF YOUR HYUNDAI
10
B070F03A-DAT Keyless Entry System (If Installed)Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, theturn signal lights will blink once to indicate that the system is armed.
Unlocking doors 1. Push the button on the transmitter once more after all doors were locked.
2. At the same time all doors unlock,
the turn signal lights will blink twiceto indicate that the system is dis- armed.
B070E01MC-AAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR1220 Replacement instructions:
1. Remove the screw with a phillipsscrewdriver.
2. Carefully separate the case with a flat-head screwdriver. OMC025004
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition
switch.
- You exceed the operating distance
limit (10 m).
- The battery in the transmitter is weak.
- Other vehicles or objects may be blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio
transmitter such as a radio station or an airport which can interfere with normal operation of the trans-mitter.
When the transmitter does not workcorrectly, open and close the doorwith the ignition key. If you have a problem with the transmitter, con- tact an authorised Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo-sure to water or liquids, it will not be covered by your manufacturer ve- hicle warranty.

1
FEATURES OF YOUR HYUNDAI
11
!
WINDOW GLASS
B050A01MC-AAT
To lower or raise the window, turn the window regulator handle clockwise or counterclockwise. WARNING:
When opening or closing the win-dows, make sure your passenger's arms, hands and body are safely out of the way.
3. Remove the battery cover with a
coin.
4. Remove the old battery from the case and note the polarity. Makesure the polarity of the new batteryis the same (+side facing up), then insert it in the transmitter.
3FDA2015
CAUTION:
An inappropriately disposed battery can be harmful to the environmentand human health. Dispose the bat- tery according to your local law(s) or regulation.
! B060A01MC-GAT POWER WINDOWS (If Installed)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's
armrest and control the front (4/3 Door)
and rear windows (4Door) on both sides of the vehicle. The windows may be openedby depressing the appropriate window switch and closed by pulling up the switch. To open the window on the driver's side,press the switch(1) halfway down. The window moves as long as the switch is operated. To fully open the driver's win-dow automatically, press the switch fully down. In automatic operation, the window will fully open even if you let go of theswitch. To stop at the desired opening, pull up and release the switch.
3 Door
4 Door
OMC029048R

1FEATURES OF YOUR HYUNDAI
12
!WARNING:
1) Be careful that someone's head, hands and body are not trapped by a closing window.
2) Never try to operate the main
switch on the driver's door andthe individual door window switch in opposing directions at the same time. If this is done, the windowwill stop and cannot be opened or closed.
3) Do not leave children alone in the car. Always remove the ignitionkey for their safety.
OMC025015
Close
Open
In order to prevent operation of the passenger front (4/3 Door) and rear windows (4Door), a window lockswitch(2) is provided on the armrest of the driver's door. To disable the power windows, press the window lock switch.To revert to normal operation, press the window lock switch a second time. NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK"positions, or removed from the igni- tion switch. If the front doors are opened during this 30 second pe-riod, the power windows can no longer be operated without the igni- tion key turned to the "ON" position.OMC029049R
NOTE: While driving with the rear windows down or with the sunroof (if installed) in an open (or partially open) posi-
tion, your vehicle may demonstrate
a wind buffeting or pulsation
noise. This noise is a normal occur-rence and can be reduced or elimi- nated by taking the following ac-
tions. If the noise occurs with oneor both of the rear windows down,
partially lower both front windows
approximately one inch. If you ex-perience the noise with the sunroof open, slightly reduce the size of the sunroof opening.

1
FEATURES OF YOUR HYUNDAI
13
OMC029025R-1
SEATS
Driver’s seat 1. Seat forward/rearward lock releaselever
2. Seatback recliner control lever 3. Seat cushion height control lever Front passenger’s seat 4. Seat forward/rearward lock release lever
5. Seatback recliner control lever Rear seats
6. Seatback folding lever
7. Armrest
B080A01MC-DAT
4 Door
3 Door
