2011 HONDA ODYSSEY Owners Manual

Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.
Remove the bulb by turning it
approximately one-quarter turn
counterclockwise.Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Reinstall the inner f ender. Make
sure it is installed under the edge
of the f ront bumper.
Reinstall the screws and mounting
bolt on the inner f ender cover, and
tighten them securely. Turn on the f og lights to test the
new bulb.
Open the tailgate.
Use a Phillips-head screwdriver to
remove the two mounting bolts.
3.
4. 5.
7. 6.
8.
9.
1.
Lights
Replacing Rear Bulbs
(in Rear Pillar)
630
BULB
TAB CONNECTOR Pull up
Slide
MOUNTING BOLTS
10/07/17 10:58:35 31TK8600_635
2011 Odyssey

CONT INUED
Remove the socket f or that bulb
by turning it one-quarter turn
counterclockwise. Determine which of the two bulbs
is burned out: stop/taillight or turn
signal light.
Rotate the assembly toward the
side panel until it slightly overlaps
the bumper and the bottom of the
taillight housing is exposed.
With the hand closest to the cargo
area, use your f ingers to grip the
bottom edge of the assembly.
Apply a rearward and upward
pulling motion to release the lower
f astener f rom the grommet.
Continue to support the assembly
while placing the f ingers of the
outer hand on the top of the outer
corner of the assembly.
Pull with the upper f inger and
hand to release the upper f astener
f rom the top grommet.
2.
3.
4.
5.
6.7.
8.
Lights
Maint enance
631
BULB
SNAP FASTENERS
SOCKET
10/07/17 10:58:44 31TK8600_636
2011 Odyssey

Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Reinstall the socket into the light
assembly by turning it one-quarter
clockwise until it locks.
Turn on the lights to make sure
the new bulb is working.
Ensure that the grommets are still
in place on the body panel.Open the tailgate. Place a cloth on
the edge of the cover to prevent
scratches. Remove it by caref ully
prying in the notch on its edge
with a small f lat-tip screwdriver.
Determine which of the two bulbs
is burned out: taillight or back-up
light.
Insert the fasteners into the
grommets and push the assembly
back into place. You will hear the
f asteners engage.
Install the mounting bolts and
tighten securely.
1.
2.
9.
11. 10.
12. 14. 13.
Lights
Replacing Rear Bulbs
(in Tailgate)
632
COVER
GROMMET
FASTENER
If the grommets are loose or completely
out of the holes af ter the taillight
assembly is removed, they must be
replaced. Ask your dealer f or more
inf ormation.
10/07/17 10:58:53 31TK8600_637
2011 Odyssey

Remove the socket by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Insert the socket back into the
light assembly. Turn it clockwise
to lock it in place.
Reinstall the base gasket.
Push the electrical connector back
onto the socket. Make sure it is on
all the way.
Turn on the lights to make sure
the new bulb is working.
Reinstall the cover.
Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.
Remove the base gasket as shown,
then remove the socket by turning
it one-quarter turn
counterclockwise. 4.
5.
6.
9.
3.
8. 7. (Taillight)
10.
(Back-up light)
3.
4.
Lights
Maint enance
633
BULB
SOCKET
CONNECTOR
BULB TAB
SOCKET
BASE GASKET
10/07/17 10:59:04 31TK8600_638
2011 Odyssey

Remove the socket f rom the light
assembly by turning it one-quarter
turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Place a cloth on the edge of the
lens segment to prevent scratches.
Remove each lens segment by
caref ully prying on its edge with a
small f lat-tip screwdriver.
Remove the screws with a Phillips-
head screwdriver, then remove
the light assembly f rom the
tailgate.
Insert the socket back into the
light assembly. Turn it clockwise
to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Reinstall the cover.
1.
2. 3.
4.
5.
6.
7.
Lights
Replacing a High-mount Brake
Light Bulb
634
SCREWS
LENS SEGMENTS
SOCKETBULB
10/07/17 10:59:13 31TK8600_639
2011 Odyssey

Turn on the parking lights and
check that the new bulb is
working.
Reinstall the socket. Snap the
cover back in place. Pull the bulb straight out of its
socket. Push the new bulb in until
it bottoms in the socket.
Open the tailgate. Place a cloth on
the edge of the cover to prevent
scratches. Remove it by caref ully
prying in the notch on its edge
with a small f lat-tip screwdriver.
Remove the license light assembly
by squeezing the tabs on both
sides of the socket.
Press the brake pedal to make
sure the new bulb is working.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Reinstall the high-mount brake
light assembly into the tailgate.
Tighten the two screws and
reinstall the covers.
1.
2. 3.
4.
5.
5.
7. 6.
Lights
Replacing a Rear License Plate
Light Bulb
Maint enance
635
BULB
COVER
TABS
10/07/17 10:59:22 31TK8600_640
2011 Odyssey

If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air dry bef ore
you use the vehicle.
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the climate control
system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the
odometer/trip meter display or on
the multi-information display. It
should be replaced every 15,000
miles (24,000 km) if you drive
primarily in urban areas that have
high concentrations of soot in the air,
or if the f low f rom the climate
control system becomes less than
usual.
Cleaning the Seat Belts
Dust and Pollen FilterCleaning the Seat Belts, Dust and Pollen Filter636
LOOP
10/07/17 10:59:28 31TK8600_641
2011 Odyssey

The floor mats that came with your
vehicle hook over the f loor mat
anchors. This keeps the f loor mats
f rom sliding f orward (possibly
interf ering with the pedals), or
backwards (making the f ront
passenger’s weight sensors
inef f ective).
To lock or unlock each anchor, turn
the knob.If you remove a f loor mat, make sure
tore-anchoritwhenyouputitback
in your vehicle.
If you use non-Honda f loor mats,
make sure they f it properly and that
theycanbeusedwiththefloormat
anchors. Do not put additional f loor
mats on top of the anchored mats.
Make sure the rear f loor mats are
also properly hooked. If not, the f loor
mat will interf ere with the seat
operation and make the f ront
passenger’s weight sensors
inef f ective.
Floor Mat s
Maint enance
637
Front
Rear
Passenger’s side
Driver’s side KNOB To Unlock
To Unlock
KNOB To Unlock
KNOB
