2011 Hyundai Accent Owner's Manual - RHD (UK. Australia)

1FEATURES OF YOUR HYUNDAI
14
!
!
To recline the seatback, lean forward to take your weight off it, then pull up onthe recliner control lever at the outside edge of the seat. Now lean back until the desired seatback angle is achieved.To lock the seatback into position, release the recliner control lever.
B080C01A-DAT Adjusting Seatback Angle
WARNING:
To ensure the seat is locked se- curely, attempt to move the seatforward or rearward without using the lock release lever.
To move the seat toward the front or rear, pull the lock release lever up-ward. This will release the seat on its track so you can move it forward or rearward to the desired position. Whenyou find the position you want, release the lever and slide the seat forward or rearward on its track until it locks intothe desired position and cannot be moved further.
B080A01FC-DAT ADJUSTABLE SEATS
B080B02FC-GATFRONT SEATS Adjusting Seat Forward andRearward
WARNING:
Never attempt to adjust the seat while the vehicle is in motion. This could result in loss of control or an accident which may cause death,serious injury, or property damage.
OMC029026/H
OMC029027/H

1
FEATURES OF YOUR HYUNDAI
15
!WARNING:
To minimise risk of severe injury in the event of a collision or a sudden stop, both the driver and passenger seatbacks should always be in anupright position while the vehicle is in motion. The protection provided by the seat belts and airbags in afrontal collision may be reduced sig- nificantly when the seatbacks are reclined. There is greater risk thatthe driver and passenger will slide under the seat belt which may result in serious injury if a crash occurswhen the seatbacks are reclined. The seat belt cannot provide full protec- tion to an occupant if the seatback isreclined.!WARNING:
o For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of theheadrest is at the same height of the centre of gravity of an occupant's head. Generally, thecentre of gravity of most people's head is similar with the height of the top of their eyes. Also, adjustthe headrest as close to your head as possible. For this reason, the use of a cushion that holds thebody away from the seatback is not recommended.
o Do not operate the vehicle with the
headrests removed as severe in-jury to the occupants may occur in the event of an accident. Head-rests may provide protection against neck injuries when prop- erly adjusted.
o Do not adjust the headrest posi- tion of the driver's seat while thevehicle is in motion.
C010104AMC Headrest
The driver's and front passenger's seats are equipped with a headrest for the occupant's safety and comfort.The headrest not only provides comfort for the driver and front passenger, but also helps to protect the head and neckin the event of a collision. OBH038075L

1FEATURES OF YOUR HYUNDAI
16
B080F01MC-AAT Seat Cushion Height Adjustment (Driver's Seat Only) To raise or lower the front part of the seat cushion, turn the knob forward or rearward.
OMC029028/H
Adjusting the height up and down To raise the headrest, pull it up to the desired position (1). To lower the head- rest, push and hold the release button (2) on the headrest support and lowerthe headrest to the desired position (3). Removal To remove the headrest, raise it as far as it can go then press the release button (1) while pulling upward (2). To reinstall the headrest, put the head-rest poles (3) into the holes while press- ing the release button (1). Then adjust it to the appropriate height.OMC029029
OMC029030
!WARNING:
Make sure the headrest locks in po- sition after adjusting it to properly protects the occupants.

1
FEATURES OF YOUR HYUNDAI
17
B130A01A-AAT REAR SEAT ENTRY (3 Door)
The front passenger's seatback should be tilted to enter the rear seat. By pulling up on the recliner control lever (1) at the outside of the frontpassenger's seat, the seatback will tilt forward and the seat will automatically slide forward.Rear seat occupants can tilt the front passenger's seatback by depressing the foot lever (2) as shown in the illus-tration. HTB258-D
(1)
(2)
!WARNING:
Passengers sitting in the rear seat should be careful not to accidentallypress the foot lever (2) while the vehicle is moving, as this may cause the seatback to move forward andinjure a front seat occupant.
B085A01MC-GAT REAR SEAT Adjusting seatback angle (3 Door)
To recline the seatback, pull up the seatback folding lever (1) and push the seatback rearward. To return the seatback to an upright position, pull upthe seatback folding lever (1) and pull the seatback forward until the seatback locks into upright position.After adjusting the seatback angle, al- ways check that it is securely locked into place. B085A01MC
(1)
!WARNING:
Do not adjust the seatback angle while the vehicle is in motion.

