2011 Hyundai Accent Owner's Manual - RHD (UK. Australia)

1FEATURES OF YOUR HYUNDAI
86
B580C01JM-AAT Sun Visor Extender (If Installed) Your vehicle is equipped with sun visor extenders that may be used when the visor is in the side glass position.
B580C01MCR
B500B01B-GAT Illuminated Vanity Mirror (If Installed) Opening the lid of the vanity mirror will automatically turn on the mirror light.
OMC025100
!WARNING:
o Do not place the sun visor in such a manner that it obscures visibility of the roadway, traffic or other objects.
o Do not move the sun visor out to
cover the side window if there isan item attended to it such as a garage door remote control, pens, air fresheners or the like. Theseobjects could cause injury if the curtain airbag is deployed.

1
FEATURES OF YOUR HYUNDAI
87HORN
B610B01L-GAT
Press the pad of the steering wheel to sound the horn.
OMC025046
!
STEERING WHEEL TILT LE- VER
B600A01A-AAT
To Adjust the Steering Wheel:
1. Push the lever downward to unlock.
2. Raise or lower the steering wheel to the desired position.
3. After adjustment, securely tighten the lever by pulling it upward.
WARNING:
Do not attempt to adjust the steeringwheel while driving as this may re-sult in loss of control of the vehicle which may cause serious injury or death.
OMC025045R
AUDIO REMOTE CONTROL SWITCH
B610A02MC-GAT (If Installed) The steering wheel audio remote con- trol switch is installed to promote safe driving. NOTE: Do not operate audio remote control switches simultaneously. MODE Switch Each press of the switch changes the display as follows: * : if installed OMC029110

RADIO (FM1
FM2 AM) TAPE* CD* CDC*
AUX*

1FEATURES OF YOUR HYUNDAI
88
3. CD (Compact Disc)/CDC(Compact Disc Changer)/ AUX mode
o Press the upper portion SEEK once to skip forward to the beginning of the next track.
o Press the lower portion SEEK once to skip back to the beginning of thetrack.
VOL Switch
o Press the upper portion VOL switch to increase volume.
o Press the lower portion VOL switch
to decease volume.
NOTE: o If there is no TAPE, CD or the
auxiliary device is not connected, the mode cannot be converted tothe TAPE, CD, CDC or AUX mode.
o The TAPE, CD, CDC or AUX mode
is not available for some audiomodels.
SEEK Switch Press the SEEK switch 1 sec. or more.
1. RADIO mode When the upper portion SEEK is pressed, the unit will automatically tuneto the next higher frequency and when the lower portion SEEK is pressed, it will automatically tune to the next lowerfrequency.
2. TAPE mode
o Pressing the upper portion SEEK will play the beginning of the next music segment.
o Pressing the lower portion SEEK will start replay at the beginning ofthe music just listened to.

1
FEATURES OF YOUR HYUNDAI
89HEATING AND COOLING CONTROL
B710A01TB-DAT (If Installed)
1. Side Demister Nozzle
2. Side Ventilator
3. Windshield Demister Ventilator
4. Centre Ventilator
B710A01MCR B710B01MC-DAT Centre Ventilator/Side Ventilator The centre ventilators are located in the middle of the dashboard. The side ven-tilators are located on each side of dashboard. To change the direction of the air flow, move the knob in the centreof the vent up-and-down and side-to- side. The vents are opened when the vent knob is moved to "
" position.
The vents are closed when the vent knob is moved to "
". Keep these
vents clear of any obstructions.

1FEATURES OF YOUR HYUNDAI
90HEATING AND VENTILA- TION
B670B01A-AAT Fan Speed Control (Blower Control) This is used to turn the blower fan on or off and to select the fan speed. This blower fan speed, and therefore the volume of air delivered from thesystem, may be controlled manually by setting the blower control between the "1" and "4" positions.
B670A02A-DAT
(If Installed)
1. Temperature control
2. Air conditioning switch
3. Air intake control switch
4. Air flow control
5. Fan speed control
B670A01MC-D
OMC025083
B670C03A-AAT Air Intake Control Switch
This is used to select fresh outside air or recirculating inside air.
Fresh

Recirculation
With the "
" mode selected, air en-
ters the vehicle from outside and is heated or cooled according to the otherfunctions selected. With the "
" mode selected, air from
within the passenger compartment is drawn through the heating system and heated or cooled according to the other functions selected.
B670C02MC

1
FEATURES OF YOUR HYUNDAI
91
B670D02MCR
NOTE: It should be noted that prolonged operation of the heating system in "
" mode will give rise to misting
of the windshield and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the "
" mode selected
may result in the air within the pas- senger compartment becoming ex- cessively dry.
Face-Level
Selecting the "Face" mode will causeair to be discharged through the face level vents.
B670D02MC-DAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, instrument panel outlets, or windshield. Five sym-bols are used to represent Face, Bi- Level, Floor, Floor-Demist and Demist air position.
B670D01MC-D

1FEATURES OF YOUR HYUNDAI
92
Bi-Level
Air is discharged through the face vents and the floor vents. Floor-Level
Air is discharged through the floor vents,windshield demister nozzle, side demister nozzle and side ventilator. Floor-Demist Level
Air is discharged through the wind-shield demister nozzle, the floor vents, side demister nozzle and side ventila-tor.
B670D03MCRB670D04MCRB670D05MCR

1
FEATURES OF YOUR HYUNDAI
93HEATING CONTROLS
For normal heating operation, set the air intake control to the fresh air (
)
position and the air flow control to the floor (
) position.
For faster heating, the air intake control should be set in the recirculate (
)
position. If the windows fog up, set the air flow control to the demist (
) position.
(Push the A/C button to turn the air conditioning system on and set the air intake control to the fresh air (
)
position.) For maximum heat, move the tempera- ture control to "Warm". B690A01MC-DAT
B670E02A-AAT Temperature Control This control is used to adjust the degree of heating or cooling desired.
Demist-Level
Air is discharged through the wind- shield demister nozzle, side demister nozzle and side ventilator.
B670D06MCR
B670E01MC
B690A01MC-D
COOL WARM
