2011 Hyundai Accent Owner's Manual - RHD (UK. Australia)

F9
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel pad surface. If there is any leakage from the air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it may damage these parts. If the liquid from air freshener does leak onto these areas, wash them withwater immediately.
!
1. Bonnet Release Lever .........................................
1-79
2. Front/Rear Fog Light Switch (If Installed) ............ 1-67
3. Instrument Panel Light Control (Rheostat) ........... 1-66
4. Instrument Cluster.............................................. 1-46
5. Multi-Function Light Switch................................. 1-61
6. Audio Remote Control Switch (If Installed) .......... 1-87
7. Horn and Driver's Front Airbag (If Installed) .................................................................. 1-87, 1-38
8. Windshield W iper/Washer Switch ........................1-63
9. Hazard Warning Light Switch.............................. 1-66
10. Digital Clock ........................................................ 1-68
11. Rear Window Demist er Switch ............................ 1-66
12. Audio System (If Installed) ................................ 1-104
13. Passenger's Front Airbag (If Installed) ................1-3814. Glove Box ...........................................................
1-75
15. Heating/Air Conditioning Control Panel (If Installed) ......................................................... 1-90
16. Multi Box ............................................................ 1-75
17. Cigarette Lighter .................................................. 1-68
18. Electronic Stability Program (ESP) Switch
(If Installed) ......................................................... 2-12
19. Power Outlet ....................................................... 1-69
20. Ashtray ............................................................... 1-69
21. Shift Lever ........................................................... 2-8
22. Hand Brake Lever ............................................... 1-78
23. Front Drink Holder ............................................... 1-70
24. Boot Lid Release Lever (If Installed) ................... 1-83
25. Fuel Filler Lid Release Lever ...............................1-80

YOUR VEHICLE AT A GLANCE
F10B255A03MC-DAT INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER * More detailed explanations of these items will be found begining on page 1-50.
Turn Signal Indicator Lights
SRS (Airbag) Service Reminder Indicator O/D OFF Indicator Light (Automatic transaxle only) High Beam Indicator Light
Low Oil Pressure Warning Light
ABS Service Reminder Indicator (If Installed)
Door Ajar Warning Light
Hand Brake/Low Brake Fluid Level Warning Light Charging System Warning Light Low Fuel Level Warning Light Malfunction Indicator Light
Immobiliser Warning Light
Boot Lid/Tail Gate Open Warning Light
Engine Coolant Temperature Warning Light Seat Belt Warning Light
Electronic Stability Program Indicator Lights (If Installed)
Automatic Transaxle Position Indicator Light (If Installed)

F11
AUSTRALIAN DESIGN RULES
The compliance plate located on the left wheel housing of the luggage compartment shows that your vehicle has been tested and found to comply with all relevant Australian Design Rules (ADR's) applicable at its date of manufacture.Any part, that is subject to these ADR's, must not be removed or altered and is to be maintained in good order at all times for the vehicle to be roadworthy and re- registerable by all registerable authorities. Consult an Authorised Hyundai Motor Dealer before conducting any repairs that may affect these areas or if requiring further classification on design rules or safetyfeatures. Failure to observe the above warning may render the vehicle compliance invalid and result in personal injury which may have otherwise been avoided.
A100A01MC-DAT

FEATURES OF YOUR HYUNDAI
1
1
Fuel Recommendations ................................................ 1-2
Running in Your New Hyundai ..................................... 1-3
Immobiliser System ...................................................... 1-3
Door Locks ................................................................... 1-5
Theft-Alarm System ...................................................... 1-8Window Glass............................................................. 1-11
Seats ........................................................................... 1-13
Seat Belts .................................................................... 1-22
Child Restraint System ................................................ 1-28
Supplemental Restraint (AIRBAG) System .................1-37
Instrument Cluster and Indicator Lights .......................1-46
Warning and Indicator Lights....................................... 1-50
Trip Computer .............................................................. 1-58
Multi-Function Light Sw itch .......................................... 1-61
Windshield Wiper/Washer Switch ................................1-63
Sunroof ........................................................................ 1-70
Mirror ........................................................................... 1-75
Bonnet Release ........................................................... 1-79
Heating and Cooling Control .......... ..............................1-89
Stereo Sound System ................................................. 1-99
Antenna ..................................................................... 1-103
Audio System ............................................................ 1-104