1FEATURES OF YOUR HYUNDAI
18
!WARNING:
o For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height ofthe centre of gravity of an occupant's head. Generally, the centre of gravity of most people'shead is similar with the height of the top of their eyes. Also, adjust the headrest as close to your headas possible. The use of a cushion that holds the body away from the seatback is not recommended.
o Do not operate the vehicle with the headrests removed as severe in-jury to an occupant may occur inthe event of an accident. Head- rests may provide protection against severe neck injuries whenproperly adjusted. Adjusting the height up and down (If Installed) To raise the headrest, pull it up to the desired position (1). To lower the head-rest, push and hold the release button (2) on the headrest support and lower the headrest to the desired position (3).
OMC029045
C010303BUN Headrest
OBH038076L
The rear seat(s) is equipped with head- rests in all the seating positions for the occupant's safety and comfort.The headrest not only provides comfort for passengers, but also helps to pro- tect the head and neck in the event ofa collision.

1
FEATURES OF YOUR HYUNDAI
19
!
B110A02MC-DAT Folding Rear Seatbacks (If Installed) The rear seatbacks may be folded to facilitate carrying long items or to in-crease the luggage capacity of the vehicle.
WARNING:
The purpose of the fold-down rearseatbacks is to allow you to carry longer objects than could otherwisebe accommodated. Never allow passengers to sit on top of the folded down seatback or cargoarea while the car is moving as this is not a proper seating position and no seat belts are available for use.This could result in serious injury or death in case of an accident or sud- den stop. Objects carried on thefolded down seatback should not extend higher than the top of the front seats. This could allow cargo toslide forward and cause injury or damage during sudden stops.
Removal (If Installed) To remove the headrest, raise it as far as it can go then press the release button (1) while pulling upward (2). To reinstall the headrest, put the head-rest poles (3) into the holes while press- ing the release button (1). Then adjust it to the appropriate height.
OMC029046
!WARNING:
Make sure the headrest locks in po- sition after adjusting it to properly protect the occupants.
To fold down the seatback :
1. Slide the front seats forward and adjust the front seatbacks to be up- right before folding the rear seatbacks down.
2. Lower the rear seat headrests to the lowest position.
CAUTION:
!
B220D05MC
o In order to prevent the centre shoulder belt from being dam- aged while folding the rear seat,disconnect the metal tab (A) from the buckle (B).

1FEATURES OF YOUR HYUNDAI
20
CAUTION:
!
o Move the rear lap/shoulder belt to the outside so that they don't inter- fere with the seatback when fold- ing.To disconnect the metal tab (A) from the buckle (B) , insert a narrow-ended tool into the groove located on the buckle (B).
3. Pull up the seatback folding lever torelease the seatback.
B110A01MC
B090A02MC
OMC029041
4 Door
3 Door
OMC025039
OMC029039
4 Door
3 Door
o Before folding the seatback, insert the buckle in the pocket. This can prevent the buckle from being dam-aged by the seatback.

1
FEATURES OF YOUR HYUNDAI
21
o Move the rear lap/shoulder belt to
the side so that it is clear of the seatback when returning to its up- right position.
o Place the rear seat belt to the proper position. 4. Fold down the seatback forward. When you return the seatback to its upright position, always be sure it has locked into position by pushing on thetop of the seatback.
OMC025040
OMC029040
4 Door
3 Door
OMC039100
!WARNING:
When you return the rear seatback to its upright position after being foldeddown: Be careful not to damage the seat belt webbing or buckle. Do not allowthe seat belt webbing or buckle to get caught or pinched in the rear seat. Ensure that the seatback is com-pletely locked into its upright posi- tion by pushing on the top of the seatback. Otherwise, in an accidentor sudden stop, the seat could fold down and allow cargo to enter the passenger compartment, whichcould result in serious injury or death.