1FEATURES OF YOUR HYUNDAI
2FUEL RECOMMENDATIONS
B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to:
o Observe all regulations regardingregistration and insurance.
o Determine that acceptable fuel is available.
Unleaded petrol with a Pump Octane Rating of 87 (Research Octane Num- ber 91) or higher must be used inyour Hyundai. If leaded petrol is used, it will cause the catalytic converter to become ineffec- tive and the emission control system to malfunction. This can also result inincreased maintenance expense. To avoid accidental use of leaded fuel, the larger nozzle used with leaded petrolat service stations cannot be inserted into the fuel tank opening of your Hyundai.
B010A01A-DAT Use Unleaded Petrol
B010E01A-DATPetrol for Cleaner Air To help contribute to cleaner air, Hyundai recommends that you usepetrol treated with detergent additives, which help prevent deposit formation in the engine. This petrol will help theengine run cleaner and enhance per- formance of the Emission Control Sys- tem.
B010D01A-DAT Do not Use Methanol Fuels containing methanol (wood al- cohol) should not be used in your Hyundai. This type of fuel can reducevehicle performance and damage com- ponents of the fuel system.
! CAUTION:
Hyundai Warranty Policy will not cover the damage of the fuel sys- tem and performance problems that are caused by the use of methanolor fuels containing methanol.
B010B01A-AAT What About Gasohol [E-10]? Gasohol (a mixture of 90% unleaded gasoline and 10% ethanol or grainalcohol) may be used in your Hyundai. However, if your engine develops drive ability problems, the use of 100% un-leaded gasoline is recommended. Fu- els with unspecified quantities of alco- hol, or alcohols other than ethanol,should not be used.
B010A01MC-A
UNLEADED
FUEL ONLY

1
FEATURES OF YOUR HYUNDAI
3IMMOBILISER SYSTEMRUNNING IN YOUR NEW HYUNDAI
B020A01S-DAT During the First 2,000 km No formal running in period is required with your new Hyundai. However, youcan contribute to the economical op- eration and durability of your Hyundai by observing the following recommen-dations during the first 2,000 km.
o Don't drive faster than 88 km/h.
o While driving, keep your engine
speed or revolutions per minutebetween 2,000 and 4,000 rpm.
o Use moderate acceleration. Don't use full-throttle starts.
o For the first 300 km, try to avoid hard stops.
o Don't labour the engine (in other
words, don't drive so slowly in toohigh a gear that the engine hesi- tates : shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than
3 minutes.
o Do not tow a trailer during the first 2,000 km of operation.
!
B880A01A-DAT The immobiliser system is an anti-theft device, designed to deter automobile theft. B880B03MC-DAT Keys All of the locks fitted to the vehicle are operated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake. NOTE: If you make your own duplicate key, you will not be able to cancel the immobiliser system or start the en-gine. CAUTION:
o When starting the engine, do not use the key with other immobiliser keys around. Otherwise the en- gine may not start or may stopsoon after it starts. Keep each keys separately not to have any malfunction after youreceive your new vehicle.
o Do not install the metal accesso-
ries near the key or ignition switch.The engine may not start for the metal accessories may interrupt the transponder signal from nor-mally transmitting.
!WARNING:
In order to prevent theft of your ve- hicle, do not leave spare keys any-where in your vehicle.

1FEATURES OF YOUR HYUNDAI
4
B880D01CM-DAT Limp Home Procedures
In case the immobiliser warning indica- tor blinks for five seconds when the ignition key is turned to "ON" position,this indicates that the immobiliser sys- tem is out of order. Should the immobiliser system be out of order,your vehicle will need to be towed to a Hyundai dealer for rectification.
In the interest of security, the metal tag attached to the keys which bears thekey number should be removed from the key ring after you receive your new vehicle. In addition, key numbers can-not be provided by Hyundai for security reasons. If you need additional keys or if youshould lose your keys, your authorised Hyundai dealer can make new keys if you can supply the key number.
B880C01MC-DAT Key Numbers
The vehicle key number is recorded upon a metal tag attached to the keys when the vehicle is first delivered toyou. The key number should be recorded and kept in a safe place in case theneed to order further keys arises. New keys are available from any Hyundai dealer by quoting the relevant keynumber.
OMC027002HNF2011

1
FEATURES OF YOUR HYUNDAI
5
!
DOOR LOCKS
B040A02Y-DAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (espe- cially if there are children in the car), be sure that all the doors are securely closed and locked so that the doors cannot be inadvert- ently opened from the inside. This helps ensure that the doors will not be opened accidentally. Also, when combined with the proper use of seat belts, locking the doors helps keep occupants from being ejected from the car in case of an accident.
o Before opening the door, always
look for and avoid oncoming traffic.
o In case of an accident, all doors
will unlock automatically (If In- stalled).
OMC025005R B040C01MC-GAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door.
B040B01A-AAT Locking and Unlocking Front Doors with a Key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key toward the rear.
UNLOCKLOCK
B040C04MCR
